NISSAN NOTE 2016 Service Repair Manual DLK-312
< REMOVAL AND INSTALLATION >[WITHOUT INTELLIGENT KEY SYSTEM]
STEERING LOCK UNIT
6. Disconnect the harness connector from the key switch.
7. For models with CVT but without intelligent key syst

Page 1002 of 3641

NISSAN NOTE 2016 Service Repair Manual EM-1
ENGINE
C
DE
F
G H
I
J
K L
M
SECTION EM
A
EM
N
O P
CONTENTS
ENGINE MECHANICAL
HR16DE
PRECAUTION ....... ........................................
3
PRECAUTIONS .....................................

EM-1
ENGINE
C
DE
F
G H
I
J
K L
M
SECTION EM
A
EM
N
O P
CONTENTS
ENGINE MECHANICAL
HR16DE
PRECAUTION ....... ........................................
3
PRECAUTIONS .............................................. .....3
Precaution for Supplemental Restraint System
(SRS) "AIR BAG" and "SEAT BELT PRE-TEN-
SIONER" ............................................................. ......
3
Precaution for Procedure without Cowl Top Cover ......3
Draining Engine Coolant ...........................................3
Disconnecting Fuel Piping .........................................3
Removal and Disassembly ........................................3
Inspection, Repair and Replacement ........................4
Assembly and Installation .........................................4
Parts Requiring Angle Tightening ....................... ......4
Precaution for Liquid Gasket .....................................4
PREPARATION ............................................6
PREPARATION .............................................. .....6
Special Service Tools .......................................... ......6
Commercial Service Tools ........................................7
BASIC INSPECTION ...................................10
CAMSHAFT VALVE CLEARANCE ............... ....10
Inspection and Adjustment .................................. ....10
COMPRESSION PRESSURE ............................13
Inspection ............................................................ ....13
SYMPTOM DIAGNOSIS ..............................14
NOISE, VIBRATION AND HARSHNESS
(NVH) TROUBLESHOOTING ........................ ....
14
NVH troubleshooting Chart ................................. ....14
PERIODIC MAINTENANCE .........................16
DRIVE BELT ................................................... ....16
Exploded View .................................................... ....16
Removal and Installation .........................................16
Inspection ............................................................ ....17
Adjustment ...............................................................17
AIR CLEANER FILTER .....................................19
Exploded View .........................................................19
Removal and Installation .........................................19
SPARK PLUG ...................................................21
Exploded View .........................................................21
Removal and Installation .........................................21
REMOVAL AND INSTALLATION ...............24
DRIVE BELT IDLER PULLEY ..........................24
Exploded View ..................................................... ....24
Removal and Installation .........................................24
AIR CLEANER AND AIR DUCT .......................26
Exploded View .........................................................26
Removal and Installation .........................................26
INTAKE MANIFOLD .........................................28
Exploded View .........................................................28
Removal and Installation .........................................28
EXHAUST MANIFOLD ......................................31
Exploded View .........................................................31
Removal and Installation .........................................31
OIL PAN AND OIL STRAINER .........................34
Exploded View .........................................................34
Removal and Installation (Lower Oil Pan) ...............34
Removal and Installation (Upper Oil Pan) ........... ....37
FUEL INJECTOR AND FUEL TUBE ................40
Exploded View .........................................................40
Removal and Installation .........................................40
IGNITION COIL .................................................47
Exploded View .........................................................47
Removal and Installation .........................................47
ROCKER COVER .............................................48
Revision: August 2015 2016 Versa Note

cardiagn.com

Page 1003 of 3641

NISSAN NOTE 2016 Service Repair Manual EM-2
Exploded View ........................................................48
Removal and Installation ........................................48
TIMING CHAIN .......................................

EM-2
Exploded View ........................................................48
Removal and Installation ........................................48
TIMING CHAIN ............................................... ...51
Exploded View ..................................................... ...51
Removal and Installation ........................................51
CAMSHAFT .......................................................60
Exploded View ..................................................... ...60
Removal and Installation ........................................60
Inspection ...............................................................68
OIL SEAL ...........................................................73
VALVE OIL SEAL .................................................. ...73
VALVE OIL SEAL : Removal and Installation .........73
FRONT OIL SEAL .................................................. ...74
FRONT OIL SEAL : Removal and Installation ........74
REAR OIL SEAL .................................................... ...74
REAR OIL SEAL : Removal and Installation ..........74
CYLINDER HEAD ........................................... ...76
Exploded View ..................................................... ...76
Removal and Installation ........................................76
Exploded View ........................................................78
Disassembly and Assembly ....................................78
Inspection ...............................................................80
UNIT REMOVAL AND INSTALLATION .....86
ENGINE ASSEMBLY ...................................... ...86
Exploded View ..................................................... ...86
Removal and Installation ........................................87
UNIT DISASSEMBLY AND ASSEMBLY ...91
ENGINE UNIT ....................................................91
Setting .................................................................. ...91
Disassembly ............................................................92
Assembly ................................................................92
CYLINDER BLOCK ...........................................93
Exploded View ........................................................93
Disassembly and Assembly ....................................94
Inspection ..............................................................102
HOW TO SELECT PISTON AND BEARING ...111
Description ........................................................... .111
Connecting Rod Bearing .......................................111
Main Bearing ........................................................113
SERVICE DATA AND SPECIFICATIONS
(SDS) ........ .................................................
116
SERVICE DATA AND SPECIFICATIONS
(SDS) .............................................................. ..
116
General Specification ........................................... .116
Drive Belt ..............................................................116
Spark Plug ............................................................117
Exhaust Manifold ..................................................117
Camshaft ...............................................................117
Cylinder head ........................................................119
Cylinder Block .......................................................121
Main Bearing .........................................................124
Connecting Rod Bearing .......................................125
Revision: August 2015 2016 Versa Note

cardiagn.com

Page 1004 of 3641

NISSAN NOTE 2016 Service Repair Manual PRECAUTIONSEM-3
< PRECAUTION > [HR16DE]
C
D
E
F
G H
I
J
K L
M A
EM
NP
O
PRECAUTION
PRECAUTIONS
Precaution for Supplemental
Restraint System (SRS) "AIR BAG" and "SEAT BELT
PRE-TENSIONER"
INFOID:00000

PRECAUTIONSEM-3
< PRECAUTION > [HR16DE]
C
D
E
F
G H
I
J
K L
M A
EM
NP
O
PRECAUTION
PRECAUTIONS
Precaution for Supplemental
Restraint System (SRS) "AIR BAG" and "SEAT BELT
PRE-TENSIONER"
INFOID:0000000012431679
The Supplemental Restraint System such as “AIR BAG” and “SEAT BELT PRE-TENSIONER”, used along
with a front seat belt, helps to reduce the risk or severi ty of injury to the driver and front passenger for certain
types of collision. Information necessary to service the system safely is included in the SR and SB section of
this Service Manual.
WARNING:
• To avoid rendering the SRS inoper ative, which could increase the risk of personal injury or death in
the event of a collision which would result in air bag inflation, all maintenance must be performed by
an authorized NISSAN/INFINITI dealer.
• Improper maintenance, including in correct removal and installation of the SRS, can lead to personal
injury caused by unintentional act ivation of the system. For removal of Spiral Cable and Air Bag
Module, see the SR section.
• Do not use electrical test equipm ent on any circuit related to the SRS unless instructed to in this
Service Manual. SRS wiring harnesses can be identi fied by yellow and/or orange harnesses or har-
ness connectors.
PRECAUTIONS WHEN USING POWER TOOLS (AIR OR ELECTRIC) AND HAMMERS
WARNING:
• When working near the Airbag Diagnosis Sensor Un it or other Airbag System sensors with the Igni-
tion ON or engine running, DO NOT use air or el ectric power tools or strike near the sensor(s) with a
hammer. Heavy vibration could activate the sensor( s) and deploy the air bag(s), possibly causing
serious injury.
• When using air or electric power tools or hammers, always switch the Ignition OFF, disconnect the
battery and wait at least three mi nutes before performing any service.
Precaution for Procedure without Cowl Top CoverINFOID:0000000012431680
When performing the procedure after removing cowl top cover, cover
the lower end of windshield with urethane, etc.
Draining Engine CoolantINFOID:0000000012431681
Drain engine coolant and engine oil when the engine is cooled.
Disconnecting Fuel PipingINFOID:0000000012431682
• Before starting work, check no fire or spark producing items are in the work area.
• Release fuel pressure before disconnecting and disassembly.
• After disconnecting pipes, plug openings to stop fuel leakage.
Removal and DisassemblyINFOID:0000000012431683
• When instructed to use SST, use specified tools. Alwa ys be careful to work safely, avoid forceful or unin-
structed operations.
• Use care to avoid damage to mating or sliding surfaces.
PIIB3706J
Revision: August 2015 2016 Versa Note

cardiagn.com

Page 1005 of 3641

NISSAN NOTE 2016 Service Repair Manual EM-4
< PRECAUTION >[HR16DE]
PRECAUTIONS
• Dowel pins are used for several parts alignment. When replacing and reassembling parts with dowel pins,
check that dowel pins are installed in the original

EM-4
< PRECAUTION >[HR16DE]
PRECAUTIONS
• Dowel pins are used for several parts alignment. When replacing and reassembling parts with dowel pins,
check that dowel pins are installed in the original position.
• Cover openings of engine system with a tape or equival ent, if necessary, to seal out foreign materials.
• Mark and arrange disassembly parts in an organi zed way for easy troubleshooting and reassembly.
• When loosening nuts and bolts, start with the one furthest outside, then the one diagonally opposite, and so on. If the order of loosening is specified, do exactl y as specified. Power tools may be used in the step.
Inspection, Repair and ReplacementINFOID:0000000012431684
Before repairing or replacing, thoroughly inspect parts. Inspect new replacement parts in the same way, and
replace if necessary.
Assembly and InstallationINFOID:0000000012431685
• Use torque wrench to tighten bolts or nuts to specification.
• Tighten nuts and bolts in order exactly as specified in the procedure. If a tightening order or procedure is not
specified, tighten nuts and bolts equally in several differ ent steps. Start with the nuts or bolts in the center
and then tighten diagonally starting with the inside and moving to the outside in a spiral pattern.
• Replace with new gasket, packing, oil seal or O-ring.
• Thoroughly wash, clean, and air-blow each part. Carefully check engine oil or engine coolant passages for restrictions and blockages.
• Avoid damaging sliding or mating surfaces. Before assembling, completely remove foreign materials such as cloth lint or dust, and oil the sliding surfaces.
• After refilling engine coolant, bleed the air from the cooling system.
• After repairing, start the engine and increase engine s peed to check for engine coolant leaks, fuel leaks,
engine oil leaks, and exhaust gas leaks.
Parts Requiring Angle TighteningINFOID:0000000012431686
• For the final tightening of the following engine parts use Tool:
- Camshaft sprocket (INT) bolt
- Cylinder head bolts
- Main bearing cap bolts
- Connecting rod cap bolts
- Crankshaft pulley bolt (Note an angle wrench is required as bolt flange is provided with notches for angle tightening)
• Do not use a torque value for final tightening.
• The torque value for these parts are for a preliminary step.
• Ensure thread and seat surfaces are clean and coated with engine oil.
Precaution for Liquid GasketINFOID:0000000012431687
REMOVAL OF LIQUID GASKET SEALING
• After removing the bolts and nuts, separate the mating surface and remove the liquid gasket using Tool (A).
CAUTION:
Be careful not to damage the mating surfaces.
• In areas where the cutter is difficult to use, use a plastic hammer to lightly tap (1) the cutter where the liquid gasket is applied. Use a
plastic hammer to slide (2) the cutter by tapping on the side.
CAUTION:
Do not damage the mating surfaces. Tool number : KV10112100 (BT-8653-A)
Tool Number (A) : KV10111100 (J-37228)
AWBIA1249GB
Revision: August 2015
2016 Versa Note

cardiagn.com

Page 1006 of 3641

NISSAN NOTE 2016 Service Repair Manual PRECAUTIONSEM-5
< PRECAUTION > [HR16DE]
C
D
E
F
G H
I
J
K L
M A
EM
NP
O
1. Using suitable tool (A), remove old liquid gasket adhering to the
liquid gasket application surface and the mating surface.
�

Page 1007 of 3641

NISSAN NOTE 2016 Service Repair Manual EM-6
< PREPARATION >[HR16DE]
PREPARATION
PREPARATION
PREPARATION
Special Service ToolsINFOID:0000000012431688
The actual shape of the tools may differ from those illustrated here.
Tool number
(TechMat

Page 1008 of 3641

NISSAN NOTE 2016 Service Repair Manual PREPARATIONEM-7
< PREPARATION > [HR16DE]
C
D
E
F
G H
I
J
K L
M A
EM
NP
O
Commercial Service ToolsINFOID:0000000012431689
EM03470000
(J-8037)
Piston ring compressor
Installing piston assembly into cyli

Load next 8 pages

Page: < prev 1-10 ... 969-976 977-984 985-992 993-1000 1001-1008 1009-1016 1017-1024 1025-1032 1033-1040 ... 3648 next >

change time fuse box diagram lights tires spare tire rear entertainment
