2016 NISSAN NOTE Service Repair Manual

air conditioning wiper blades OBD port airbag off air bleeding tire pressure reset

Load previous 8 pages

Page 809 of 3641

NISSAN NOTE 2016 Service Repair Manual DLK-120
< SYMPTOM DIAGNOSIS >[WITH INTELLIGENT KEY SYSTEM]
AUTO DOOR LOCK OPERATIO
N DOES NOT OPERATE
AUTO DOOR LOCK OPERATION DOES NOT OPERATE
Diagnosis ProcedureINFOID:0000000012430070
1.CHECK AUTO

Page 810 of 3641

NISSAN NOTE 2016 Service Repair Manual VEHICLE SPEED SENSING AUTO LOCK OPERATION DOES NOT OPERATE
DLK-121
< SYMPTOM DIAGNOSIS > [WITH INTELLIGENT KEY SYSTEM]
C
D
E
F
G H
I
J
L
M A
B
DLK
N
O P
VEHICLE SPEED SENSING AUTO LOCK OPERATION DOES

Page 811 of 3641

NISSAN NOTE 2016 Service Repair Manual DLK-122
< SYMPTOM DIAGNOSIS >[WITH INTELLIGENT KEY SYSTEM]
IGN OFF INTERLOCK DOOR UNLOCK FUNCTION DOES NOT OPERATE
IGN OFF INTERLOCK DOOR UNLOCK
FUNCTION DOES NOT OPERATE
Diagnosis ProcedureINFOID:00

Page 812 of 3641

NISSAN NOTE 2016 Service Repair Manual HAZARD AND BUZZER REMINDER DOES NOT OPERATEDLK-123
< SYMPTOM DIAGNOSIS > [WITH INTELLIGENT KEY SYSTEM]
C
D
E
F
G H
I
J
L
M A
B
DLK
N
O P
HAZARD AND BUZZER REMI NDER DOES NOT OPERATE
Diagnosis Procedur

HAZARD AND BUZZER REMINDER DOES NOT OPERATEDLK-123
< SYMPTOM DIAGNOSIS > [WITH INTELLIGENT KEY SYSTEM]
C
D
E
F
G H
I
J
L
M A
B
DLK
N
O P
HAZARD AND BUZZER REMI NDER DOES NOT OPERATE
Diagnosis ProcedureINFOID:0000000012430073
1.CHECK HAZARD ANSWER BACK SETTING IN WORK SUPPORT
1. Select “INTELLIGENT KEY” of “BCM” using CONSULT.
2. Select “HAZARD ANSWER BACK” in “Work support”.
3. Check the “HAZARD ANSWER BA CK” setting in “Work support”.
Refer to BCS-22, "
INTELLIGENT KEY : CONSULT Function (BCM - INTELLIGENT KEY)".
Is the inspection result normal?
YES >> GO TO 2.
NO >> Set the “Lock Only”, “Unlock Only” or “Lock/Unlock” in “HAZARD ANSWER BACK”.
2.CHECK ANS BACK I-KEY LOCK SETTING IN WORK SUPPORT
1. Select “INTELLIGENT KEY” of “BCM” using CONSULT.
2. Select “ANS BACK I-KE Y LOCK” in “Work support.
3. Check the “ANS BACK I-KEY LOCK” setting in “Work support”. Refer to BCS-22, "
INTELLIGENT KEY : CONSULT Function (BCM - INTELLIGENT KEY)".
Is the inspection result normal?
YES >> GO TO 3.
NO >> Set the “Horn Chirp” or “Buzzer” in “ANS BACK I-KEY LOCK”.
3.CHECK ANS BACK I-KEY UNLOCK SETTING IN WORK SUPPORT
1. Select “INTELLIGENT KEY” of “BCM” using CONSULT.
2. Select “ANS BACK I-KEY UNLOCK” in “Work support”.
3. Check the “ANS BACK I-KEY UNLOCK” setting in “Work support”. Refer to BCS-22, "
INTELLIGENT KEY : CONSULT Function (BCM - INTELLIGENT KEY)".
Is the inspection result normal?
YES >> GO TO 4.
NO >> Set the “On” in “ANS BACK I-KEY UNLOCK”.
4.CHECK HAZARD FUNCTION
Check hazard function.
Refer to DLK-101, "
ComponentFunctionCheck".
Is the inspection result normal?
YES >> GO TO 5.
NO >> Repair or replace the malfunctioning parts.
5.CHECK INTELLIGENT KEY WARNING BUZZER
Check Intelligent Key warning buzzer.
Refer to DLK-102, "
ComponentFunctionCheck".
Is the inspection result normal?
YES >> GO TO 6.
NO >> Repair or replace the malfunctioning parts.
6.REPLACE BCM
1. Replace BCM. Refer to BCS-74, "
Removal and Installation".
2. Confirm the operation after replacement.
Is the result normal?
YES >> Inspection End.
NO >> Check intermittent incident. Refer to GI-42, "
Intermittent Incident".
Revision: August 2015 2016 Versa Note

cardiagn.com

Page 813 of 3641

NISSAN NOTE 2016 Service Repair Manual DLK-124
< SYMPTOM DIAGNOSIS >[WITH INTELLIGENT KEY SYSTEM]
KEY REMINDER FUNCTION DOES NOT OPERATE
KEY REMINDER FUNCTION DOES NOT OPERATE
Diagnosis ProcedureINFOID:0000000012430074
1.CHECK ANTI KEY LOC

Page 814 of 3641

NISSAN NOTE 2016 Service Repair Manual OFF POSITION WARNING DOES NOT OPERATEDLK-125
< SYMPTOM DIAGNOSIS > [WITH INTELLIGENT KEY SYSTEM]
C
D
E
F
G H
I
J
L
M A
B
DLK
N
O P
OFF POSITION WARNIN G DOES NOT OPERATE
Diagnosis ProcedureINFOID:0000

Page 815 of 3641

NISSAN NOTE 2016 Service Repair Manual DLK-126
< SYMPTOM DIAGNOSIS >[WITH INTELLIGENT KEY SYSTEM]
P POSITION WARNING DOES NOT OPERATE
P POSITION WARNING DOES NOT OPERATE
Diagnosis ProcedureINFOID:0000000012430076
1.CHECK DTC WITH BCM
Check

Page 816 of 3641

NISSAN NOTE 2016 Service Repair Manual P POSITION WARNING DOES NOT OPERATEDLK-127
< SYMPTOM DIAGNOSIS > [WITH INTELLIGENT KEY SYSTEM]
C
D
E
F
G H
I
J
L
M A
B
DLK
N
O P
NO >> Check intermittent incident. Refer to GI-42, "Intermittent Incid
