Page 873 of 3641
DLK-184
< REMOVAL AND INSTALLATION >[WITH INTELLIGENT KEY SYSTEM]
OUTSIDE KEY ANTENNA
OUTSIDE KEY ANTENNA
OUTSIDE HANDLE
OUTSIDE HANDLE : Removal and InstallationINFOID:0000000012430142
REMOVAL
1. Remove outside handle. Refer to
DLK-170, "OUTSIDE HANDLE : Removal and Installation".
2. Remove screw (A) and outside handle finisher (1) from outside handle (2).
3. Remove outside key antenna (outside handle) (1) from outside handle (2).
INSTALLATION
Installation is in the reverse order of removal.
REAR BUMPER
REAR BUMPER : Removal and InstallationINFOID:0000000012430143
REMOVAL
1. Remove the rear bumper fascia. Refer to EXT-29, "Removal and Installation".
2. Disconnect the harness connector from the outside key antenna (rear bumper)
3. Release clips (A) and remove outside key antenna (rear bumper) (1).
INSTALLATION
Installation is in the reverse order of removal.
ALKIA3209ZZ
ALKIA3210ZZ
JMKIA7952ZZ
Revision: August 2015 2016 Versa Note
cardiagn.com
Page 874 of 3641
DOOR REQUEST SWITCHDLK-185
< REMOVAL AND INSTALLATION > [WITH INTELLIGENT KEY SYSTEM]
C
D
E
F
G H
I
J
L
M A
B
DLK
N
O P
DOOR REQUEST SWITCH
DRIVER SIDE
DRIVER SIDE : Removal and InstallationINFOID:0000000012430144
The door request switch (driver side) is serviced as an assembly with the outside handle. Refer to DLK-170,
"OUTSIDE HANDLE : Removal and Installation".
PASSENGER SIDE
PASSENGER SIDE : Removal and InstallationINFOID:0000000012430145
The door request switch (passenger side) is serviced as an assembly with the outside handle. Refer to DLK-
170, "OUTSIDE HANDLE : Removal and Installation".
BACK DOOR
BACK DOOR : Removal and InstallationINFOID:0000000012430146
REMOVAL
1. Remove back door outer finisher. Refer to EXT-48, "Removal and Installation".
2. Remove screws (A) and back door request switch (1) from back
door outer finisher (2).
INSTALLATION
Installation is in the reverse order of removal.
AWKIA2584ZZ
Revision: August 2015 2016 Versa Note
cardiagn.com
Page 875 of 3641
DLK-186
< REMOVAL AND INSTALLATION >[WITH INTELLIGENT KEY SYSTEM]
INTELLIGENT KEY WARNING BUZZER
INTELLIGENT KEY WARNING BUZZER
Removal and InstallationINFOID:0000000012430147
REMOVAL
1. Remove front combination lamp (LH). Refer to
EXL-102, "Removal and Installation"
2. Remove bolt (A) and Intelligent Key warning buzzer (1).
INSTALLATION
Installation is in the reverse order of removal.
JMKIA7949ZZ
Revision: August 2015 2016 Versa Note
cardiagn.com
Page 876 of 3641
REMOTE KEYLESS ENTRY RECEIVERDLK-187
< REMOVAL AND INSTALLATION > [WITH INTELLIGENT KEY SYSTEM]
C
D
E
F
G H
I
J
L
M A
B
DLK
N
O P
REMOTE KEYLESS ENTRY RECEIVER
Removal and InstallationINFOID:0000000012430148
REMOVAL
1. Remove glove box assembly. Refer to IP-25, "Removal and Installation".
2. Remove remote keyless entry receiver bolt (A).
3. Disconnect the harness connector and remove remote keyless entry receiver (1)
INSTALLATION
Installation is in the reverse order of removal.
JMKIA7947ZZ
Revision: August 2015 2016 Versa Note
cardiagn.com
Page 877 of 3641
![NISSAN NOTE 2016 Service Repair Manual DLK-188
< REMOVAL AND INSTALLATION >[WITH INTELLIGENT KEY SYSTEM]
INTELLIGENT KEY BATTERY
INTELLIGENT KEY BATTERY
Removal and InstallationINFOID:0000000012430149
1. Release the lock knob at the back o NISSAN NOTE 2016 Service Repair Manual DLK-188
< REMOVAL AND INSTALLATION >[WITH INTELLIGENT KEY SYSTEM]
INTELLIGENT KEY BATTERY
INTELLIGENT KEY BATTERY
Removal and InstallationINFOID:0000000012430149
1. Release the lock knob at the back o](/manual-img/5/57363/w960_57363-876.png)
DLK-188
< REMOVAL AND INSTALLATION >[WITH INTELLIGENT KEY SYSTEM]
INTELLIGENT KEY BATTERY
INTELLIGENT KEY BATTERY
Removal and InstallationINFOID:0000000012430149
1. Release the lock knob at the back of the Intelligent Key and remove the mechanical key.
2. Insert a suitable tool (A) wrapped wi
th a cloth into the slit of the
corner and rotate it to separate the upper part from the lower
part.
CAUTION:
• Do not touch the circuit board or battery terminal.
• The key fob is water-resistant. However, if it does get wet,
immediately wipe it dry.
3. Replace the battery with new one.
4. Align the tips of the upper and lower parts, and then push them together until it is securely closed.
CAUTION:
• When replacing battery, keep dirt, grease, and other for-eign materials off the electrode contact area.
• After replacing the battery, check that all Intelligent Key functions work normally.
PIIB6221E
Battery replacement :Coin-type lithium battery
(CR2025)
PIIB6222E
Revision: August 2015 2016 Versa Note
cardiagn.com
Page 878 of 3641
![NISSAN NOTE 2016 Service Repair Manual PRECAUTIONSDLK-189
< PRECAUTION > [WITHOUT INTELLIGENT KEY SYSTEM]
C
D
E
F
G H
I
J
L
M A
B
DLK
N
O P
PRECAUTION
PRECAUTIONS
Precaution for Supplemental Restraint System (SRS) "AIR BAG" and "SEAT BELT NISSAN NOTE 2016 Service Repair Manual PRECAUTIONSDLK-189
< PRECAUTION > [WITHOUT INTELLIGENT KEY SYSTEM]
C
D
E
F
G H
I
J
L
M A
B
DLK
N
O P
PRECAUTION
PRECAUTIONS
Precaution for Supplemental Restraint System (SRS) "AIR BAG" and "SEAT BELT](/manual-img/5/57363/w960_57363-877.png)
PRECAUTIONSDLK-189
< PRECAUTION > [WITHOUT INTELLIGENT KEY SYSTEM]
C
D
E
F
G H
I
J
L
M A
B
DLK
N
O P
PRECAUTION
PRECAUTIONS
Precaution for Supplemental Restraint System (SRS) "AIR BAG" and "SEAT BELT
PRE-TENSIONER"
INFOID:0000000012430150
The Supplemental Restraint System such as “AIR BAG” and “SEAT BELT PRE-TENSIONER”, used along
with a front seat belt, helps to reduce the risk or severi ty of injury to the driver and front passenger for certain
types of collision. Information necessary to service the system safely is included in the SR and SB section of
this Service Manual.
WARNING:
• To avoid rendering the SRS inoper ative, which could increase the risk of personal injury or death in
the event of a collision which would result in air bag inflation, all maintenance must be performed by
an authorized NISSAN/INFINITI dealer.
• Improper maintenance, including in correct removal and installation of the SRS, can lead to personal
injury caused by unintentional act ivation of the system. For removal of Spiral Cable and Air Bag
Module, see the SR section.
• Do not use electrical test equipm ent on any circuit related to the SRS unless instructed to in this
Service Manual. SRS wiring harnesses can be identi fied by yellow and/or orange harnesses or har-
ness connectors.
PRECAUTIONS WHEN USING POWER TOOLS (AIR OR ELECTRIC) AND HAMMERS
WARNING:
• When working near the Airbag Diagnosis Sensor Un it or other Airbag System sensors with the Igni-
tion ON or engine running, DO NOT use air or el ectric power tools or strike near the sensor(s) with a
hammer. Heavy vibration could activate the sensor( s) and deploy the air bag(s), possibly causing
serious injury.
• When using air or electric power tools or hammers, always switch the Ignition OFF, disconnect the
battery and wait at least three mi nutes before performing any service.
Procedure without Cowl Top CoverINFOID:0000000012430151
When performing the procedure after removing cowl top cover, cover
the lower end of windshield with urethane, etc. to prevent damage to
the windshield.
Precaution for Servicing Doors and LocksINFOID:0000000012430152
WARNING:
Radio waves could adversely affect electric medical equipment. Those who use a pacemaker should
contact the electric medical equipment manufacturer for the possible influences before use,
• After removing and installing the opening/closing parts, be sure to carry out fitting adjustments to check their operation.
• Check the lubrication level, damage, and wear of each part. If necessary, grease or replace it.
• When removing or disassembling each component, be ca reful not to damage or deform it. If a component
may be subject to interference, be sure to protect it with a shop cloth.
• When removing (disengaging) components with a screwdriver or similar tool, be sure to wrap the component
with a shop cloth or vinyl tape to protect it.
• Protect the removed parts with a shop cloth and prevent them from being dropped.
• Replace a deformed or damaged clip.
• If a part is specified as a non-reusabl e part, always replace it with a new one.
PIIB3706J
Revision: August 2015 2016 Versa Note
cardiagn.com
Page 879 of 3641
![NISSAN NOTE 2016 Service Repair Manual DLK-190
< PRECAUTION >[WITHOUT INTELLIGENT KEY SYSTEM]
PRECAUTIONS
• Be sure to tighten bolts and nuts securely to the specified torque.
• After installation is complete, be sure
to check that ea NISSAN NOTE 2016 Service Repair Manual DLK-190
< PRECAUTION >[WITHOUT INTELLIGENT KEY SYSTEM]
PRECAUTIONS
• Be sure to tighten bolts and nuts securely to the specified torque.
• After installation is complete, be sure
to check that ea](/manual-img/5/57363/w960_57363-878.png)
DLK-190
< PRECAUTION >[WITHOUT INTELLIGENT KEY SYSTEM]
PRECAUTIONS
• Be sure to tighten bolts and nuts securely to the specified torque.
• After installation is complete, be sure
to check that each part works properly.
• Follow the steps below to clean components:
- Water soluble dirt:
• Dip a soft cloth into lukewarm water, wring the water out of the cloth and wipe the dirty area.
• Then rub with a soft, dry cloth.
- Oily dirt:
• Dip a soft cloth into lukewarm water with mild detergent (concentration: within 2 to 3%) and wipe the dirty area.
• Then dip a cloth into fresh water, wring the water out of the cloth and wipe the detergent off.
• Then rub with a soft, dry cloth.
- Do not use organic solvent such as thinner, benzene, alcohol or gasoline.
- For genuine leather seats, use a genuine leather seat cleaner.
Precaution for WorkINFOID:0000000012918341
• When removing or disassembling each component, be careful not to damage or deform it. If a component may be subject to interference, be sure to protect it with a shop cloth.
• When removing (disengaging) components with a screwdriver or similar tool, be sure to wrap the component with a shop cloth or vinyl tape to protect it.
• Protect the removed parts with a shop cloth and prevent them from being dropped.
• Replace a deformed or damaged clip.
• If a part is specified as a non-reusable part, always replace it with a new one.
• Be sure to tighten bolts and nuts securely to the specified torque.
• After installation is complete, be sure to check that each part works properly.
• Follow the steps below to clean components:
- Water soluble dirt:
• Dip a soft cloth into lukewarm water, wring the water out of the cloth and wipe the dirty area.
• Then rub with a soft, dry cloth.
- Oily dirt:
• Dip a soft cloth into lukewarm water with mild detergent (concentration: within 2 to 3%) and wipe the dirty area.
• Then dip a cloth into fresh water, wring the water out of the cloth and wipe the detergent off.
• Then rub with a soft, dry cloth.
- Do not use organic solvent such as thinner, benzene, alcohol or gasoline.
- For genuine leather seats, use a genuine leather seat cleaner.
Revision: August 2015 2016 Versa Note
cardiagn.com
Page 880 of 3641
PREPARATIONDLK-191
< PREPARATION > [WITHOUT INTELLIGENT KEY SYSTEM]
C
D
E
F
G H
I
J
L
M A
B
DLK
N
O P
PREPARATION
PREPARATION
Special Service ToolsINFOID:0000000012430153
The actual shape of the tools may di ffer from those illustrated here.
Tool number
(TechMate No.)
Tool name Description
—
(J-39570)
Chassis Ear Locating the noise
—
(J-50397)
NISSAN Squeak and Rattle Kit Repairing the cause of noise
—
(J-43241)
Remote Keyless Entry Tester Used to test keyfobs
—
(J-50190)
Signal Tech II • Activate and display TPMS transmitter
IDs
• Display tire pressure reported by the TPMS transmitter
• Read TPMS DTCs
• Register TPMS transmitter IDs
• Test remote keyless entry keyfob rela- tive signal strength
• Compatible with future sensors
• Equipped with a display
• Check Intelligent Key relative signal strength
• Confirm vehicle Intelligent Key anten- na signal strength
SIIA0993E
ALJIA1232ZZ
LEL946A
ALEIA0131ZZ
