Page 3113 of 3641

NISSAN NOTE 2016 Service Repair Manual SRC-96
< DTC/CIRCUIT DIAGNOSIS >
B142X COLLISION DETECTION
B142X COLLISION DETECTION
DescriptionINFOID:0000000012430680
DTC B142X COLLISION DETECTION
The air bag diagnosis sensor unit will set this DT

Page 3114 of 3641

NISSAN NOTE 2016 Service Repair Manual SRS AIR BAG WARNING LAMP DOES NOT TURN OFF
SRC-97
< SYMPTOM DIAGNOSIS >
C
D E
F
G
I
J
K L
M A
B
SRC
N
O P
SYMPTOM DIAGNOSIS
SRS AIR BAG WARNING LAMP DOES NOT TURN OFF
Diagnosis ProcedureINFOID:000000

Page 3115 of 3641

NISSAN NOTE 2016 Service Repair Manual SRC-98
< SYMPTOM DIAGNOSIS >
SRS AIR BAG WARNING LAMP DOES NOT TURN ON
SRS AIR BAG WARNING LAMP DOES NOT TURN ON
Diagnosis ProcedureINFOID:0000000012430684
1.CHECK COMBINATION METER POWER SUPPLY AND G

Page 3116 of 3641

NISSAN NOTE 2016 Service Repair Manual SEAT BELT WARNING SYSTEMSRC-99
< SYMPTOM DIAGNOSIS >
C
DE
F
G
I
J
K L
M A
B
SRC
N
O P
SEAT BELT WARNING SYSTEM
Seat Belt Warning Syst em Does Not FunctionINFOID:0000000012430685
1.SEAT BELT WARNING LI

Page 3117 of 3641

NISSAN NOTE 2016 Service Repair Manual SR-1
RESTRAINTS
C
DE
F
G
I
J
K L
M
SECTION SR
A
B
SR
N
O P
CONTENTS
SRS AIRBAG
PRECAUTION ....... ........................................2
PRECAUTIONS .............................................. .

SR-1
RESTRAINTS
C
DE
F
G
I
J
K L
M
SECTION SR
A
B
SR
N
O P
CONTENTS
SRS AIRBAG
PRECAUTION ....... ........................................2
PRECAUTIONS .............................................. .....2
Precaution for Supplemental Restraint System
(SRS) "AIR BAG" and "SEAT BELT PRE-TEN-
SIONER" ............................................................. ......
2
Service ......................................................................2
Precaution for Work ..................................................2
PREPARATION ............................................4
PREPARATION .............................................. .....4
Special Service Tools .......................................... ......4
BASIC INSPECTION ....................................5
COLLISION DIAGNOSIS ............................... .....5
For Frontal Collision ..................................................5
For Side and Rollover Collision ........................... ......7
REMOVAL AND INSTALLATION ...............12
DRIVER AIR BAG MODULE .......................... ....12
Exploded View .................................................... ....12
Removal and Installation .........................................12
SPIRAL CABLE ............................................. ....16
Exploded View .................................................... ....16
Removal and Installation .........................................16
FRONT PASSENGER AIR BAG MODULE ... ....19
Exploded View .................................................... ....19
Removal and Installation .........................................19
SIDE CURTAIN AIR BAG MODULE .............. ....21
Exploded View .................................................... ....21
Removal and Installation ..................................... ....21
SIDE AIR BAG MODULE ..................................23
Removal and Installation .........................................23
CRASH ZONE SENSOR ...................................24
Exploded View ..................................................... ....24
Removal and Installation .........................................24
SATELLITE SENSOR .......................................26
Exploded View .........................................................26
Removal and Installation - Front Door Satellite
Sensor ................................................................. ....
26
Removal and Installation - Front Side Air Bag Sat-
ellite Sensor .............................................................
27
Removal and Installation - Rear Side Air Bag Sat-
ellite Sensor ......................................................... ....
28
AIR BAG DIAGNOSIS SENSOR UNIT .............30
Exploded View .........................................................30
Removal and Installation .........................................30
OCCUPANT CLASSIFICATION SYSTEM
CONTROL UNIT ................................................
32
Removal and Installation .........................................32
SEAT BELT PRE-TENSIONER ........................34
Removal and Installation .........................................34
FRONT SEAT BELT BUCKLE SWITCH ..........35
Removal and Installation .........................................35
FRONT PASSENGER AIR BAG OFF INDICA-
TOR ...................................................................
36
Removal and Installation .........................................36
Revision: August 2015 2016 Versa Note

cardiagn.com

Page 3118 of 3641

NISSAN NOTE 2016 Service Repair Manual SR-2
< PRECAUTION >
PRECAUTIONS
PRECAUTION
PRECAUTIONS
Precaution for Supplemental Restraint System (SRS) "AIR BAG" and "SEAT BELT
PRE-TENSIONER"
INFOID:0000000012430560
The Supplemental Restraint Sy

SR-2
< PRECAUTION >
PRECAUTIONS
PRECAUTION
PRECAUTIONS
Precaution for Supplemental Restraint System (SRS) "AIR BAG" and "SEAT BELT
PRE-TENSIONER"
INFOID:0000000012430560
The Supplemental Restraint System such as “A IR BAG” and “SEAT BELT PRE-TENSIONER”, used along
with a front seat belt, helps to reduce the risk or severity of injury to the driver and front passenger for certain
types of collision. Information necessary to service the system safely is included in the SR and SB section of
this Service Manual.
WARNING:
• To avoid rendering the SRS inopera tive, which could increase the risk of personal injury or death in
the event of a collision which would result in air bag inflation, all maintenance must be performed by
an authorized NISSAN/INFINITI dealer.
• Improper maintenance, including in correct removal and installation of the SRS, can lead to personal
injury caused by unintent ional activation of the system. For re moval of Spiral Cable and Air Bag
Module, see the SR section.
• Do not use electrical test equipmen t on any circuit related to the SRS unless instructed to in this
Service Manual. SRS wiring harn esses can be identified by yellow and/or orange harnesses or har-
ness connectors.
PRECAUTIONS WHEN USING POWER TOOLS (AIR OR ELECTRIC) AND HAMMERS
WARNING:
• When working near the Airbag Diagnosis Sensor Unit or other Airbag System sensors with the Igni-
tion ON or engine running, DO NOT use air or electri c power tools or strike near the sensor(s) with a
hammer. Heavy vibration could activate the sensor( s) and deploy the air bag(s), possibly causing
serious injury.
• When using air or electric power tools or hammers , always switch the Ignition OFF, disconnect the
battery and wait at least three minutes before performing any service.
ServiceINFOID:0000000012430561
• Do not use electrical test equipment to check SRS ci rcuits unless instructed to in this Service Manual.
• Before servicing the SRS, turn ignition switch OFF, disconnect both battery cables and wait at least three
minutes.
For approximately three minutes after the cables are remo ved, it is still possible for the air bag and seat belt
pre-tensioner to deploy. Therefore, do not work on any SRS connectors or wires until at least three minutes
have passed.
• Diagnosis sensor unit must always be installed with their arrow marks “ ⇐” pointing towards the front of the
vehicle for proper operation. Also chec k diagnosis sensor unit for cracks, deformities or rust before installa-
tion and replace as required.
• The spiral cable must be aligned with the neutral position since its rotations are limited. Do not turn steering wheel and column after removal of steering gear.
• Handle air bag module carefully. Always place driver and front passenger air bag modules with the pad side facing upward and seat mounted front side air bag module standing with the stud bolt side facing down.
• Conduct self-diagnosis to check entire SRS for proper function after replacing any components.
• After air bag inflates, the instrument panel assembly should be replaced if damaged.
• Always replace instrument panel pad following front passenger air bag deployment.
Precaution for WorkINFOID:0000000012430562
• When removing or disassembling each component, be careful not to damage or deform it. If a component may be subject to interference, be sure to protect it with a shop cloth.
• When removing (disengaging) components with a screwdriver or similar tool, be sure to wrap the component with a shop cloth or vinyl tape to protect it.
• Protect the removed parts with a shop cloth and prevent them from being dropped.
• Replace a deformed or damaged clip.
• If a part is specified as a non-reusable part, always replace it with a new one.
• Be sure to tighten bolts and nuts securely to the specified torque.
• After installation is complete, be sure to check that each part works properly.
Revision: August 2015 2016 Versa Note

cardiagn.com

Page 3119 of 3641

NISSAN NOTE 2016 Service Repair Manual PRECAUTIONSSR-3
< PRECAUTION >
C
DE
F
G
I
J
K L
M A
B
SR
N
O P
• Follow the steps below to clean components:
- Water soluble dirt:
• Dip a soft cloth into lukewarm water, wring the water out of th

Page 3120 of 3641

NISSAN NOTE 2016 Service Repair Manual SR-4
< PREPARATION >
PREPARATION
PREPARATION
PREPARATION
Special Service ToolsINFOID:0000000012430563
The actual shape of the tools may differ from those illustrated here.
Tool number
(TechMate No.)
T
