Page 1169 of 3641
![NISSAN NOTE 2016 Service Repair Manual EC-42
< SYSTEM DESCRIPTION >[HR16DE]
SYSTEM
*1: ECM determines the start signal status
by the signals of engine speed and battery voltage.
*2: This signal is sent to the ECM through CAN communication NISSAN NOTE 2016 Service Repair Manual EC-42
< SYSTEM DESCRIPTION >[HR16DE]
SYSTEM
*1: ECM determines the start signal status
by the signals of engine speed and battery voltage.
*2: This signal is sent to the ECM through CAN communication](/manual-img/5/57363/w960_57363-1168.png)
EC-42
< SYSTEM DESCRIPTION >[HR16DE]
SYSTEM
*1: ECM determines the start signal status
by the signals of engine speed and battery voltage.
*2: This signal is sent to the ECM through CAN communication line.
SYSTEM DESCRIPTION
This mechanism hydraulically controls cam phases c ontinuously with the fixed operating angle of the intake
valve.
The ECM receives signals such as crankshaft position, camshaft position, engine speed, engine oil tempera-
ture and engine coolant temperature. Then, the ECM s ends ON/OFF pulse duty signals to the intake valve
timing (IVT) control solenoid valve depending on driving stat us. This makes it possible to control the shut/open
timing of the intake valve to increase engine torque in low/mid speed range and output in high-speed range.
EXHAUST VALVE TIMING CONTROL
EXHAUST VALVE TIMING CO NTROL : System DiagramINFOID:0000000012431322
EXHAUST VALVE TIMING CONT ROL : System DescriptionINFOID:0000000012431323
INPUT/OUTPUT SIGNAL CHART
JPBIA4884GB
JPBIA4885GB
SensorInput signal to ECM ECM functionActuator
Crankshaft position sensor (POS) Engine speed
*1
Piston position
Exhaust valve timing controlExhaust valve timing control
solenoid valve
Camshaft position sensor (PHASE)
Engine oil temperature sensor Engine oil temperature
Engine coolant temperature sensor Engine coolant temperature
Combination meter
Vehicle speed
*2
Revision: August 2015 2016 Versa Note
cardiagn.com
Page 1170 of 3641
![NISSAN NOTE 2016 Service Repair Manual SYSTEMEC-43
< SYSTEM DESCRIPTION > [HR16DE]
C
D
E
F
G H
I
J
K L
M A
EC
NP
O
*1: ECM determines the start signal status
by the signals of engine speed and battery voltage.
*2: This signal is sent to t NISSAN NOTE 2016 Service Repair Manual SYSTEMEC-43
< SYSTEM DESCRIPTION > [HR16DE]
C
D
E
F
G H
I
J
K L
M A
EC
NP
O
*1: ECM determines the start signal status
by the signals of engine speed and battery voltage.
*2: This signal is sent to t](/manual-img/5/57363/w960_57363-1169.png)
SYSTEMEC-43
< SYSTEM DESCRIPTION > [HR16DE]
C
D
E
F
G H
I
J
K L
M A
EC
NP
O
*1: ECM determines the start signal status
by the signals of engine speed and battery voltage.
*2: This signal is sent to the ECM through CAN communication line.
SYSTEM DESCRIPTION
This mechanism hydraulically controls cam phases continuously with the fixed operating angle of the exhaust
valve.
The ECM receives signals such as crankshaft positi on, camshaft position, engine speed, engine oil tempera-
ture and engine coolant temperature. Then, the ECM s ends ON/OFF pulse duty signals to the exhaust valve
timing (EVT) control solenoid valve depending on driving stat us. This makes it possible to control the shut/
open timing of the exhaust valve to increase engi ne torque and output in a range of high engine speed.
ENGINE PROTECTION CONTROL AT LOW ENGINE OIL PRESSURE
ENGINE PROTECTION CONTROL AT LOW ENGINE OIL PRESSURE : System Dia-
gram
INFOID:0000000012431324
ENGINE PROTECTION CONTROL AT LOW ENGINE OIL PRESSURE : System De-
scription
INFOID:0000000012431325
INPUT/OUTPUT SIGNAL CHART
SYSTEM DESCRIPTION
• The engine protection control at low engine oil pressure warns the driver of a decrease in engine oil pres-
sure by the oil pressure warning lamp a before the engine becomes damaged.
• When detecting a decrease in engine oil pressure at an engine speed less than 1,000 rpm, ECM transmits an oil pressure warning lamp signal to the combination meter. The combination meter turns ON the oil pres-
sure warning lamp, according to the signal.
JPBIA4886GB
JSBIA0704GB
Sensor Input signal to ECM ECM function Actuator
Engine oil pressure sensor Engine pressure Engine protection control
• Oil pressure warning lamp signalCombination meter
• Oil pressure warning lamp
Crankshaft position sensor (POS) Engine speed
Revision: August 2015 2016 Versa Note
cardiagn.com
Page 1171 of 3641
![NISSAN NOTE 2016 Service Repair Manual EC-44
< SYSTEM DESCRIPTION >[HR16DE]
SYSTEM
*: When detecting a normal engine oil pressure, ECM turns OFF the oil pressure warning lamp.
FUEL FILLER CAP WARNING SYSTEM
FUEL FILLER CAP WARNING
SYSTEM NISSAN NOTE 2016 Service Repair Manual EC-44
< SYSTEM DESCRIPTION >[HR16DE]
SYSTEM
*: When detecting a normal engine oil pressure, ECM turns OFF the oil pressure warning lamp.
FUEL FILLER CAP WARNING SYSTEM
FUEL FILLER CAP WARNING
SYSTEM](/manual-img/5/57363/w960_57363-1170.png)
EC-44
< SYSTEM DESCRIPTION >[HR16DE]
SYSTEM
*: When detecting a normal engine oil pressure, ECM turns OFF the oil pressure warning lamp.
FUEL FILLER CAP WARNING SYSTEM
FUEL FILLER CAP WARNING
SYSTEM : System DiagramINFOID:0000000012431326
FUEL FILLER CAP WARNING SYS TEM : System DescriptionINFOID:0000000012431327
INPUT/OUTPUT SIGNAL CHART
Input
*: This signal is sent to the ECM via the CAN communication line.
Output
*: This signal is sent to the combination meter via the CAN communication line.
SYSTEM DESCRIPTION
The fuel filler cap warning system alerts the driver to the prevention of the fuel filler being left uncapped and
malfunction occurrences after refueling, by turning ON the fuel filler cap warning display on the combination
meter.
ECM judges a refueled state, based on a fuel level signal transmitted from the combination meter.
When a very small leak is detected through the EVAP leak diagnosis performed after judging the refueled
state, ECM transmits a fuel filler cap warning display signal (request for display ON) to the combination meter
via CAN communication.
When receiving the signal, the combination meter turns ON the fuel filler cap warning display.
CAUTION:
Check fuel filler cap installation condition when the fuel filler cap warning display turns ON.
Reset Operation
Decrease in engine
oil pressure Engine speed Combination meter
Oil pressure warning lamp
Detection Less than 1,000 rpm
ON*
1,000 rpm or more ON
Unit/Sensor Input signal to ECM ECM function
EVAP control system pressure sensor Pressure in purge line
Fuel filler cap warning control
Combination meter Fuel level
Fuel filler cap warning reset signal
*
JSBIA0797GB
Unit
Output signal Actuator
ECM Fuel filler cap warning display signal
*Combination meter
Revision: August 2015 2016 Versa Note
cardiagn.com
Page 1172 of 3641
![NISSAN NOTE 2016 Service Repair Manual SYSTEMEC-45
< SYSTEM DESCRIPTION > [HR16DE]
C
D
E
F
G H
I
J
K L
M A
EC
NP
O
The fuel filler cap warning lamp tunes OFF, according to any condition listed below:
• Reset operation is performed by ope NISSAN NOTE 2016 Service Repair Manual SYSTEMEC-45
< SYSTEM DESCRIPTION > [HR16DE]
C
D
E
F
G H
I
J
K L
M A
EC
NP
O
The fuel filler cap warning lamp tunes OFF, according to any condition listed below:
• Reset operation is performed by ope](/manual-img/5/57363/w960_57363-1171.png)
SYSTEMEC-45
< SYSTEM DESCRIPTION > [HR16DE]
C
D
E
F
G H
I
J
K L
M A
EC
NP
O
The fuel filler cap warning lamp tunes OFF, according to any condition listed below:
• Reset operation is performed by operating the meter control switch on the combination meter. Refer to
MWI-
16, "Switch Name and Function".
- When the reset operation is performed, the combination meter transmits a fuel filler cap warning reset signal to ECM via CAN communication. ECM transmits a fuel filler cap warning display signal (request for display
OFF) to the combination meter via CAN communication. When receiving the signal, the combination meter
turns OFF the fuel filler cap warning display.
• EVAP leak diagnosis result is normal.
• Fuel refilled.
• DTC erased by using CONSULT.
NOTE:
MIL turns ON if a malfunction is detected in leak diagnosis results again at the trip after the fuel filler cap warn-
ing display turns ON/OFF.
AUTOMATIC SPEED CONTROL DEVICE (ASCD)
AUTOMATIC SPEED CONTROL DEVI CE (ASCD) : System DiagramINFOID:0000000012431328
AUTOMATIC SPEED CONTROL DEVICE (ASCD) : System DescriptionINFOID:0000000012431329
INPUT/OUTPUT SIGNAL CHART
*: This signal is sent to the ECM via the CAN communication line
BASIC ASCD SYSTEM
Automatic Speed Control Device (ASCD) allows a driver to keep vehicle at predetermined constant speed
without depressing accelerator pedal. Driver can be set the vehicle speed in the set speed range.
ECM controls throttle angle of electric thro ttle control actuator to regulate engine speed.
Operation status of ASCD is indicated in combination meter.
If any malfunction occurs in the ASCD system, it automatically deactivates the ASCD control.
JSBIA3607GB
SensorInput signal to ECM ECM functionActuator
ASCD steering switch ASCD steering switch operation
ASCD vehicle speed control Electric throttle control actuator
Brake pedal position switch
Brake pedal operation
Stop lamp switch
Clutch pedal position switch Clutch pedal operation
Transmission range switch Gear position
Park/neutral position (PNP) switch PNP signal
Combination meter Vehicle speed signal*
TCM Output shaft revolution signal*
Revision: August 2015 2016 Versa Note
cardiagn.com
Page 1173 of 3641
EC-46
< SYSTEM DESCRIPTION >[HR16DE]
SYSTEM
Refer to
EC-47, "AUTOMATIC SPEED CONTROL DEVICE (A SCD) : Switch Name and Function" for ASCD
operating instructions.
CAUTION:
Always drive vehicle in a safe manner according to traffic conditions and obey all traffic laws.
Revision: August 2015 2016 Versa Note
cardiagn.com
Page 1174 of 3641
![NISSAN NOTE 2016 Service Repair Manual OPERATIONEC-47
< SYSTEM DESCRIPTION > [HR16DE]
C
D
E
F
G H
I
J
K L
M A
EC
NP
O
OPERATION
AUTOMATIC SPEED CONTROL DEVICE (ASCD)
AUTOMATIC SPEED CONTROL DEVICE (
ASCD) : Switch Name and Function
INFOID: NISSAN NOTE 2016 Service Repair Manual OPERATIONEC-47
< SYSTEM DESCRIPTION > [HR16DE]
C
D
E
F
G H
I
J
K L
M A
EC
NP
O
OPERATION
AUTOMATIC SPEED CONTROL DEVICE (ASCD)
AUTOMATIC SPEED CONTROL DEVICE (
ASCD) : Switch Name and Function
INFOID:](/manual-img/5/57363/w960_57363-1173.png)
OPERATIONEC-47
< SYSTEM DESCRIPTION > [HR16DE]
C
D
E
F
G H
I
J
K L
M A
EC
NP
O
OPERATION
AUTOMATIC SPEED CONTROL DEVICE (ASCD)
AUTOMATIC SPEED CONTROL DEVICE (
ASCD) : Switch Name and Function
INFOID:0000000012431330
SWITCHES AND INDICATORS
SET SPEED RANGE
ASCD system can be set the following vehicle speed.
SWITCH OPERATION
SET OPERATION
Press MAIN switch. (The CRUISE indicator in combination meter illuminates.)
When vehicle speed reaches a desired speed between approximately 38 km/h (24 MPH) and 144 km/h (90
MPH), press COAST/SET switch.
ACCELERATE OPERATION
If the ACCEL/RES switch is press ed during the cruise control driving, increase the vehicle speed until the
switch is released or vehicle speed reaches maximum speed controlled by the system.
And then ASCD will keep the new set speed.
CANCEL OPERATION
When any of following conditions exis t, cruise operation will be canceled.
• CANCEL switch is pressed
• More than 2 switches at ASCD steer ing switch are pressed at the same time (Set speed will be cleared)
• Brake pedal is depressed
• Clutch pedal is depressed or gear position is changed to neutral position. (M/T models)
• Selector lever is changed to N, P or R position (CVT models)
• Vehicle speed decreased to 13 km/h (8 MPH) lower than the set speed
CRUISE indicator SET indicator CANCEL switch
ACCEL/RES switch COAST/SET switch ASCD MAIN switch
On the combination meter
(Information display) On the steering wheel
JPBIA5485ZZ
Minimum speed (Approx.)
Maximum speed (Approx.)
38 km/h (24 MPH) 144 km/h (90 MPH)
ItemFunction
CANCEL switch Cancels the cruise control driving.
ACCEL/RES switch
(ACCELERATE/RESUME) • Resumes the set speed.
• Increases speed incrementally during cruise control driving.
COAST/SET switch • Sets desired cruise speed.
• Decreases speed incrementally during cruise control driving.
ASCD MAIN switch Master switch to activate the ASCD system.
Revision: August 2015 2016 Versa Note
cardiagn.com
Page 1175 of 3641
![NISSAN NOTE 2016 Service Repair Manual EC-48
< SYSTEM DESCRIPTION >[HR16DE]
OPERATION
• TCS system is operated
When the ECM detects any of the following conditions, the ECM will cancel the cruise operation and inform
the driver by blinki NISSAN NOTE 2016 Service Repair Manual EC-48
< SYSTEM DESCRIPTION >[HR16DE]
OPERATION
• TCS system is operated
When the ECM detects any of the following conditions, the ECM will cancel the cruise operation and inform
the driver by blinki](/manual-img/5/57363/w960_57363-1174.png)
EC-48
< SYSTEM DESCRIPTION >[HR16DE]
OPERATION
• TCS system is operated
When the ECM detects any of the following conditions, the ECM will cancel the cruise operation and inform
the driver by blinking indicator lamp.
• Engine coolant temperature is slightly higher than t
he normal operating temperature, CRUISE indicator may
blink slowly.
When the engine coolant temperature decreases to the normal operating temperature, CRUISE indicator will
stop blinking and the cruise operation will be able to work by pressing SET/ − switch or RES/+ switch.
• Malfunction for some self-diagnoses regarding AS CD control: SET indicator will blink quickly.
• Speed limiter MAIN switch is pressed.(Set speed is cleared.)
• ASCD MAIN switch is pressed.(Set speed is cleared.)
COAST OPERATION
When the COAST/SET switch is pressed during the cruise control driving, decrease vehicle set speed until the
switch is released. And then ASCD will keep the new set speed.
RESUME OPERATION
When the ACCEL/RES switch is pressed after cancel operation other than pressing MAIN switch is performed,
vehicle speed will return to last set speed. To resume vehicle set speed, vehicle condition must meet following
conditions.
• Brake pedal is released
• Clutch pedal is released (M/T models)
• Selector lever is in other than P and N positions (CVT models)
• Vehicle speed is greater than 38 km/h (24 MPH) and less than 144 km/h (90 MPH)
Revision: August 2015 2016 Versa Note
cardiagn.com
Page 1176 of 3641
ON BOARD DIAGNOSTIC (OBD) SYSTEMEC-49
< SYSTEM DESCRIPTION > [HR16DE]
C
D
E
F
G H
I
J
K L
M A
EC
NP
O
ON BOARD DIAGNOSTIC (OBD) SYSTEM
Diagnosis DescriptionINFOID:0000000012431331
This system is an on board diagnostic system that re
cords exhaust emission-related diagnostic information
and detects a sensors/actuator-related malfunction. A ma lfunction is indicated by the malfunction indicator
lamp (MIL) and stored in ECU memory as a DTC. The diagnostic information can be obtained with the diag-
nostic tool (GST: Generic Scan Tool).
GST (Generic Scan Tool)INFOID:0000000012431332
When GST is connected with a data link connector equipped on the vehicle side, it will communicate with the
control unit equipped in the vehicle and then enable various kinds of diagnostic tests. Refer to EC-49, "
Diag-
nosis Description".
NOTE:
Service $0A is not applied for regions where it is not mandated.
Revision: August 2015 2016 Versa Note
cardiagn.com
