< WIRING DIAGRAM > [TYPE B]
C
D
E
F
G H
I
J
K L
M B A
O P
ABNIA8055GB
Revision: August 2015 2016 Versa Note
cardiagn.com
Page 2450 of 3641
![NISSAN NOTE 2016 Service Repair Manual MWI-92
< BASIC INSPECTION >[TYPE B]
DIAGNOSIS AND REPAIR WORK FLOW
BASIC INSPECTION
DIAGNOSIS AND REPAIR WORK FLOW
Work FlowINFOID:0000000012432618
OVERALL SEQUENCE
DETAILED FLOW
1.CONFIRM SYMPTOM
Con NISSAN NOTE 2016 Service Repair Manual MWI-92
< BASIC INSPECTION >[TYPE B]
DIAGNOSIS AND REPAIR WORK FLOW
BASIC INSPECTION
DIAGNOSIS AND REPAIR WORK FLOW
Work FlowINFOID:0000000012432618
OVERALL SEQUENCE
DETAILED FLOW
1.CONFIRM SYMPTOM
Con](/manual-img/5/57363/w960_57363-2449.png)
MWI-92
< BASIC INSPECTION >[TYPE B]
DIAGNOSIS AND REPAIR WORK FLOW
BASIC INSPECTION
DIAGNOSIS AND REPAIR WORK FLOW
Work FlowINFOID:0000000012432618
OVERALL SEQUENCE
DETAILED FLOW
1.CONFIRM SYMPTOM
Confirm symptom or customer complaint.
>> GO TO 2.
2.SELF-DIAGNOSIS OF COMBINATION METER
Perform self-diagnosis of combination meter. Refer to MWI-69, "
On Board Diagnosis Function".
Is the inspection result normal?
YES >> GO TO 3.
NO >> If self-diagnosis will not start, check power supply and ground circuit of combination meter. Refer to MWI-98, "
COMBINATION METER : Diagnosis Procedure". If power supply and ground circuits
are OK, replace combination meter. Refer to MWI-115, "
Removal and Installation".
3.CHECK COMBINATION METER WITH CONSULT
Select METER/M&A on CONSULT and perform self-d iagnosis of combination meter. Refer to MWI-71, "
CON-
SULT Function (METER/M&A)".
Is the inspection result normal?
YES >> Check symptom. GO TO 4.
NO >> Refer to MWI-77, "
DTC Index".
4.CHECK SYSTEM OPERATION
Check the combination meter to verify that the repair has been completed successfully.
Is the inspection result normal?
YES >> Inspection End.
NO >> GO TO 1.
AWNIA2458GB
Revision: August 2015 2016 Versa Note
cardiagn.com
Page 2451 of 3641
MWI
U1000 CAN COMM CIRCUITMWI-93
< DTC/CIRCUIT DIAGNOSIS > [TYPE B]
C
D
E
F
G H
I
J
K L
M B A
O P
DTC/CIRCUIT DIAGNOSIS
U1000 CAN COMM CIRCUIT
DTC LogicINFOID:0000000012432619
DTC DETECTION LOGIC
Diagnosis ProcedureINFOID:0000000012432620
1.CHECK CAN COMMUNICATION
Select SELF-DIAG RESULTS m ode for METER/M&A with CONSULT.
>> GO TO LAN system. Refer to LAN-16, "
Trouble Diagnosis Flow Chart".
DTC Display Item Malfunction detected condition Possible malfunction
U1000 CAN COMM CIRC
[U1000] When combination meter is not transmitting or receiving CAN
communication signals for 2 seconds or more.
CAN communication system
Revision: August 2015
2016 Versa Note
cardiagn.com
Page 2452 of 3641
MWI-94
< DTC/CIRCUIT DIAGNOSIS >[TYPE B]
U1010 CONTROL UNIT (CAN)
U1010 CONTROL UNIT (CAN)
DescriptionINFOID:0000000012432621
Initial diagnosis of combination meter.
DTC LogicINFOID:0000000012432622
DTC DETECTION LOGIC
Diagnosis ProcedureINFOID:0000000012432623
1.REPLACE COMBINATION METER
When DTC U1010 is detected, replace combination meter. Refer to MWI-115, "
Removal and Installation".
>> Inspection End.
DTC Display Item Malfunction detected condition Possible malfunction
U1010 CONTROL UNIT (CAN)
[U1010] When detecting error during the initial diagnosis of
the CAN controller of combination meter.
Combination meter
Revision: August 2015
2016 Versa Note
cardiagn.com
Page 2453 of 3641
![NISSAN NOTE 2016 Service Repair Manual MWI
B2205 VEHICLE SPEEDMWI-95
< DTC/CIRCUIT DIAGNOSIS > [TYPE B]
C
D
E
F
G H
I
J
K L
M B A
O P
B2205 VEHICLE SPEED
DescriptionINFOID:0000000012432624
The ABS actuator and electric unit (control unit) NISSAN NOTE 2016 Service Repair Manual MWI
B2205 VEHICLE SPEEDMWI-95
< DTC/CIRCUIT DIAGNOSIS > [TYPE B]
C
D
E
F
G H
I
J
K L
M B A
O P
B2205 VEHICLE SPEED
DescriptionINFOID:0000000012432624
The ABS actuator and electric unit (control unit)](/manual-img/5/57363/w960_57363-2452.png)
MWI
B2205 VEHICLE SPEEDMWI-95
< DTC/CIRCUIT DIAGNOSIS > [TYPE B]
C
D
E
F
G H
I
J
K L
M B A
O P
B2205 VEHICLE SPEED
DescriptionINFOID:0000000012432624
The ABS actuator and electric unit (control unit) provi des a vehicle speed signal to the combination meter via
CAN communication lines.
DTC LogicINFOID:0000000012432625
DTC DETECTION LOGIC
Diagnosis ProcedureINFOID:0000000012432626
1.CHECK COMBINATION METER INPUT SIGNAL
1. Start engine and select METER/M&A on CONSULT.
2. Using SPEED METER on DATA MONITOR, compar e the value of DATA MONITOR with speedometer
pointer of combination meter. Speedometer and DATA MONITOR indications should be close.
Is the inspection result normal?
YES >> Perform ABS actuator and electric unit (control unit) self-diagnosis. Refer to BRC-31, "CONSULT
Function (ABS)".
NO >> Replace combination meter. Refer to MWI-115, "
Removal and Installation".
DTC Display Item Malfunction detected condition Possible malfunction
B2205 VEHICLE SPEED CIRC
[B2205] Malfunction is detected when an erroneous
speed signal is received for 2 seconds or
more. • Combination meter
• ABS actuator and electric unit (control unit)
Revision: August 2015
2016 Versa Note
cardiagn.com
Page 2454 of 3641
MWI-96
< DTC/CIRCUIT DIAGNOSIS >[TYPE B]
B2267 ENGINE SPEED
B2267 ENGINE SPEED
DescriptionINFOID:0000000012432627
The engine speed signal is transmitted from ECM to
the combination meter via CAN communication.
DTC LogicINFOID:0000000012432628
DTC DETECTION LOGIC
Diagnosis ProcedureINFOID:0000000012432629
1.PERFORM SELF-DIAGNOSIS OF ECM
Perform Self Diagnostic Result of ECM, and repair or replace malfunctioning parts.
>> Refer to EC-60, "
CONSULT Function".
DTC Display Item Malfunction detected condition Possible malfunction
B2267 TACHO METER
[B2267] ECM continuously transmits abnormal engine
speed signals for 2 seconds or more • Crankshaft position sensor (POS)
•ECM
Revision: August 2015
2016 Versa Note
cardiagn.com
Page 2455 of 3641
MWI
B2268 WATER TEMPMWI-97
< DTC/CIRCUIT DIAGNOSIS > [TYPE B]
C
D
E
F
G H
I
J
K L
M B A
O P
B2268 WATER TEMP
DescriptionINFOID:0000000012432630
The engine coolant temperature signal is transmitted fr om ECM to the combination meter via CAN communi-
cation.
DTC LogicINFOID:0000000012432631
DTC DETECTION LOGIC
Diagnosis ProcedureINFOID:0000000012432632
1.PERFORM SELF-DIAGNOSIS OF ECM
Perform Self Diagnostic Result of ECM, and repair or replace malfunctioning parts.
>> Refer to EC-60, "
CONSULT Function".
DTC Display Item Malfunction detected condition Possible malfunction
B2268 WATER TEMP METER
[B2268] ECM continuously transmits abnormal engine coolant
temperature signals for 60 seconds or more • Engine coolant temperature sensor
•ECM
Revision: August 2015
2016 Versa Note
cardiagn.com
Page 2456 of 3641
![NISSAN NOTE 2016 Service Repair Manual MWI-98
< DTC/CIRCUIT DIAGNOSIS >[TYPE B]
POWER SUPPLY AND GROUND CIRCUIT
POWER SUPPLY AND GROUND CIRCUIT
COMBINATION METER
COMBINATION METER : Diagnosis ProcedureINFOID:0000000012432633
Regarding Wiri NISSAN NOTE 2016 Service Repair Manual MWI-98
< DTC/CIRCUIT DIAGNOSIS >[TYPE B]
POWER SUPPLY AND GROUND CIRCUIT
POWER SUPPLY AND GROUND CIRCUIT
COMBINATION METER
COMBINATION METER : Diagnosis ProcedureINFOID:0000000012432633
Regarding Wiri](/manual-img/5/57363/w960_57363-2455.png)
MWI-98
< DTC/CIRCUIT DIAGNOSIS >[TYPE B]
POWER SUPPLY AND GROUND CIRCUIT
POWER SUPPLY AND GROUND CIRCUIT
COMBINATION METER
COMBINATION METER : Diagnosis ProcedureINFOID:0000000012432633
Regarding Wiring Diagram information, refer to
MWI-79, "Wiring Diagram".
1.CHECK FUSE
Check that the following fuses are not blown.
Is the fuse blown?
YES >> Replace the blown fuse after repairing the affected circuit.
NO >> GO TO 2.
2.POWER SUPPLY CIRCUIT CHECK
1. Disconnect combination meter connector.
2. Check voltage between combination meter harne ss connector M24, terminals 27, 28, 15 and ground.
Is the inspection result normal?
YES >> GO TO 3.
NO >> Repair or replace harness or connector.
3.GROUND CIRCUIT CHECK
1. Turn ignition switch OFF.
2. Disconnect combination meter connector.
3. Check continuity between combination meter har ness connector M24, terminals 21, 22, 23 and ground.
Is the inspection result normal?
YES >> Inspection End.
NO >> Repair or replace harness or connector.
BCM (BODY CONTROL SYSTEM) (WIT HOUT INTELLIGENT KEY SYSTEM)
BCM (BODY CONTROL SYSTEM) (WITHOUT INTELLIGENT KEY SYSTEM) : Diag-
Power source Fuse No.
Battery 8
Ignition switch ON or START 3
Ignition switch ACC or ON 18
TerminalsIgnition switch position
(+) (–)OFF ACC ONSTART
Connector Terminal
M24 27
GroundBattery voltage Battery voltage Battery voltage Battery voltage
28 0V0VBattery voltage Battery voltage
15 0V Battery voltage Battery voltage 0V
Te r m i n a l s
Continuity
(+)
(–)
Connector Terminal
M24 21
Ground Yes
22
23
