Page 3129 of 3641

DRIVER AIR BAG MODULESR-13
< REMOVAL AND INSTALLATION >
C
DE
F
G
I
J
K L
M A
B
SR
N
O P
• Do not use air tools or electric tools for servicing.
CAUTION:
• Do not allow oil, grease, detergent or water to come in contact with the driver air bag module.
REMOVAL
1. Disconnect negative and positive battery terminals, then wait at least three minutes. Refer to PG-70,
"Removal and Installation (Battery)".
2. Remove driver air bag module type 1:
a. Locate the access holes on side of steering wheel rear finisher (1) and insert ( ) a 5.0 mm (0.20 in) diameter suitable tool (A).
b. Push suitable tool inward ( ) and make sure the tool contacts the spring (D). While pushing on spring (D), push on the driver
air bag module. The driver air bag module hook will release,
then pull to release from steering wheel. Repeat procedure on
springs (B) and (C).
NOTE:
Driver air bag module removed for clarity.
c. Lift driver air bag module away from the steering wheel and dis- connect the driver air bag module harness connectors (A) and
the horn harness connector (B). Then remove the harnesses
from hook (C).
NOTE:
Take note of harness routing for correct installation.
CAUTION:
• For removing/installing the driver air bag module harness
connector, insert a thin screwdriver wrapped in tape into
the notch, then lift the lock and remove the harness con-
nector as shown.
• Install the harness connector with the lock raised, and push the lock into the connector as shown.
• After installing the connector, check that the lock is pushed in securely.
3. Remove driver air bag module type 2:
AWHIA0528ZZ
AWHIA0551ZZ
PHIA0953J
Revision: August 2015 2016 Versa Note
cardiagn.com
Page 3130 of 3641

SR-14
< REMOVAL AND INSTALLATION >
DRIVER AIR BAG MODULE
a. Remove side lid (LH and RH).Insert flat-bladed screwdriver between side lid and steering
wheel to disengage pawls as shown in the figure.
b. Remove bolts (LH and RH) from the steering wheel lower side.
c. Pull out driver air bag module.
d. Disconnect spiral cable harness connector (A).
e. Disconnect driver air bag harness connector (B).
CAUTION:
• For installing/removing the driver air bag module harnessconnector, insert thin screwdriver wrapped in tape into
notch, lift lock and remove the connector.
• Install the connector with lock raised, and push lock into
the connector.
• After installing the conn ector, check that the lock is
pushed securely into it.
4. Remove the driver air bag module. NOTE:
Driver air bag type 1 shown, type 2 similar.
CAUTION:
• Always place the driver air ba g module with pad side fac-
ing upward.
: Upward
: Pawl
JMHIA1605ZZ
JMHIA1606ZZ
PHIA0953J
JMHIA2077ZZ
Revision: August 2015 2016 Versa Note
cardiagn.com
Page 3131 of 3641
DRIVER AIR BAG MODULESR-15
< REMOVAL AND INSTALLATION >
C
DE
F
G
I
J
K L
M A
B
SR
N
O P
• Replace the driver air bag module if it has been dropped or sustained an impact.
• Do not strike the driver air bag module.
INSTALLATION
Note the following items and install in the reverse order of removal.
CAUTION:
• To install the driver air bag module (type 1)onto the steering wheel, align the hooks over the springs
and push to snap into place.
• Fix the driver air bag module (type 2) harnesses to the har- ness fixing hook (A).
• Be careful not to damage or pinch the harness while installing.
• After the work is completed, check the function of the horn and each steering switch.
• After the work is completed, perform diagnosis to check that no malfunction is detected. Refer to
SRC-14, "
Description".
JMHIA0009ZZ
JMHIA1608ZZ
Revision: August 2015 2016 Versa Note
cardiagn.com
Page 3132 of 3641

SR-16
< REMOVAL AND INSTALLATION >
SPIRAL CABLE
SPIRAL CABLE
Exploded ViewINFOID:0000000012430568
Removal and InstallationINFOID:0000000012430569
WARNING:
• Before servicing the SRS, turn ignition switch OFF, disconnect bot h battery terminals then wait at
least three minutes.
• Do not disassemble the spiral cable.
• Do not use air tools or el ectric tools for servicing.
CAUTION:
• Do not allow oil, grease, detergent or water to come in contact with the spiral cable.
REMOVAL
1. Disconnect negative and positive battery terminals, then wait at least three minutes. Refer to PG-70,
"Removal and Installation (Battery)".
2. Remove steering wheel. Refer to ST-8, "
Removal and Installation".
3. Remove steering column covers. Refer to IP-17, "
Removal and Installation".
4. Disconnect the harness connector (A) from spiral cable and har- ness connector (B) from steering angle sensor.
1. Combination switch 2. Steering angle sensor3. Spiral cable
Pawl
AWHIA0504ZZ
ALHIA0272ZZ
Revision: August 2015 2016 Versa Note
cardiagn.com
Page 3133 of 3641
SPIRAL CABLESR-17
< REMOVAL AND INSTALLATION >
C
DE
F
G
I
J
K L
M A
B
SR
N
O P
5. Remove screws (A), then release pawls and remove spiral cable and steering angle sensor (1) as an assembly.
: Pawl
CAUTION:
Do not turn the spiral cable quickly or beyond the limit
number of turns (approximately 2.5 turns from the neutral
position), this may cause the cable to snap.
6. Remove screws (A), then release pawls (B) and separate the steering angle sensor (2) from spiral cable (1).
CAUTION:
Do not reuse steering angle sensor.
CAUTION:
• Do not strike or drop the spiral cable.
• Replace the spiral cable if it has been dropped or sustained
an impact.
INSTALLATION
Installation is in the reverse order of removal.
• The turn signal lever must be in the neutral position for spiral cable installation.
AWHIA0538ZZ
ALHIA0271ZZ
JMHIA0009ZZ
Revision: August 2015 2016 Versa Note
cardiagn.com
Page 3134 of 3641

SR-18
< REMOVAL AND INSTALLATION >
SPIRAL CABLE
• Set the spiral cable neutral position by carefully turning the spiralcable (1) clockwise to the stop position. Turn the spiral cable coun-
terclockwise 2.5 turns stopping when the locating pin (A) is at the
top most position, triangles (B) are aligned as shown and the win-
dow (C) appears white.
NOTE:
If a new service part is installed, the neutral position is already set
with a stopper clip in place and should not be adjusted after the
stopper clip is removed. Make sure the stopper clip is removed
before installing the steering wheel.
• During steering wheel (2) installation, make sure the locating pin hole (D) is aligned with the locating pin (A) of the spiral cable.
• Adjust the neutral position of the steering angle sensor. Refer to
BRC-55, "
ADJUSTMENT OF STEERI NG ANGLE SENSOR NEU-
TRAL POSITION : Description".
CAUTION:
• The spiral cable may snap during steering operation if the spiral cable is installed in an improper
position.
• Do not overturn the spiral cable or go beyond the maximum number of turns allowed. This will cause
the cable to snap.
• Do not apply lubricant to the spiral cable.
• Do not allow oil, grease, detergent or water to come in contact with the spiral cable.
• After the work is completed, perform diagnosis to check that no malfunction is detected. Refer to
SRC-14, "
Description".
AWHIA0531ZZ
Revision: August 2015 2016 Versa Note
cardiagn.com
Page 3135 of 3641

FRONT PASSENGER AIR BAG MODULESR-19
< REMOVAL AND INSTALLATION >
C
DE
F
G
I
J
K L
M A
B
SR
N
O P
FRONT PASSENGER AIR BAG MODULE
Exploded ViewINFOID:0000000012430570
Removal and InstallationINFOID:0000000012430571
WARNING:
• Before servicing the SRS, turn ig nition switch OFF, disconnect both battery terminals then wait at
least three minutes.
• Always work from the side of air bag module. Do not work in front of it.
• Do not expose the front passenger air bag module to temperatures exceeding 90 °C (194° F).
• Do not attempt to disassemble the front passenger air bag module.
• Do not insert any foreign objects (screwdriver, etc.) into the front passenger air bag module.
• Do not use air tools or electric tools for servicing.
CAUTION:
• Do not allow oil, grease, detergent, or water to co me in contact with the front passenger air bag mod-
ule.
REMOVAL
1. Disconnect negative and positive battery terminals, then wait at least three minutes. Refer to PG-70,
"Removal and Installation (Battery)".
2. Remove the glove box assembly. Refer to IP-25, "
Removal and Installation".
1. Front passenger air bag module 2. Instrument panel assembly Pawl
AWHIA0529ZZ
Revision: August 2015 2016 Versa Note
cardiagn.com
Page 3136 of 3641

SR-20
< REMOVAL AND INSTALLATION >
FRONT PASSENGER AIR BAG MODULE
3. Disconnect the harness connector (A) from front passenger airbag module.
4. Remove and discard the front passenger air bag module bolts (B).
CAUTION:
Do not reuse front passenger air bag module bolts.
5. Release pawls using a suitable tool and remove front passenger air bag module (1).
: Pawl
CAUTION:
• Always place the front passenger air bag module with pad side facing upward.
: Upward
• Do not strike the front passenger air bag module.
• Replace the front passenger air bag module if it has been dropped or sustained an impact.
INSTALLATION
Installation is in the reverse order of removal.
CAUTION:
• Do not reuse the front passenger air bag module bolts.
• Do not damage the front passenger air bag module harness during installation.
• After the work is completed, perform diagnosis to check that no malfunction is detected. Refer to
SRC-14, "
Description".
JMHIA2022ZZ
AWHIA0527ZZ
JMHIA2461ZZ
JMHIA0009ZZ
Revision: August 2015 2016 Versa Note
