Page 801 of 3641

NISSAN NOTE 2016 Service Repair Manual DLK-112
< SYMPTOM DIAGNOSIS >[WITH INTELLIGENT KEY SYSTEM]
DOOR DOES NOT LOCK/UNLOCK WITH DOOR LOCK AND UNLOCK SWITCH
SYMPTOM DIAGNOSIS
DOOR DOES NOT LOCK/UNLOCK WI
TH DOOR LOCK AND UNLOCK
SWITCH
ALL

Page 802 of 3641

NISSAN NOTE 2016 Service Repair Manual DOOR DOES NOT LOCK/UNLOCK WITH DOOR LOCK AND UNLOCK SWITCH
DLK-113
< SYMPTOM DIAGNOSIS > [WITH INTELLIGENT KEY SYSTEM]
C
D
E
F
G H
I
J
L
M A
B
DLK
N
O P
PASSENGER SIDE : DescriptionINFOID:000000001243

Page 803 of 3641

NISSAN NOTE 2016 Service Repair Manual DLK-114
< SYMPTOM DIAGNOSIS >[WITH INTELLIGENT KEY SYSTEM]
DOOR DOES NOT LOCK/UNLOCK WITH DOOR LOCK AND UNLOCK SWITCH
2. Confirm the operation after replacement.
Is the result normal?
YES >> Inspectio

Page 804 of 3641

NISSAN NOTE 2016 Service Repair Manual DOOR DOES NOT LOCK/UNLOCK WITH DRIVER SIDE DOOR LOCK KNOB OR
DOOR KEY CYLINDER
DLK-115
< SYMPTOM DIAGNOSIS > [WITH INTELLIGENT KEY SYSTEM]
C
D
E
F
G H
I
J
L
M A
B
DLK
N
O P
DOOR DOES NOT LOCK/UNLOCK

Page 805 of 3641

NISSAN NOTE 2016 Service Repair Manual DLK-116
< SYMPTOM DIAGNOSIS >[WITH INTELLIGENT KEY SYSTEM]
DOOR DOES NOT LOCK/UNLOCK WITH DOOR REQUEST SWITCH
DOOR DOES NOT LOCK/UNLOCK
WITH DOOR REQUEST SWITCH
ALL DOOR REQUEST SWITCHES
ALL DOOR REQ

DLK-116
< SYMPTOM DIAGNOSIS >[WITH INTELLIGENT KEY SYSTEM]
DOOR DOES NOT LOCK/UNLOCK WITH DOOR REQUEST SWITCH
DOOR DOES NOT LOCK/UNLOCK
WITH DOOR REQUEST SWITCH
ALL DOOR REQUEST SWITCHES
ALL DOOR REQUEST SWITCHES : DescriptionINFOID:0000000012430062
All doors do not lock/unlock using all door request switches.
ALL DOOR REQUEST SWITCHES : Diagnosis ProcedureINFOID:0000000012430063
1.CHECK REMOTE KEYLESS ENTRY FUNCTION
Check remote keyless entry function.
Does door lock/unlock with Intelligent Key button?
YES >> GO TO 2.
NO >> Refer to DLK-22, "
INTELLIGENT KEY SYSTEM : System Description".
2.CHECK LOCK/UNLOCK BY I-KEY SETTING IN WORK SUPPORT
1. Select “INTELLIGENT KEY” of “BCM” using CONSULT.
2. Select “LOCK/UNLOCK BY I-KEY” in “Work support”.
3. Check “LOCK/UNLOCK BY I-KEY” setting in “Work support”.
Refer to BCS-22, "
INTELLIGENT KEY : CONSULT Func tion (BCM - INTELLIGENT KEY)".
Is the inspection result normal?
YES >> GO TO 3.
NO >> Set “ON” in “LOCK/UNLOCK BY I-KEY”.
3.CHECK DOOR SWITCH
Check door switch.
Refer to DLK-98, "
ComponentFunctionCheck".
Is the inspection result normal?
YES >> GO TO 4.
NO >> Repair or replace the malfunctioning parts.
4.CHECK INSIDE KEY ANTENNA
Check inside key antenna.
• Instrument center: Refer to DLK-65, "
DTC Logic".
• Console: Refer to DLK-67, "
DTC Logic".
• Trunk room: Refer to DLK-69, "
DTC Logic".
Is the inspection result normal?
YES >> GO TO 5.
NO >> Repair or replace the malfunctioning parts.
5.CHECK OUTSIDE KEY ANTENNA
Check outside key antenna.
• LH side: Refer to DLK-73, "
DTC Logic".
• RH side: Refer to DLK-71, "
DTC Logic".
• Rear bumper: Refer to DLK-75, "
DTC Logic".
Is the inspection result normal?
YES >> GO TO 6.
NO >> Repair or replace the malfunctioning parts.
6.REPLACE BCM
1. Replace BCM. Refer to BCS-74, "
Removal and Installation".
2. Confirm the operation after replacement.
Is the result normal?
YES >> Inspection End.
NO >> Check intermittent incident. Refer to GI-42, "
Intermittent Incident".
DRIVER SIDE DOOR REQUEST SWITCH
Revision: August 2015 2016 Versa Note

cardiagn.com

Page 806 of 3641

NISSAN NOTE 2016 Service Repair Manual DOOR DOES NOT LOCK/UNLOCK WITH DOOR REQUEST SWITCH
DLK-117
< SYMPTOM DIAGNOSIS > [WITH INTELLIGENT KEY SYSTEM]
C
D
E
F
G H
I
J
L
M A
B
DLK
N
O P
DRIVER SIDE DOOR REQU EST SWITCH : DescriptionINFOID:00

Page 807 of 3641

NISSAN NOTE 2016 Service Repair Manual DLK-118
< SYMPTOM DIAGNOSIS >[WITH INTELLIGENT KEY SYSTEM]
DOOR DOES NOT LOCK/UNLOCK WITH INTELLIGENT KEY
DOOR DOES NOT LOCK/UNLOC
K WITH INTELLIGENT KEY
Diagnosis ProcedureINFOID:0000000012430068
1.C

Page 808 of 3641

NISSAN NOTE 2016 Service Repair Manual IGNITION POSITION WARNING FUNCTION DOES NOT OPERATE
DLK-119
< SYMPTOM DIAGNOSIS > [WITH INTELLIGENT KEY SYSTEM]
C
D
E
F
G H
I
J
L
M A
B
DLK
N
O P
IGNITION POSITION WARNING FUNCTION DOES NOT OPERATE
D
