2016 NISSAN NOTE Service Repair Manual

wiper blades android auto towing capacity bluetooth carplay key battery

Load previous 8 pages

Page 3081 of 3641

NISSAN NOTE 2016 Service Repair Manual SRC-64
< DTC/CIRCUIT DIAGNOSIS >
B0094 CRASH ZONE SENSOR
NO >> Perform one of the following repairs:• Visible damage: Replace the harness.
• Loose terminal: Secure the terminal.
• Poor connectio

Page 3082 of 3641

NISSAN NOTE 2016 Service Repair Manual B0093 FRONT DOOR SATELLITE SENSOR LHSRC-65
< DTC/CIRCUIT DIAGNOSIS >
C
DE
F
G
I
J
K L
M A
B
SRC
N
O P
B0093 FRONT DOOR SATELLITE SENSOR LH
DTC LogicINFOID:0000000012430643
DTC DETECTION LOGIC
With CO

Page 3083 of 3641

NISSAN NOTE 2016 Service Repair Manual SRC-66
< DTC/CIRCUIT DIAGNOSIS >
B0093 FRONT DOOR SATELLITE SENSOR LH
Is the inspection result normal?
YES >> GO TO 2.
NO >> Perform one of the following repairs:• Visible damage: Replace the harnes

Page 3084 of 3641

NISSAN NOTE 2016 Service Repair Manual B0098 FRONT DOOR SATELLITE SENSOR RHSRC-67
< DTC/CIRCUIT DIAGNOSIS >
C
DE
F
G
I
J
K L
M A
B
SRC
N
O P
B0098 FRONT DOOR SATELLITE SENSOR RH
DTC LogicINFOID:0000000012430645
DTC DETECTION LOGIC
With CO

Page 3085 of 3641

NISSAN NOTE 2016 Service Repair Manual SRC-68
< DTC/CIRCUIT DIAGNOSIS >
B0098 FRONT DOOR SATELLITE SENSOR RH
Is the inspection result normal?
YES >> GO TO 2.
NO >> Perform one of the following repairs:• Visible damage: Replace the harnes

Page 3086 of 3641

NISSAN NOTE 2016 Service Repair Manual B1500 DOOR SATELLITE SENSORSRC-69
< DTC/CIRCUIT DIAGNOSIS >
C
DE
F
G
I
J
K L
M A
B
SRC
N
O P
B1500 DOOR SATELLITE SENSOR
DTC LogicINFOID:0000000012430647
DTC DETECTION LOGIC
With CONSULT
DTC CONFIRMA

Page 3087 of 3641

NISSAN NOTE 2016 Service Repair Manual SRC-70
< DTC/CIRCUIT DIAGNOSIS >
B1500 DOOR SATELLITE SENSOR
• Loose terminal: Secure the terminal.
• Poor connection: Secure the connection.
2.CONFIRM DTC
1. Reconnect all harness connectors.
2.

Page 3088 of 3641

NISSAN NOTE 2016 Service Repair Manual B0091 FRONT SIDE AIR BAG SATELLITE SENSOR LHSRC-71
< DTC/CIRCUIT DIAGNOSIS >
C
DE
F
G
I
J
K L
M A
B
SRC
N
O P
B0091 FRONT SIDE AIR BAG SATELLITE SENSOR LH
DescriptionINFOID:0000000012430649
DTC B0091

B0091 FRONT SIDE AIR BAG SATELLITE SENSOR LHSRC-71
< DTC/CIRCUIT DIAGNOSIS >
C
DE
F
G
I
J
K L
M A
B
SRC
N
O P
B0091 FRONT SIDE AIR BAG SATELLITE SENSOR LH
DescriptionINFOID:0000000012430649
DTC B0091 FRONT SATELLITE SENSOR LH
The front side air bag satellite sensor LH is wired to the air bag diagnosis sensor unit. The air bag diagnosis
sensor unit will monitor the front side air bag satellite sensor LH for internal failures and its circuits for commu-
nication errors.
PA R T L O C AT I O N
Refer to SRC-5, "Component Parts Location".
DTC LogicINFOID:0000000012430650
DTC DETECTION LOGIC
With CONSULT
DTC CONFIRMATION PROCEDURE (With CONSULT)
1.CHECK SELF-DIAG RESULT
1. Turn ignition switch ON.
2. Check for DTC using CONSULT.
Is the DTC detected?
YES (Current DTC)>>Refer to SRC-72, "Diagnosis Procedure".
YES (Past DTC)>>GO TO 2.
NO >> Inspection End.
2.ERASE SELF-DIAG RESULT
Erase the DTC using CONSULT.
Can the DTC be erased?
YES >> Inspection End.
NO >> Refer to SRC-72, "
Diagnosis Procedure".
DTC CONFIRMATION PROCEDURE (Without CONSULT)
1.CHECK SELF-DIAG RESULT
1. Turn ignition switch ON.
2. Check the air bag warning lamp status. Refer to SRC-14, "
On Board Diagnosis Function".
NOTE:
SRS will not enter diagnosis mode if no malfunction is detected in user mode.
Is the DTC detected?
YES >> Refer to SRC-72, "Diagnosis Procedure".
NO >> Inspection End.
CONSULT name DTC DTC detecting condition Repair order
B-PILLAR SATELLITE SENSOR LH [SENSOR FAIL]
B0091Front side air bag satellite sensor LH
has malfunctioned.
Refer to
SRC-72, "
Diagnosis Procedure".
B-PILLAR SATELLITE SENSOR LH [COMM FAIL] Front side air bag satellite sensor LH
communication error.
B-PILLAR SATELLITE SENSOR LH [DISCONNECT] Front side air bag satellite sensor LH is
disconnected.
B-PILLAR SATELLITE SENSOR LH [UNMATCH] Front side air bag satellite sensor LH is
out of specification.
B-PILLAR SATELLITE SENSOR LH [GND-SHORT] Front side air bag satellite sensor LH cir-
cuit is shorted to ground.
Revision: August 2015
2016 Versa Note

cardiagn.com
