Page 2705 of 3641

NISSAN NOTE 2016 Service Repair Manual PWC-44
< SYMPTOM DIAGNOSIS >
NONE OF THE POWER WINDOWS CAN BE OPERATED USING ANY SWITCH
NONE OF THE POWER WINDOWS CAN BE OPERATED USING ANY
SWITCH
Diagnosis ProcedureINFOID:0000000012431835
1.CHECK BC

Page 2706 of 3641

NISSAN NOTE 2016 Service Repair Manual DRIVER SIDE POWER WINDOW DOES NOT OPERATE
PWC-45
< SYMPTOM DIAGNOSIS >
C
D E
F
G H
I
J
L
M A
B
PWC
N
O P
DRIVER SIDE POWER WI NDOW DOES NOT OPERATE
Diagnosis ProcedureINFOID:0000000012431836
1.CHECK F

Page 2707 of 3641

NISSAN NOTE 2016 Service Repair Manual PWC-46
< SYMPTOM DIAGNOSIS >
FRONT PASSENGER SIDE POWER WINDOW DOES NOT OPERATE
FRONT PASSENGER SIDE POWER WINDOW DOES NOT OPERATE
WHEN BOTH POWER WINDOW MAIN SWITCH AND FRONT POWER WINDOW
SWITCH ARE

PWC-46
< SYMPTOM DIAGNOSIS >
FRONT PASSENGER SIDE POWER WINDOW DOES NOT OPERATE
FRONT PASSENGER SIDE POWER WINDOW DOES NOT OPERATE
WHEN BOTH POWER WINDOW MAIN SWITCH AND FRONT POWER WINDOW
SWITCH ARE OPERATED
WHEN BOTH POWER WINDOW MAIN SWITCH AND FRONT POWER WINDOW
SWITCH ARE OPERATED : Diagnosis Procedure
INFOID:0000000012431837
1.CHECK POWER WINDOW AND DO OR LOCK/UNLOCK SWITCH RH
Check power window and door lock/unlock switch RH.
Refer to PWC-30, "
Component Function Check".
Is the inspection result normal?
YES >> GO TO 2.
NO >> Repair or replace the malfunctioning parts.
2.CHECK FRONT POWER WINDOW MOTOR RH
Check front power window motor RH.
Refer to PWC-35, "
PASSENGER SIDE : Component Function Check".
Is the inspection result normal?
YES >> GO TO 3.
NO >> Repair or replace the malfunctioning parts.
3.CONFIRM THE OPERATION
Confirm the operation again.
Is the result normal?
YES >> Check intermittent incident. Refer to GI-42, "Intermittent Incident".
NO >> GO TO 1.
WHEN FRONT POWER WINDOW SWITCH (PASSENGER SIDE) IS OPERATED
WHEN FRONT POWER WINDOW SWITCH (P ASSENGER SIDE) IS OPERATED :
Diagnosis Procedure
INFOID:0000000012431838
1.CHECK POWER WINDOW AND DOOR LOCK/UNLOCK SWITCH RH POWER SUPPLY AND GROUND
CIRCUIT
Check power window and door lock/unlock switch RH power supply and ground circuit.
Refer to PWC-27, "
FRONT POWER WINDOW SWITCH (PASSE NGER SIDE) : Diagnosis Procedure".
Is the inspection result normal?
YES >> GO TO 2.
NO >> Repair or replace the malfunctioning parts.
2.CHECK POWER WINDOW AND DO OR LOCK/UNLOCK SWITCH RH
Check power window and door lock/unlock switch RH.
Refer to PWC-30, "
Component Function Check".
Is the inspection result normal?
YES >> GO TO 3.
NO >> Repair or replace the malfunctioning parts.
3.CONFIRM THE OPERATION
Confirm the operation again.
Is the result normal?
YES >> Check intermittent incident. Refer to GI-42, "Intermittent Incident".
NO >> GO TO 1.
WHEN POWER WINDOW MAIN SWITCH IS OPERATED
Revision: August 2015 2016 Versa Note

cardiagn.com

Page 2708 of 3641

NISSAN NOTE 2016 Service Repair Manual FRONT PASSENGER SIDE POWER WINDOW DOES NOT OPERATE
PWC-47
< SYMPTOM DIAGNOSIS >
C
D E
F
G H
I
J
L
M A
B
PWC
N
O P
WHEN POWER WINDOW MAIN SWITCH IS OPERATED : Diagnosis Procedure
INFOID:00000000124318

Page 2709 of 3641

NISSAN NOTE 2016 Service Repair Manual PWC-48
< SYMPTOM DIAGNOSIS >
REAR LH SIDE POWER WINDOW DOES NOT OPERATE
REAR LH SIDE POWER WINDOW DOES NOT OPERATE
WHEN BOTH POWER WINDOW MAIN SWITCH AND REAR POWER WINDOW
SWITCH LH ARE OPERATED
WHEN

Page 2710 of 3641

NISSAN NOTE 2016 Service Repair Manual REAR LH SIDE POWER WINDOW DOES NOT OPERATE
PWC-49
< SYMPTOM DIAGNOSIS >
C
D E
F
G H
I
J
L
M A
B
PWC
N
O P
WHEN POWER WINDOW MAIN SWITCH IS OPERATED : Diagnosis Procedure
INFOID:0000000012431842
1.CHE

Page 2711 of 3641

NISSAN NOTE 2016 Service Repair Manual PWC-50
< SYMPTOM DIAGNOSIS >
REAR RH SIDE POWER WINDOW DOES NOT OPERATE
REAR RH SIDE POWER WINDOW DOES NOT OPERATE
WHEN BOTH POWER WINDOW MAIN SWITCH AND REAR POWER WINDOW
SWITCH RH ARE OPERATED
WHEN

Page 2712 of 3641

NISSAN NOTE 2016 Service Repair Manual REAR RH SIDE POWER WINDOW DOES NOT OPERATE
PWC-51
< SYMPTOM DIAGNOSIS >
C
D E
F
G H
I
J
L
M A
B
PWC
N
O P
WHEN POWER WINDOW MAIN SWITCH IS OPERATED : Diagnosis Procedure
INFOID:0000000012431845
1.CHE
