2016 NISSAN NOTE Service Repair Manual

spare tire location fuel pressure technical data engine overheat jacking points immobilizer

Page 3233 of 3641

NISSAN NOTE 2016 Service Repair Manual ST-12
< REMOVAL AND INSTALLATION >
STEERING SHAFT
STEERING SHAFT
Exploded ViewINFOID:0000000012430504
Removal and InstallationINFOID:0000000012430505
REMOVAL
CAUTION:
Spiral cable may be cut if steeri

Page 3234 of 3641

NISSAN NOTE 2016 Service Repair Manual STEERING SHAFTST-13
< REMOVAL AND INSTALLATION >
C
DE
F
H I
J
K L
M A
B
ST
N
O P
• Before installation, check that steering column tilt is in the middle position.
• For intermediate shaft bolt, a

STEERING SHAFTST-13
< REMOVAL AND INSTALLATION >
C
DE
F
H I
J
K L
M A
B
ST
N
O P
• Before installation, check that steering column tilt is in the middle position.
• For intermediate shaft bolt, and lower joint bolt direction, refer to ST-12, "
Exploded View".
• To install align the steering gear guide protrusion (A) with the
groove of lower joint (1), make sure the bolt is securely seated in
groove (B) of steering gear before final tightening.
CAUTION:
If a guide protrusion is not included, align with the matching
mark placed at the removal step.
• When tightening lower joint bolt to the steering gear lower shaft,
temporarily tighten it and make sure there is no sticking or galling
before final tightening.
• When connecting intermediate shaft upper side (1) and column shaft, make sure the bolt is securely seated in groove (A) of col-
umn shaft before final tightening.
• Perform inspection after installation. Refer to ST-13, "
Inspection".
InspectionINFOID:0000000012430506
INSPECTION AFTER REMOVAL
• Check each part of steering intermediate shaft, lowe r joint, and steering column for damage or other mal-
functions. Replace if there are any abnormal conditions.
INSPECTION AFTER INSTALLATION
• Rotate steering wheel to make sure it is centered and there is no binding, noise or excessive steering effort.
• Make sure that the number of turns are the same from the straight-ahead position to the left and right locks.
• Check each part of steering intermediate shaft, lowe r joint, and steering column for damage or other mal-
functions. Replace if there are any abnormal conditions.
• Check the steering wheel play, neutral position steeri ng wheel, steering wheel turning force, and front wheel
turning angle. Refer to ST-5, "
Inspection".
• Check the neutral position of the steering angle sensor. Refer to BRC-55, "
ADJUSTMENT OF STEERING
ANGLE SENSOR NEUTRAL POSITION : Description".
JPGIA0041ZZ
SGIA1295E
Revision: August 2015 2016 Versa Note

cardiagn.com

Page 3235 of 3641

NISSAN NOTE 2016 Service Repair Manual ST-14
< REMOVAL AND INSTALLATION >
STEERING GEAR AND LINKAGE
STEERING GEAR AND LINKAGE
Exploded ViewINFOID:0000000012430507
Removal and InstallationINFOID:0000000012430508
CAUTION:
• Spiral cable ma

Page 3236 of 3641

NISSAN NOTE 2016 Service Repair Manual STEERING GEAR AND LINKAGEST-15
< REMOVAL AND INSTALLATION >
C
DE
F
H I
J
K L
M A
B
ST
N
O P
INSPECTION AFTER INSTALLATION
• Rotate steering wheel to make sure it is centered and there is no binding,

Page 3237 of 3641

NISSAN NOTE 2016 Service Repair Manual ST-16
< UNIT DISASSEMBLY AND ASSEMBLY >
STEERING GEAR AND LINKAGE
UNIT DISASSEMBLY AND ASSEMBLY
STEERING GEAR AND LINKAGE
Exploded ViewINFOID:0000000012430510
Disassembly and AssemblyINFOID:0000000012

Page 3238 of 3641

NISSAN NOTE 2016 Service Repair Manual STEERING GEAR AND LINKAGEST-17
< UNIT DISASSEMBLY AND ASSEMBLY >
C
DE
F
H I
J
K L
M A
B
ST
N
O P
2. Install large end (1) of boot (2) to gear housing assembly.
3. Install small end (3) of boot (2) to

Page 3239 of 3641

NISSAN NOTE 2016 Service Repair Manual ST-18
< UNIT DISASSEMBLY AND ASSEMBLY >
STEERING GEAR AND LINKAGE
When tightening outer socket lock nut (1), be sure to hold
outer socket (2) using a suitable tool to prevent ball joint
from contacti

Page 3240 of 3641

NISSAN NOTE 2016 Service Repair Manual SERVICE DATA AND SPECIFICATIONS (SDS)ST-19
< SERVICE DATA AND SPECIFICATIONS (SDS)
C
DE
F
H I
J
K L
M A
B
ST
N
O P
SERVICE DATA AND SPECIFICATIONS (SDS)
SERVICE DATA AND SPECIFICATIONS (SDS)
General
