AV-12
< SYSTEM DESCRIPTION >[BASE AUDIO]
SYSTEM
SYSTEM
System DescriptionINFOID:0000000012432870
SYSTEM DIAGRAM
AUDIO SYSTEM
The audio system consists of the following components
• Audio unit
• Front door speakers
• Rear door speakers
• Steering wheel audio control switches
• Antenna base (antenna amp.)
• Rod antenna
When the audio system is on, AM/FM signals received
by the rod antenna are amplified by the antenna amp.
and sent to the audio unit. The audio unit then sends audio signals to the front door speakers and rear door
speakers.
Refer to Owner's Manual for audio system operating instructions.
HANDS-FREE PHONE SYSTEM
System Operation
NOTE:
Cellular telephones must have their wireless connec tion set up (paired) before using the Bluetooth
® telephone
system.
The Bluetooth
® telephone system allows users who have a Bluetooth® cellular telephone to make a wireless
connection between their cellular telephone and the Bluetooth
® control unit. Hands-free cellular telephone
calls can be sent and received. Some Bluetooth
® cellular telephones may not be recognized by the Bluetooth®
control unit. When a cellular telephone or the Bluetooth® control unit is replaced, the telephone must be paired
with the Bluetooth
® control unit. Different cellular telephones may have different pairing procedures, refer to
the cellular telephone operating manual.
Refer to the Owner's Manual for Bluetooth
® telephone system operating instructions.
Bluetooth® Control Unit
When the ignition switch is turned to ACC or ON, the Bluetooth® control unit will power up. During power up,
the Bluetooth
® control unit is initialized and performs various self-checks. Initialization may take up to 20 sec-
onds.
Steering Wheel Audio Control Switches
When buttons on the steering wheel audio control switches are pushed, the resistance in steering wheel audio
control switch circuit changes, depending on which button is pushed.
The following functions can be performed using the steering wheel audio control switches:
• Initiate self-diagnosis of the Bluetooth
® telephone system
• Answer and end telephone calls
AWNIA4134GB
Revision: August 2015 2016 Versa Note
cardiagn.com
Page 18 of 3641
AV
SYSTEMAV-13
< SYSTEM DESCRIPTION > [BASE AUDIO]
C
D
E
F
G H
I
J
K L
M B A
O P
• Adjust the volume of calls
Microphone
The microphone is located in the roof console asse mbly. The microphone sends a signal to the Bluetooth®
control unit. The microphone can be actively tested during self-diagnosis.
Audio Unit
The audio unit receives signals from the Bluetooth® control unit and sends audio signals to the speakers.
SPEED SENSITIVE VOLUME SYSTEM
Volume level of this system goes up and down automatica lly in proportion to the vehicle speed. The control
level can be selected by the customer. Refer to Owner's Manual for operating instructions.
Revision: August 2015 2016 Versa Note
cardiagn.com
Page 19 of 3641
![NISSAN NOTE 2016 Service Repair Manual AV-14
< SYSTEM DESCRIPTION >[BASE AUDIO]
DIAGNOSIS SYSTEM (AUDIO UNIT)
DIAGNOSIS SYSTEM (AUDIO UNIT)
Diagnosis DescriptionINFOID:0000000012432871
The audio unit on board diagnosis performs the functio NISSAN NOTE 2016 Service Repair Manual AV-14
< SYSTEM DESCRIPTION >[BASE AUDIO]
DIAGNOSIS SYSTEM (AUDIO UNIT)
DIAGNOSIS SYSTEM (AUDIO UNIT)
Diagnosis DescriptionINFOID:0000000012432871
The audio unit on board diagnosis performs the functio](/manual-img/5/57363/w960_57363-18.png)
AV-14
< SYSTEM DESCRIPTION >[BASE AUDIO]
DIAGNOSIS SYSTEM (AUDIO UNIT)
DIAGNOSIS SYSTEM (AUDIO UNIT)
Diagnosis DescriptionINFOID:0000000012432871
The audio unit on board diagnosis performs the functions listed in the table below:
On Board Diagn
osis FunctionINFOID:0000000012432872
METHOD OF STARTING
Hardware/Software Versions and Speaker Channel Check
1. Turn the ignition ON.
2. Turn the audio system OFF.
3. While pressing the preset 1 butt on, turn the volume control dial
clockwise or counterclockwise 30 clicks or more.
4. Initially, all display segments will be illuminated.
5. To exit hardware/software versions and speaker channel check, turn the ignition OFF.
Communication Diagnosis
1. Turn the ignition ON.
2. Turn the audio system OFF.
Mode Description
Hardware/Software Versions The following information is available for the audio unit:
• hardware version.
• software version.
• EQ pin info.
Speaker Channel Check The connection of the speakers to the audio unit can be confirmed.
Communication Diagnosis The AV communication (M-CAN) message history can be monitored.
AWNIA3042ZZ
ALNIA1382GB
Revision: August 2015 2016 Versa Note
cardiagn.com
Page 20 of 3641
AV
DIAGNOSIS SYSTEM (AUDIO UNIT)AV-15
< SYSTEM DESCRIPTION > [BASE AUDIO]
C
D
E
F
G H
I
J
K L
M B A
O P
3. While pressing the preset 6 button, turn the volume control dial clockwise or counterclockwise 30 clicks or more.
4. Initially, the communication diagnosis mode is displayed.
5. To exit communication diagnosis, turn the ignition OFF.
SELF DIAGNOSIS MODE
Hardware/Software Versions
1. Press the DISP button to enter versions display, and the audio head unit software version is displayed.
2. With each additional press of the DISP button, the following information is available:
- HARD V###### (hardware version)
- EEP V###### (EEPROM version)
- @@@@ EQ1-4 # (EQ pin info) If an EQ error is present, INVALID EQ is displayed
3. Hold the DISP button down to return to all display segments screen.
Speaker Channel Check
ALNIA1516ZZ
ALNIA1387GB
ALNIA1383GB
Revision: August 2015 2016 Versa Note
cardiagn.com
Page 21 of 3641
![NISSAN NOTE 2016 Service Repair Manual AV-16
< SYSTEM DESCRIPTION >[BASE AUDIO]
DIAGNOSIS SYSTEM (AUDIO UNIT)
1. Press the RPT/DRM button to enter speaker channel check, and
the front left tweeter (front tweeter LH) is displayed.
2. With e NISSAN NOTE 2016 Service Repair Manual AV-16
< SYSTEM DESCRIPTION >[BASE AUDIO]
DIAGNOSIS SYSTEM (AUDIO UNIT)
1. Press the RPT/DRM button to enter speaker channel check, and
the front left tweeter (front tweeter LH) is displayed.
2. With e](/manual-img/5/57363/w960_57363-20.png)
AV-16
< SYSTEM DESCRIPTION >[BASE AUDIO]
DIAGNOSIS SYSTEM (AUDIO UNIT)
1. Press the RPT/DRM button to enter speaker channel check, and
the front left tweeter (front tweeter LH) is displayed.
2. With each additional press of the RPT/DRM button, the following information is available:
- FR RIGHT TWEETER (front tweeter RH)
- FR RIGHT (front door speaker RH)
- RR RIGHT (rear speaker RH)
- RR LEFT (rear speaker LH)
- FR LEFT (front door speaker LH)
3. Hold the RPT/DRM button down to return to all display segments screen.
Communication Diagnosis
1. Press the DISP button, and the M-CAN message transmission error history screen is displayed.
2. Press the DISP button again, and the TEL $$ nn (CMF message reception error history from M-CAN TEL)
screen is displayed.
3. Press the DISP button again, and the TROUBLE DE L. (deletion of M-CAN message communication his-
tory) screen is displayed. To retain the M-CAN message communication history and return to the commu-
nication diagnosis mode screen, press the DISP button.
4. To proceed to the M-CAN message communication history deletion screen, press the SEEK/TRACK button. The REC DEL-NO? (selection of M-CAN mess age communication history deletion) screen is dis-
played. To cancel M-CAN message communication hi story deletion, wait 6 seconds and you will be
returned to the TROUBLE DEL. (deletion of M-CAN message communication history) screen. To proceed
with M-CAN message communication history del etion, press the SEEK/TRACK button again.
5. The REC DEL-YES?@ (selection of M-CAN message communication history deletion) screen is dis-
played. To cancel M-CAN message communication hi story deletion, press the SEEK/TRACK button
and you will be returned to the REC DEL-NO? (selec tion of M-CAN message communication history dele-
tion) screen. To proceed with M-CAN message communication history deletion, wait 6 seconds and the
communication history deletion will be executed. Af ter the communication history deletion has been exe-
cuted, you will be returned to the TROUBLE DEL. (deletion of M-CAN message communication history)
screen. To return to the communication di agnosis mode screen, press the DISP button.
ALNIA1384GB
ALNIA1386GB
Revision: August 2015 2016 Versa Note
cardiagn.com
Page 22 of 3641
![NISSAN NOTE 2016 Service Repair Manual AV
DIAGNOSIS SYSTEM (BLUETOOTH® CONTROL UNIT)AV-17
< SYSTEM DESCRIPTION > [BASE AUDIO]
C
D
E
F
G H
I
J
K L
M B A
O P
DIAGNOSIS SYSTEM (BLU ETOOTH® CONTROL UNIT)
Diagnosis DescriptionINFOID:000000001 NISSAN NOTE 2016 Service Repair Manual AV
DIAGNOSIS SYSTEM (BLUETOOTH® CONTROL UNIT)AV-17
< SYSTEM DESCRIPTION > [BASE AUDIO]
C
D
E
F
G H
I
J
K L
M B A
O P
DIAGNOSIS SYSTEM (BLU ETOOTH® CONTROL UNIT)
Diagnosis DescriptionINFOID:000000001](/manual-img/5/57363/w960_57363-21.png)
AV
DIAGNOSIS SYSTEM (BLUETOOTH® CONTROL UNIT)AV-17
< SYSTEM DESCRIPTION > [BASE AUDIO]
C
D
E
F
G H
I
J
K L
M B A
O P
DIAGNOSIS SYSTEM (BLU ETOOTH® CONTROL UNIT)
Diagnosis DescriptionINFOID:0000000012432873
The Bluetooth® control unit has two diagnostic checks. The fi rst diagnostic check is performed automatically
every ignition cycle during control unit initialization. The second diagnostic check is performed by the techni-
cian using the steering wheel audio control switches prior to trouble diagnosis.
BLUETOOTH® CONTROL UNIT INITIALIZATION CHECKS
• Internal control unit failure
• Bluetooth
® antenna connection open or shorted
• Steering wheel audio control switches [ (PHONE/SEND), (PHONE/END)] stuck closed
• Vehicle speed pulse count
• Microphone connection test (with playback to operator)
• Bluetooth
® inquiry check
OPERATION PROCEDURE
1. Turn ignition switch to ACC or ON.
2. Wait for the Bluetooth
® system to complete initialization. This may take up to 20 seconds.
3. Press and hold the steering wheel audio control switch (PHONE/SEND) button for at least 5 seconds. The Bluetooth
®
system will begin to play a verbal prompt.
4. While the prompt is playing, press and hold the steering wheel audio control switch (PHONE/END) button until you hear the
“Diagnostics mode” prompt. The Bluetooth
® system will sound a
5-second beep.
5. While the beep is sounding, press and hold the steering wheel
audio control switch (PHONE/END) button again until you
hear prompts.
6. The Bluetooth
® system has now entered into the diagnostic
mode. Results of the diagnostic checks will be verbalized to the
technician. Refer to AV-17, "
Work Flow".
7. After the failure records are reported, an interactive microphone test will be performed. Follow the voice prompt. If the micro-
phone test fails, refer to AV-17, "
Work Flow".
Work FlowINFOID:0000000012432874
AWNIA3082ZZ
AWNIA3083ZZ
Failure Message Action
“Internal failure” Replace Bluetooth
® control unit. Refer to AV- 5 6 , "Removal and Installation".
“Bluetooth
® antenna open” 1. Inspect harness connection.
2. Replace Bluetooth
® antenna. Refer to AV- 5 7 , "Removal and Installation".
“Bluetooth® antenna shorted”
“Phone/Send for Hands Free System is stuck” Check steering switches. Refer to AV- 4 6 , "
Diagnosis Procedure".
“Phone/End for the Hands Free System is stuck”
“Microphone test” (fai led interactive test) 1. Inspect harness between Bluetooth
® control unit and microphone.
2. Replace microphone. Refer to AV-59, "
Removal and Installation" .
Revision: August 2015 2016 Versa Note
cardiagn.com
Page 23 of 3641
AV-18
< ECU DIAGNOSIS INFORMATION >[BASE AUDIO]
AUDIO UNIT
ECU DIAGNOSIS INFORMATION
AUDIO UNIT
Reference ValueINFOID:0000000012432875
TERMINAL LAYOUT
PHYSICAL VALUES
AWNIA3649ZZ
Te r m i n a l
(Wire color) Description
Condition
Reference value
(Approx.)
+ – Signal nameInput/
Output Ignition
switch Operation
2
(GR) 3
(P) Sound signal front speaker
LH
Output ON Sound output.
4
(W) 5
(R) Sound signal rear speaker
LH
Output ON Sound output.
6
(BR) 15
(GR) Steering switch signal A Input ON Press SOURCE switch
0V
Press switch 1.0V
Press switch 2.0V
Press switch 3.0V
Except above 5.0V
7
(W) Ground ACC power supply
Input ACC—Battery voltage
9
(R) 8
(B) Illumination control signal Input ON Headlamps ON.
Battery voltage
SKIA0177E
SKIA0177E
Revision: August 2015 2016 Versa Note
cardiagn.com
Page 24 of 3641
![NISSAN NOTE 2016 Service Repair Manual AV
AUDIO UNITAV-19
< ECU DIAGNOSIS INFORMATION > [BASE AUDIO]
C
D
E
F
G H
I
J
K L
M B A
O P11
(BG) 12
(V) Sound signal front speaker
RH
Output ON Sound output.
13
(L) 14
(Y) Sound signal rear sp NISSAN NOTE 2016 Service Repair Manual AV
AUDIO UNITAV-19
< ECU DIAGNOSIS INFORMATION > [BASE AUDIO]
C
D
E
F
G H
I
J
K L
M B A
O P11
(BG) 12
(V) Sound signal front speaker
RH
Output ON Sound output.
13
(L) 14
(Y) Sound signal rear sp](/manual-img/5/57363/w960_57363-23.png)
AV
AUDIO UNITAV-19
< ECU DIAGNOSIS INFORMATION > [BASE AUDIO]
C
D
E
F
G H
I
J
K L
M B A
O P11
(BG) 12
(V) Sound signal front speaker
RH
Output ON Sound output.
13
(L) 14
(Y) Sound signal rear speaker
RH
Output ON Sound output.
16
(V) 15
(GR) Steering switch signal B Input ON Press switch
0V
Press switch 1.0V
Press switch 2.0V
Except above 5.0V
18
(LG) Ground Vehicle speed signal Input ON When vehicle speed is ap-
prox. 40 km/h (25 MPH).
19
(Y) Ground Battery power supply Input OFF
—Battery voltage
22
(B) Ground EQ2 Ground
— ON— 0 V
24
(B) Ground EQ4 Ground
— ON— 0 V
27
(SB) — AV communication (H)
Input/
Output ——
—
28
(LG) — AV communication (L) Input/
Output ——
—
29
(P) Ground TEL ON
Output ON— —
30
(Shield) — TEL voice signal shield — —
——
32
(G) 31
(R) TEL voice signal
Input ONDuring voice guide output
with switch pressed.
Te r m i n a l
(Wire color) Description
Condition
Reference value
(Approx.)
+ – Signal nameInput/
Output Ignition
switch Operation
SKIA0177E
SKIA0177E
JSNIA0012GB
SKIB3609E
Revision: August 2015
2016 Versa Note
cardiagn.com
