NISSAN NOTE 2016 Service Repair Manual DLK-24
< SYSTEM DESCRIPTION >[WITH INTELLIGENT KEY SYSTEM]
SYSTEM (INTELLIGENT KEY SYSTEM)
*: Even with a registered Intelligent Key remaining inside the vehicle, door locks can be unlocked from outsi

DLK-24
< SYSTEM DESCRIPTION >[WITH INTELLIGENT KEY SYSTEM]
SYSTEM (INTELLIGENT KEY SYSTEM)
*: Even with a registered Intelligent Key remaining inside the vehicle, door locks can be unlocked from outside of the vehicle
with a spare
Intelligent Key as long as key IDs are different.
Door lock function can be changed using “LOCK/UNLOCK BY I-KEY” in “Work support”. Refer to BCS-22,
"INTELLIGENT KEY : CONSULT Function (BCM - INTELLIGENT KEY)".
OUTSIDE KEY ANTENNA DETECTION AREA
The outside key antenna detection area of door lock/unlock function
is in the range of approximately 80 cm (31.50 in) surrounding the
driver, passenger door handles (1). However, this operating range
depends on the ambient conditions.
HAZARD AND BUZZER REMINDER FUNCTION
For the operation check, BCM blinks hazard warning lamps (lock: 2 times, unlock: 1 time) and sounds Intelli-
gent Key warning buzzer (lock: 1 time, unlock: 1 time) when door lock or unlock operates by operation of each
door request switch.
How to Change Hazard and Buzzer Reminder Mode
Refer to BCS-22, "INTELLIGENT KEY : CONSULT Func tion (BCM - INTELLIGENT KEY)".
AUTO DOOR LOCK FUNCTION
After door is unlocked by door request switch operation and if 30 seconds or more passes without performing
the following operation, all doors are automatically locked: However, operation check function does not acti-
vate.
Auto door lock mode can be changed by the “AUTO LOCK SET” in “Work support”. Refer to BCS-22, "
INTEL-
LIGENT KEY : CONSULT Function (BCM - INTELLIGENT KEY)".
LIST OF OPERATION RELATED PARTS
Parts marked with × are the parts related to operation.
Each request switch operation Operation condition
Lock • All doors are closed.
• Ignition switch is in the LOCK or OFF position.
• Panic alarm is not activated.
• Intelligent Key is outside the vehicle.
• Intelligent Key is within outside key antenna detection area.
• P position warning is not activated.
Unlock • All doors are closed.
• Ignition switch is in the LOCK or OFF position.
• Panic alarm is not activated.
• Intelligent Key is outside the vehicle.
• Intelligent Key is within outside key antenna detection area. *
JMKIA4881ZZ
Operating condition
• Door switch is ON
. (door is open)
• BCM receives lock signal.
• Push switch is pressed.
Revision: August 2015 2016 Versa Note

cardiagn.com

Page 714 of 3641

NISSAN NOTE 2016 Service Repair Manual SYSTEM (INTELLIGENT KEY SYSTEM)DLK-25
< SYSTEM DESCRIPTION > [WITH INTELLIGENT KEY SYSTEM]
C
D
E
F
G H
I
J
L
M A
B
DLK
N
O P
REMOTE KEYLESS ENTRY FUNCTION
REMOTE KEYLESS ENTRY FUNCT ION : System Descr

Page 715 of 3641

NISSAN NOTE 2016 Service Repair Manual DLK-26
< SYSTEM DESCRIPTION >[WITH INTELLIGENT KEY SYSTEM]
SYSTEM (INTELLIGENT KEY SYSTEM)
HAZARD AND BUZZER REMINDER FUNCTION
For the operation check, BCM blinks hazard warning lamps (lock: 2 times,

Page 716 of 3641

NISSAN NOTE 2016 Service Repair Manual SYSTEM (INTELLIGENT KEY SYSTEM)DLK-27
< SYSTEM DESCRIPTION > [WITH INTELLIGENT KEY SYSTEM]
C
D
E
F
G H
I
J
L
M A
B
DLK
N
O P
KEY REMINDER FUNCTION : System DescriptionINFOID:0000000012429986
System Di

SYSTEM (INTELLIGENT KEY SYSTEM)DLK-27
< SYSTEM DESCRIPTION > [WITH INTELLIGENT KEY SYSTEM]
C
D
E
F
G H
I
J
L
M A
B
DLK
N
O P
KEY REMINDER FUNCTION : System DescriptionINFOID:0000000012429986
System Diagram
BASIC OPERATION
Key reminder is the function that prevents the key from being left in the vehicle.
Key reminder has the following 3 functions:
*:When closing the door if something comes into contact with the door lock switch it might activate the door locks accidentally , but the
unlock operation will override this.
NOTE:
The above function operates when the Intelligent Key is in side the vehicle. However, there may be times when
the Intelligent Key cannot be detected, and this func tion does not operate when the Intelligent Key is on the
instrument panel, rear parcel shelf, or in the glove box. Also, this system sometimes does not operate if the
Intelligent Key is in the door pocket for the open door.
WARNING FUNCTION
WARNING FUNCTION : System DescriptionINFOID:0000000012429987
OPERATION DESCRIPTION
The warning function are as per the following items and are given to the user as warning information and
warnings using combinations of Intelligent Key warni ng buzzer, combination meter buzzer, KEY warning lamp,
shift P warning lamp and engine start operation indicator lamp:
• Intelligent Key system malfunction
• OFF position warning
• P position warning
• ACC warning
• Take away warning
• Door lock operation warning
• Engine start information
ALKIA3196GB
Key reminder function Operation condition Operation
Driver side door closed* Right after driver side door is closed under the following conditions:
• Intelligent Key is inside the vehicle.
• Driver side door is opened.
• Driver side door is in unlock state. All doors unlock
Door is open or closed Right after all doors are closed under the following conditions:
• Door lock/unlock switch or driver side door lock knob are operated.
• Intelligent Key is inside the vehicle.
• Any door is opened.
• All doors are locked. • All doors unlock
• Honk Intelligent Key warn-
ing buzzer
Back door is closed Right after Back door is closed under the following conditions:
• Intelligent Key is inside trunk room.
• All doors are closed.
• All doors are locked. • Back door open
• Honk Intelligent Key warn-
ing buzzer
Revision: August 2015 2016 Versa Note

cardiagn.com

Page 717 of 3641

NISSAN NOTE 2016 Service Repair Manual DLK-28
< SYSTEM DESCRIPTION >[WITH INTELLIGENT KEY SYSTEM]
SYSTEM (INTELLIGENT KEY SYSTEM)
• Intelligent Key low battery warning
• Key ID warning
OPERATION CONDITION
Operation condition of warning

DLK-28
< SYSTEM DESCRIPTION >[WITH INTELLIGENT KEY SYSTEM]
SYSTEM (INTELLIGENT KEY SYSTEM)
• Intelligent Key low battery warning
• Key ID warning
OPERATION CONDITION
Operation condition of warning and information is as per the following table:
WARNING METHOD
The following table shows the alarm or warning methods with chime:
Warning/Information functions
Operation procedure
Intelligent Key system malfunction A malfunction is detected on BCM and key warning lamp turns ON
OFF position warning When condition A, B or condition C is satisfied:
• Condition A
- Ignition switch: ACC position
- Door switch (driver side
): ON (Door is open)
• Condition B
- Turn ignition switch from ON to OFF while door is open.
• Condition C
- Intelligent Key backside is contacted to push-button ignition switch while brake pedal is depressed and ignition switch is LOCK or OFF. (When the
Intelligent Key battery is discharged.)
- Door switch (driver side ): ON (Door is open)
P position warning For internal
• Shift position: Other than P
• Engine is stopped. (Ignition switch is turned from ON to OFF.)
For external • P position warning (For internal) operates.
• Door switch: ON to OFF (Door is open to close.)
• Intelligent Key cannot be detected inside the vehicle.
ACC warning • After P position warning operates, or when ignition switch is turned ON
immediately after P position warning operates.
• Ignition switch: ACC
Ta k e a w a y w a r n i n g Door status changes
from open to close
• Ignition switch: Other than LOCK and OFF.
• Door switch: ON to OFF (Door status changes from open to close.)
• Registered Intelligent Key is not detected inside the vehicle.
Door status is open • Ignition switch: Other than LOCK and OFF.
• Door switch: ON (Door is open.)
• Registered Intelligent Key is not detected inside the vehicle during Key
ID verification for 5 seconds.
Push-button ignition
switch operation • Ignition switch: Other than LOCK position.
• Push-button ignition switch is pressed.
• Registered Intelligent Key is not detected inside the vehicle.
Door lock operation warning Door lock operation is requested while door lock operation condition of
door request switch is not satisfied.
Engine start information Ignition switch is ON po-
sition
• Ignition switch: ON position
• Shift position: P
• Engine is stopped.
Ignition switch is other
than ON position • Ignition switch: Other than ON.
• Shift position: P
• Intelligent Key is in the passenger room after driver door is opened and
closed.
Ignition switch is ON po-
sition to OFF position • Ignition switch: ON position to OFF position.
• Shift position: P position
NOTE:
Engine start information turns ON for several seconds and then turns OFF,
when ignition switch is turned to the ON position from the OFF position. En-
gine start information does not turn ON until opening and closing of driver
door is detected again.
Intelligent Key low battery warning BCM detects that Intelligent Key is low battery, after ignition switch is turned
ON.
Key ID warning • Push-button ignition switch is pressed.
• Registered Intelligent Key is not detected inside the vehicle.
Revision: August 2015
2016 Versa Note

cardiagn.com

Page 718 of 3641

NISSAN NOTE 2016 Service Repair Manual SYSTEM (INTELLIGENT KEY SYSTEM)DLK-29
< SYSTEM DESCRIPTION > [WITH INTELLIGENT KEY SYSTEM]
C
D
E
F
G H
I
J
L
M A
B
DLK
N
O P
LIST OF OPERATION RELATED PARTS
Parts marked with × are the parts relate

Page 719 of 3641

NISSAN NOTE 2016 Service Repair Manual DLK-30
< SYSTEM DESCRIPTION >[WITH INTELLIGENT KEY SYSTEM]
DIAGNOSIS SYSTEM (BCM)
DIAGNOSIS SYSTEM (BCM)
COMMON ITEM
COMMON ITEM : CONSULT Fu
nction (BCM - COMMON ITEM)INFOID:0000000012542542
APPLICAT

Page 720 of 3641

NISSAN NOTE 2016 Service Repair Manual DIAGNOSIS SYSTEM (BCM)DLK-31
< SYSTEM DESCRIPTION > [WITH INTELLIGENT KEY SYSTEM]
C
D
E
F
G H
I
J
L
M A
B
DLK
N
O P
DOOR LOCK
DOOR LOCK : CONSULT Func tion (BCM - DOOR LOCK)INFOID:0000000012542543
DAT

DIAGNOSIS SYSTEM (BCM)DLK-31
< SYSTEM DESCRIPTION > [WITH INTELLIGENT KEY SYSTEM]
C
D
E
F
G H
I
J
L
M A
B
DLK
N
O P
DOOR LOCK
DOOR LOCK : CONSULT Func tion (BCM - DOOR LOCK)INFOID:0000000012542543
DATA MONITOR
ACTIVE TEST
WORK SUPPORT
*: Initial setting
INTELLIGENT KEY
INTELLIGENT KEY : CONSULT Func tion (BCM - INTELLIGENT KEY)INFOID:0000000012542544
SELF DIAGNOSTIC RESULT
Refer to BCS-50, "DTCIndex".
Monitor Item [Unit] Description
REQ SW -DR [On/Off] Indicates condition of door request switch LH.
REQ SW -AS [On/Off] Indicates condition of door request switch RH.
REQ SW -BD/TR [On/Off] Indicates condition of back door request switch.
DOOR SW-DR [On/Off] Indicates condition of front door switch LH.
DOOR SW-AS [On/Off] Indicates condition of front door switch RH.
DOOR SW-RR [On/Off] Indicates condition of rear door switch RH.
DOOR SW-RL [On/Off] Indicates condition of rear door switch LH.
DOOR SW-BK [On/Off] Indicates condition of back door switch.
CDL LOCK SW [On/Off] Indicates condition of lock signal from door lock and unlock switch.
CDL UNLOCK SW [On/Off] Indicates condition of unlock signal from door lock and unlock switch.
KEY CYL LK-SW [On/Off] Indicates condition of lock signal from door key cylinder switch.
KEY CYL UN-SW [On/Off] Indicates condition of unlock signal from door key cylinder switch.
Test Item Description
DOOR LOCK This test is able to check door lock operation [OTR ULK/AS UNLK/DR UNLK/ALL UNLK/ALL
LOCK].
Support Item
Setting Description
DOOR LOCK-UNLOCK SET On*
Automatic door locks function ON.
Off Automatic door locks function OFF.
AUTOMATIC LOCK/UNLOCK
SELECT Lock/Unlock* Automatic door locks function operates in lock and unlock.
Lock Only Automatic door locks function operates in lock only.
Unlock Only Automatic door locks function operates in unlock only.
Off
Automatic door locks function OFF.
AUTOMATIC DOOR LOCK SELECT P RANGE Doors lock automatically when shifted out of Park (P).
VH SPD* Doors lock automatically when vehicle speed reaches 24 km/h (15 mph).
AUTOMATIC DOOR UNLOCK
SELECT MODE6* Drivers door unlocks automatically when key is removed.
MODE5 Drivers door unlocks automatically when shifted into Park (P).
MODE4 Drivers door unlocks automatically when ignition is switched from ON to OFF.
MODE3 Doors unlock automatically when key is removed.
MODE2 Doors unlock automatically when shifted into Park (P).
MODE1 Doors unlock automatically when ignition is switched from ON to OFF.
Revision: August 2015
2016 Versa Note

cardiagn.com

Load next 8 pages

Page: < prev 1-10 ... 681-688 689-696 697-704 705-712 713-720 721-728 729-736 737-744 745-752 ... 3648 next >

dead battery odometer MPG fuel reserve headlamp dashboard
