Page 225 of 3641
![NISSAN NOTE 2016 Service Repair Manual AV-220
< DTC/CIRCUIT DIAGNOSIS >[NAVIGATION]
REAR DOOR SPEAKER
REAR DOOR SPEAKER
Diagnosis ProcedureINFOID:0000000012433087
Regarding Wiring Diagram information, refer to
AV-155, "Wiring Diagram".
1. NISSAN NOTE 2016 Service Repair Manual AV-220
< DTC/CIRCUIT DIAGNOSIS >[NAVIGATION]
REAR DOOR SPEAKER
REAR DOOR SPEAKER
Diagnosis ProcedureINFOID:0000000012433087
Regarding Wiring Diagram information, refer to
AV-155, "Wiring Diagram".
1.](/manual-img/5/57363/w960_57363-224.png)
AV-220
< DTC/CIRCUIT DIAGNOSIS >[NAVIGATION]
REAR DOOR SPEAKER
REAR DOOR SPEAKER
Diagnosis ProcedureINFOID:0000000012433087
Regarding Wiring Diagram information, refer to
AV-155, "Wiring Diagram".
1.CONNECTOR CHECK
Check the AV control unit and speaker connectors for the following:
• Proper connection
• Damage
• Disconnected or loose terminals
Is the inspection result normal?
YES >> GO TO 2.
NO >> Repair the terminals or connectors.
2.CHECK REAR DOOR SPEAKER SIGNAL CIRCUIT CONTINUITY
1. Disconnect AV control unit connector M70 and suspect rear door speaker connector.
2. Check continuity between AV control unit connec tor M70 and suspect rear door speaker connector.
3. Check continuity between AV control unit connector M70 and ground.
Is the inspection result normal?
YES >> GO TO 3.
NO >> Repair or replace harness or connectors.
3.CHECK REAR DOOR SPEAKER SIGNAL
1. Connect AV control unit connector M70 and suspect rear door speaker connector.
2. Turn ignition switch to ACC.
3. Push AV control unit POWER switch.
4. Check signal between the terminals of AV control unit connector M70.
AV control unit Rear door speaker
Continuity
Connector TerminalConnector Terminal
M70 4
D207 (LH) 1
Ye s
52
13 D307 (RH) 1
14 2
AV control unit
GroundContinuity
Connector Terminal
M70 4
—N o
5
13
14
AV control unit connector M70 ConditionReference value
(+) (− )
Terminal Terminal
Revision: August 2015 2016 Versa Note
cardiagn.com
Page 226 of 3641
AV
REAR DOOR SPEAKERAV-221
< DTC/CIRCUIT DIAGNOSIS > [NAVIGATION]
C
D
E
F
G H
I
J
K L
M B A
O PIs the inspection result normal?
YES >> Replace rear door speaker. Refer to AV-244, "Removal and Installation".
NO >> Replace AV control unit. Refer to AV-241, "
Removal and Installation".
45
Audio signal output
13 14
SKIB3609E
Revision: August 2015 2016 Versa Note
cardiagn.com
Page 227 of 3641
![NISSAN NOTE 2016 Service Repair Manual AV-222
< DTC/CIRCUIT DIAGNOSIS >[NAVIGATION]
MICROPHONE SIGNAL CIRCUIT
MICROPHONE SIGNAL CIRCUIT
Diagnosis ProcedureINFOID:0000000012433088
Regarding Wiring Diagram information, refer to
AV-155, "Wir NISSAN NOTE 2016 Service Repair Manual AV-222
< DTC/CIRCUIT DIAGNOSIS >[NAVIGATION]
MICROPHONE SIGNAL CIRCUIT
MICROPHONE SIGNAL CIRCUIT
Diagnosis ProcedureINFOID:0000000012433088
Regarding Wiring Diagram information, refer to
AV-155, "Wir](/manual-img/5/57363/w960_57363-226.png)
AV-222
< DTC/CIRCUIT DIAGNOSIS >[NAVIGATION]
MICROPHONE SIGNAL CIRCUIT
MICROPHONE SIGNAL CIRCUIT
Diagnosis ProcedureINFOID:0000000012433088
Regarding Wiring Diagram information, refer to
AV-155, "Wiring Diagram".
1.CHECK MICROPHONE SIGNAL CIRCUIT CONTINUITY
1. Turn ignition switch OFF.
2. Disconnect AV control unit connector M71 and microphone connector R15.
3. Check continuity between AV control unit connector M71 and microphone connector R15.
4. Check continuity between AV control unit connector M71 and ground.
Is inspection result normal?
YES >> GO TO 2.
NO >> Repair or replace harness or connectors.
2.CHECK MICROPHONE VCC VOLTAGE
1. Connect AV control unit connector M71.
2. Turn ignition switch ON.
3. Check voltage between terminals of AV control unit connector M71.
Is the inspection result normal?
YES >> GO TO 3.
NO >> Replace AV control unit. Refer to AV-241, "
Removal and Installation".
3.CHECK MICROPHONE SIGNAL
1. Connect microphone connector.
2. Check signal between terminals of AV control unit connector M71.
AV control unit Microphone
Continuity
Connector TerminalConnector Terminal
M71 41
R15 2
Ye s
42 4
43 1
AV control unit
Ground Continuity
Connector Terminal
M71 42
—N o
43
AV control unit connector M71
Voltag e
(Approx.)
(+)
(− )
Te r m i n a l Te r m i n a l
42 415.0 V
Revision: August 2015 2016 Versa Note
cardiagn.com
Page 228 of 3641
AV
MICROPHONE SIGNAL CIRCUITAV-223
< DTC/CIRCUIT DIAGNOSIS > [NAVIGATION]
C
D
E
F
G H
I
J
K L
M B A
O P
Is the inspection result normal?
YES >> Replace AV control unit. Refer to AV-241, "Removal and Installation".
NO >> Replace microphone. Refer to AV-248, "
Removal and Installation".
AV control unit connector M71
ConditionReference value
(+) (− )
Terminal Terminal
43 41Speak into microphone.
SKIB3609E
Revision: August 2015 2016 Versa Note
cardiagn.com
Page 229 of 3641
![NISSAN NOTE 2016 Service Repair Manual AV-224
< DTC/CIRCUIT DIAGNOSIS >[NAVIGATION]
STEERING SWITCH
STEERING SWITCH
Diagnosis ProcedureINFOID:0000000012433089
Regarding Wiring Diagram information, refer to
AV-155, "Wiring Diagram".
1.CHEC NISSAN NOTE 2016 Service Repair Manual AV-224
< DTC/CIRCUIT DIAGNOSIS >[NAVIGATION]
STEERING SWITCH
STEERING SWITCH
Diagnosis ProcedureINFOID:0000000012433089
Regarding Wiring Diagram information, refer to
AV-155, "Wiring Diagram".
1.CHEC](/manual-img/5/57363/w960_57363-228.png)
AV-224
< DTC/CIRCUIT DIAGNOSIS >[NAVIGATION]
STEERING SWITCH
STEERING SWITCH
Diagnosis ProcedureINFOID:0000000012433089
Regarding Wiring Diagram information, refer to
AV-155, "Wiring Diagram".
1.CHECK STEERING WHEEL AUDIO CONTROL SWITCH RESISTANCE
1. Turn ignition switch OFF.
2. Disconnect combination switch connector M88.
3. Check resistance between the terminals of combination switch connector M88.
Is the inspection result normal?
YES >> GO TO 2.
NO >> Replace steering switches. Refer to AV-247, "
Removal and Installation".
2.CHECK COMBINATION SWITCH
1. Disconnect combination switch connector M30.
2. Check continuity between combinat ion switch connectors M88 and M30.
Is the inspection result normal?
YES >> GO TO 3.
NO >> Replace spiral cable. Refer to SR-16, "
Removal and Installation".
3.CHECK HARNESS BETWEEN COMBINAT ION SWITCH AND AV CONTROL UNIT
1. Disconnect AV control unit connector M70.
2. Check continuity between combination switch connector M30 and AV control unit connector M70.
Combination switch connector M88
ConditionResistance
Ω
(Approx.)
Te r m i n a l Te r m i n a l
14 17Depress SOURCE switch.
1
Depress switch. 121
Depress switch. 321
Depress switch. 723
15 Depress switch.
1
Depress switch. 121
Depress switch. 321
Combination switch
Continuity
Connector TerminalConnector Terminal
M88 14
M30 24
Ye s
15 31
17 33
Combination switch AV control unit
Continuity
Connector TerminalConnector Terminal
M30 24
M70 6
Ye s
31 16
33 15
Revision: August 2015 2016 Versa Note
cardiagn.com
Page 230 of 3641
AV
STEERING SWITCHAV-225
< DTC/CIRCUIT DIAGNOSIS > [NAVIGATION]
C
D
E
F
G H
I
J
K L
M B A
O P
3. Check continuity between combi nation switch connector M30 and ground.
Is the inspection result normal?
YES >> Replace AV control unit. Refer to AV-241, "Removal and Installation".
NO >> Repair or replace harness or connectors.
Combination switch Ground Continuity
Connector Terminal
M30 24
—N o
31
33
Revision: August 2015 2016 Versa Note
cardiagn.com
Page 231 of 3641
AV-226
< DTC/CIRCUIT DIAGNOSIS >[NAVIGATION]
USB CONNECTOR
USB CONNECTOR
Diagnosis ProcedureINFOID:0000000012433090
Regarding Wiring Diagram information, refer to
AV-155, "Wiring Diagram".
1.CHECK USB INTERFACE HARNESS CONTINUITY
1. Turn ignition switch OFF.
2. Disconnect AV control unit connector M76 and USB interface connector M47.
3. Check continuity between AV control unit connector M76 and USB interface connector M47.
4. Check continuity between AV control unit connector M76 and ground.
Is the inspection result normal?
YES >> Replace the USB interface. Refer to AV-245, "Removal and Installation".
NO >> Repair or replace harness or connectors.
AV control unit USB interface
Continuity
Connector TerminalConnector Terminal
M76 45
M47 1
Ye s
46
5
47 3
48 2
49 6
AV control unit
—Continuity
Connector Terminal
M76 45
Ground No
47
Revision: August 2015 2016 Versa Note
cardiagn.com
Page 232 of 3641
AV
AUXILIARY INPUT JACKAV-227
< DTC/CIRCUIT DIAGNOSIS > [NAVIGATION]
C
D
E
F
G H
I
J
K L
M B A
O P
AUXILIARY INPUT JACK
Diagnosis ProcedureINFOID:0000000012433091
Regarding Wiring Diagram information, refer to AV-155, "Wiring Diagram".
1.CHECK AUX IN JACK HARNESS CONTINUITY
1. Turn ignition switch OFF.
2. Disconnect AV control unit connector M71 and AUX in jack connector.
3. Check continuity between AV control unit connector M71 and AUX in jack connector.
4. Check continuity between AV control unit connector M71 and ground.
Is the inspection result normal?
YES >> Replace the AUX in jack. Refer to AV-246, "Removal and Installation".
NO >> Repair or replace harness or connectors.
AV control unit AUX in jack
Continuity
Connector TerminalConnector Terminal
M71 30
M46 (without heated
seats)
M215 (with heated- seats) 1
Ye s
31
3
32 4
AV c o n t r o l u n i t
—Continuity
Connector Terminal
M71 30
Ground No
32
Revision: August 2015 2016 Versa Note
