Page 1153 of 3641

NISSAN NOTE 2016 Service Repair Manual EC-26
< SYSTEM DESCRIPTION >[HR16DE]
COMPONENT PARTS
BATTERY TEMPERATURE SENSOR
Battery temperature sensor is int
egrated in battery current sensor.
The sensor measures temperature around the battery.

EC-26
< SYSTEM DESCRIPTION >[HR16DE]
COMPONENT PARTS
BATTERY TEMPERATURE SENSOR
Battery temperature sensor is int
egrated in battery current sensor.
The sensor measures temperature around the battery.
The electrical resistance of the t hermistor decreases as temperature
increases.

*: These data are reference values and are measured between battery temperature
sensor signal terminal and sensor ground.
Malfunction Indicator Lamp (MIL)INFOID:0000000012431296
The MIL is located on the combination meter.
The MIL will illuminate when the ignition switch is turned ON without
the engine running. This is a bulb check.
When the engine is started, the MIL should turn OFF. If MIL remains
ON or continues blinking, the on board diagnostic system detects a
DTC(s) that affects exhaust gas.
For details, refer to EC-57, "
DIAGNOSIS DESCRIPTION : Malfunc-
tion Indicator Lamp (MIL)".
Mass Air Flow SensorINFOID:0000000012431297
The mass air flow sensor (1) is placed in the stream of intake air. It
measures the intake flow rate by measuring a part of the entire
intake flow. The mass air flow sensor controls the temperature of the
hot wire to a certain amount. The heat generated by the hot wire is
reduced as the intake air flows around it. The more air, the greater
the heat loss.
Therefore, the electric current supplied to hot wire is changed to
maintain the temperature of the hot wire as air flow increases. The
ECM detects the air flow by means of this current change.
Oil Pressure Warning LampINFOID:0000000012431298
Oil pressure warning lamp is located on the combination meter.
It indicates the low pressure of the engine oil and the malfunction of
the engine oil pressure system.
Combination meter turns the oil pressure warning lamp ON/OFF
according to the oil pressure warning lamp signal received from
ECM via CAN communication.
For details, refer to EC-43, "
ENGINE PROTECTION CONTROL AT
LOW ENGINE OIL PRESSURE : System Description".
Temperature [°C ( °F)]
Vo l ta g e* (V) Resistance (k
Ω)
25 (77) 3.3331.9 - 2.1
90 (194) 0.9690.222 - 0.258
SEF012P
SAT652J
PBIA9559J
PBIA8559J
Revision: August 2015 2016 Versa Note

cardiagn.com

Page 1154 of 3641

NISSAN NOTE 2016 Service Repair Manual COMPONENT PARTSEC-27
< SYSTEM DESCRIPTION > [HR16DE]
C
D
E
F
G H
I
J
K L
M A
EC
NP
O
Refrigerant Pressure SensorINFOID:0000000012431299
The refrigerant pressure sensor is installed at the c
ondenser o

COMPONENT PARTSEC-27
< SYSTEM DESCRIPTION > [HR16DE]
C
D
E
F
G H
I
J
K L
M A
EC
NP
O
Refrigerant Pressure SensorINFOID:0000000012431299
The refrigerant pressure sensor is installed at the c
ondenser of the air conditioner system. The sensor uses an
electrostatic volume pressure transducer to convert refrigerant pressure to voltage. The voltage signal is sent
to ECM, and ECM controls cooling fan system.
Stop Lamp Switch & ASCD Brake SwitchINFOID:0000000012431300
Stop lamp switch and ASCD brake switch are installed to brake pedal bracket.
ECM detects the state of the brake pedal by those two types of input (ON/OFF signal).
Throttle Control MotorINFOID:0000000012431301
The throttle control motor is operated by the ECM and it opens and closes the throttle valve.
The current opening angle of the throttle valve is detected by the throttle position sensor and it provides feed-
back to the ECM to control the throttle valve in response to driving conditions via the throttle control motor.
Throttle Control Motor RelayINFOID:0000000012431302
Power supply for the throttle control motor is provided to the ECM via throttle control motor relay. The throttle
control motor relay is ON/OFF controlled by the ECM. When the ignition switch is turned ON, the ECM sends
an ON signal to throttle control motor relay and batte ry voltage is provided to the ECM. When the ignition
switch is turned OFF, the ECM sends an OFF signal to throttle control motor relay and battery voltage is not
provided to the ECM.
Throttle Position SensorINFOID:0000000012431303
Electric throttle control actuator consists of throttle control motor,
throttle position sensor, etc. The throttle position sensor responds to
the throttle valve movement.
The throttle position sensor has two sensors. These sensors are a
kind of potentiometer which transform the throttle valve position into
output voltage, and emit the voltage signals to the ECM. The ECM
judges the current opening angle of the throttle valve from these sig-
nals and controls the throttle valve in response to driving conditions
via the throttle control motor.
ASCD Steering SwitchINFOID:0000000012431304
ASCD steering switch has variant values of electrical resistance for each button. ECM reads voltage variation
of switch, and determines which button is operated.
PBIB2657E
Brake pedal ASCD brake switch Stop lamp switch
Released ONOFF
Depressed OFFON
PBIB0145E
Revision: August 2015 2016 Versa Note

cardiagn.com

Page 1155 of 3641

NISSAN NOTE 2016 Service Repair Manual EC-28
< SYSTEM DESCRIPTION >[HR16DE]
STRUCTURE AND OPERATION
STRUCTURE AND OPERATION
Positive Crankcase VentilationINFOID:0000000012431305
This system returns blow-by gas to the intake manifold.
The p

Page 1156 of 3641

NISSAN NOTE 2016 Service Repair Manual STRUCTURE AND OPERATIONEC-29
< SYSTEM DESCRIPTION > [HR16DE]
C
D
E
F
G H
I
J
K L
M A
EC
NP
O
On Board Refueling Vapor Recovery (ORVR)INFOID:0000000012431306
From the beginning of refueling, the air an

Page 1157 of 3641

NISSAN NOTE 2016 Service Repair Manual EC-30
< SYSTEM DESCRIPTION >[HR16DE]
SYSTEM
SYSTEM
ENGINE CONTROL SYSTEM
ENGINE CONTROL SYSTEM : System DiagramINFOID:0000000012431307
JPBIA5483GB
Revision: August 2015
2016 Versa Note

cardiagn.com

Page 1158 of 3641

NISSAN NOTE 2016 Service Repair Manual SYSTEMEC-31
< SYSTEM DESCRIPTION > [HR16DE]
C
D
E
F
G H
I
J
K L
M A
EC
NP
O
ENGINE CONTROL SYSTEM : System DescriptionINFOID:0000000012431308
ECM performs various controls such as fuel
injection cont

Page 1159 of 3641

NISSAN NOTE 2016 Service Repair Manual EC-32
< SYSTEM DESCRIPTION >[HR16DE]
SYSTEM
MULTIPORT FUEL INJECTION SYSTEM : System Diagram
INFOID:0000000012431309
MULTIPORT FUEL INJECTION SY STEM : System DescriptionINFOID:0000000012431310
INPUT/

Page 1160 of 3641

NISSAN NOTE 2016 Service Repair Manual SYSTEMEC-33
< SYSTEM DESCRIPTION > [HR16DE]
C
D
E
F
G H
I
J
K L
M A
EC
NP
O
*1: M/T models
*2: CVT models
*3: This sensor is not used to contro
l the engine system under normal conditions.
*4: ECM det

SYSTEMEC-33
< SYSTEM DESCRIPTION > [HR16DE]
C
D
E
F
G H
I
J
K L
M A
EC
NP
O
*1: M/T models
*2: CVT models
*3: This sensor is not used to contro
l the engine system under normal conditions.
*4: ECM determines the start signal status by the signals of engine speed and battery voltage.
*5: This signal is sent to the ECM through CAN communication line.
SYSTEM DESCRIPTION
The amount of fuel injected from the fuel injector is determined by the ECM. The ECM controls the length of
time the valve remains open (injection pulse duration). T he amount of fuel injected is a program value in the
ECM memory. The program value is preset by engine operating conditions. These conditions are determined
by input signals (for engine speed and intake air) from the crankshaft position sensor, camshaft position sen-
sor and the mass air flow sensor.
VARIOUS FUEL INJECTION INCREASE/DECREASE COMPENSATION
In addition, the amount of fuel injected is compensated to improve engine performance under various operat-
ing conditions as listed below.

• During warm-up
• When starting the engine
• During acceleration
• Hot-engine operation
• When selector lever position is changed from N to D (CVT models)
• High-load, high-speed operation
• During deceleration
• During high engine speed operation
Sensor Input signal to ECM ECM functionActuator
Crankshaft position sensor (POS) Engine speed
*4
Piston position
Fuel injection & mixture
ratio controlFuel injector
Camshaft position sensor (PHASE)
Mass air flow sensor
Amount of intake air
Intake air temperature sensor Intake air temperature
Engine coolant temperature sensor Engine coolant temperature
Air fuel ratio (A/F) sensor 1 Density of oxygen in exhaust gas
Throttle position sensor Throttle position
Accelerator pedal position sensor Accelerator pedal position
Park/neutral position (PNP) switch
*1
PNP signal
Transmission range switch*2
Battery Battery voltage*4
Knock sensor Engine knocking condition
Heated oxygen sensor 2
*3Density of oxygen in exhaust gas
EPS control unit EPS operation signal
*5
Combination meter
Vehicle speed*5
BCMA/C ON signal*5
Blower fan signal*5
Revision: August 2015
2016 Versa Note

cardiagn.com
