• BCM detects the combination switch status signal “5AD” when the signals of OUTPUT 1 and OUTPUT 4 are
input to INPUT 5.
• BCM judges that the TURN RH switch and TAIL LAMP switch are ON when the signal “5AD” is detected.
WIPER INTERMITTENT DIAL POSITION (WITH VARIABLE INTERMITTENT WIPERS)
BCM judges the wiper intermittent dial 1 - 7 by the status of INT VOLUME 1, 2 and 3 switches.
NOTE:
For details of wiper intermittent dial position, refer to WW-8, "
FRONT WIPER AND WASHER SYSTEM : System Description".
SIGNAL BUFFER
AWMIA1444GB
Wiper intermittent
dial position Switch status
INT VOLUME 1 INT VOLUME 2INT VOLUME 3
1O NONO N
2O NONOFF
3O NOFFO FF
4 OFF OFFOFF
5O FFO FFO N
6 OFF ONON
7 OFF ONOFF
Revision: August 2015 2016 Versa Note
cardiagn.com
Page 346 of 3641
![NISSAN NOTE 2016 Service Repair Manual BCS
SYSTEMBCS-85
< SYSTEM DESCRIPTION > [WITHOUT INTELLIGENT KEY SYSTEM]
C
D
E
F
G H
I
J
K L
B A
O P
N
SIGNAL BUFFER : System DescriptionINFOID:0000000012432366
SYSTEM DIAGRAM
OUTLINE
BCM has the sign NISSAN NOTE 2016 Service Repair Manual BCS
SYSTEMBCS-85
< SYSTEM DESCRIPTION > [WITHOUT INTELLIGENT KEY SYSTEM]
C
D
E
F
G H
I
J
K L
B A
O P
N
SIGNAL BUFFER : System DescriptionINFOID:0000000012432366
SYSTEM DIAGRAM
OUTLINE
BCM has the sign](/manual-img/5/57363/w960_57363-345.png)
BCS
SYSTEMBCS-85
< SYSTEM DESCRIPTION > [WITHOUT INTELLIGENT KEY SYSTEM]
C
D
E
F
G H
I
J
K L
B A
O P
N
SIGNAL BUFFER : System DescriptionINFOID:0000000012432366
SYSTEM DIAGRAM
OUTLINE
BCM has the signal transmission function that output
s/transmits each input/received signal to each unit.
SIGNAL TRASNMISSION FUNCTION LIST
POWER CONSUMPTION CONTROL SYSTEM
POWER CONSUMPTION CONTROL SYSTEM : System DescriptionINFOID:0000000012432367
SYSTEM DIAGRAM
AWMIA1528GB
Signal nameInputOutputDescription
Ignition switch ON signal Ignition switch IPDM E/R (CAN)Inputs the ignition switch signal
and transmits it via CAN com-
munication.
Brake switch signal Stop lamp switch IPDM E/R (CAN)Inputs the brake switch signal
and transmits it via CAN com-
munication.
Door switch signal Any door switch • Combination meter (CAN)
• IPDM E/R (CAN)Inputs the door switch signal
and transmits it via CAN com-
munication.
Blower fan ON signal Front air control ECM (CAN)Inputs each signal and trans-
mits them via CAN communica-
tion.
A/C ON signal
AWMIA1529GB
Revision: August 2015
2016 Versa Note
cardiagn.com
Page 347 of 3641
![NISSAN NOTE 2016 Service Repair Manual BCS-86
< SYSTEM DESCRIPTION >[WITHOUT INTELLIGENT KEY SYSTEM]
SYSTEM
OUTLINE
• BCM incorporates a power saving control function t
hat reduces the power consumption according to the
vehicle status.
NISSAN NOTE 2016 Service Repair Manual BCS-86
< SYSTEM DESCRIPTION >[WITHOUT INTELLIGENT KEY SYSTEM]
SYSTEM
OUTLINE
• BCM incorporates a power saving control function t
hat reduces the power consumption according to the
vehicle status.](/manual-img/5/57363/w960_57363-346.png)
BCS-86
< SYSTEM DESCRIPTION >[WITHOUT INTELLIGENT KEY SYSTEM]
SYSTEM
OUTLINE
• BCM incorporates a power saving control function t
hat reduces the power consumption according to the
vehicle status.
• BCM switches the status (control mode) by itself wit h the power saving control function. It performs the sleep
request to each unit (IPDM E/R and combination mete r) that operates with the ignition switch OFF.
Normal mode (wake-up)- CAN communication is normally performed with other units
- Each control with BCM is operating properly
CAN communication sleep mode (CAN sleep)- CAN transmission is stopped
- Control with BCM only is operating
Low power consumption mode (BCM sleep)- Low power consumption control is active
- CAN transmission is stopped
LOW POWER CONSUMPTION CONTROL WITH BCM
BCM reduces the power consumption with the following operation in the low power consumption mode.
• The reading interval of each switch changes from 10 ms interval to 60 ms interval.
SLEEP MODE ACTIVATION
• BCM receives the sleep-ready signal (ready) from IPDM E/R and combination meter via CAN communica-
tion.
• BCM transmits the sleep wake up signal (sleep) to each unit when all of the CAN sleep conditions are ful- filled.
• Each unit stops the transmission of CAN communication with the sleep wake-up signal. BCM is in CAN com- munication sleep mode.
• BCM is in the low power consumption mode and perform s the low power consumption control when all of the
BCM sleep conditions are fulfilled with CAN sleep condition.
Sleep condition
WAKE-UP OPERATION
• BCM transmits the sleep wake up signal (wake up) to each unit when any of the wake-up conditions are ful- filled. It changes from the low power consumption mode to the normal mode.
• Each unit starts the transmission of CAN communica tion with the sleep wake up signal. Each unit transmits
the wake up signal to BCM via CAN communication to report the CAN communication start.
CAN sleep condition BCM sleep condition
• Receiving the sleep-ready signal (ready) from all units
• Ignition switch: OFF
• Vehicle security system alarm: No operation
• Warning lamp: Not operation
• Stop lamp switch: OFF
• Turn signal indicator lamp: No operation
• Exterior lamp: OFF
• Door lock status: No change
• CONSULT communication status: No communication
• Door switch status: No change
• Rear window defogger: OFF
• Driver door lock status: No change
• Key switch status: No change • Interior room lamp battery saver: Time out
• RAP system: OFF
• Nissan Vehicle Immobilizer System (NVIS) - NATS: No opera-
tion
• Remote keyless entry receiver communication status: No com- munication
Revision: August 2015 2016 Versa Note
cardiagn.com
Page 348 of 3641
![NISSAN NOTE 2016 Service Repair Manual BCS
SYSTEMBCS-87
< SYSTEM DESCRIPTION > [WITHOUT INTELLIGENT KEY SYSTEM]
C
D
E
F
G H
I
J
K L
B A
O P
N
SHIPPING MODE CONTROL SYSTEM
SHIPPING MODE CONTROL SYSTEM : System DescriptionINFOID:000000001243 NISSAN NOTE 2016 Service Repair Manual BCS
SYSTEMBCS-87
< SYSTEM DESCRIPTION > [WITHOUT INTELLIGENT KEY SYSTEM]
C
D
E
F
G H
I
J
K L
B A
O P
N
SHIPPING MODE CONTROL SYSTEM
SHIPPING MODE CONTROL SYSTEM : System DescriptionINFOID:000000001243](/manual-img/5/57363/w960_57363-347.png)
BCS
SYSTEMBCS-87
< SYSTEM DESCRIPTION > [WITHOUT INTELLIGENT KEY SYSTEM]
C
D
E
F
G H
I
J
K L
B A
O P
N
SHIPPING MODE CONTROL SYSTEM
SHIPPING MODE CONTROL SYSTEM : System DescriptionINFOID:0000000012432368
SYSTEM DIAGRAM
DESCRIPTION
• The BCM switches the status (shipping mode or norma
l mode) by itself according to the extended storage
switch condition, and transmits the shipping mode status signal to the combination meter and each unit via
CAN communication.
• When the shipping mode function is activated, the control units will not detect DTCs.
• BCM control functions are limited in shipping mode. Refer to BCS-136, "
Description".
• When the BCM is in shipping mode, a message may be shown in the combination meter or display.
• For shipping mode cancel operation refer to BCS-125, "
Work Procedure".
TRANSIT MODE CONTROL SYSTEM
Wake-up condition
• Receiving the sleep-ready signal (Not-ready) from any unit
• Hazard switch: OFF →ON
• HI BEAM switch: OFF →ON, ON→OFF
• PASSING switch: OFF→ ON, ON→OFF
• HEADLAMP 1 switch: OFF →ON, ON→OFF
• HEADLAMP 2 switch: OFF →ON, ON→OFF
• TAIL LAMP switch: OFF →ON
• TURN LH: OFF →ON, ON→OFF
• TURN RH: OFF →ON, ON→OFF
• Front door switch LH: OFF→ON, ON →OFF
• Front door switch RH: OFF → ON, ON → OFF
• Rear door switch LH: OFF→ON, ON→OFF
• Rear door switch RH: OFF → ON, ON → OFF
• Stop lamp switch: ON
• Door lock and unlock switch: NEUTRAL → LOCK, NEUTRAL → UNLOCK
• Front door lock assembly LH (key cylinder switch): NEUTRAL → LOCK, NEUTRAL → UNLOCK
• Remote keyless entry receiver: Receiving valid keyfob
AWMIA1687GB
Revision: August 2015 2016 Versa Note
cardiagn.com
Page 349 of 3641
![NISSAN NOTE 2016 Service Repair Manual BCS-88
< SYSTEM DESCRIPTION >[WITHOUT INTELLIGENT KEY SYSTEM]
SYSTEM
TRANSIT MODE CONTROL SYST EM : System Description
INFOID:0000000012432369
DESCRIPTION
Transit mode is a BCM function that disables NISSAN NOTE 2016 Service Repair Manual BCS-88
< SYSTEM DESCRIPTION >[WITHOUT INTELLIGENT KEY SYSTEM]
SYSTEM
TRANSIT MODE CONTROL SYST EM : System Description
INFOID:0000000012432369
DESCRIPTION
Transit mode is a BCM function that disables](/manual-img/5/57363/w960_57363-348.png)
BCS-88
< SYSTEM DESCRIPTION >[WITHOUT INTELLIGENT KEY SYSTEM]
SYSTEM
TRANSIT MODE CONTROL SYST EM : System Description
INFOID:0000000012432369
DESCRIPTION
Transit mode is a BCM function that disables several elec trical functions such as door lock/unlock by remote,
back door open by remote, panic alarm, anti-theft alarm, etc. Vehicles are shipped with the BCM in transit
mode to help prevent the battery from becoming discharged during dealer storage.
DETERMINING TRANSIT MODE STATUS
Use the table below to determine the transit mode status.
CANCELING TRANSIT MODE
NOTE:
Transit mode can only be canceled. Once transit mode has been canceled, it cannot be activated again.
To cancel transit mode, refer to BCS-126, "
Work Procedure".
Status Symptom
Transit Mode When ignition switch is turned from OFF to ON, turn signal indicators will illuminate for 1 minute.
Normal Mode (not in transit mode) When ignition switch is turned from OFF to ON, turn signal indicators stay OFF (do not illumi-
nate).
Revision: August 2015
2016 Versa Note
cardiagn.com
Page 350 of 3641
![NISSAN NOTE 2016 Service Repair Manual BCS
DIAGNOSIS SYSTEM (BCM)BCS-89
< SYSTEM DESCRIPTION > [WITHOUT INTELLIGENT KEY SYSTEM]
C
D
E
F
G H
I
J
K L
B A
O P
N
DIAGNOSIS SYSTEM (BCM)
COMMON ITEM
COMMON ITEM : CONSULT Function (BCM - COMMON I NISSAN NOTE 2016 Service Repair Manual BCS
DIAGNOSIS SYSTEM (BCM)BCS-89
< SYSTEM DESCRIPTION > [WITHOUT INTELLIGENT KEY SYSTEM]
C
D
E
F
G H
I
J
K L
B A
O P
N
DIAGNOSIS SYSTEM (BCM)
COMMON ITEM
COMMON ITEM : CONSULT Function (BCM - COMMON I](/manual-img/5/57363/w960_57363-349.png)
BCS
DIAGNOSIS SYSTEM (BCM)BCS-89
< SYSTEM DESCRIPTION > [WITHOUT INTELLIGENT KEY SYSTEM]
C
D
E
F
G H
I
J
K L
B A
O P
N
DIAGNOSIS SYSTEM (BCM)
COMMON ITEM
COMMON ITEM : CONSULT Function (BCM - COMMON ITEM)INFOID:0000000012432370
APPLICATION ITEM
CONSULT performs the following functions via CAN communication with BCM.
SYSTEM APPLICATION
BCM can perform the following functions.
Direct Diagnostic Mode
Description
ECU Identification The BCM part number is displayed.
Self Diagnostic Result The BCM self diagnostic results are displayed.
Data Monitor The BCM input/output data is displayed in real time.
Active Test The BCM activates outputs to test components.
Work support The settings for BCM functions can be changed.
Configuration • The vehicle specification can be read and saved.
• The vehicle specification can be written when replacing BCM.
CAN DIAG SUPPORT MNTR The result of transmit/receive diagnosis of CAN communication is displayed.
System Sub System Direct Diagnostic Mode
ECU Identification
Self Diagnostic Result
Data Monitor
Active Test
Work support
Configuration
CAN DIAG SUPPORT MNTR
Door lock
DOOR LOCK ×××
Rear window defogger REAR DEFOGGER ××
Warning chime BUZZER ××
Interior room lamp timer INT LAMP ×××
Remote keyless entry system MULTI REMOTE ENT ×××
Exterior lamp HEAD LAMP ×××
Wiper and washer WIPER ×××
Turn signal and hazard warning lamps FLASHER ××
Air conditioner AIR CONDITIONER ×
Combination switch COMB SW ×
BCM BCM× × ×××
Immobilizer IMMU ×××
Interior room lamp battery saver BATTERY SAVER ×××
Vehicle security system THEFT ALM ××
RAP system RETAINED PWR ××
Signal buffer system SIGNAL BUFFER ×
TPMS AIR PRESSURE MONITOR ××××
Panic alarm system PANIC ALARM ×
Revision: August 2015 2016 Versa Note
cardiagn.com
Page 351 of 3641
![NISSAN NOTE 2016 Service Repair Manual BCS-90
< SYSTEM DESCRIPTION >[WITHOUT INTELLIGENT KEY SYSTEM]
DIAGNOSIS SYSTEM (BCM)
DOOR LOCK
DOOR LOCK : CONSULT Func
tion (BCM - DOOR LOCK)INFOID:0000000012432371
DATA MONITOR
ACTIVE TEST
WORK SUPP NISSAN NOTE 2016 Service Repair Manual BCS-90
< SYSTEM DESCRIPTION >[WITHOUT INTELLIGENT KEY SYSTEM]
DIAGNOSIS SYSTEM (BCM)
DOOR LOCK
DOOR LOCK : CONSULT Func
tion (BCM - DOOR LOCK)INFOID:0000000012432371
DATA MONITOR
ACTIVE TEST
WORK SUPP](/manual-img/5/57363/w960_57363-350.png)
BCS-90
< SYSTEM DESCRIPTION >[WITHOUT INTELLIGENT KEY SYSTEM]
DIAGNOSIS SYSTEM (BCM)
DOOR LOCK
DOOR LOCK : CONSULT Func
tion (BCM - DOOR LOCK)INFOID:0000000012432371
DATA MONITOR
ACTIVE TEST
WORK SUPPORT
* : Initial setting
REAR DEFOGGER
Monitor Item [Unit] Description
IGN ON SW [On/Off] Indicates condition of ignition switch ON position.
KEY ON SW [On/Off] Indicates condition of key switch.
CDL LOCK SW [On/Off] Indicates condition of lock signal from door lock and unlock switch.
CDL UNLOCK SW [On/Off] Indicates condition of unlock signal from door lock and unlock switch.
DOOR SW-DR [On/Off] Indicates condition of front door switch LH.
DOOR SW-AS [On/Off] Indicates condition of front door switch RH.
DOOR SW-RR [On/Off] Indicates condition of rear door switch RH.
DOOR SW-RL [On/Off] Indicates condition of rear door switch LH.
DOOR SW-BK [On/Off] Indicates condition of back door switch.
ACC ON SW [On/Off] Indicates condition of ignition switch ACC position.
KEYLESS LOCK [On/Off] Indicates condition of lock signal from keyfob.
KEYLESS UNLOCK [On/Off] Indicates condition of unlock signal from keyfob.
KEY CYL LK-SW [On/Off] Indicates condition of lock signal from door key cylinder switch.
KEY CYL UN-SW [On/Off] Indicates condition of unlock signal from door key cylinder switch.
VEHICLE SPEED [km/h/mph] Indicates vehicl e speed signal received from combination meter on CAN communication line.
Test Item Description
DOOR LOCK This test is able to check door lock operation [OTR ULK/DR UNLK/ALL UNLK/ALL LCK].
Support ItemSetting Description
DOOR LOCK-UNLOCK SET ON*
Automatic door locks function ON.
OFF Automoatic door locks function OFF.
AUTOMATIC DOOR LOCK SELECT P RANGE Doors lock automatically when shifted out of Park (P).
VH SPD* Doors lock automatically when vehicle speed reaches 24 km/h (15 mph).
AUTOMATIC DOOR UNLOCK
SELECT MODE6* Drivers door unlocks automatically when key is removed.
MODE5 Drivers door unlocks automatically when shifted into Park (P).
MODE4 Drivers door unlocks automatically when ignition is switched from ON to OFF.
MODE3 Doors unlock automatically when key is removed.
MODE2 Doors unlock automatically when shifted into Park (P).
MODE1 Doors unlock automatically when ignition is switched from ON to OFF.
AUTOMATIC LOCK/UNLOCK
SELECT Lock/Unlock* Automatic door locks function operates in lock and unlock.
Lock Only Automatic door locks function operates in lock only.
Unlock Only Automatic door locks function operates in unlock only.
Off
Automatic door locks function OFF.
Revision: August 2015 2016 Versa Note
cardiagn.com
Page 352 of 3641
![NISSAN NOTE 2016 Service Repair Manual BCS
DIAGNOSIS SYSTEM (BCM)BCS-91
< SYSTEM DESCRIPTION > [WITHOUT INTELLIGENT KEY SYSTEM]
C
D
E
F
G H
I
J
K L
B A
O P
N
REAR DEFOGGER : CONSULT Function (BCM - REAR DEFOGGER)INFOID:0000000012432372
DAT NISSAN NOTE 2016 Service Repair Manual BCS
DIAGNOSIS SYSTEM (BCM)BCS-91
< SYSTEM DESCRIPTION > [WITHOUT INTELLIGENT KEY SYSTEM]
C
D
E
F
G H
I
J
K L
B A
O P
N
REAR DEFOGGER : CONSULT Function (BCM - REAR DEFOGGER)INFOID:0000000012432372
DAT](/manual-img/5/57363/w960_57363-351.png)
BCS
DIAGNOSIS SYSTEM (BCM)BCS-91
< SYSTEM DESCRIPTION > [WITHOUT INTELLIGENT KEY SYSTEM]
C
D
E
F
G H
I
J
K L
B A
O P
N
REAR DEFOGGER : CONSULT Function (BCM - REAR DEFOGGER)INFOID:0000000012432372
DATA MONITOR
ACTIVE TEST
BUZZER
BUZZER : CONSULT Func
tion (BCM - BUZZER)INFOID:0000000012432373
DATA MONITOR
ACTIVE TEST
INT LAMP
INT LAMP : CONSULT Func tion (BCM - INT LAMP) INFOID:0000000012432374
DATA MONITOR
Monitor Item [Unit] Description
IGN ON SW [On/Off] Indicates condition of ignition switch ON position.
ACC ON SW [On/Off] Indicates condition of ignition switch ACC position.
REAR DEF SW [On/Off] Indicates condition of rear window defogger switch.
RR DEF TIME [On/Off] Indicates condition of rear window defogger switch timer.
Test Item Description
REAR DEFOGGER This test is able to check rear window defogger operation [Off/On].
Monitor Item [Unit] Description
IGN ON SW [On/Off] Indicates condition of ignition switch ON position.
KEY ON SW [On/Off] Indicates condition of key switch.
DOOR SW-DR [On/Off] Indicates condition of front door switch LH.
REVERSE SW CAN [On/Off] Indicates reverse switch sign al received from TCM on CAN communication line.
TAIL LAMP SW [On/Off] Indicates condition of combination switch.
FR FOG SW [On/Off] Indicates condition of front fog lamp switch.
VEHICLE SPEED [km/h/mph] Indicates vehicle speed signal received from combination meter on CAN communication line.
Test Item Description
IGN KEY WARN ALM This test is able to check key warning chime operation [On/Off].
SEAT BELT WARN TEST This test is able to check seat belt warning chime operation [On/Off].
LIGHT WARN ALM This test is able to check light warning chime operation [On/Off].
Monitor Item [Unit] Description
IGN ON SW [On/Off] Indicates condition of ignition switch ON position.
KEY ON SW [On/Off] Indicates condition of key switch.
DOOR SW-DR [On/Off] Indicates condition of front door switch LH.
DOOR SW-AS [On/Off] Indicates condition of front door switch RH.
DOOR SW-RR [On/Off] Indicates condition of rear door switch RH.
DOOR SW-RL [On/Off] Indicates condition of rear door switch LH.
DOOR SW-BK [On/Off] Indicates condition of back door switch.
CDL LOCK SW [On/Off] Indicates condition of lock signal from door lock and unlock switch.
Revision: August 2015 2016 Versa Note
cardiagn.com
