NISSAN NOTE 2016 Service Repair Manual MWI
SYSTEMMWI-67
< SYSTEM DESCRIPTION > [TYPE B]
C
D
E
F
G H
I
J
K L
M B A
O P
- Loose fuel cap warning
ODO/TRIP METER
The combination meter calculates mileage using the vehicle speed signal from the

Page 2426 of 3641

NISSAN NOTE 2016 Service Repair Manual MWI-68
< SYSTEM DESCRIPTION >[TYPE B]
OPERATION
OPERATION
Switch Name and FunctionINFOID:0000000012432610
ILLUMINATION CONTROL SWITCH/
TRIP ODOMETER RESET SWITCH
STEERING WHEEL AUDIO CONTROL SWITCH (M

Page 2427 of 3641

NISSAN NOTE 2016 Service Repair Manual MWI
DIAGNOSIS SYSTEM (COMBINATION METER)MWI-69
< SYSTEM DESCRIPTION > [TYPE B]
C
D
E
F
G H
I
J
K L
M B A
O P
DIAGNOSIS SYSTEM (C OMBINATION METER)
On Board Diagnosis FunctionINFOID:0000000012432611
ON

Page 2428 of 3641

NISSAN NOTE 2016 Service Repair Manual MWI-70
< SYSTEM DESCRIPTION >[TYPE B]
DIAGNOSIS SYSTEM (COMBINATION METER)
*1: Error code A-D
*2: Error code E-H
Test order
Test item Description
1 Work instruction code
This item is displayed, but no

Page 2429 of 3641

NISSAN NOTE 2016 Service Repair Manual MWI
DIAGNOSIS SYSTEM (COMBINATION METER)MWI-71
< SYSTEM DESCRIPTION > [TYPE B]
C
D
E
F
G H
I
J
K L
M B A
O P
CONSULT Function (METER/M&A)INFOID:0000000012432612
APPLICATION ITEMS
CONSULT can display e

MWI
DIAGNOSIS SYSTEM (COMBINATION METER)MWI-71
< SYSTEM DESCRIPTION > [TYPE B]
C
D
E
F
G H
I
J
K L
M B A
O P
CONSULT Function (METER/M&A)INFOID:0000000012432612
APPLICATION ITEMS
CONSULT can display each diagnostic item using the diagnostic test modes shown.
SELF DIAG RESULT
Refer to MWI-77, "DTC Index".
DATA MONITOR
Display Item List
X: Applicable
Tachometer 0Normal
—
1 An engine speed signal cannot be received from
ECM. Perform “Self Diagnostic Result” of “ECM.”
Refer to EC-87, "
DTCIndex".
Speedometer 0Normal
—
1 A vehicle speed signal cannot be received from
ABS actuator and electric
unit (control unit).
Perform “Self Diagnostic Result” of “ABS.”
Refer to BRC-43, "
DTC Index".
2 A vehicle speed si
gnal received from the ABS ac-
tuator and electric unit (control unit) is abnormal.
— 0 Displays “0” constantly. —
— 0 Displays “0” constantly. —
— 0 Displays “0” constantly. —
Trip odometer reset
switch 0Normal
—
2 When judging that the trip odometer reset switch
signal circuit is short-circuited for 5 minutes or
more. Replace combination meter.
Refer to MWI-115, "
Removal and Installa-
tion".
Item Code Description Action to take/Reference
METER/M&A Diagnosis mode
Description
Self Diagnostic Result The combination meter self-diagnosis results.
Data Monitor Displays combination meter input/output data in real time.
Work support Supports combination meter diagnosis.
ECU Identification The combination meter part number is displayed.
Warning History Lighting history of the warning lamp and indicator lamp can be checked.
Display item [Unit]MAIN
SIGNALS Description
SPEED METER
[mph] or [km/h] X Displays the value of vehicle speed signal.
SPEED OUTPUT
[mph] or [km/h] XDisplays the value of vehicle speed signal, which is transmitted to each unit with
CAN communication.
ODO OUTPUT
[mph] or [km/h] Displays odometer signal value transmitted to other units via CAN communica-
tion.
TACHO METER
[rpm] X Displays the value of engine speed signal, which is input from ECM.
FUEL METER
[L] X Displays the fuel level.
W TEMP METER
[ ° C] or [ °F] X Displays the value of engine coolant temperature signal, which is input from ECM.
ABS W/L
[On/Off] Displays [ON/OFF] condition of ABS warning indicator
Revision: August 2015
2016 Versa Note

cardiagn.com

Page 2430 of 3641

NISSAN NOTE 2016 Service Repair Manual MWI-72
< SYSTEM DESCRIPTION >[TYPE B]
DIAGNOSIS SYSTEM (COMBINATION METER)
VDC/TCS IND
[ON/OFF]Displays [ON/OFF] condition of VDC OFF indicator lamp.
SLIP IND
[ON/OFF] Displays [ON/OFF] condition of

Page 2431 of 3641

NISSAN NOTE 2016 Service Repair Manual MWI
DIAGNOSIS SYSTEM (COMBINATION METER)MWI-73
< SYSTEM DESCRIPTION > [TYPE B]
C
D
E
F
G H
I
J
K L
M B A
O P
NOTE:
Some items are not available according to vehicle specification.
WORK SUPPORT
WARNING

Page 2432 of 3641

NISSAN NOTE 2016 Service Repair Manual MWI-74
< ECU DIAGNOSIS INFORMATION >[TYPE B]
COMBINATION METER
ECU DIAGNOSIS INFORMATION
COMBINATION METER
Reference ValueINFOID:0000000012432613
VALUES ON THE DIAGNOSIS TOOL
Monitor Item Display cont

MWI-74
< ECU DIAGNOSIS INFORMATION >[TYPE B]
COMBINATION METER
ECU DIAGNOSIS INFORMATION
COMBINATION METER
Reference ValueINFOID:0000000012432613
VALUES ON THE DIAGNOSIS TOOL
Monitor Item Display contentData monitor
Condition Reference value in normal operation
SPEED METER
[mph or km/h] Speed meter
operation
While driving
Vehicle speed matches speed meter
SPEED OUTPUT
[mph or km/h] Vehicle speed While driving The speed output signal value via CAN
communication is approx. value of ve-
hicle speed.
ODO OUTPUT
[mph or km/h] ODO meter op-
eration
Driving
Distance driven
TACHO METER
[rpm] Ta c h o m e t e r
operation
Engine running The tacho meter is approx. value of en-
gine speed via CAN communication.
FUEL METER
[L] Fuel level Ignition ON Fuel level is approx. value of fuel
gauge.
W TEMP METER
[ ° F] or [ °C] Engine coolant
temperature
Engine running Input value of engine coolant tempera-
ture signal via CAN communication.
ABS W/L ABS warning
lampWhen ABS warning lamp is ON
On
When ABS warning lamp is OFF Off
VDC/TCS IND VDC indicator
lampWhen VDC indicator lamp is ON
On
When VDC indicator lamp is OFF OFF
SLIP IND Slip indicator
lampWhen SLIP indicator lamp is ON
On
When SLIP indicator lamp is OFF Off
BRAKE W/L Brake warning
lamp When Brake warning lamp is ON
On
*
When Brake warning lamp is OFF Off
DOOR W/L Door open
warning lampWhen Door warning lamp is ON
On
When Door warning lamp is OFF Off
HI-BEAM IND HI-Beam indi-
cator lampWhen High-beam indicator lamp is ON
On
When High-beam indicator lamp is OFF Off
TURN IND Turn signal in-
dicatorWhen Turn signal indicator lamp is ON
On
When Turn signal indicator lamp is OFF Off
LIGHT IND Light indicatorWhen Tail lamp indicator lamp is ON
On
When Tail lamp indicator lamp is OFF Off
FR FOG IND Front fog lamp
indicatorFront fog lamp indicator lamp ON
On
Front fog lamp indicator lamp OFF Off
OIL W/L Engine oil pres-
sure warning
light When engine oil pressure warning lamp is
ON
On
When engine oil pressure warning lamp is
OFF Off
MIL MIL warning
lampWhen Malfunction indi
cator lamp (MIL) is
ON On
When Malfunction indi cator lamp (MIL) is
OFF Off
