1.CHECK CON](/manual-img/5/57363/w960_57363-2304.png)
LAN
IPDM-E BRANCH LINE CIRCUITLAN-117
< DTC/CIRCUIT DIAGNOSIS > [CAN SYSTEM (TYPE 505)]
C
D
E
F
G H
I
J
K L
B A
O P
N
IPDM-E BRANCH
LINE CIRCUIT
Diagnosis ProcedureINFOID:0000000012785726
1.CHECK CONNECTOR
1. Turn the ignition switch OFF.
2. Disconnect the battery cabl e from the negative terminal.
3. Check the terminals and connectors of the IPDM E/R for damage, bend and loose connection (unit side
and connector side).
Is the inspection result normal?
YES >> GO TO 2.
NO >> Repair the terminal and connector.
2.CHECK HARNESS FOR OPEN CIRCUIT
1. Disconnect the connector of IPDM E/R.
2. Check the resistance between the IPDM E/R harness connector terminals.
Is the measurement value within the specification?
YES >> GO TO 3.
NO >> Repair the IPDM E/R branch line.
3.CHECK POWER SUPPLY AND GROUND CIRCUIT
Check the power supply and the ground circuit of the IPDM E/R. Refer to PCS-29, "
Diagnosis Procedure".
Is the inspection result normal?
YES (Present error)>>Replace the IPDM E/R. Refer to PCS-30, "Removal and Installation".
YES (Past error)>>Error was detected in the IPDM E/R branch line.
NO >> Repair the power supply and the ground circuit.
IPDM E/R harness connector Resistance (Ω)
Connector No. Terminal No.
E46 62 61 Approx. 54 – 66
Revision: August 2015 2016 Versa Note
cardiagn.com
Page 2306 of 3641
![NISSAN NOTE 2016 Service Repair Manual LAN-118
< DTC/CIRCUIT DIAGNOSIS >[CAN SYSTEM (TYPE 505)]
TCM BRANCH LINE CIRCUIT
TCM BRANCH LINE CIRCUIT
Diagnosis ProcedureINFOID:0000000012785727
1.CHECK CONNECTOR
1. Turn the ignition switch OFF.
2 NISSAN NOTE 2016 Service Repair Manual LAN-118
< DTC/CIRCUIT DIAGNOSIS >[CAN SYSTEM (TYPE 505)]
TCM BRANCH LINE CIRCUIT
TCM BRANCH LINE CIRCUIT
Diagnosis ProcedureINFOID:0000000012785727
1.CHECK CONNECTOR
1. Turn the ignition switch OFF.
2](/manual-img/5/57363/w960_57363-2305.png)
LAN-118
< DTC/CIRCUIT DIAGNOSIS >[CAN SYSTEM (TYPE 505)]
TCM BRANCH LINE CIRCUIT
TCM BRANCH LINE CIRCUIT
Diagnosis ProcedureINFOID:0000000012785727
1.CHECK CONNECTOR
1. Turn the ignition switch OFF.
2. Disconnect the battery cable from the negative terminal.
3. Check the following terminals and connectors fo r damage, bend and loose connection (unit side and con-
nector side).
-TCM
- Harness connector F8
- Harness connector E8
Is the inspection result normal?
YES >> GO TO 2.
NO >> Repair the terminal and connector.
2.CHECK HARNESS FOR OPEN CIRCUIT
1. Disconnect the connector of TCM.
2. Check the resistance between the TCM harness connector terminals.
Is the measurement value within the specification?
YES >> GO TO 3.
NO >> Repair the TCM branch line.
3.CHECK POWER SUPPLY AND GROUND CIRCUIT
Check the power supply and the ground circuit of the TCM. Refer to TM-215, "
Diagnosis Procedure".
Is the inspection result normal?
YES (Present error)>>Replace the TCM. Refer to TM-239, "Removal and Installation".
YES (Past error)>>Error was detected in the TCM branch line.
NO >> Repair the power supply and the ground circuit.
TCM harness connector Resistance (Ω)
Connector No. Terminal No.
F44 3323Approx. 54 – 66
Revision: August 2015 2016 Versa Note
cardiagn.com
Page 2307 of 3641
![NISSAN NOTE 2016 Service Repair Manual LAN
A-BAG BRANCH LINE CIRCUITLAN-119
< DTC/CIRCUIT DIAGNOSIS > [CAN SYSTEM (TYPE 505)]
C
D
E
F
G H
I
J
K L
B A
O P
N
A-BAG BRANCH LINE CIRCUIT
Diagnosis ProcedureINFOID:0000000012785728
WARNING:
Alway NISSAN NOTE 2016 Service Repair Manual LAN
A-BAG BRANCH LINE CIRCUITLAN-119
< DTC/CIRCUIT DIAGNOSIS > [CAN SYSTEM (TYPE 505)]
C
D
E
F
G H
I
J
K L
B A
O P
N
A-BAG BRANCH LINE CIRCUIT
Diagnosis ProcedureINFOID:0000000012785728
WARNING:
Alway](/manual-img/5/57363/w960_57363-2306.png)
LAN
A-BAG BRANCH LINE CIRCUITLAN-119
< DTC/CIRCUIT DIAGNOSIS > [CAN SYSTEM (TYPE 505)]
C
D
E
F
G H
I
J
K L
B A
O P
N
A-BAG BRANCH LINE CIRCUIT
Diagnosis ProcedureINFOID:0000000012785728
WARNING:
Always observe the following items fo
r preventing accidental activation.
• Before servicing, turn ignition sw itch OFF, disconnect battery negative terminal, and wait 3 minutes
or more. (To discharge backup capacitor.)
• Never use unspecified tester or other measuring device.
1.CHECK CONNECTOR
1. Turn the ignition switch OFF.
2. Disconnect the battery cabl e from the negative terminal.
3. Check the terminals and connectors of the air bag diagnosis sensor unit for damage, bend and loose con-
nection (unit side and connector side).
Is the inspection result normal?
YES >> GO TO 2.
NO >> Replace the main harness.
2.CHECK AIR BAG DIAGNOSIS SENSOR UNIT
Check the air bag diagnosis sensor unit. Refer to SRC-36, "
Work Flow".
Is the inspection result normal?
YES >> Replace the main harness.
NO >> Replace parts whose air bag system has a malfunction.
Revision: August 2015 2016 Versa Note
cardiagn.com
Page 2308 of 3641
![NISSAN NOTE 2016 Service Repair Manual LAN-120
< DTC/CIRCUIT DIAGNOSIS >[CAN SYSTEM (TYPE 505)]
AV BRANCH LINE CIRCUIT
AV BRANCH LINE CIRCUIT
Diagnosis ProcedureINFOID:0000000012785735
1.CHECK CONNECTOR
1. Turn the ignition switch OFF.
2. NISSAN NOTE 2016 Service Repair Manual LAN-120
< DTC/CIRCUIT DIAGNOSIS >[CAN SYSTEM (TYPE 505)]
AV BRANCH LINE CIRCUIT
AV BRANCH LINE CIRCUIT
Diagnosis ProcedureINFOID:0000000012785735
1.CHECK CONNECTOR
1. Turn the ignition switch OFF.
2.](/manual-img/5/57363/w960_57363-2307.png)
LAN-120
< DTC/CIRCUIT DIAGNOSIS >[CAN SYSTEM (TYPE 505)]
AV BRANCH LINE CIRCUIT
AV BRANCH LINE CIRCUIT
Diagnosis ProcedureINFOID:0000000012785735
1.CHECK CONNECTOR
1. Turn the ignition switch OFF.
2. Disconnect the battery cable from the negative terminal.
3. Check the terminals and connectors of the AV control unit for damage, bend and loose connection (unit side and connector side).
Is the inspection result normal?
YES >> GO TO 2.
NO >> Repair the terminal and connector.
2.CHECK HARNESS FOR OPEN CIRCUIT
1. Disconnect the connector of AV control unit.
2. Check the resistance between the AV control unit harness connector terminals.
Is the measurement value within the specification?
YES >> GO TO 3.
NO >> Repair the AV control unit branch line.
3.CHECK POWER SUPPLY AND GROUND CIRCUIT
Check the power supply and the ground circuit of the AV control unit. Refer to AV-216, "
AV CONTROL UNIT :
Diagnosis Procedure".
Is the inspection result normal?
YES (Present error)>>Replace the AV control unit. Refer to AV-241, "Removal and Installation".
YES (Past error)>>Error was detected in the AV control unit branch line.
NO >> Repair the power supply and the ground circuit.
AV control unit harness connector Resistance (Ω)
Connector No. Terminal No.
M70 817Approx. 54 – 66
Revision: August 2015 2016 Versa Note
cardiagn.com
Page 2309 of 3641
![NISSAN NOTE 2016 Service Repair Manual LAN
DLC BRANCH LINE CIRCUITLAN-121
< DTC/CIRCUIT DIAGNOSIS > [CAN SYSTEM (TYPE 505)]
C
D
E
F
G H
I
J
K L
B A
O P
N
DLC BRANCH LINE CIRCUIT
Diagnosis ProcedureINFOID:0000000012785729
1.CHECK CONNECTOR
NISSAN NOTE 2016 Service Repair Manual LAN
DLC BRANCH LINE CIRCUITLAN-121
< DTC/CIRCUIT DIAGNOSIS > [CAN SYSTEM (TYPE 505)]
C
D
E
F
G H
I
J
K L
B A
O P
N
DLC BRANCH LINE CIRCUIT
Diagnosis ProcedureINFOID:0000000012785729
1.CHECK CONNECTOR](/manual-img/5/57363/w960_57363-2308.png)
LAN
DLC BRANCH LINE CIRCUITLAN-121
< DTC/CIRCUIT DIAGNOSIS > [CAN SYSTEM (TYPE 505)]
C
D
E
F
G H
I
J
K L
B A
O P
N
DLC BRANCH LINE CIRCUIT
Diagnosis ProcedureINFOID:0000000012785729
1.CHECK CONNECTOR
1. Turn the ignition switch OFF.
2. Disconnect the battery cabl e from the negative terminal.
3. Check the terminals and connectors of the data link connector for damage, bend and loose connection (connector side and harness side).
Is the inspection result normal?
YES >> GO TO 2.
NO >> Repair the terminal and connector.
2.CHECK HARNESS FOR OPEN CIRCUIT
Check the resistance between the data link connector terminals.
Is the measurement value within the specification?
YES (Present error)>>Check CA N system type decision again.
YES (Past error)>>Error was detected in the data link connector branch line circuit.
NO >> Repair the data link connector branch line.
Data link connector Resistance (Ω)
Connector No. Terminal No.
M22 614Approx. 54 – 66
Revision: August 2015 2016 Versa Note
cardiagn.com
Page 2310 of 3641
![NISSAN NOTE 2016 Service Repair Manual LAN-122
< DTC/CIRCUIT DIAGNOSIS >[CAN SYSTEM (TYPE 505)]
EPS BRANCH LINE CIRCUIT
EPS BRANCH LINE CIRCUIT
Diagnosis ProcedureINFOID:0000000012785730
1.CHECK CONNECTOR
1. Turn the ignition switch OFF.
2 NISSAN NOTE 2016 Service Repair Manual LAN-122
< DTC/CIRCUIT DIAGNOSIS >[CAN SYSTEM (TYPE 505)]
EPS BRANCH LINE CIRCUIT
EPS BRANCH LINE CIRCUIT
Diagnosis ProcedureINFOID:0000000012785730
1.CHECK CONNECTOR
1. Turn the ignition switch OFF.
2](/manual-img/5/57363/w960_57363-2309.png)
LAN-122
< DTC/CIRCUIT DIAGNOSIS >[CAN SYSTEM (TYPE 505)]
EPS BRANCH LINE CIRCUIT
EPS BRANCH LINE CIRCUIT
Diagnosis ProcedureINFOID:0000000012785730
1.CHECK CONNECTOR
1. Turn the ignition switch OFF.
2. Disconnect the battery cable from the negative terminal.
3. Check the terminals and connectors of the EPS control unit for damage, bend and loose connection (unit side and connector side).
Is the inspection result normal?
YES >> GO TO 2.
NO >> Repair the terminal and connector.
2.CHECK HARNESS FOR OPEN CIRCUIT
1. Disconnect the connector of EPS control unit.
2. Check the resistance between the EPS control unit harness connector terminals.
Is the measurement value within the specification?
YES >> GO TO 3.
NO >> Repair the EPS control unit branch line.
3.CHECK POWER SUPPLY AND GROUND CIRCUIT
Check the power supply and the ground circui t of the EPS control unit. Refer to STC-18, "
Diagnosis Proce-
dure".
Is the inspection result normal?
YES (Present error)>>Replace the EPS control unit. Refer to STC-37, "Removal and Installation".
YES (Past error)>>Error was detected in the EPS control unit branch line.
NO >> Repair the power supply and the ground circuit.
EPS control unit harness connector Resistance (Ω)
Connector No. Terminal No.
M53 21Approx. 54 – 66
Revision: August 2015 2016 Versa Note
cardiagn.com
Page 2311 of 3641
![NISSAN NOTE 2016 Service Repair Manual LAN
M&A BRANCH LINE CIRCUITLAN-123
< DTC/CIRCUIT DIAGNOSIS > [CAN SYSTEM (TYPE 505)]
C
D
E
F
G H
I
J
K L
B A
O P
N
M&A BRANCH LINE CIRCUIT
Diagnosis ProcedureINFOID:0000000012785731
1.CHECK CONNECTOR
NISSAN NOTE 2016 Service Repair Manual LAN
M&A BRANCH LINE CIRCUITLAN-123
< DTC/CIRCUIT DIAGNOSIS > [CAN SYSTEM (TYPE 505)]
C
D
E
F
G H
I
J
K L
B A
O P
N
M&A BRANCH LINE CIRCUIT
Diagnosis ProcedureINFOID:0000000012785731
1.CHECK CONNECTOR](/manual-img/5/57363/w960_57363-2310.png)
LAN
M&A BRANCH LINE CIRCUITLAN-123
< DTC/CIRCUIT DIAGNOSIS > [CAN SYSTEM (TYPE 505)]
C
D
E
F
G H
I
J
K L
B A
O P
N
M&A BRANCH LINE CIRCUIT
Diagnosis ProcedureINFOID:0000000012785731
1.CHECK CONNECTOR
1. Turn the ignition switch OFF.
2. Disconnect the battery cabl e from the negative terminal.
3. Check the terminals and connectors of the combination meter for damage, bend and loose connection (unit side and connector side).
Is the inspection result normal?
YES >> GO TO 2.
NO >> Repair the terminal and connector.
2.CHECK HARNESS FOR OPEN CIRCUIT
1. Disconnect the connector of combination meter.
2. Check the resistance between the combination meter harness connector terminals. NOTE:
Check the vehicle type confirm the service information. Refer to MWI-5, "
Information".
- With Type A
- With Type B
Is the measurement value within the specification?
YES >> GO TO 3.
NO >> Repair the combination meter branch line.
3.CHECK POWER SUPPLY AND GROUND CIRCUIT
Check the power supply and the ground circuit of the combination meter. Refer to following.
• TYPE A: MWI-43, "
COMBINATION METER : Diagnosis Procedure".
• TYPE B: MWI-98, "
COMBINATION METER : Diagnosis Procedure".
Is the inspection result normal?
YES (Present error)>>Replace the combination meter. Refer to the following. • TYPE A: MWI-54, "
Removal and Installation"
• TYPE B: MWI-115, "Removal and Installation"
YES (Past error)>>Error was detected in the combination meter branch line.
NO >> Repair the power supply and the ground circuit.
Combination meter harness connector
Resistance (Ω)
Connector No. Terminal No.
M82 12Approx. 54 – 66
Combination meter harness connector Resistance (Ω)
Connector No. Terminal No.
M24 12Approx. 54 – 66
Revision: August 2015 2016 Versa Note
cardiagn.com
Page 2312 of 3641
![NISSAN NOTE 2016 Service Repair Manual LAN-124
< DTC/CIRCUIT DIAGNOSIS >[CAN SYSTEM (TYPE 505)]
STRG BRANCH LINE CIRCUIT
STRG BRANCH LINE CIRCUIT
Diagnosis ProcedureINFOID:0000000012785732
1.CHECK CONNECTOR
1. Turn the ignition switch OFF. NISSAN NOTE 2016 Service Repair Manual LAN-124
< DTC/CIRCUIT DIAGNOSIS >[CAN SYSTEM (TYPE 505)]
STRG BRANCH LINE CIRCUIT
STRG BRANCH LINE CIRCUIT
Diagnosis ProcedureINFOID:0000000012785732
1.CHECK CONNECTOR
1. Turn the ignition switch OFF.](/manual-img/5/57363/w960_57363-2311.png)
LAN-124
< DTC/CIRCUIT DIAGNOSIS >[CAN SYSTEM (TYPE 505)]
STRG BRANCH LINE CIRCUIT
STRG BRANCH LINE CIRCUIT
Diagnosis ProcedureINFOID:0000000012785732
1.CHECK CONNECTOR
1. Turn the ignition switch OFF.
2. Disconnect the battery cable from the negative terminal.
3. Check the terminals and connectors of the steering angle sensor for damage, bend and loose connection (unit side and connector side).
Is the inspection result normal?
YES >> GO TO 2.
NO >> Repair the terminal and connector.
2.CHECK HARNESS FOR OPEN CIRCUIT
1. Disconnect the connector of steering angle sensor.
2. Check the resistance between the steeri ng angle sensor harness connector terminals.
Is the measurement value within the specification?
YES >> GO TO 3.
NO >> Repair the steering angle sensor branch line.
3.CHECK POWER SUPPLY AND GROUND CIRCUIT
Check the power supply and the ground circuit of the steering angle sensor. Refer to BRC-44, "
Wiring Dia-
gram".
Is the inspection result normal?
YES (Present error)>>Replace the steering angle sensor. Refer to BRC-147, "Removal and Installation".
YES (Past error)>>Error was detected in the steering angle sensor branch line.
NO >> Repair the power supply and the ground circuit.
Steering angle sensor harness connector Resistance (Ω)
Connector No. Terminal No.
M64 5 2 Approx. 54 – 66
Revision: August 2015 2016 Versa Note
cardiagn.com
