Page 3505 of 3641
TM-264
< UNIT DISASSEMBLY AND ASSEMBLY >[CVT: RE0F11A]
TORQUE CONVERTER AND CONVERTER HOUSING OIL SEAL
• Attach the pawl (A) of the torque converter to the drive sprocket
hole (B) on the transaxle assembly side.
CAUTION:
• Rotate the torque converter fo r installing torque converter.
• Never damage the bushing inside the torque converter sleeve when installing the converter housing oil seal.
InspectionINFOID:0000000012431229
INSPECTION BEFORE INSTALLATION
After inserting a torque converter to the CVT, check dimension (A)
with in the reference value limit.
SCIA7907J
B: Scale
C : Straightedge
Dimension (A) : Refer to TM-265, "Torque Converter".
JSDIA4115ZZ
Revision: August 2015 2016 Versa Note
cardiagn.com
Page 3506 of 3641
![NISSAN NOTE 2016 Service Repair Manual SERVICE DATA AND SPECIFICATIONS (SDS)TM-265
< SERVICE DATA AND SPECIFICATIONS (SDS) [CVT: RE0F11A]
C
EF
G H
I
J
K L
M A
B
TM
N
O P
SERVICE DATA AND SPECIFICATIONS (SDS)
SERVICE DATA AND SPECIFICATION NISSAN NOTE 2016 Service Repair Manual SERVICE DATA AND SPECIFICATIONS (SDS)TM-265
< SERVICE DATA AND SPECIFICATIONS (SDS) [CVT: RE0F11A]
C
EF
G H
I
J
K L
M A
B
TM
N
O P
SERVICE DATA AND SPECIFICATIONS (SDS)
SERVICE DATA AND SPECIFICATION](/manual-img/5/57363/w960_57363-3505.png)
SERVICE DATA AND SPECIFICATIONS (SDS)TM-265
< SERVICE DATA AND SPECIFICATIONS (SDS) [CVT: RE0F11A]
C
EF
G H
I
J
K L
M A
B
TM
N
O P
SERVICE DATA AND SPECIFICATIONS (SDS)
SERVICE DATA AND SPECIFICATIONS (SDS)
General SpecificationINFOID:0000000012431230
Shift CharacteristicsINFOID:0000000012431231
Unit: rpm
CAUTION:
Lock-up is engaged at the vehicle speed of approximately 10 km/h (11 MPH) to 90 km/h (56 MPH).
Stall SpeedINFOID:0000000012431232
Unit: rpm
Line PressureINFOID:0000000012431233
Unit: MPa (bar, kg/cm2, psi)
Torque ConverterINFOID:0000000012431234
Applied model Engine HR16DE
Axle
2WD
Transaxle model RE0F11A
Stall torque ratio 1.91 : 1
Pulley ratio Forward
2.200 – 0.550
Reverse 2.200
Auxiliary gearbox gear ratio 1GR
1.821
2GR 1.000
Reverse 1.714
Counter gear 0.967
Final drive 3.882
Recommended fluid Refer to MA-11, "
Fluids and Lubricants".
Fluid capacity
Throttle position Shift pattern Engine speed
At 40 km/h (25 MPH) At 60 km/h (37 MPH)
2/8 “D” position (Overdrive control OFF)
1,300 – 3,1001,400 – 3,400
“D” position (Overdrive control ON) 2,200 – 3,1002,700 – 3,500
“L” position 3,000 – 3,8003,500 – 4,300
8/8 “D” position (Overdrive control OFF)
3,600 – 4,4004,300 – 5,100
“D” position (Overdrive control ON) 3,600 – 4,4004,300 – 5,100
“L” position 3,600 – 4,4004,300 – 5,100
Stall speed 2,420 – 2,870
Shift selector positionEngine speed Line pressure
“P” and “N” At idle 0.40 (4, 4.1, 58)
“R” and “D” At idle
0.40 (4, 4.1, 58) – 1.39 (13.9, 14.2, 201.6)
At stall 4.20 (42, 42.8, 609) – 4.70 (47, 47.9, 681.5)
Distance (A) between the converter housing and torque converter 16.2 mm
Revision: August 2015 2016 Versa Note
cardiagn.com
Page 3507 of 3641

VTL-1
VENTILATION, HEATER & AIR CONDITIONER
C
DE
F
G H
J
K L
M
SECTION VTL
A
B
VTL
N
O P
CONTENTS
VENTILATION SYSTEM
PRECAUTION ....... ........................................2
PRECAUTIONS .............................................. .....2
Precaution for Supplemental Restraint System
(SRS) "AIR BAG" and "SEAT BELT PRE-TEN-
SIONER" ............................................................. ......
2
Precaution for Work ..................................................2
PREPARATION ............................................3
PREPARATION .............................................. .....3
Special Service Tool ........................................... ......3
Commercial Service Tool ..........................................3
SYSTEM DESCRIPTION ..............................4
VENTILATION SYSTEM ................................ .....4
System Description ............................................. ......4
REMOVAL AND INSTALLATION ................5
DUCT AND GRILLE ....................................... .....5
Exploded View .................................................... ......5
CENTER VENTILATOR GRILLE .......................... ......6
CENTER VENTILATOR GRILLE : Removal and
Installation .................................................................
6
SIDE VENTILATOR GRILLE ................................. .....6
SIDE VENTILATOR GRILLE : Removal and In-
stallation ...................................................................
6
SIDE DEFROSTER GRILLE .................................. .....6
SIDE DEFROSTER GRILLE : Removal and In-
stallation ...................................................................
6
CENTER VENTILATOR DUCT .............................. .....7
CENTER VENTILATOR DUCT : Removal and In-
stallation ...................................................................
7
CENTER DEFROSTER DUCT ............................... .....7
CENTER DEFROSTER DUCT : Removal and In-
stallation ...................................................................
7
SIDE DEFROSTER DUCT ..................................... .....7
SIDE DEFROSTER DUCT : Removal and Instal-
lation .........................................................................
7
FOOT DUCT ........................................................... .....7
FOOT DUCT : Removal and Installation ..................7
REAR FLOOR DUCT ............................................. .....8
REAR FLOOR DUCT : Removal and Installation .....8
FRONT BLOWER MOTOR ................................9
Exploded View ..........................................................9
Removal and Installation ..........................................9
Revision: August 2015 2016 Versa Note
cardiagn.com
Page 3508 of 3641

VTL-2
< PRECAUTION >
PRECAUTIONS
PRECAUTION
PRECAUTIONS
Precaution for Supplemental Restraint System (SRS) "AIR BAG" and "SEAT BELT
PRE-TENSIONER"
INFOID:0000000012430544
The Supplemental Restraint System such as “A IR BAG” and “SEAT BELT PRE-TENSIONER”, used along
with a front seat belt, helps to reduce the risk or severity of injury to the driver and front passenger for certain
types of collision. Information necessary to service the system safely is included in the SR and SB section of
this Service Manual.
WARNING:
• To avoid rendering the SRS inopera tive, which could increase the risk of personal injury or death in
the event of a collision which would result in air bag inflation, all maintenance must be performed by
an authorized NISSAN/INFINITI dealer.
• Improper maintenance, including in correct removal and installation of the SRS, can lead to personal
injury caused by unintent ional activation of the system. For re moval of Spiral Cable and Air Bag
Module, see the SR section.
• Do not use electrical test equipmen t on any circuit related to the SRS unless instructed to in this
Service Manual. SRS wiring harn esses can be identified by yellow and/or orange harnesses or har-
ness connectors.
PRECAUTIONS WHEN USING POWER TOOLS (AIR OR ELECTRIC) AND HAMMERS
WARNING:
• When working near the Airbag Diagnosis Sensor Unit or other Airbag System sensors with the Igni-
tion ON or engine running, DO NOT use air or electri c power tools or strike near the sensor(s) with a
hammer. Heavy vibration could activate the sensor( s) and deploy the air bag(s), possibly causing
serious injury.
• When using air or electric power tools or hammers , always switch the Ignition OFF, disconnect the
battery and wait at least three minutes before performing any service.
Precaution for WorkINFOID:0000000012430545
• When removing or disassembling each component, be careful not to damage or deform it. If a component may be subject to interference, be sure to protect it with a shop cloth.
• When removing (disengaging) components with a screwdriver or similar tool, be sure to wrap the component with a shop cloth or vinyl tape to protect it.
• Protect the removed parts with a shop cloth and prevent them from being dropped.
• Replace a deformed or damaged clip.
• If a part is specified as a non-reusable part, always replace it with a new one.
• Be sure to tighten bolts and nuts securely to the specified torque.
• After installation is complete, be sure to check that each part works properly.
• Follow the steps below to clean components:
- Water soluble dirt:
• Dip a soft cloth into lukewarm water, wring the water out of the cloth and wipe the dirty area.
• Then rub with a soft, dry cloth.
- Oily dirt:
• Dip a soft cloth into lukewarm water with mild detergent (concentration: within 2 to 3%) and wipe the dirty area.
• Then dip a cloth into fresh water, wring the water out of the cloth and wipe the detergent off.
• Then rub with a soft, dry cloth.
- Do not use organic solvent such as thinner, benzene, alcohol or gasoline.
- For genuine leather seats, use a genuine leather seat cleaner.
Revision: August 2015 2016 Versa Note
cardiagn.com
Page 3509 of 3641
PREPARATIONVTL-3
< PREPARATION >
C
DE
F
G H
J
K L
M A
B
VTL
N
O P
PREPARATION
PREPARATION
Special Service ToolINFOID:0000000012430546
The actual shape of the tools may di ffer from those illustrated here.
Commercial Service ToolINFOID:0000000012430547
Tool number
(TechMate No.)
Tool name Description
—
(J-46534)
Trim Tool Set Removing trim components
AWJIA0483ZZ
Tool name
Description
Power tool Loosening nuts, screws and bolts
PIIB1407E
Revision: August 2015 2016 Versa Note
cardiagn.com
Page 3510 of 3641
VTL-4
< SYSTEM DESCRIPTION >
VENTILATION SYSTEM
SYSTEM DESCRIPTION
VENTILATION SYSTEM
System DescriptionINFOID:0000000012430548
OUTLINE
The ventilation system is controlled by the front air control.
AIR FLOW
Front
Rear (if equipped)
× : Applicable
AWIIA1690ZZ
AWIIA1463ZZ
MODE/DEF setting AIR OUTLET
Ventilator Foot
Defroster (4)
Center (1) Side (2)Front (3) Rear (3) (Canada only)
×× ———
×× × × —
— ×× × ×
— ×× × ×
— ×—— ×
Revision: August 2015 2016 Versa Note
cardiagn.com
Page 3511 of 3641
DUCT AND GRILLEVTL-5
< REMOVAL AND INSTALLATION >
C
DE
F
G H
J
K L
M A
B
VTL
N
O P
REMOVAL AND INSTALLATION
DUCT AND GRILLE
Exploded ViewINFOID:0000000012430549
FRONT
AWIIA1860ZZ
1. Center defroster duct 2. Side defroster duct (LH)3. Center ventilator duct
4. Side ventilator grille (LH) 5. Side defroster grille (LH)6. Heating and cooling unit assembly
7. Foot duct (LH) 8. Foot duct (RH)9. Center ventilator grille (LH)
10. Cluster lid C 11. Center ventilator grille (RH) 12. Side defroster grille (RH)
13. Instrument panel assembly 14. Side ventilator grille (RH) 15. Side defroster duct (RH)
Revision: August 2015 2016 Versa Note
cardiagn.com
Page 3512 of 3641

VTL-6
< REMOVAL AND INSTALLATION >
DUCT AND GRILLE
REAR (if equipped)
CENTER VENTILAT O R G R I L L E
CENTER VENTILATOR GRILLE : Removal and InstallationINFOID:0000000012430550
REMOVAL
1. Remove cluster lid C. Refer to IP-22, "Removal and Installation".
2. Release pawls and remove the center ventilator grille from cluster lid C.
INSTALLATION
Installation is in the reverse order of removal.
SIDE VENTILATOR GRILLE
SIDE VENTILATOR GRILLE : Removal and InstallationINFOID:0000000012430551
REMOVAL
1. Remove instrument panel assembly. Refer to IP-15, "Removal and Installation".
2. Remove center ventilator duct. Refer to VTL-7, "
CENTER VENTILATOR DUCT : Removal and Installa-
tion".
3. Remove screw and the side ventilator grille.
INSTALLATION
Installation is in the reverse order of removal.
SIDE DEFROSTER GRILLE
SIDE DEFROSTER GRILLE : Removal and InstallationINFOID:0000000012430552
REMOVAL
1. Remove front pillar finisher. Refer to INT-21, "FRONT PILLAR FINISHER : Removal and Installation".
JMIIA1736ZZ
1. Heating and cooling unit assembly 2. Connector duct 3. Rear floor duct (LH)
4. Rear floor nozzle (LH) 5. Rear floor nozzle (RH) 6. Rear floor duct (RH)
