Page 3201 of 3641

NISSAN NOTE 2016 Service Repair Manual DIAGNOSIS AND REPAIR WORKFLOWSTC-17 < BASIC INSPECTION > C DE F H I J K L M A B STC N O P Other conditions Memo Interview sheet Customer name MR/MSRegistration number Initial year registration Veh

Page 3202 of 3641

NISSAN NOTE 2016 Service Repair Manual STC-18 < DTC/CIRCUIT DIAGNOSIS > C1601 BATTERY POWER SUPPLY DTC/CIRCUIT DIAGNOSIS C1601 BATTERY POWER SUPPLY DTC LogicINFOID:0000000012431953 DTC DETECTION LOGIC DTC CONFIRMATION PROCEDURE 1.PRECONDIT

Page 3203 of 3641

NISSAN NOTE 2016 Service Repair Manual C1601 BATTERY POWER SUPPLYSTC-19 < DTC/CIRCUIT DIAGNOSIS > C DE F H I J K L M A B STC N O P 2. Turn ignition switch ON. CAUTION: Never start the engine. 3. Check voltage between EPS control unit harne

Page 3204 of 3641

NISSAN NOTE 2016 Service Repair Manual STC-20 < DTC/CIRCUIT DIAGNOSIS > C1601 BATTERY POWER SUPPLY NO >> Repair or replace malfunctioning component. 6.CHECK CONNECTOR 1. Turn ignition switch OFF. 2. Disconnect torque sensor harness connect

Page 3205 of 3641

NISSAN NOTE 2016 Service Repair Manual C1604 TORQUE SENSORSTC-21 < DTC/CIRCUIT DIAGNOSIS > C DE F H I J K L M A B STC N O P C1604 TORQUE SENSOR DTC LogicINFOID:0000000012431955 DTC DETECTION LOGIC DTC CONFIRMATION PROCEDURE 1.PRECONDITIONI

Page 3206 of 3641

NISSAN NOTE 2016 Service Repair Manual STC-22 < DTC/CIRCUIT DIAGNOSIS > C1604 TORQUE SENSOR Is the inspection result normal? YES >> GO TO 3. NO >> Repair open circuit or short to ground or short to power in harness or connectors. 3.CHECK T

Page 3207 of 3641

NISSAN NOTE 2016 Service Repair Manual C1606 EPS MOTORSTC-23 < DTC/CIRCUIT DIAGNOSIS > C DE F H I J K L M A B STC N O P C1606 EPS MOTOR DTC LogicINFOID:0000000012431957 DTC DETECTION LOGIC DTC CONFIRMATION PROCEDURE 1.PRECONDITIONING If

Page 3208 of 3641

NISSAN NOTE 2016 Service Repair Manual STC-24 < DTC/CIRCUIT DIAGNOSIS > C1606 EPS MOTOR YES >> Inspection End. NO >> EPS motor is malfunctioning. Replace steering column assembly. Refer to ST-9, " Removal and Installation". Revision: Aug
