Page 2457 of 3641
![NISSAN NOTE 2016 Service Repair Manual MWI
POWER SUPPLY AND GROUND CIRCUITMWI-99
< DTC/CIRCUIT DIAGNOSIS > [TYPE B]
C
D
E
F
G H
I
J
K L
M B A
O P
nosis ProcedureINFOID:0000000012542966
Regarding Wiring Diagram information, refer to BCS-11 NISSAN NOTE 2016 Service Repair Manual MWI
POWER SUPPLY AND GROUND CIRCUITMWI-99
< DTC/CIRCUIT DIAGNOSIS > [TYPE B]
C
D
E
F
G H
I
J
K L
M B A
O P
nosis ProcedureINFOID:0000000012542966
Regarding Wiring Diagram information, refer to BCS-11](/manual-img/5/57363/w960_57363-2456.png)
MWI
POWER SUPPLY AND GROUND CIRCUITMWI-99
< DTC/CIRCUIT DIAGNOSIS > [TYPE B]
C
D
E
F
G H
I
J
K L
M B A
O P
nosis ProcedureINFOID:0000000012542966
Regarding Wiring Diagram information, refer to BCS-117, "Wiring Diagram".
1.CHECK FUSES AND FUSIBLE LINK
Check that the following fuses and fusible link are not blown.
Is the fuse blown?
YES >> Replace the blown fuse or fusible link after repairing the affected circuit.
NO >> GO TO 2.
2.CHECK POWER SUPPLY CIRCUIT
1. Turn ignition switch OFF.
2. Disconnect BCM connectors.
3. Check voltage between BCM connector and ground.
Is the inspection result normal?
YES >> GO TO 3.
NO >> Repair harness or connector.
3.CHECK GROUND CIRCUIT
Check continuity between BCM connector and ground.
Is the inspection result normal?
YES >> Inspection End.
NO >> Repair harness or connector.
BCM (BODY CONTROL SYSTEM) (W ITH INTELLIGENT KEY SYSTEM)
BCM (BODY CONTROL SYSTEM) (WITH IN TELLIGENT KEY SYSTEM) : Diagnosis
Procedure
INFOID:0000000012542967
Regarding Wiring Diagram information, refer to BCS-52, "Wiring Diagram".
Terminal No.Signal nameFuses and fusible link No.
37 Battery power supply 8 (10A)
42 12 (10A)
50 G (40A)
11 Ignition switch ACC or ON 18 (10A)
38 Ignition switch ON or START 2 (10A)
BCMGround Ignition switch position
Connector Terminal
—OFF
ACC ON
M18 11
0 V
Battery voltage
Battery voltage
37
Battery voltage
38 0 V0 V
M19 42
Battery voltage Battery voltage
50
BCM GroundContinuity
Connector Terminal
M19 55—Yes
Revision: August 2015 2016 Versa Note
cardiagn.com
Page 2458 of 3641
MWI-100
< DTC/CIRCUIT DIAGNOSIS >[TYPE B]
POWER SUPPLY AND GROUND CIRCUIT
1.CHECK FUSES AND FUSIBLE LINK
Check that the following fuses and fusible link are not blown.
Is the fuse blown?
YES >> Replace the blown fuse or fusible link after repairing the affected circuit.
NO >> GO TO 2.
2.CHECK POWER SUPPLY CIRCUIT
1. Disconnect BCM connector M99.
2. Check voltage between BCM connector M99 and ground.
Is the inspection result normal?
YES >> GO TO 3.
NO >> Repair harness or connector.
3.CHECK GROUND CIRCUIT
Check continuity between BCM connector M99 and ground.
Is the inspection result normal?
YES >> Inspection End.
NO >> Repair harness or connector.
Terminal No. Signal nameFuses and fusible link No.
57 Battery power supply 12 (10A)
70 G (40A)
BCM
Ground Voltage
Connector Terminal
M99 57
— Battery voltage
70
BCM GroundContinuity
Connector Terminal
M99 67—Yes
Revision: August 2015 2016 Versa Note
cardiagn.com
Page 2459 of 3641
![NISSAN NOTE 2016 Service Repair Manual MWI
FUEL LEVEL SENSOR SIGNAL CIRCUITMWI-101
< DTC/CIRCUIT DIAGNOSIS > [TYPE B]
C
D
E
F
G H
I
J
K L
M B A
O P
FUEL LEVEL SENSOR SIGNAL CIRCUIT
DescriptionINFOID:0000000012432636
The fuel level sensor u NISSAN NOTE 2016 Service Repair Manual MWI
FUEL LEVEL SENSOR SIGNAL CIRCUITMWI-101
< DTC/CIRCUIT DIAGNOSIS > [TYPE B]
C
D
E
F
G H
I
J
K L
M B A
O P
FUEL LEVEL SENSOR SIGNAL CIRCUIT
DescriptionINFOID:0000000012432636
The fuel level sensor u](/manual-img/5/57363/w960_57363-2458.png)
MWI
FUEL LEVEL SENSOR SIGNAL CIRCUITMWI-101
< DTC/CIRCUIT DIAGNOSIS > [TYPE B]
C
D
E
F
G H
I
J
K L
M B A
O P
FUEL LEVEL SENSOR SIGNAL CIRCUIT
DescriptionINFOID:0000000012432636
The fuel level sensor unit and fuel pump detects the approx imate fuel level in the fuel tank and transmits the
fuel level signal to the combination meter.
Component Function CheckINFOID:0000000012432637
1.COMBINATION METER INPUT SIGNAL
1. Select METER/M&A on CONSULT.
2. Using FUEL METER of DATA MONITOR, compare the DATA MONITOR value with the fuel gauge posi- tion.
Does monitor value match fuel gauge reading?
YES >> Inspection End.
NO >> Replace combination meter. Refer to MWI-115, "
Removal and Installation".
Diagnosis ProcedureINFOID:0000000012432638
Regarding Wiring Diagram information, refer to MWI-79, "Wiring Diagram".
1.CHECK HARNESS CONNECTOR
1. Turn ignition switch OFF.
2. Check combination meter and fuel level sensor unit terminals (meter-side and harness-side) for poor con- nection.
Is the inspection result normal?
YES >> GO TO 2.
NO >> Repair or replace terminals or connectors.
2.CHECK FUEL LEVEL SENSOR UNIT CIRCUIT
1. Disconnect combination meter harness connector M24 and fuel level sensor unit and fuel pump harness
connector B44.
2. Check continuity between combination meter harness connector M24 terminal 6 and fuel level sensor unit
and fuel pump harness connector B44 terminal 2.
3. Check continuity between fuel level sensor unit and fuel pump harness connector B44 terminal 2 and ground.
Is the inspection result normal?
YES >> GO TO 3.
NO >> Repair harness or connector.
Fuel gauge indication position Reference value of data monitor [L]
1A pp ro x. 3 9.7
3/4 Approx. 32.9
1/2 Approx. 22.7
1/4 Approx. 11.9
0A ppro x. 2 .7
Connector TerminalConnector Terminal Continuity
M24 6B44 2Yes
Connector Terminal
GroundContinuity
B44 2 No
Revision: August 2015 2016 Versa Note
cardiagn.com
Page 2460 of 3641
![NISSAN NOTE 2016 Service Repair Manual MWI-102
< DTC/CIRCUIT DIAGNOSIS >[TYPE B]
FUEL LEVEL SENSOR SIGNAL CIRCUIT
3.CHECK FUEL LEVEL SENSOR GROUND CIRCUIT
1. Disconnect ECM connector F11
2. Check continuity between combination meter har ne NISSAN NOTE 2016 Service Repair Manual MWI-102
< DTC/CIRCUIT DIAGNOSIS >[TYPE B]
FUEL LEVEL SENSOR SIGNAL CIRCUIT
3.CHECK FUEL LEVEL SENSOR GROUND CIRCUIT
1. Disconnect ECM connector F11
2. Check continuity between combination meter har ne](/manual-img/5/57363/w960_57363-2459.png)
MWI-102
< DTC/CIRCUIT DIAGNOSIS >[TYPE B]
FUEL LEVEL SENSOR SIGNAL CIRCUIT
3.CHECK FUEL LEVEL SENSOR GROUND CIRCUIT
1. Disconnect ECM connector F11
2. Check continuity between combination meter har ness connector M24 terminal 24 and fuel level sensor
unit and fuel pump harness connector B44 terminal 5.
3. Check continuity between fuel level sensor unit and fuel pump harness connector B44 terminal 5 and ground.
Is the inspection result normal?
YES >> GO TO 4.
NO >> Repair harness or connector.
4.CHECK INSTALLATION CONDITION
Check fuel level sensor unit installation, and verify t he float arm does not interfere or bind with the internal
components in the fuel tank.
Is the inspection result normal?
YES >> Inspection End.
NO >> Install the fuel level sensor unit properly.
Component InspectionINFOID:0000000012432639
1.REMOVE FUEL LEVEL SENSOR UNIT
Remove the fuel level sensor unit. Refer to FL-6, "
Removal and Installation".
>> GO TO 2.
2.CHECK FUEL LEVEL SENSOR UNIT
Check the resistance between fuel level sensor unit and fuel pump.
*: When float rod is in contact with stopper.
Is inspection result OK?
YES >> Inspection End.
NO >> Replace fuel level sensor unit and fuel pump. Refer to
FL-6, "
Removal and Installation".
Connector TerminalConnector Terminal Continuity
M24 24B44 5Yes
Connector Terminal
GroundContinuity
B44 5 No
Te r m i n a l s
ConditionResistance (Ω
)
(Approx.) Height [mm (in)]
Fuel level sensor unit
25 Full
* (A)
51 168.2 (6.62)
Empty
* (B) 283 17.5 (0.69)
JPNIA0841ZZ
Revision: August 2015
2016 Versa Note
cardiagn.com
Page 2461 of 3641
![NISSAN NOTE 2016 Service Repair Manual MWI
STEERING SWITCHMWI-103
< DTC/CIRCUIT DIAGNOSIS > [TYPE B]
C
D
E
F
G H
I
J
K L
M B A
O P
STEERING SWITCH
Diagnosis ProcedureINFOID:0000000012432640
Regarding Wiring Diagram information, refer to M NISSAN NOTE 2016 Service Repair Manual MWI
STEERING SWITCHMWI-103
< DTC/CIRCUIT DIAGNOSIS > [TYPE B]
C
D
E
F
G H
I
J
K L
M B A
O P
STEERING SWITCH
Diagnosis ProcedureINFOID:0000000012432640
Regarding Wiring Diagram information, refer to M](/manual-img/5/57363/w960_57363-2460.png)
MWI
STEERING SWITCHMWI-103
< DTC/CIRCUIT DIAGNOSIS > [TYPE B]
C
D
E
F
G H
I
J
K L
M B A
O P
STEERING SWITCH
Diagnosis ProcedureINFOID:0000000012432640
Regarding Wiring Diagram information, refer to MWI-79, "Wiring Diagram".
1.CHECK STEERING SWITCH
1. Turn ignition switch OFF.
2. Disconnect combination switch (spiral cable) connector M88.
3. Check for continuity between the termi nals of combination switch connector M88.
Is the inspection result normal?
YES >> GO TO 2.
NO >> Replace steering switches. Refer to AV-58, "
Removal and Installation".
2.CHECK COMBINATION SWITCH (SPIRAL CABLE)
Check continuity between combination swit ch (spiral cable) connectors M88 and M30.
Is the inspection result normal?
YES >> • Display audio system: Refer to AV-104, "Diagnosis Procedure".
• Navigation system: Refer to AV-224, "
Diagnosis Procedure".
NO >> Replace combination switch (spiral cable). Refer to SR-16, "
Removal and Installation".
Combination switch (spiral cable) connector M88
Condition Continuity
Terminal Terminal
16 17When steering switch is pressed.
Yes
Other than above. No
Combination switch (spiral cable)
Continuity
Connector TerminalConnector Terminal
M88 16
M30 32
Ye s
17 33
Revision: August 2015 2016 Versa Note
cardiagn.com
Page 2462 of 3641
![NISSAN NOTE 2016 Service Repair Manual MWI-104
< DTC/CIRCUIT DIAGNOSIS >[TYPE B]
AMBIENT SENSOR SIGNAL CIRCUIT
AMBIENT SENSOR SIGNAL CIRCUIT
DescriptionINFOID:0000000012432641
The ambient sensor detects outside air temperature and c
onvert NISSAN NOTE 2016 Service Repair Manual MWI-104
< DTC/CIRCUIT DIAGNOSIS >[TYPE B]
AMBIENT SENSOR SIGNAL CIRCUIT
AMBIENT SENSOR SIGNAL CIRCUIT
DescriptionINFOID:0000000012432641
The ambient sensor detects outside air temperature and c
onvert](/manual-img/5/57363/w960_57363-2461.png)
MWI-104
< DTC/CIRCUIT DIAGNOSIS >[TYPE B]
AMBIENT SENSOR SIGNAL CIRCUIT
AMBIENT SENSOR SIGNAL CIRCUIT
DescriptionINFOID:0000000012432641
The ambient sensor detects outside air temperature and c
onverts it into a resistance value which is then input
into the combination meter.
Diagnosis ProcedureINFOID:0000000012432642
Regarding Wiring Diagram information, refer to MWI-79, "Wiring Diagram".
1.CHECK AMBIENT SENSOR POWER SUPPLY
1. Turn ignition switch OFF.
2. Disconnect ambient sensor connector.
3. Turn ignition switch ON.
4. Check voltage between ambient sensor harness connector and ground.
Is the inspection result normal?
YES >> GO TO 3.
NO >> GO TO 2.
2.CHECK AMBIENT SENSOR POWER SUPPLY FOR OPEN OR SHORT
1. Turn ignition switch OFF.
2. Disconnect combination meter connec tor and ambient sensor connector.
3. Check continuity between combination meter harness connector and ambient sensor harness connector.
4. Check continuity between combination meter harness connector and ground.
Is the inspection result normal?
YES >> Replace combination meter. Refer to MWI-115, "Removal and Installation".
NO >> Repair or replace harness or connector.
3.CHECK AMBIENT SENSOR GROUND CIRCUIT
Check continuity between combination meter har ness connector and ambient sensor harness connector.
Is the inspection result normal?
YES >> Inspection End.
NO >> Repair or replace harness or connector.
+ −Vo l ta g e
(Approx.)
Ambient sensor
Connector Terminal
E69 1 Ground 5 V
Combination meter Ambient sensor
Continuity
Connector TerminalConnector Terminal
M24 19E69 1Yes
Combination meter
GroundContinuity
Connector Terminal
M24 19 No
Combination meterAmbient sensor
Continuity
Connector TerminalConnector Terminal
M24 20E69 2Yes
Revision: August 2015 2016 Versa Note
cardiagn.com
Page 2463 of 3641
MWI
AMBIENT SENSOR SIGNAL CIRCUITMWI-105
< DTC/CIRCUIT DIAGNOSIS > [TYPE B]
C
D
E
F
G H
I
J
K L
M B A
O P
Component InspectionINFOID:0000000012432643
1.CHECK AMBIENT SENSOR
1. Turn ignition switch OFF.
2. Disconnect ambient sensor connector.
3. Check resistance between ambient sensor terminals.
Is the inspection result normal?
YES >> Inspection End.
NO >> Replace ambient sensor. Refer to MWI-116, "
Removal and Installation".
Te r m i n a lCondition
Resistance: kΩ
Temperature: °C ( °F)
12
− 15 (5) 12.73
− 10 (14) 9.92
− 5 (23) 7.80
0 (32) 6.19
5 (41) 4.95
10 (50) 3.99
15 (59) 3.24
20 (68) 2.65
25 (77) 2.19
30 (86) 1.81
35 (95) 1.51
40 (104) 1.27
45 (113) 1.07
Revision: August 2015 2016 Versa Note
cardiagn.com
Page 2464 of 3641
![NISSAN NOTE 2016 Service Repair Manual MWI-106
< DTC/CIRCUIT DIAGNOSIS >[TYPE B]
WASHER FLUID LEVEL SWITCH CIRCUIT
WASHER FLUID LEVEL SWITCH CIRCUIT
DescriptionINFOID:0000000012432644
Transmits the washer fluid level switch signal to the c NISSAN NOTE 2016 Service Repair Manual MWI-106
< DTC/CIRCUIT DIAGNOSIS >[TYPE B]
WASHER FLUID LEVEL SWITCH CIRCUIT
WASHER FLUID LEVEL SWITCH CIRCUIT
DescriptionINFOID:0000000012432644
Transmits the washer fluid level switch signal to the c](/manual-img/5/57363/w960_57363-2463.png)
MWI-106
< DTC/CIRCUIT DIAGNOSIS >[TYPE B]
WASHER FLUID LEVEL SWITCH CIRCUIT
WASHER FLUID LEVEL SWITCH CIRCUIT
DescriptionINFOID:0000000012432644
Transmits the washer fluid level switch signal to the combination meter.
Diagnosis ProcedureINFOID:0000000012432645
Regarding Wiring Diagram information, refer to
MWI-79, "Wiring Diagram".
1.CHECK WASHER FLUID LEVEL SWITCH SIGNAL CIRCUIT
1. Turn ignition switch OFF.
2. Disconnect combination meter connector and washer fluid level switch connector.
3. Check continuity between combination meter harne ss connector M24 terminal 17 and washer fluid level
switch harness connector E50 terminal 1.
4. Check continuity between combination meter harness connector M24 terminal 17 and ground.
Is the inspection result normal?
YES >> GO TO 2.
NO >> Repair or replace harness or connector.
2.CHECK WASHER FLUID LEVEL SWITCH GROUND CIRCUIT
Check continuity between washer fluid level switch harness connector E50 terminal 2 and ground.
Is the inspection result normal?
YES >> Inspection End.
NO >> Repair or replace harness or connector.
Component InspectionINFOID:0000000012432646
1.CHECK WASHER FLUID LEVEL SWITCH
Check continuity between washer fluid level switch terminals 1 and 2.
Is the inspection result normal?
YES >> Inspection End.
NO >> Replace washer fluid level switch. Refer to WW-59, "
Removal and Installation".
ConnectorTerminalConnector Terminal Continuity
M24 17E50 1Yes
Connector Terminal
GroundContinuity
M24 17 No
ConnectorTerminal
GroundContinuity
E50 2 Yes
TerminalWasher fluid level Continuity
1 - 2 Low
Yes
High No
Revision: August 2015 2016 Versa Note
cardiagn.com
