NISSAN NOTE 2016 Service Repair Manual BCS-60
< BASIC INSPECTION >[WITH INTELLIGENT KEY SYSTEM]
CONFIGURATION (BCM)
>> GO TO 4.
4.OPERATION CHECK
Confirm that each function controlled by BCM operates normally.
>> WORK END
Configuration Lis

Page 322 of 3641

NISSAN NOTE 2016 Service Repair Manual BCS
SHIPPING MODE CANCEL OPERATION
BCS-61
< BASIC INSPECTION > [WITH INTELLIGENT KEY SYSTEM]
C
D
E
F
G H
I
J
K L
B A
O P
N
SHIPPING MODE CANCEL OPERATION
Work ProcedureINFOID:0000000012432342
1.SHIPPI

Page 323 of 3641

NISSAN NOTE 2016 Service Repair Manual BCS-62
< BASIC INSPECTION >[WITH INTELLIGENT KEY SYSTEM]
TRANSIT MODE CANCEL OPERATION
TRANSIT MODE CANCEL OPERATION
Work ProcedureINFOID:0000000012432343
1.TRANSIT MODE CANCEL OPERATION
1. Turn ignit

Page 324 of 3641

NISSAN NOTE 2016 Service Repair Manual BCS
U1000 CAN COMM CIRCUITBCS-63
< DTC/CIRCUIT DIAGNOSIS > [WITH INTELLIGENT KEY SYSTEM]
C
D
E
F
G H
I
J
K L
B A
O P
N
DTC/CIRCUIT DIAGNOSIS
U1000 CAN COMM CIRCUIT
DescriptionINFOID:0000000012432344
R

Page 325 of 3641

NISSAN NOTE 2016 Service Repair Manual BCS-64
< DTC/CIRCUIT DIAGNOSIS >[WITH INTELLIGENT KEY SYSTEM]
U1010 CONTROL UNIT (CAN)
U1010 CONTROL UNIT (CAN)
DTC LogicINFOID:0000000012432347
DTC DETECTION LOGIC
Diagnosis ProcedureINFOID:000000001

Page 326 of 3641

NISSAN NOTE 2016 Service Repair Manual BCS
U0415 VEHICLE SPEEDBCS-65
< DTC/CIRCUIT DIAGNOSIS > [WITH INTELLIGENT KEY SYSTEM]
C
D
E
F
G H
I
J
K L
B A
O P
N
U0415 VEHICLE SPEED
DTC LogicINFOID:0000000012432349
DTC DETECTION LOGIC
NOTE:
• I

BCS
U0415 VEHICLE SPEEDBCS-65
< DTC/CIRCUIT DIAGNOSIS > [WITH INTELLIGENT KEY SYSTEM]
C
D
E
F
G H
I
J
K L
B A
O P
N
U0415 VEHICLE SPEED
DTC LogicINFOID:0000000012432349
DTC DETECTION LOGIC
NOTE:
• If DTC U0415 is displayed with DTC U1000, first perform the trouble diagnosis for DTC U1000. Refer to
BCS-63, "
DTC Logic".
• If DTC U0415 is displayed with DTC U1010, first perform the trouble diagnosis for DTC U1010. Refer to BCS-64, "
DTC Logic".
DTC CONFIRMATION PROCEDURE
1. DTC CONFIRMATION
1. Erase the DTC.
2. Turn ignition switch OFF.
3. Perform Self Diagnostic Result of BCM with CONSULT, after the ignition switch has been turned ON for 2
seconds or more.
Is any DTC detected?
YES >> Refer to BCS-65, "Diagnosis Procedure".
NO >> Inspection End.
Diagnosis ProcedureINFOID:0000000012432350
1. ABS ACTUATOR AND ELECTRIC UNIT (CONTROL UNIT) SELF DIAGNOSTIC RESULT
Perform “Self Diagnostic Result” of “ABS” with CONSULT. Refer to BRC-31, "
CONSULT Function (ABS)".
Is any DTC detected?
YES >> Perform the trouble diagnosis related to the detected DTC. Refer to BRC-43, "DTC Index".
NO >> GO TO 2.
2. CHECK ABS ACTUATOR AND ELECTRIC UNIT (CONTROL UNIT) POWER SUPPLY AND GROUND
CIRCUIT
Check ABS actuator and electric unit (control unit) power and ground. Refer to BRC-121, "
Diagnosis Proce-
dure".
Is the inspection result normal?
YES >> GO TO 3.
NO >> Repair or replace harness or connectors.
3. COMBINATION METER SE LF DIAGNOSTIC RESULT
Perform “Self Diagnostic Result” of “ME TER M&A” with CONSULT. Refer to MWI-71, "
CONSULT Function
(METER/M&A)".
Is any DTC detected?
YES >> Perform the trouble diagnosis related to the detected DTC. Refer to MWI-77, "DTC Index".
NO >> Refer to GI-42, "
Intermittent Incident".
CONSULT Display DTC Detection Condition Probable Cause
VDC CAN CIR2
[U0415] When the vehicle speed signal received from the
ABS actuator and electric
unit (control unit) re-
mains abnormal for 2 seconds or more. • ABS system
• Combination meter system
• CAN bus harness
Revision: August 2015
