Page 129 of 3641

NISSAN NOTE 2016 Service Repair Manual AV-124
< REMOVAL AND INSTALLATION >[DISPLAY AUDIO]
ANTENNA FEEDER
ANTENNA FEEDER
Feeder LayoutINFOID:0000000012432990
1. Antenna base (antenna amp. and
satellite antenna) 2. Rod Antenna
3. M351
4. M3

Page 130 of 3641

NISSAN NOTE 2016 Service Repair Manual AV
SATELLITE RADIO ANTENNAAV-125
< REMOVAL AND INSTALLATION > [DISPLAY AUDIO]
C
D
E
F
G H
I
J
K L
M B A
O P
SATELLITE RADIO ANTENNA
Removal and InstallationINFOID:0000000012432991
The satellite radio

Page 131 of 3641

NISSAN NOTE 2016 Service Repair Manual AV-126
< PRECAUTION >[NAVIGATION]
PRECAUTIONS
PRECAUTION
PRECAUTIONS
Precaution for Supplemental Restraint Syst
em (SRS) "AIR BAG" and "SEAT BELT
PRE-TENSIONER"
INFOID:0000000012432992
The Supplement

AV-126
< PRECAUTION >[NAVIGATION]
PRECAUTIONS
PRECAUTION
PRECAUTIONS
Precaution for Supplemental Restraint Syst
em (SRS) "AIR BAG" and "SEAT BELT
PRE-TENSIONER"
INFOID:0000000012432992
The Supplemental Restraint System such as “A IR BAG” and “SEAT BELT PRE-TENSIONER”, used along
with a front seat belt, helps to reduce the risk or severity of injury to the driver and front passenger for certain
types of collision. Information necessary to service the system safely is included in the SR and SB section of
this Service Manual.
WARNING:
• To avoid rendering the SRS inopera tive, which could increase the risk of personal injury or death in
the event of a collision which would result in air bag inflation, all maintenance must be performed by
an authorized NISSAN/INFINITI dealer.
• Improper maintenance, including in correct removal and installation of the SRS, can lead to personal
injury caused by unintent ional activation of the system. For re moval of Spiral Cable and Air Bag
Module, see the SR section.
• Do not use electrical test equipmen t on any circuit related to the SRS unless instructed to in this
Service Manual. SRS wiring harn esses can be identified by yellow and/or orange harnesses or har-
ness connectors.
PRECAUTIONS WHEN USING POWER TOOLS (AIR OR ELECTRIC) AND HAMMERS
WARNING:
• When working near the Airbag Diagnosis Sensor Unit or other Airbag System sensors with the Igni-
tion ON or engine running, DO NOT use air or electri c power tools or strike near the sensor(s) with a
hammer. Heavy vibration could activate the sensor( s) and deploy the air bag(s), possibly causing
serious injury.
• When using air or electric power tools or hammers , always switch the Ignition OFF, disconnect the
battery and wait at least three minutes before performing any service.
Cautions in Removing Battery Terminal and AV Control Unit (Models with AV Control
Unit)
INFOID:0000000012432993
CAUTION:
Remove battery terminal and AV control unit 30 seconds or more after turning the ignition switch OFF.
NOTE:
After the ignition switch is turned OFF, the AV cont rol unit continues operating for approximately 30 seconds.
Therefore, data corruption may occur if battery voltage is cut off within 30 seconds.
Precaution for Trouble DiagnosisINFOID:0000000012432994
AV COMMUNICATION SYSTEM
• Do not apply voltage of 7.0 V or higher to the measurement terminals.
• Use the tester with its open terminal voltage being 7.0 V or less.
• Be sure to turn ignition switch OFF and disconnect the battery cable from\
the negative terminal before checking the circuit.
Precaution for Harness RepairINFOID:0000000012432995
AV COMMUNICATION SYSTEM
Revision: August 2015 2016 Versa Note

cardiagn.com

Page 132 of 3641

NISSAN NOTE 2016 Service Repair Manual AV
PRECAUTIONSAV-127
< PRECAUTION > [NAVIGATION]
C
D
E
F
G H
I
J
K L
M B A
O P
• Solder the repaired parts, and wrap with tape. [Frays of twisted line must be within 110 mm (4.33 in).]
• Do not pe

Page 133 of 3641

NISSAN NOTE 2016 Service Repair Manual AV-128
< PREPARATION >[NAVIGATION]
PREPARATION
PREPARATION
PREPARATION
Special Service ToolsINFOID:0000000012432997
The actual shape of the tools may differ from those illustrated here.
Commercial Ser

Page 134 of 3641

NISSAN NOTE 2016 Service Repair Manual AV
COMPONENT PARTSAV-129
< SYSTEM DESCRIPTION > [NAVIGATION]
C
D
E
F
G H
I
J
K L
M B A
O P
SYSTEM DESCRIPTION
COMPONENT PARTS
Component Parts LocationINFOID:0000000012432999
A. Front of headliner B. V

Page 135 of 3641

NISSAN NOTE 2016 Service Repair Manual AV-130
< SYSTEM DESCRIPTION >[NAVIGATION]
COMPONENT PARTS
*: Around View Monitor is a parking aid/convenience feature. Around View Monitor cannot completely eliminate
blind spots. Around View Monitor

Page 136 of 3641

NISSAN NOTE 2016 Service Repair Manual AV
COMPONENT PARTSAV-131
< SYSTEM DESCRIPTION > [NAVIGATION]
C
D
E
F
G H
I
J
K L
M B A
O P
USB Interface and AUX In JackINFOID:0000000012433002
• USB Interface and AUX in jack is installed in the co
