Page 3001 of 3641

NISSAN NOTE 2016 Service Repair Manual SEC-144
< DTC/CIRCUIT DIAGNOSIS >[WITHOUT INTELLIGENT KEY SYSTEM]
B2190, P1614 NATS ANTENNA AMP.
B2190, P1614 NATS ANTENNA AMP.
DescriptionINFOID:0000000012430468
Performs ID verification through BCM

Page 3002 of 3641

NISSAN NOTE 2016 Service Repair Manual B2190, P1614 NATS ANTENNA AMP.SEC-145
< DTC/CIRCUIT DIAGNOSIS > [WITHOUT INTELLIGENT KEY SYSTEM]
C
D
E
F
G H
I
J
L
M A
B
SEC
N
O P
Is the inspection result normal?
YES >> GO TO 4.
NO >> Repair or repl

Page 3003 of 3641

NISSAN NOTE 2016 Service Repair Manual SEC-146
< DTC/CIRCUIT DIAGNOSIS >[WITHOUT INTELLIGENT KEY SYSTEM]
B2190, P1614 NATS ANTENNA AMP.
Is the inspection result normal?
YES >> NATS antenna amp. is malfunctioning. Replace NATS antenna amp.

Page 3004 of 3641

NISSAN NOTE 2016 Service Repair Manual B2191, P1615 DIFFERENCE OF KEYSEC-147
< DTC/CIRCUIT DIAGNOSIS > [WITHOUT INTELLIGENT KEY SYSTEM]
C
D
E
F
G H
I
J
L
M A
B
SEC
N
O P
B2191, P1615 DIFFERENCE OF KEY
DescriptionINFOID:0000000012430471
Per

Page 3005 of 3641

NISSAN NOTE 2016 Service Repair Manual SEC-148
< DTC/CIRCUIT DIAGNOSIS >[WITHOUT INTELLIGENT KEY SYSTEM]
B2192, P1611 ID DI
SCORD, IMMU-ECM
B2192, P1611 ID DISCORD, IMMU-ECM
DescriptionINFOID:0000000012430474
BCM performs the ID verificati

SEC-148
< DTC/CIRCUIT DIAGNOSIS >[WITHOUT INTELLIGENT KEY SYSTEM]
B2192, P1611 ID DI
SCORD, IMMU-ECM
B2192, P1611 ID DISCORD, IMMU-ECM
DescriptionINFOID:0000000012430474
BCM performs the ID verification with ECM that allows the engine to start. BCM starts the communication with
ECM if ignition switch is turned ON and starts the engine if the ID is OK. ECM prevents the engine from start-
ing if the ID is not registered.
DTC LogicINFOID:0000000012430475
DTC DETECTION LOGIC
NOTE:
• If DTC B2192 is displayed with DTC U1000, first perform the trouble diagnosis for DTC U1000. Refer to BCS-127, "
DTC Logic".
• If DTC B2192 is displayed with DTC U1010, first perform the trouble diagnosis for DTC U1010. Refer to
BCS-128, "
DTC Logic".
DTC CONFIRMATION PROCEDURE
1.PERFORM DTC CONFIRMATION PROCEDURE
1. Turn ignition switch ON.
2. Check “Self Diagnostic Result” using CONSULT.
Is DTC detected?
YES >> Refer to SEC-148, "Diagnosis Procedure".
NO >> Inspection End.
Diagnosis ProcedureINFOID:0000000012430476
1.PERFORM INITIALIZATION
Perform initialization with CONSULT. Re-register all mechanical keys.
For initialization and registration of mechanical key, refer to CONSULT Immobilizer mode and follow the on-
screen instructions.
Can the system be initialized and can the engine be started with re-registered mechanical key?
YES >> ID was unregistered.
NO >> GO TO 2.
2.REPLACE BCM
1. Replace BCM. Refer to BCS-137, "
Removal and Installation".
2. Perform initialization with CONSULT. Re-register all mechanical keys. For initialization and registration of mechanical key, refer to CONSULT Immobilizer mode and follow the
on-screen instructions.
Can the system be initialized and can the engine be started with re-registered mechanical key?
YES >> BCM is malfunctioning.
NO >> GO TO 3.
3.REPLACE ECM
1. Replace ECM. Refer to EC-477, "
Removal and Installation".
2. Perform initialization with CONSULT. Re-register all mechanical keys.
For initialization and registration of mechanical key, refer to CONSULT Immobilizer mode and follow the
on-screen instructions.
Can the system be initialized and can the engine be started with re-registered mechanical key?
YES >> ECM is malfunctioning.
NO >> GO TO 4.
DTC No. Trouble diagnosis
name DTC detecting condition
Possible cause
B2192 ID DISCORD BCM-
ECM The ID verification results between BCM and ECM
are NG. The registration is necessary. •BCM
•ECM
P1611
Revision: August 2015 2016 Versa Note

cardiagn.com

Page 3006 of 3641

NISSAN NOTE 2016 Service Repair Manual B2192, P1611 ID DISCORD, IMMU-ECMSEC-149
< DTC/CIRCUIT DIAGNOSIS > [WITHOUT INTELLIGENT KEY SYSTEM]
C
D
E
F
G H
I
J
L
M A
B
SEC
N
O P
4.CHECK INTERMITTENT INCIDENT
Refer to GI-42, "
Intermittent Inci

Page 3007 of 3641

NISSAN NOTE 2016 Service Repair Manual SEC-150
< DTC/CIRCUIT DIAGNOSIS >[WITHOUT INTELLIGENT KEY SYSTEM]
B2193, P1612 CH
AIN OF ECM-IMMU
B2193, P1612 CHAIN OF ECM-IMMU
DescriptionINFOID:0000000012430477
BCM performs the ID verification wit

Page 3008 of 3641

NISSAN NOTE 2016 Service Repair Manual B2195 ANTI-SCANNINGSEC-151
< DTC/CIRCUIT DIAGNOSIS > [WITHOUT INTELLIGENT KEY SYSTEM]
C
D
E
F
G H
I
J
L
M A
B
SEC
N
O P
B2195 ANTI-SCANNING
DTC LogicINFOID:0000000012430480
DTC DETECTION LOGIC
DTC CON
