BCS-68
< DTC/CIRCUIT DIAGNOSIS >[WITH INTELLIGENT KEY SYSTEM]
COMBINATION SWITCH INPUT CIRCUIT
COMBINATION SWITCH INPUT CIRCUIT
Diagnosis ProcedureINFOID:0000000012432354
Regarding Wiring Diagram information, refer to
BCS-52, "Wiring Diagram".
1.CHECK INPUT 1 - 5 CIRCUIT FOR OPEN
1. Turn ignition switch OFF.
2. Disconnect BCM and combination switch connectors.
3. Check continuity between BCM connector and combination switch connector.
Is the inspection result normal?
YES >> GO TO 2.
NO >> Repair harness or connectors.
2.CHECK INPUT 1 - 5 CIRCUIT FOR SHORT
Check for continuity between BCM connector and ground.
Is the inspection result normal?
YES >> GO TO 3.
NO >> Repair harness or connectors.
3.CHECK BCM OUTPUT VOLTAGE
1. Connect BCM connector.
2. Check voltage between BCM connector and ground.
Combination switch signal BCM
Combination switch
Continuity
Connector TerminalConnector Terminal
INPUT 1
M9736
M28 11
Ye s
INPUT 2
359
INPUT 3 347
INPUT 4 3310
INPUT 5 3213
Combination switch
signal BCM
GroundContinuity
Connector Terminal
INPUT 1
M9736
No
INPUT 2
35
INPUT 3 34
INPUT 4 33
INPUT 5 32
Revision: August 2015 2016 Versa Note
cardiagn.com
Page 330 of 3641
BCS
COMBINATION SWITCH INPUT CIRCUITBCS-69
< DTC/CIRCUIT DIAGNOSIS > [WITH INTELLIGENT KEY SYSTEM]
C
D
E
F
G H
I
J
K L
B A
O P
N
Is the inspection result normal?
YES >> Replace combination switch. Refer to
BCS-75, "Removal and Installation".
NO >> Replace BCM. Refer to BCS-74, "
Removal and Installation".
BCM signal Te r m i n a l s
Vo l ta g e
(+)
(− )
BCM
Ground
Connector
Terminal
OUTPUT 1
M9736
Refer to BCS-30, "
Refer-
ence Value".
OUTPUT 2
35
OUTPUT 3 34
OUTPUT 4 33
OUTPUT 5 32
Revision: August 2015 2016 Versa Note
cardiagn.com
Page 331 of 3641
![NISSAN NOTE 2016 Service Repair Manual BCS-70
< DTC/CIRCUIT DIAGNOSIS >[WITH INTELLIGENT KEY SYSTEM]
COMBINATION SWITCH OUTPUT CIRCUIT
COMBINATION SWITCH OUTPUT CIRCUIT
Diagnosis ProcedureINFOID:0000000012432355
Regarding Wiring Diagram in NISSAN NOTE 2016 Service Repair Manual BCS-70
< DTC/CIRCUIT DIAGNOSIS >[WITH INTELLIGENT KEY SYSTEM]
COMBINATION SWITCH OUTPUT CIRCUIT
COMBINATION SWITCH OUTPUT CIRCUIT
Diagnosis ProcedureINFOID:0000000012432355
Regarding Wiring Diagram in](/manual-img/5/57363/w960_57363-330.png)
BCS-70
< DTC/CIRCUIT DIAGNOSIS >[WITH INTELLIGENT KEY SYSTEM]
COMBINATION SWITCH OUTPUT CIRCUIT
COMBINATION SWITCH OUTPUT CIRCUIT
Diagnosis ProcedureINFOID:0000000012432355
Regarding Wiring Diagram information, refer to
BCS-52, "Wiring Diagram".
1.CHECK OUTPUT 1 - 5 CIRCUIT FOR OPEN
1. Turn ignition switch OFF.
2. Disconnect BCM and combination switch connectors.
3. Check continuity between BCM connector and combination switch connector.
Is the inspection result normal?
YES >> GO TO 2.
NO >> Repair harness or connectors.
2.CHECK OUTPUT 1 - 5 CIRCUIT FOR SHORT
Check for continuity between BCM connector and ground.
Is the inspection result normal?
YES >> GO TO 3.
NO >> Repair harness or connectors.
3.CHECK BCM INPUT SIGNAL
1. Connect BCM and combination switch connectors.
2. Turn ON any switch in the system that is malfunctioning.
3. Check voltage between BCM connector and ground.
Combination switch signal BCM
Combination switch
Continuity
Connector TerminalConnector Terminal
OUTPUT 1
M976
M28 12
Ye s
OUTPUT 2
514
OUTPUT 3 45
OUTPUT 4 32
OUTPUT 5 28
Combination switch
signal BCM
GroundContinuity
Connector Terminal
OUTPUT 1
M976
No
OUTPUT 2
5
OUTPUT 3 4
OUTPUT 4 3
OUTPUT 5 2
Revision: August 2015 2016 Versa Note
cardiagn.com
Page 332 of 3641
BCS
COMBINATION SWITCH OUTPUT CIRCUITBCS-71
< DTC/CIRCUIT DIAGNOSIS > [WITH INTELLIGENT KEY SYSTEM]
C
D
E
F
G H
I
J
K L
B A
O P
N
Is the inspection result normal?
Yes >> Replace BCM. Refer to
BCS-74, "Removal and Installation".
No >> Replace combination switch. Refer to BCS-75, "
Removal and Installation".
BCM signal Te r m i n a l s
Voltag e
(+)
(− )
BCM
Ground
Connector
Terminal
INPUT 1
M976
Refer to BCS-30, "
Refer-
ence Value".
INPUT 2
5
INPUT 3 4
INPUT 4 3
INPUT 5 2
Revision: August 2015 2016 Versa Note
cardiagn.com
Page 333 of 3641
![NISSAN NOTE 2016 Service Repair Manual BCS-72
< SYMPTOM DIAGNOSIS >[WITH INTELLIGENT KEY SYSTEM]
COMBINATION SWITCH SYSTEM SYMPTOMS
SYMPTOM DIAGNOSIS
COMBINATION SWITCH SYSTEM SYMPTOMS
Symptom TableINFOID:0000000012432356
1. Perform the da NISSAN NOTE 2016 Service Repair Manual BCS-72
< SYMPTOM DIAGNOSIS >[WITH INTELLIGENT KEY SYSTEM]
COMBINATION SWITCH SYSTEM SYMPTOMS
SYMPTOM DIAGNOSIS
COMBINATION SWITCH SYSTEM SYMPTOMS
Symptom TableINFOID:0000000012432356
1. Perform the da](/manual-img/5/57363/w960_57363-332.png)
BCS-72
< SYMPTOM DIAGNOSIS >[WITH INTELLIGENT KEY SYSTEM]
COMBINATION SWITCH SYSTEM SYMPTOMS
SYMPTOM DIAGNOSIS
COMBINATION SWITCH SYSTEM SYMPTOMS
Symptom TableINFOID:0000000012432356
1. Perform the data monitor of CONSULT
to check for any malfunctioning item.
2. Check the malfunction combinations.
Malfunction item: ×
3. Identify the malfunctioning part from the agreed combination and repair or replace the part.
Malfunction combination Data monitor item
FR WIPER HI
FR WIPER LOW
FR WASHER SW FR WIPER INTINT VOLUME
RR WIPER ON
RR WIPER INT
RR WASHER SW TURN SIGNAL RTURN SIGNAL L TAIL LAMP SW HI BEAM SW
HEAD LAMP SW 1
HEAD LAMP SW 2 PASSING SWFR FOG SW
A ×× ××
B ×× ××
C ×× ××
D ×××
E ×× ×
F ×× ×
G ××××
H ××
I ××××
J × ×××
K All Items
L If only one item is detected or the item is not applicable to the combinations A to K
Malfunction
combination Malfunctioning part
Repair or replace
A Combination switch INPUT 1 circuit
Inspect the combination switch input circuit applicable to the malfunctioning
part. Refer to BCS-68, "
Diagnosis Procedure".
B Combination switch INPUT 2 circuit
C Combination switch INPUT 3 circuit
D Combination switch INPUT 4 circuit E Combination switch INPUT 5 circuitF Combination switch OUTPUT 1 circuit
Inspect the combination switch output circuit applicable to the malfunction-
ing part. Refer to BCS-70, "
Diagnosis Procedure".
G Combination switch OUTPUT 2 circuit
H Combination switch OUTPUT 3 circuit I Combination switch OUTPUT 4 circuit
J Combination switch OUTPUT 5 circuit
K BCM Replace BCM. Refer to BCS-74, "
Removal and Installation".
L Combination switch Replace the combination switch. Refer to
BCS-75, "
Removal and Installa-
tion".
Revision: August 2015 2016 Versa Note
cardiagn.com
Page 334 of 3641
![NISSAN NOTE 2016 Service Repair Manual BCS
NORMAL OPERATING CONDITIONBCS-73
< SYMPTOM DIAGNOSIS > [WITH INTELLIGENT KEY SYSTEM]
C
D
E
F
G H
I
J
K L
B A
O P
N
NORMAL OPERATING CONDITION
DescriptionINFOID:0000000012432357
SHIPPING MODE
• S NISSAN NOTE 2016 Service Repair Manual BCS
NORMAL OPERATING CONDITIONBCS-73
< SYMPTOM DIAGNOSIS > [WITH INTELLIGENT KEY SYSTEM]
C
D
E
F
G H
I
J
K L
B A
O P
N
NORMAL OPERATING CONDITION
DescriptionINFOID:0000000012432357
SHIPPING MODE
• S](/manual-img/5/57363/w960_57363-333.png)
BCS
NORMAL OPERATING CONDITIONBCS-73
< SYMPTOM DIAGNOSIS > [WITH INTELLIGENT KEY SYSTEM]
C
D
E
F
G H
I
J
K L
B A
O P
N
NORMAL OPERATING CONDITION
DescriptionINFOID:0000000012432357
SHIPPING MODE
• Shipping mode inhibits battery power consumption during transportation or storage of the vehicle. Vehicle is
set to shipping mode before being shipped from the factory.
• When ignition switch is OFF, BCM operates shipping mode.
• BCM control function is limited in shipping mode. Re mote keyless entry function does not operate in ship-
ping mode.
• For shipping mode cancel operation, refer to BCS-61, "
Work Procedure".
NOTE:
Do not cancel shipping mode during storage of the v ehicle. Shipping mode should not be canceled until just
prior to customer delivery.
TRANSIT MODE
• BCM is in transit mode if turn signal indicators in combination meter illuminate for 1 minute when ignition
switch is turned from OFF to ON.
• In this case, cancel operation must be performed.
• For transit mode cancel operation, refer to BCS-62, "
Work Procedure".
NOTE:
Do not cancel transit mode during storage of the vehicl e. Transit mode should not be canceled until just prior
to customer delivery.
Revision: August 2015 2016 Versa Note
cardiagn.com
Page 335 of 3641
![NISSAN NOTE 2016 Service Repair Manual BCS-74
< REMOVAL AND INSTALLATION >[WITH INTELLIGENT KEY SYSTEM]
BCM (BODY CONTROL MODULE)
REMOVAL AND INSTALLATION
BCM (BODY CONTROL MODULE)
Removal and InstallationINFOID:0000000012432358
REMOVAL
CA NISSAN NOTE 2016 Service Repair Manual BCS-74
< REMOVAL AND INSTALLATION >[WITH INTELLIGENT KEY SYSTEM]
BCM (BODY CONTROL MODULE)
REMOVAL AND INSTALLATION
BCM (BODY CONTROL MODULE)
Removal and InstallationINFOID:0000000012432358
REMOVAL
CA](/manual-img/5/57363/w960_57363-334.png)
BCS-74
< REMOVAL AND INSTALLATION >[WITH INTELLIGENT KEY SYSTEM]
BCM (BODY CONTROL MODULE)
REMOVAL AND INSTALLATION
BCM (BODY CONTROL MODULE)
Removal and InstallationINFOID:0000000012432358
REMOVAL
CAUTION:
Before replacing BCM, perform “READ CONFIGURATI
ON” to save or print current vehicle specifica-
tion. Refer to BCS-59, "
Description".
1. Disconnect negative and positive battery terminals, then wait at least three minutes. Refer to PG-70,
"Removal and Installation (Battery)".
2. Remove instrument lower panel LH. Refer to IP-24, "
Removal and Installation".
3. Remove screws (A) and remove the BCM (1) from the steering member and position aside.
: Front
4. Disconnect the harness connectors from the BCM.
5. Remove relays from relay bracket.
6. Remove relay bracket from BCM to transfer to new BCM.
INSTALLATION
Installation is in the reverse order of removal.
CAUTION:
• Perform “CONFIGURATION (BCM)” when replacing BCM. Refer to BCS-59, "
Description".
• Make sure to perform the system initialization (NATS) (if equipped) when replacing BCM. Refer to
BCS-58, "
Description".
• When replacing BCM, if new BCM does not come wi th keyfobs attached, all existing keyfobs must be
re-registered.
• For initialization and registration of Intelligent Key, refer to CONSULT Immobilizer mode and fol- lowthe on-screen instructions.
ALMIA0656ZZ
Revision: August 2015 2016 Versa Note
cardiagn.com
Page 336 of 3641
![NISSAN NOTE 2016 Service Repair Manual BCS
COMBINATION SWITCHBCS-75
< REMOVAL AND INSTALLATION > [WITH INTELLIGENT KEY SYSTEM]
C
D
E
F
G H
I
J
K L
B A
O P
N
COMBINATION SWITCH
Removal and InstallationINFOID:0000000012432359
CAUTION:
• Be NISSAN NOTE 2016 Service Repair Manual BCS
COMBINATION SWITCHBCS-75
< REMOVAL AND INSTALLATION > [WITH INTELLIGENT KEY SYSTEM]
C
D
E
F
G H
I
J
K L
B A
O P
N
COMBINATION SWITCH
Removal and InstallationINFOID:0000000012432359
CAUTION:
• Be](/manual-img/5/57363/w960_57363-335.png)
BCS
COMBINATION SWITCHBCS-75
< REMOVAL AND INSTALLATION > [WITH INTELLIGENT KEY SYSTEM]
C
D
E
F
G H
I
J
K L
B A
O P
N
COMBINATION SWITCH
Removal and InstallationINFOID:0000000012432359
CAUTION:
• Before servicing, turn the ignition
switch OFF, disconnect both battery terminals and wait at least
three minutes.
• Do not use air or electric tools when remo ving or installing the combination switch.
REMOVAL
1. Disconnect the negative and positive bat tery terminals, then wait at least three minutes. Refer to PG-70,
"Removal and Installation (Battery)".
2. Remove the steering column covers. Refer to IP-17, "
Removal and Installation".
3. Rotate steering wheel clockwise to access first combination switch screw (A) and remove.
4. Rotate steering wheel counter-clockwise to access second com- bination switch screw (A) and remove.
5. Disconnect the harness connector (B) from the combination switch (1) and remove.
INSTALLATION
Installation is in the reverse order of removal.
CAUTION:
• After the work is completed, make sure no system malfunction is detected by air bag warning lamp.
• In case a malfunction is detected by the air bag wa rning lamp, reset with the self-diagnosis function
and delete the memory with CONSULT.
• If a malfunction is still detected after the above operation, perform self-diagnosis to repair malfunc-
tions. Refer to BCS-58, "
Description".
ALMIA0648ZZ
ALMIA0649ZZ
Revision: August 2015 2016 Versa Note
cardiagn.com
