MWI
POWER SUPPLY AND GROUND CIRCUITMWI-43
< DTC/CIRCUIT DIAGNOSIS > [TYPE A]
C
D
E
F
G H
I
J
K L
M B A
O P
POWER SUPPLY AND GROUND CIRCUIT
COMBINATION METER
COMBINATION METER : Diagnosis ProcedureINFOID:0000000012432574
Regarding Wiring Diagram information, refer to MWI-26, "Wiring Diagram".
1.CHECK FUSE
Check that the following fuses are not blown.
Is the fuse blown?
YES >> Replace the blown fuse after repairing the affected circuit.
NO >> GO TO 2.
2.POWER SUPPLY CIRCUIT CHECK
1. Disconnect combination meter connector.
2. Check voltage between combination meter harness connector M82, terminals 27, 28, 15 and ground.
Is the inspection result normal?
YES >> GO TO 3.
NO >> Repair or replace harness or connector.
3.GROUND CIRCUIT CHECK
1. Turn ignition switch OFF.
2. Disconnect combination meter connector.
3. Check continuity between combination meter harness connector M82, terminals 21, 22, 23 and ground.
Is the inspection result normal?
YES >> Inspection End.
NO >> Repair or replace harness or connector.
BCM (BODY CONTROL MODULE)
Power source Fuse No.
Battery 8
Ignition switch ON or START 3
Ignition switch ACC or ON 18
TerminalsIgnition switch position
(+) (–)OFF ACC ONSTART
Connector Terminal
M82 27
GroundBattery voltage Battery voltage Battery voltage Battery voltage
28 0V0VBattery voltage Battery voltage
15 0V Battery voltage Battery voltage 0V
Te r m i n a l s
Continuity
(+)
(–)
Connector Terminal
M82 21
Ground Yes
22
23
Revision: August 2015 2016 Versa Note
cardiagn.com
Page 2402 of 3641
![NISSAN NOTE 2016 Service Repair Manual MWI-44
< DTC/CIRCUIT DIAGNOSIS >[TYPE A]
POWER SUPPLY AND GROUND CIRCUIT
BCM (BODY CONTROL MODULE) : Diagnosis Procedure
INFOID:0000000012542950
Regarding Wiring Diagram information, refer to BCS-11 NISSAN NOTE 2016 Service Repair Manual MWI-44
< DTC/CIRCUIT DIAGNOSIS >[TYPE A]
POWER SUPPLY AND GROUND CIRCUIT
BCM (BODY CONTROL MODULE) : Diagnosis Procedure
INFOID:0000000012542950
Regarding Wiring Diagram information, refer to BCS-11](/manual-img/5/57363/w960_57363-2401.png)
MWI-44
< DTC/CIRCUIT DIAGNOSIS >[TYPE A]
POWER SUPPLY AND GROUND CIRCUIT
BCM (BODY CONTROL MODULE) : Diagnosis Procedure
INFOID:0000000012542950
Regarding Wiring Diagram information, refer to BCS-117, "Wiring Diagram".
1.CHECK FUSES AND FUSIBLE LINK
Check that the following fuses and fusible link are not blown.
Is the fuse blown?
YES >> Replace the blown fuse or fusible link after repairing the affected circuit.
NO >> GO TO 2.
2.CHECK POWER SUPPLY CIRCUIT
1. Turn ignition switch OFF.
2. Disconnect BCM connectors.
3. Check voltage between BCM connector and ground.
Is the inspection result normal?
YES >> GO TO 3.
NO >> Repair harness or connector.
3.CHECK GROUND CIRCUIT
Check continuity between BCM connector and ground.
Is the inspection result normal?
YES >> Inspection End.
NO >> Repair harness or connector.
Terminal No. Signal nameFuses and fusible link No.
37 Battery power supply 8 (10A)
42 12 (10A)
50 G (40A)
11 Ignition switch ACC or ON 18 (10A)
38 Ignition switch ON or START 2 (10A)
BCMGround Ignition switch position
Connector Terminal
—OFF
ACC ON
M18 11
0 V
Battery voltage
Battery voltage
37
Battery voltage
38 0 V0 V
M19 42
Battery voltage Battery voltage
50
BCM GroundContinuity
Connector Terminal
M19 55—Yes
Revision: August 2015 2016 Versa Note
cardiagn.com
Page 2403 of 3641
![NISSAN NOTE 2016 Service Repair Manual MWI
FUEL LEVEL SENSOR SIGNAL CIRCUITMWI-45
< DTC/CIRCUIT DIAGNOSIS > [TYPE A]
C
D
E
F
G H
I
J
K L
M B A
O P
FUEL LEVEL SENSOR SIGNAL CIRCUIT
DescriptionINFOID:0000000012432576
The fuel level sensor un NISSAN NOTE 2016 Service Repair Manual MWI
FUEL LEVEL SENSOR SIGNAL CIRCUITMWI-45
< DTC/CIRCUIT DIAGNOSIS > [TYPE A]
C
D
E
F
G H
I
J
K L
M B A
O P
FUEL LEVEL SENSOR SIGNAL CIRCUIT
DescriptionINFOID:0000000012432576
The fuel level sensor un](/manual-img/5/57363/w960_57363-2402.png)
MWI
FUEL LEVEL SENSOR SIGNAL CIRCUITMWI-45
< DTC/CIRCUIT DIAGNOSIS > [TYPE A]
C
D
E
F
G H
I
J
K L
M B A
O P
FUEL LEVEL SENSOR SIGNAL CIRCUIT
DescriptionINFOID:0000000012432576
The fuel level sensor unit and fuel pump detects the approx imate fuel level in the fuel tank and transmits the
fuel level signal to the combination meter.
Component Function CheckINFOID:0000000012432577
1.COMBINATION METER INPUT SIGNAL
1. Select METER/M&A on CONSULT.
2. Using FUEL METER of DATA MONITOR, compare the DATA MONITOR value with the fuel gauge posi- tion.
Does monitor value match fuel gauge reading?
YES >> Inspection End.
NO >> Replace combination meter. Refer to MWI-54, "
Removal and Installation".
Diagnosis ProcedureINFOID:0000000012432578
Regarding Wiring Diagram information, refer to MWI-26, "Wiring Diagram".
1.CHECK HARNESS CONNECTOR
1. Turn ignition switch OFF.
2. Check combination meter and fuel level sensor unit terminals (meter-side and harness-side) for poor con- nection.
Is the inspection result normal?
YES >> GO TO 2.
NO >> Repair or replace terminals or connectors.
2.CHECK FUEL LEVEL SENSOR UNIT CIRCUIT
1. Disconnect combination meter harness connector M82 and fuel level sensor unit and fuel pump harness
connector B44.
2. Check continuity between combination meter harness connector M82 terminal 6 and fuel level sensor unit
and fuel pump harness connector B44 terminal 2.
3. Check continuity between fuel level sensor unit and fuel pump harness connector B44 terminal 2 and ground.
Is the inspection result normal?
YES >> GO TO 3.
NO >> Repair harness or connector.
Fuel gauge indication position Reference value of data monitor [L]
1A pp ro x. 3 9.8
3/4 Approx. 31.2
1/2 Approx. 20.8
1/4 Approx. 10.8
0A ppro x. 2 .9
Connector TerminalConnector Terminal Continuity
M82 6B44 2Yes
Connector Terminal
GroundContinuity
B44 2 No
Revision: August 2015 2016 Versa Note
cardiagn.com
Page 2404 of 3641
![NISSAN NOTE 2016 Service Repair Manual MWI-46
< DTC/CIRCUIT DIAGNOSIS >[TYPE A]
FUEL LEVEL SENSOR SIGNAL CIRCUIT
3.CHECK FUEL LEVEL SENSOR GROUND CIRCUIT
1. Disconnect ECM connector F11.
2. Check continuity between combination meter har ne NISSAN NOTE 2016 Service Repair Manual MWI-46
< DTC/CIRCUIT DIAGNOSIS >[TYPE A]
FUEL LEVEL SENSOR SIGNAL CIRCUIT
3.CHECK FUEL LEVEL SENSOR GROUND CIRCUIT
1. Disconnect ECM connector F11.
2. Check continuity between combination meter har ne](/manual-img/5/57363/w960_57363-2403.png)
MWI-46
< DTC/CIRCUIT DIAGNOSIS >[TYPE A]
FUEL LEVEL SENSOR SIGNAL CIRCUIT
3.CHECK FUEL LEVEL SENSOR GROUND CIRCUIT
1. Disconnect ECM connector F11.
2. Check continuity between combination meter har ness connector M82 terminal 24 and fuel level sensor
unit and fuel pump harness connector B44 terminal 5.
3. Check continuity between fuel level sensor unit and fuel pump harness connector B44 terminal 5 and ground.
Is the inspection result normal?
YES >> GO TO 4.
NO >> Repair harness or connector.
4.CHECK INSTALLATION CONDITION
Check fuel level sensor unit installation, and verify t he float arm does not interfere or bind with the internal
components in the fuel tank.
Is the inspection result normal?
YES >> Inspection End.
NO >> Install the fuel level sensor unit properly.
Component InspectionINFOID:0000000012432579
