Page 3625 of 3641

NISSAN NOTE 2016 Service Repair Manual WW-60 < REMOVAL AND INSTALLATION > FRONT WASHER NOZZLE AND TUBE FRONT WASHER NOZZLE AND TUBE Exploded ViewINFOID:0000000012433238 WASHER NOZZLE WASHER NOZZLE : Removal and InstallationINFOID:000000001

Page 3626 of 3641

NISSAN NOTE 2016 Service Repair Manual FRONT WASHER NOZZLE AND TUBEWW-61 < REMOVAL AND INSTALLATION > C DE F G H I J K M A B WW N O P WASHER NOZZLE : AdjustmentINFOID:0000000012433240 If washer nozzle (1) spray pattern is not within specif

Page 3627 of 3641

NISSAN NOTE 2016 Service Repair Manual WW-62 < REMOVAL AND INSTALLATION > FRONT WASHER NOZZLE AND TUBE INSTALLATION Installation is in the reverse order of removal. WASHER TUBE : InspectionINFOID:0000000012433242 INSPECTION Check that air

Page 3628 of 3641

NISSAN NOTE 2016 Service Repair Manual FRONT WIPER ARMWW-63 < REMOVAL AND INSTALLATION > C DE F G H I J K M A B WW N O P FRONT WIPER ARM Exploded ViewINFOID:0000000012433243 Removal and InstallationINFOID:0000000012433244 REMOVAL 1. Open h

Page 3629 of 3641

NISSAN NOTE 2016 Service Repair Manual WW-64 < REMOVAL AND INSTALLATION > FRONT WIPER ARM 4. Install front wiper arm and front wiper arm nut.CAUTION: Tighten front wiper arm nut to specification. Refer to WW-63, " Exploded View". 5. Insta

Page 3630 of 3641

NISSAN NOTE 2016 Service Repair Manual FRONT WIPER BLADEWW-65 < REMOVAL AND INSTALLATION > C DE F G H I J K M A B WW N O P FRONT WIPER BLADE Removal and InstallationINFOID:0000000012433246 REMOVAL 1. Lift up wiper arm and set to the positi

Page 3631 of 3641

NISSAN NOTE 2016 Service Repair Manual WW-66 < REMOVAL AND INSTALLATION > FRONT WIPER DRIVE ASSEMBLY FRONT WIPER DRIVE ASSEMBLY Exploded ViewINFOID:0000000012433247 Removal and InstallationINFOID:0000000012433248 REMOVAL 1. Remove cowl top

Page 3632 of 3641

NISSAN NOTE 2016 Service Repair Manual FRONT WIPER DRIVE ASSEMBLYWW-67 < REMOVAL AND INSTALLATION > C DE F G H I J K M A B WW N O P Exploded ViewINFOID:0000000012433249 Disassembly and AssemblyINFOID:0000000012433250 DISASSEMBLY 1. Remove
