Page 2937 of 3641

NISSAN NOTE 2016 Service Repair Manual SEC-80
< DTC/CIRCUIT DIAGNOSIS >[WITH INTELLIGENT KEY SYSTEM]
B2605 SHIFT POSITION
B2605 SHIFT POSITION
DTC LogicINFOID:0000000012430393
DTC DETECTION LOGIC
NOTE:
• If DTC B2605 is displayed with DT

SEC-80
< DTC/CIRCUIT DIAGNOSIS >[WITH INTELLIGENT KEY SYSTEM]
B2605 SHIFT POSITION
B2605 SHIFT POSITION
DTC LogicINFOID:0000000012430393
DTC DETECTION LOGIC
NOTE:
• If DTC B2605 is displayed with DTC U1000, first perform the trouble diagnosis for DTC U1000. Refer to
BCS-63, "
DTC Logic".
• If DTC B2605 is displayed with DTC U1010, first perform the trouble diagnosis for DTC U1010. Refer to BCS-64, "
DTC Logic".
DTC CONFIRMATION PROCEDURE
1.PERFORM DTC CONFIRMATION PROCEDURE
1. Shift the selector lever to the P position.
2. Turn ignition switch ON and wait 1 second or more.
3. Shift the selector lever to the N position and wait 1 second or more.
4. Shift the selector lever to any position other than P and N, and wait 1 second or more.
5. Check DTC in “Self Diagnostic Result” of “BCM” using CONSULT.
Is DTC detected?
YES >> Go to SEC-80, "Diagnosis Procedure".
NO >> Inspection End.
Diagnosis ProcedureINFOID:0000000012430394
Regarding Wiring Diagram information, refer to SEC-37, "Wiring Diagram".
1.CHECK IPDM E/R INPUT SIGNAL
1. Turn ignition switch ON.
2. Check voltage between IPDM E/R harness connector and ground.
Is the inspection result normal?
YES >> GO TO 3.
NO >> GO TO 2.
2.CHECK IPDM E/R INPUT SIGNAL CIRCUIT
1. Turn ignition switch OFF.
2. Disconnect IPDM E/R connector.
3. Disconnect transmission range switch connector.
DTC No. Trouble diagnosis name DTC detecting condition Possible cause
B2605 SHIFT PN DIAG IPDM When ignition switch is ON, P/N position
signal input from transmission range switch
and P/N position signal (CAN) input from
IPDM E/R do not match. • Harness or connectors
(The CAN communication line is open or
shorted.)
• Harness or connectors (Transmission range switch circuit is
open or shorted.)
• Transmission range switch
• IPDM E/R
•BCM
(+)
(–)Condition Voltage (V)
(Approx.)
IPDM E/R
Connector Terminal
F42 40Ground Selector lever P or N position Battery voltage
Other than above 0
Revision: August 2015 2016 Versa Note

cardiagn.com

Page 2938 of 3641

NISSAN NOTE 2016 Service Repair Manual B2605 SHIFT POSITIONSEC-81
< DTC/CIRCUIT DIAGNOSIS > [WITH INTELLIGENT KEY SYSTEM]
C
D
E
F
G H
I
J
L
M A
B
SEC
N
O P
4. Check continuity between IPDM E/R harness connector and transmission range switc

Page 2939 of 3641

NISSAN NOTE 2016 Service Repair Manual SEC-82
< DTC/CIRCUIT DIAGNOSIS >[WITH INTELLIGENT KEY SYSTEM]
B2608 STARTER RELAY
B2608 STARTER RELAY
DTC LogicINFOID:0000000012430395
DTC DETECTION LOGIC
NOTE:
• If DTC B2608 is displayed with DTC

SEC-82
< DTC/CIRCUIT DIAGNOSIS >[WITH INTELLIGENT KEY SYSTEM]
B2608 STARTER RELAY
B2608 STARTER RELAY
DTC LogicINFOID:0000000012430395
DTC DETECTION LOGIC
NOTE:
• If DTC B2608 is displayed with DTC U1000, first perform the trouble diagnosis for DTC U1000. Refer to
BCS-63, "
DTC Logic".
• If DTC B2608 is displayed with DTC U1010, first perform the trouble diagnosis for DTC U1010. Refer to BCS-64, "
DTC Logic".
• If DTC B2608 is displayed with other DTC (BCM), first perform the trouble diagnosis for other DTC detected.\
DTC CONFIRMATION PROCEDURE
1.PERFORM DTC CONFIRMATION PROCEDURE
1. Press push-button ignition switch under t he following conditions to start engine.
- Selector lever: In the P position
- Brake pedal: Depressed
2. Wait 1 second after engine started.
3. Check DTC in “Self Diagnostic Result” of “BCM” using CONSULT.
Is DTC detected?
YES >> Go to SEC-82, "Diagnosis Procedure".
NO >> Inspection End.
Diagnosis ProcedureINFOID:0000000012430396
Regarding Wiring Diagram information, refer to SEC-37, "Wiring Diagram".
1.CHECK DTC OF IPDM E/R
Check DTC in “Self Diagnostic Result” of “IPDM E/R” using CONSULT.
Is DTC detected?
YES >> Perform the trouble diagnosis relat ed to the detected DTC. Refer to PCS-20, "DTCIndex".
NO >> GO TO 2.
2.CHECK STARTER RELAY POWER SUPPLY CIRCUIT
1. Turn ignition switch ON.
2. Check voltage between BCM harness connector and ground.
Is the inspection result normal?
YES >> GO TO 4.
NO >> GO TO 3.
DTC No. Trouble diagnosis name DTC detecting condition Possible cause
B2608 STARTER RELAY BCM outputs starter relay OFF signal but
BCM receives starter relay ON signal from
IPDM E/R (CAN). • Harness or connectors
(The CAN communication line is open or
shorted.)
• Harness or connectors (Starter relay circuit is open or shorted.)
•IPDM E/R
• Starter relay
(+)
(–) Condition Voltage (V)
(Approx.)
BCM
Connector Terminal
M98 97 Ground CVT selector lever N or P position Battery voltage
Other than above
0
Revision: August 2015 2016 Versa Note

cardiagn.com

Page 2940 of 3641

NISSAN NOTE 2016 Service Repair Manual B2608 STARTER RELAYSEC-83
< DTC/CIRCUIT DIAGNOSIS > [WITH INTELLIGENT KEY SYSTEM]
C
D
E
F
G H
I
J
L
M A
B
SEC
N
O P
3.CHECK STARTER RELAY CIRCUIT
1. Turn ignition switch OFF.
2. Disconnect starter rel

Page 2941 of 3641

NISSAN NOTE 2016 Service Repair Manual SEC-84
< DTC/CIRCUIT DIAGNOSIS >[WITH INTELLIGENT KEY SYSTEM]
B260F ENGINE STATUS
B260F ENGINE STATUS
DescriptionINFOID:0000000012430398
BCM receives the engine status signal from ECM via CAN communic

Page 2942 of 3641

NISSAN NOTE 2016 Service Repair Manual B261F ASCD CLUTCH SWITCHSEC-85
< DTC/CIRCUIT DIAGNOSIS > [WITH INTELLIGENT KEY SYSTEM]
C
D
E
F
G H
I
J
L
M A
B
SEC
N
O P
B261F ASCD CLUTCH SWITCH
DTC LogicINFOID:0000000012430401
DTC DETECTION LOGIC
N

B261F ASCD CLUTCH SWITCHSEC-85
< DTC/CIRCUIT DIAGNOSIS > [WITH INTELLIGENT KEY SYSTEM]
C
D
E
F
G H
I
J
L
M A
B
SEC
N
O P
B261F ASCD CLUTCH SWITCH
DTC LogicINFOID:0000000012430401
DTC DETECTION LOGIC
NOTE:
• If DTC B261F is displayed with DTC U1000, first perform the trouble diagnosis for DTC U1000. Refer to
BCS-63, "
DTC Logic".
• If DTC B261F is displayed with DTC U1010, first perform the trouble diagnosis for DTC U1010. Refer to
BCS-64, "
DTC Logic".
DTC CONFIRMATION PROCEDURE
1.PERFORM DTC CONFIRMATION PROCEDURE
1. Start the engine.
2. Drive vehicle at a speed of 40 km/h (24.8 MPH) or more for 10 seconds.
3. Decrease the vehicle speed to below 40 km/h (24.8 MPH).
4. Repeat steps 2 and 3 twice (total of 3 times).
5. Check DTC in “Self Diagnostic Result” of “BCM” using CONSULT.
Is DTC detected?
YES >> Go to SEC-85, "Diagnosis Procedure".
NO >> Inspection End
Diagnosis ProcedureINFOID:0000000012430402
Regarding Wiring Diagram information, refer to SEC-37, "Wiring Diagram".
1.CHECK DTC OF COMBINATION METER
Check DTC in “Self Diagnostic Result ” of “METER/M&A” using CONSULT.
Refer to MWI-24, "
DTC Index".
Is the inspection result normal?
YES >> GO TO 2.
NO >> Repair or replace the malfunctioning parts.
2.CHECK FUSE
1. Turn power switch OFF.
2. Check that the following fuse in the fuse block (J/B) is not blown.
Is the inspection result normal?
YES >> GO TO 3.
NO >> Replace the blown fuse after repairing the cause of blowing.
DTC No. CONSULT screen items
(Trouble diagnosis content) DTC detecting condition
Possible cause
B261F ASCD CNCL/CLTCH SW
(ASCD clutch interlock
switch) BCM detects the following status for 10 seconds
3 times:
• Clutch interlock switch input: 0 V.
• Vehicle speed: 40 km/h (24.8 MPH) or more. • Harness or connectors.
(CAN communication line is open
or shorted.)
• Harness or connectors. (Clutch interlock switch circuit is
open or shorted)
• Clutch interlock switch
• Combination meter
•BCM
Signal name Fuse No.
Ignition power supply 10 (10 A)
Revision: August 2015 2016 Versa Note

cardiagn.com

Page 2943 of 3641

NISSAN NOTE 2016 Service Repair Manual SEC-86
< DTC/CIRCUIT DIAGNOSIS >[WITH INTELLIGENT KEY SYSTEM]
B261F ASCD CLUTCH SWITCH
3.CHECK CLUTCH INTERLOCK SWITCH POWER SUPPLY
1. Disconnect clutch interlock switch connector.
2. Turn ignition sw

Page 2944 of 3641

NISSAN NOTE 2016 Service Repair Manual B261F ASCD CLUTCH SWITCHSEC-87
< DTC/CIRCUIT DIAGNOSIS > [WITH INTELLIGENT KEY SYSTEM]
C
D
E
F
G H
I
J
L
M A
B
SEC
N
O P
>> Inspection End.
Component InspectionINFOID:0000000012430403
1.CHECK CLUTCH I
