PRECAUTIONSBRC-5
< PRECAUTION > [VDC/TCS/ABS]
C
D
E
G H
I
J
K L
M A
B
BRC
N
O P
Precaution for Brake Control SystemINFOID:0000000012430822
• Just after starting vehicle after ignition switch is ON, brake pedal may vibrate or motor operating noise may be heard from engine compartment. This is a normal condition.
• When an error is indicated by ABS or another warning lamp, collect all necessary information from customer
(what symptoms are present under what conditions) and check for simple causes before starting diagnostic
servicing. Besides electrical system inspection, c heck brake booster operation, brake fluid level and oil
leaks.
• If tire size and type are used in an improper combinati on or brake pads are not Genuine NISSAN parts, stop-
ping distance or steering stability may deteriorate.
• ABS might be out of order or malfunctions by putting a radio (wiring inclusive), an antenna and a lead-in wire
near the control unit.
• If aftermarket parts (car stereo, CD player, etc.) have been installed, check for incidents such as harness pinches, open circuits, and improper wiring.
• VDC system may not operate normally or a VDC OFF indi cator lamp or SLIP indicator lamp may light.
- When replacing the following parts with parts other than genuine parts or making modifications: Suspension- related parts (shock absorber, spring, bushing, etc.), tire s, wheels (other than specified sizes), brake-related
parts (pad, rotor, caliper, etc.), engine-related parts (muffler, ECM, etc.) and body reinforcement-related parts
(roll bar, tower bar, etc.).
- When driving with worn or deteriorated suspension, tires and brake-related parts.
Precaution for Harness RepairINFOID:0000000012430823
• Solder the repair part, and wrap it with tape. [Twisted wire fray
must be 110 mm (4.33 in) or less.]
• Do not bypass the repair point with wire. (If it is bypassed, the turn- out point cannot be separated and the twisted wire characteristics
are lost.)
SKIB8766E
SKIB8767E
Revision: August 2015 2016 Versa Note

cardiagn.com

C1105, C1106, C1107, C1108 WHEEL SENSOR
BRC-63
< DTC/CIRCUIT DIAGNOSIS > [VDC/TCS/ABS]
C
D
E
G H
I
J
K L
M A
B
BRC
N
O P
C1105, C1106, C1107, C1108 WHEEL SENSOR
DTC DescriptionINFOID:0000000012430856
DTC DETECTION LOGIC
POSSIBLE CAUSE
NOTE:
Confirm if DTC is PAST or CRNT. If DTC is CRNT, proceed with Diagnosis Procedure. If DTC is PAST, clear
the DTC. Do not replace the ABS actuator and electric unit (control unit) for a PAST DTC.
DTC CONFIRMATION PROCEDURE
1.PRECONDITIONING
If “DTC CONFIRMATION PROCEDURE” has been previously conducted, always turn the ignition switch OFF
and wait at least 10 seconds before conducting the next test.
>> GO TO 2.
2.CHECK DTC DETECTION
With CONSULT
1. Start the engine.
2. Drive the vehicle at approx. 50 km/h ( 31 MPH) or more for approx. 2 minutes.
3. Stop the vehicle.
4. Turn the ignition switch OFF.
DTC Display Item
(Trouble diagnosis content) Malfunction detected condition
C1105 RR RH SENSOR-2
(Rear RH wheel sensor-2) • When power supply voltage of rear RH wheel sensor is low.
• When distance between rear RH wheel sensor and rear RH wheel sensor rotor is large.
• When installation of rear RH wheel sensor or rear RH wheel sensor rotor is not normal.
• When there is contamination on or damage to the rear RH wheel sensor or rear RH sen-
sor rotor.
C1106 RR LH SENSOR-2
(Rear LH wheel sensor-2) • When power supply voltage of rear LH wheel sensor is low.
• When distance between rear LH wheel sensor and rear LH wheel sensor rotor is large.
• When installation of rear LH wheel sensor or rear LH wheel sensor rotor is not normal.
• When there is contamination on or damage to the rear LH wheel sensor or rear LH sen-
sor rotor.
C1107 FR RH SENSOR-2
(Front RH wheel sensor-2) • When power supply voltage of front RH wheel sensor is low.
• When distance between front RH wheel sensor and front RH wheel sensor rotor is large.
• When installation of front RH wheel sensor or front RH wheel sensor rotor is not normal.
• When there is contamination on or damage to the front RH wheel sensor or front RH sen-
sor rotor.
C1108 FR LH SENSOR-2
(Front LH wheel sensor-2) • When power supply voltage of front LH wheel sensor is low.
• When distance between front LH wheel sensor and front LH wheel sensor rotor is large.
• When installation of front LH wheel sensor or front LH wheel sensor rotor is not normal.
• When there is contamination on or damage to the front LH wheel sensor or front LH sen-
sor rotor.
PAST DTC CRNT DTC
• Harness or connector
• Wheel sensor
• Sensor rotor
• Tire size
• ABS actuator and electric unit (control unit) power supply sys-
tem
•Fuse
• Fusible link
•Battery • Harness or connector
• Wheel sensor
• Sensor rotor
• ABS actuator and electric unit (control unit)
• Tire size
• ABS actuator and electric unit
(control unit) power supply sys-
tem
•Fuse
• Fusible link
•Battery
• Vehicle was not driven after previous repair
Revision: August 2015 2016 Versa Note

cardiagn.com

BRC-64
< DTC/CIRCUIT DIAGNOSIS >[VDC/TCS/ABS]
C1105, C1106, C1107, C1108 WHEEL SENSOR
NOTE:
Wait at least 10 seconds after turning ignition switch OFF.
5. Start the engine.
NOTE:
Wait at least 10 seconds after starting the engine.
6. Perform “Self Diagnostic Result” of “ABS”.
Is DTC
“C1105”, “C1106”, “C1107” or “C1108” detected?
YES-1 >> “C1105”, “C1106”, “C1107” or “C1108” is displayed as “CRNT”: Proceed to BRC-64, "Diagnosis
Procedure".
YES-2 >> “C1105”, “C1106”, “C1107” or “C1108” is disp layed as “PAST”: Inspection End (Erase “Self Diag-
nostic Result” of “ABS”).
NO-1 >> To check malfunction symptom before repair: Refer to GI-42, "
Intermittent Incident".
NO-2 >> Confirmation after repair: Inspection End.
Diagnosis ProcedureINFOID:0000000012430857
CAUTION:
Never check between wheel senso r harness connector terminals.
1.CHECK WHEEL HUB ASSEMBLY
Check that there is no excessive looseness in wheel hub assembly.
• Front: Refer to FA X - 7 , "
Inspection".
• Rear: Refer to RAX-5, "
Inspection".
Is the inspection result normal?
YES >> GO TO 2.
NO >> Repair or replace the wheel hub assembly, and GO TO 2. • Front: Refer to FA X - 9 , "
Removal and Installation".
• Rear: Refer to RAX-6, "
Removal and Installation".
2.CHECK ABS ACTUATOR AND ELECTRIC UNIT (CONTROL UNIT) POWER SUPPLY AND GROUND CIR-
CUIT
Check the ABS actuator and electric unit (contro l unit) power supply and ground circuits. Refer to BRC-121,
"Diagnosis Procedure".
Is the inspection result normal?
YES >> GO TO 3.
NO >> Repair / replace harness, connector, fuse, or fusible link.
3.CHECK TIRE
1. Turn the ignition switch OFF.
2. Check the tire air pressure, wear and size. Refer to WT-54, "
Tire Air Pressure".
Is the inspection result normal?
YES >> GO TO 6.
NO >> Adjust air pressure or replace tire, and GO TO 4.
4.CHECK DATA MONITOR (1)
With CONSULT
1. Erase “Self Diagnostic Result” of “ABS”.
2. Turn the ignition switch OFF → ON → OFF.
NOTE:
Wait at least 10 seconds after turning ignition switch OFF or ON.
3. Start the engine.
4. Select “DATA MONITOR” of “ABS”, check “FR LH SENSOR”, “FR RH SENSOR”, “RR LH SENSOR” and
“RR RH SENSOR”.
NOTE:
Set the “DATA MONITOR” recording speed to “10 msec”.
5. Read the values (wheel speed) of both the norma l wheel sensors and malfunctioning wheel sensor.
NOTE:
Vehicle must be driven after repair or replacement to erase the previous DTCs.
Revision: August 2015 2016 Versa Note

cardiagn.com

C1115 WHEEL SENSORBRC-77
< DTC/CIRCUIT DIAGNOSIS > [VDC/TCS/ABS]
C
D
E
G H
I
J
K L
M A
B
BRC
N
O P
C1115 WHEEL SENSOR
DTC DescriptionINFOID:0000000012430864
DTC DETECTION LOGIC
POSSIBLE CAUSE
NOTE:
Confirm if DTC is PAST or CRNT. If DTC is CRNT, proceed with Diagnosis Procedure. If DTC is PAST, clear
the DTC. Do not replace the ABS actuator and electric unit (control unit) for a PAST DTC.
DTC CONFIRMATION PROCEDURE
1.PRECONDITIONING
If “DTC CONFIRMATION PROCEDURE” has been previously conducted, always turn the ignition switch OFF
and wait at least 10 seconds before conducting the next test.
>> GO TO 2.
2.CHECK DTC DETECTION
With CONSULT
1. Start the engine.
2. Drive the vehicle at approx. 50 km/h ( 31 MPH) or more for approx. 2 minutes.
3. Stop the vehicle.
4. Turn the ignition switch OFF. NOTE:
Wait at least 10 seconds after turning ignition switch OFF.
5. Start the engine.
NOTE:
Wait at least 10 seconds after starting the engine.
6. Perform “Self Diagnostic Result” of “ABS”.
Is DTC
“C 111 5” detected?
YES-1 >> “C1115” is displayed as “CRNT”: Proceed to BRC-77, "Diagnosis Procedure".
YES-2 >> “C1115” is displayed as “PAST”: Inspec tion End (Erase “Self Diagnostic Result” of “ABS”).
NO-1 >> To check malfunction symptom before repair: Refer to GI-42, "
Intermittent Incident".
NO-2 >> Confirmation after repair: Inspection End.
Diagnosis ProcedureINFOID:0000000012430865
CAUTION:
Never check between wheel sensor harness connector terminals.
DTC Display Item
(Trouble diagnosis content) Malfunction detected condition
C 111 5 ABS SENSOR [ABNORMAL
SIGNAL]
(Wheel sensor [abnormal sig-
nal]) When difference in wheel speed between any wheel and others is detected when the ve-
hicle is driven, because of installation of other tires than specified.
PAST DTC
CRNT DTC
• Harness or connector
• Wheel sensor
• Sensor rotor
• ABS actuator and electric unit (control unit) power supply sys-
tem
•Fuse
• Fusible link
•Battery • Harness or connector
• Wheel sensor
• Sensor rotor
• ABS actuator and electric unit (control unit)
• ABS actuator and electric unit
(control unit) power supply sys-
tem
•Fuse
• Fusible link
•Battery
• Tire size
Revision: August 2015 2016 Versa Note

cardiagn.com

BRC-78
< DTC/CIRCUIT DIAGNOSIS >[VDC/TCS/ABS]
C1115 WHEEL SENSOR
1.CHECK TIRE
Check the tire air pressure, wear and size. Refer to WT-54, "
Tire Air Pressure".
Is the inspection result normal?
YES >> GO TO 4.
NO >> Adjust air pressure or replace tire and GO TO 2.
2.CHECK DATA MONITOR (1)
With CONSULT
1. Erase “Self Diagnostic Result” of “ABS”
2. Turn the ignition switch OFF → ON → OFF.
NOTE:
Wait at least 10 seconds after turning ignition switch OFF or ON.
3. Start the engine.
4. Select “DATA MONITOR” of “ABS”, check “FR LH SENSOR”, “FR RH SENSOR”, “RR LH SENSOR” and
“RR RH SENSOR”.
NOTE:
Set the “DATA MONITOR” recording speed to “10 msec”.
5. Read the values (wheel speed) of both the norma l wheel sensors and malfunctioning wheel sensor.
NOTE:
Vehicle must be driven after repair or replacement to erase the previous DTCs.
Note the difference at 50 km/h (31 MPH) between the wheel speed detected by the malfunctioning wheel sen-
sor and the maximum/minimum wheel speed detected by t he normal wheel sensors, is the difference within
5%, respectively?
YES >> GO TO 3.
NO >> GO TO 4.
3.PERFORM SELF-DIAGNOSIS (1)
With CONSULT
1. Stop the vehicle.
2. Turn the ignition switch OFF. NOTE:
Wait at least 10 seconds after turning ignition switch OFF.
3. Start the engine. NOTE:
Wait at least 10 seconds after starting the engine.
4. Perform “Self Diagnostic Result” of “ABS”.
Is DTC
“C1115” detected?
YES >> GO TO 4.
NO >> Inspection End.
4.CHECK ABS ACTUATOR AND ELECTRIC UNIT (CONTROL UNIT) POWER SUPPLY AND GROUND CIR-
CUIT
Check the ABS actuator and electric unit (contro l unit) power supply and ground circuits. Refer to BRC-121,
"Diagnosis Procedure".
Is the inspection result normal?
YES >> GO TO 5.
NO >> Repair / replace harness, connector, fuse, or fusible link.
5.CHECK WHEEL SENSOR AND SENSOR ROTOR
1. Turn the ignition switch OFF.
2. Disconnect wheel sensor harness connector.
3. Remove dust and foreign matter adhered to the wheel sensor and sensor rotor with a vacuum dust collec- tor through the wheel sensor mounting hole.
CAUTION:
Install wheel sensor with no backlash and float, and tighten the mounting bolt to the specified
torque.
• Front: Refer to BRC-140, "
FRONT WHEEL SENSOR : Exploded View".
•Rear: Refer to BRC-141, "
REAR WHEEL SENSOR : Exploded View".
Revision: August 2015 2016 Versa Note

cardiagn.com

OVERHEATING CAUSE ANALYSISCO-7
< SYMPTOM DIAGNOSIS > [HR16DE]
C
D
E
F
G H
I
J
K L
M A
CO
NP
O
Except cool-
ing system
parts mal-
function —
Overload on engine Abusive driving
High engine rpm under no
load
Driving in low gear for ex-
tended time
Driving at extremely high
speed
Power train system mal-
function
—
Installed improper size
wheels and tires
Dragging brakes
Improper ignition timing
Blocked or restricted air
flow Blocked bumper
Installed front bumper fas-
cia cover
—
Blocked radiator grille Mud contamination or paper
clogging
Blocked radiator Blocked air flow
Blocked condenser
Installed large fog lamp
Symptom
Check items
Revision: August 2015 2016 Versa Note

cardiagn.com

SERVICE DATA AND SPECIFICATIONS (SDS)FSU-21
< SERVICE DATA AND SPECIFICATIONS (SDS)
C
DF
G H
I
J
K L
M A
B
FSU
N
O P
Wheelarch Height (Unladen*)INFOID:0000000012430320
Unit: mm (in)
*: Fuel, engine coolant, and lubricants are full. Spare tire, jack, hand tools, and mats are in designated positions. Tire size
185/65R15195/55R16
Front (Hf) 692 (27.24)691 (27.20)
Rear (Hr) 678 (26.69)677 (26.65)
LEIA0085E
Revision: August 2015 2016 Versa Note

cardiagn.com

IDENTIFICATION INFORMATIONGI-37
< VEHICLE INFORMATION >
C
DE
F
G H
I
J
K L
M B
GI
N
O P
Wheels & TiresINFOID:0000000012433182
Conventional Spare
Road wheel/offset mm (in) 15 X 5.5J Steel/40 (1.57)
15 X 5.5J Aluminum/40 (1.57)
16 X 6.0J Aluminum/45 (1.77)
T125/70D15
Tire size P185/65R15
P195/55R16
Revision: August 2015
2016 Versa Note

cardiagn.com
