DLK-248
< DTC/CIRCUIT DIAGNOSIS >[WITHOUT INTELLIGENT KEY SYSTEM]
REMOTE KEYLESS ENTRY RECEIVER
2.CHECK REMOTE KEYLESS ENTRY RECEIVER POWER SUPPLY
1. Disconnect remote keyless entry receiver connector.
2. Check signal between remote keyless entry receiver connector and ground with oscilloscope.
Is the inspection result normal?
YES >> GO TO 4.
NO >> GO TO 3.
3.CHECK REMOTE K EYLESS ENTRY RECEIVER CIRCUIT 1
1. Disconnect BCM connector.
2. Check continuity between BCM connector and remote keyless entry receiver connector.
3. Check continuity between BCM connector and ground.
Is the inspection result normal?
YES >> Reconnect BCM, GO TO 4.
NO >> Repair or replace harness between BCM and remote keyless entry receiver.
4.CHECK REMOTE KEYL ESS ENTRY RECEIVER GROUND CIRCUIT
Check continuity between remote keyless entry receiver connector and ground.
Is the inspection result normal?
YES >> GO TO 6.
NO >> GO TO 5.
5.CHECK REMOTE K EYLESS ENTRY RECEIVER CIRCUIT 2
Check continuity between BCM connector and remote keyless entry receiver connector.
Is the inspection result normal?
YES >> GO TO 7.
Te r m i n a l s
Signal
(Reference value)
(+)
(–)
Remote keyless entry receiver
connector Te r m i n a l
M23 4Ground
JPMIA0338JP
BCM connector TerminalRemote keyless entry receiver
connector Terminal
Continuity
M18 19 M23 4Yes
BCM connector Terminal
GroundContinuity
M18 19 No
Remote keyless entry receiver
connector Te r m i n a l
GroundContinuity
M23 1 Yes
BCM
connector Te r m i n a lRemote keyless entry receiver
connector Terminal
Continuity
M18 18 M23 1Yes
Revision: August 2015 2016 Versa Note
cardiagn.com
Page 938 of 3641
REMOTE KEYLESS ENTRY RECEIVERDLK-249
< DTC/CIRCUIT DIAGNOSIS > [WITHOUT INTELLIGENT KEY SYSTEM]
C
D
E
F
G H
I
J
L
M A
B
DLK
N
O P
NO >> Repair or replace harness between BCM and remote keyless entry receiver.
6.CHECK REMOTE KEYLESS EN TRY RECEIVER CIRCUIT 3
1. Check continuity between BCM connector and remote keyless entry receiver connector.
2. Check continuity between BCM connector and ground.
Is the inspection result normal?
YES >> GO TO 7.
NO >> Repair or replace harness between BCM and remote keyless entry.
7.CHECK INTERMITTENT INCIDENT
Refer to GI-42, "
Intermittent Incident".
>> Inspection End.
BCM
connector Te r m i n a l
Remote keyless entry receiver
connector Terminal
Continuity
M18 20 M23 2Yes
BCM connector Terminal
GroundContinuity
M18 20 No
Revision: August 2015 2016 Versa Note
cardiagn.com
Page 939 of 3641
![NISSAN NOTE 2016 Service Repair Manual DLK-250
< DTC/CIRCUIT DIAGNOSIS >[WITHOUT INTELLIGENT KEY SYSTEM]
KEYFOB BATTERY AND FUNCTION
KEYFOB BATTERY AND FUNCTION
DescriptionINFOID:0000000012430212
The following functions are available when NISSAN NOTE 2016 Service Repair Manual DLK-250
< DTC/CIRCUIT DIAGNOSIS >[WITHOUT INTELLIGENT KEY SYSTEM]
KEYFOB BATTERY AND FUNCTION
KEYFOB BATTERY AND FUNCTION
DescriptionINFOID:0000000012430212
The following functions are available when](/manual-img/5/57363/w960_57363-938.png)
DLK-250
< DTC/CIRCUIT DIAGNOSIS >[WITHOUT INTELLIGENT KEY SYSTEM]
KEYFOB BATTERY AND FUNCTION
KEYFOB BATTERY AND FUNCTION
DescriptionINFOID:0000000012430212
The following functions are available when having and carrying the keyfob:
• Door lock/unlock
• Panic mode (horn and head-lamp operation)
Remote control entry function and panic alarm functi
on are available when operating the remote buttons.
Component Function CheckINFOID:0000000012430213
NOTE:
The Signal Tech II Tool [- (J-50190)] can be used to perform the following functions: Refer to the Signal Tech II
User Guide for additional information.
• Check keyfob relative signal strength.
• Confirm vehicle antenna signal strength.
1.CHECK FUNCTION
With CONSULT
Check remote keyless entry receiver “KEYLESS LOCK”, “KEYLESS UNLOCK”, and “KEYLESS PANIC” in
“Data Monitor”.
Is the inspection result normal?
YES >> Keyfob is OK.
NO >> Refer to DLK-250, "
Diagnosis Procedure".
Diagnosis ProcedureINFOID:0000000012430214
NOTE:
The Signal Tech II Tool [- (J-50190)] can be used to perform the following functions: Refer to the Signal Tech II
User Guide for additional information.
• Check keyfob relative signal strength.
• Confirm vehicle antenna signal strength.
1.CHECK KEYFOB FUNCTION
Check keyfob function using Signal Tech II Tool [- (J-50190)] or
Remote Keyless Entry Tester [- (J-43241)] (shown).
Does the test pass?
YES >> Keyfob is OK.
NO >> GO TO 2.
2. CHECK KEYFOB COMPONENTS
Monitor item Condition
KEYLESS LOCK Checks whether value changes from “Off” to “On” when operating keyfob lock button.
KEYLESS UNLOCK Checks whether value changes from “Off” to “On” when operating keyfob unlock button.
KEYLESS PANIC Checks whether value changes from “Off” to “On” when operating keyfob panic button.
ALKIA2300ZZ
Revision: August 2015 2016 Versa Note
cardiagn.com
Page 940 of 3641
![NISSAN NOTE 2016 Service Repair Manual KEYFOB BATTERY AND FUNCTIONDLK-251
< DTC/CIRCUIT DIAGNOSIS > [WITHOUT INTELLIGENT KEY SYSTEM]
C
D
E
F
G H
I
J
L
M A
B
DLK
N
O P
1. Remove the screw (A).
2. Insert a small screwdriver into the slit of NISSAN NOTE 2016 Service Repair Manual KEYFOB BATTERY AND FUNCTIONDLK-251
< DTC/CIRCUIT DIAGNOSIS > [WITHOUT INTELLIGENT KEY SYSTEM]
C
D
E
F
G H
I
J
L
M A
B
DLK
N
O P
1. Remove the screw (A).
2. Insert a small screwdriver into the slit of](/manual-img/5/57363/w960_57363-939.png)
KEYFOB BATTERY AND FUNCTIONDLK-251
< DTC/CIRCUIT DIAGNOSIS > [WITHOUT INTELLIGENT KEY SYSTEM]
C
D
E
F
G H
I
J
L
M A
B
DLK
N
O P
1. Remove the screw (A).
2. Insert a small screwdriver into the slit of the corner (B) and twist it to separate the upper part from the power part. Use a cloth to
protect the casing.
CAUTION:
• Do not touch the circuit board or battery terminal.
• The keyfob is water-resistant. However, if it does get wet,
immediately wipe it dry.
3. Remove the keyfob battery.
CAUTION:
• Keep dirt, grease, and other fo reign materials off the elec-
trode contact area.
4. Visually inspect keyfob internal components.
Is the inspection result normal?
YES >> GO TO 3.
NO >> Repair or replace malfunctioning parts.
3.CHECK KEYFOB BATTERY
Check by connecting a resistance (approximately 300 Ω) so that the
current value becomes about 10 mA.
Is the measurement val ue within specification?
YES >> Keyfob battery is OK. Check remote keyless entry
receiver. Refer to DLK-247,
"ComponentFunctionCheck".
NO >> GO TO 4.
4. REPLACE KEYFOB BATTERY
1. Replace the keyfob battery with a new one. CAUTION:
• When replacing battery, keep dirt, grease, and other for-eign materials off the electrode contact area.
• Make sure that the + side faces the bottom of the case.
2. Align the tips of the upper and lower parts, and then push them
together until it is securely closed.
3. After replacing the battery, check that all keyfob functions work properly.
Is the inspection result normal?
YES >> Keyfob is OK.
NO >> Check remote keyless entry receiver. Refer to DLK-247,
"ComponentFunctionCheck".
ALKIA2301ZZ
Standard : Approx. 2.5 - 3.0V
OCC0607D
ALKIA2302ZZ
Revision: August 2015 2016 Versa Note
cardiagn.com
Page 941 of 3641
![NISSAN NOTE 2016 Service Repair Manual DLK-252
< DTC/CIRCUIT DIAGNOSIS >[WITHOUT INTELLIGENT KEY SYSTEM]
HORN FUNCTION
HORN FUNCTION
DescriptionINFOID:0000000012430215
Perform answer-back for each operation with horn.
Component Function Ch NISSAN NOTE 2016 Service Repair Manual DLK-252
< DTC/CIRCUIT DIAGNOSIS >[WITHOUT INTELLIGENT KEY SYSTEM]
HORN FUNCTION
HORN FUNCTION
DescriptionINFOID:0000000012430215
Perform answer-back for each operation with horn.
Component Function Ch](/manual-img/5/57363/w960_57363-940.png)
DLK-252
< DTC/CIRCUIT DIAGNOSIS >[WITHOUT INTELLIGENT KEY SYSTEM]
HORN FUNCTION
HORN FUNCTION
DescriptionINFOID:0000000012430215
Perform answer-back for each operation with horn.
Component Function CheckINFOID:0000000012430216
1.CHECK FUNCTION
1. Select “HORN” in “Active Test” using CONSULT.
2. Check the horn operation.
Is the operation normal?
YES >> Inspection End.
NO >> Refer to DLK-252, "
DiagnosisProcedure".
Diagnosis ProcedureINFOID:0000000012430217
Regarding Wiring Diagram information, refer to DLK-216, "Wiring Diagram".
1.CHECK HORN FUNCTION
Check horn function with horn switch.
Does the horn sound?
YES >> GO TO 2.
NO >> Refer to HRN-3, "
Wiring Diagram".
2.CHECK HORN RELAY POWER SUPPLY
1. Turn ignition switch ON.
2. Perform “Active Test”“HORN” using CONSULT.
3. Using an oscilloscope or analog voltmeter to check voltage between IPDM E/R connector and ground.
Is the inspection result normal?
YES >> GO TO 3.
NO >> Replace IPDM E/R. Refer to PCS-30, "
Removal and Installation".
3.CHECK HORN RELAY CIRCUIT
1. Turn ignition switch OFF.
2. Disconnect IPDM E/R and horn relay connector.
3. Check continuity between IPDM E/R har ness connector and horn relay harness connector.
4. Check continuity between IP DM E/R harness connector and ground.
Test item Description
HORN ON Horn relay ON (for 20 ms)
IPDM E/R
Ground Test item Voltage (V)
(Approx.)
Connector Terminal
E46 73Ground HORN ON
Battery voltage → 0 → Battery voltage
Other than above Battery voltage
IPDM E/R Horn relay
Continuity
Connector TerminalConnector Terminal
E46 73E39 1Yes
Revision: August 2015 2016 Versa Note
cardiagn.com
Page 942 of 3641
HORN FUNCTIONDLK-253
< DTC/CIRCUIT DIAGNOSIS > [WITHOUT INTELLIGENT KEY SYSTEM]
C
D
E
F
G H
I
J
L
M A
B
DLK
N
O P
Is the inspection result normal?
YES >> GO TO 4.
NO >> Repair or replace harness.
4.CHECK INTERMITTENT INCIDENT
Refer to GI-42, "
Intermittent Incident".
Is the inspection result normal?
YES >> Replace IPDM E/R. Refer to PCS-30, "Removal and Installation".
NO >> Repair or replace the malfunctioning part.
IPDM E/R GroundContinuity
Connector Terminal
E46 73Ground No
Revision: August 2015 2016 Versa Note
cardiagn.com
Page 943 of 3641
![NISSAN NOTE 2016 Service Repair Manual DLK-254
< DTC/CIRCUIT DIAGNOSIS >[WITHOUT INTELLIGENT KEY SYSTEM]
WARNING CHIME FUNCTION
WARNING CHIME FUNCTION
DescriptionINFOID:0000000012430218
Performs operation method guide and warning with buzz NISSAN NOTE 2016 Service Repair Manual DLK-254
< DTC/CIRCUIT DIAGNOSIS >[WITHOUT INTELLIGENT KEY SYSTEM]
WARNING CHIME FUNCTION
WARNING CHIME FUNCTION
DescriptionINFOID:0000000012430218
Performs operation method guide and warning with buzz](/manual-img/5/57363/w960_57363-942.png)
DLK-254
< DTC/CIRCUIT DIAGNOSIS >[WITHOUT INTELLIGENT KEY SYSTEM]
WARNING CHIME FUNCTION
WARNING CHIME FUNCTION
DescriptionINFOID:0000000012430218
Performs operation method guide and warning with buzzer.
Component Function CheckINFOID:0000000012430219
1.CHECK FUNCTION
With CONSULT
1. Check the operation of “BUZZER” in “Active Test”.
2. Touch “IGN KEY WARN ALM”, “SEAT BELT WARN TEST”or “LIGHT WARN ALM”on screen.
Is the inspection result normal?
YES >> Warning buzzer into combination meter is OK.
NO >> Refer to DLK-254, "
Diagnosis Procedure".
Diagnosis ProcedureINFOID:0000000012430220
1.CHECK METER BUZZER CIRCUIT
Operate the hazard lights by turni ng ON the hazard warning switch.
Is the inspection result normal?
YES >> GO TO 2.
NO >> Replace combination meter. Refer to MWI-54, "
Removal and Installation" (Type A) or MWI-115,
"Removal and Installation" (Type B).
2.CHECK INTERMITTENT INCIDENT
Refer to GI-42, "
Intermittent Incident".
>> Inspection End.
Revision: August 2015 2016 Versa Note
cardiagn.com
Page 944 of 3641
HAZARD FUNCTIONDLK-255
< DTC/CIRCUIT DIAGNOSIS > [WITHOUT INTELLIGENT KEY SYSTEM]
C
D
E
F
G H
I
J
L
M A
B
DLK
N
O P
HAZARD FUNCTION
DescriptionINFOID:0000000012430221
Perform answer-back for each oper ation with number of blinks.
Component Function CheckINFOID:0000000012430222
1.CHECK FUNCTION
Check hazard warning lamp “FLASHER” in “Active Test”.
Is the inspection result normal?
YES >> Hazard warning lamp circuit is OK.
NO >> Refer to DLK-255, "
Diagnosis Procedure".
Diagnosis ProcedureINFOID:0000000012430223
1.CHECK HAZARD SWITCH CIRCUIT
Operate the hazard lights by turni ng ON the hazard warning switch.
Is the inspection result normal?
YES >> GO TO 2.
NO >> Repair or replace hazard warning switch circuit. Refer to EXL-108, "
Removal and Installation".
2.CHECK INTERMITTENT INCIDENT
Refer to GI-42, "
Intermittent Incident".
>> Inspection End.
Revision: August 2015 2016 Versa Note
cardiagn.com
