DLK-96
< DTC/CIRCUIT DIAGNOSIS >[WITH INTELLIGENT KEY SYSTEM]
BACK DOOR REQUEST SWITCH
BACK DOOR REQUEST SWITCH
DescriptionINFOID:0000000012430033
Transmits lock/unlock operation to BCM.
Component Function CheckINFOID:0000000012430034
1.CHECK FUNCTION
Check “REQSW-BD/TR” in “Data Monitor” using CONSULT.
Is the inspection result normal?
YES >> Back door request switch is OK.
NO >> Refer to DLK-96, "
Diagnosis Procedure".
Diagnosis ProcedureINFOID:0000000012430035
Regarding Wiring Diagram information, refer to DLK-46, "Wiring Diagram".
1.CHECK BACK DOOR REQUEST SWITCH INPUT SIGNAL
1. Turn ignition switch OFF.
2. Disconnect back door request switch connector.
3. Check voltage between back door request switch harness connector and ground.
Is the inspection result normal?
YES >> GO TO 3.
NO >> GO TO 2.
2.CHECK BACK DOOR REQUEST SWITCH CIRCUIT
1. Disconnect BCM connector.
2. Check continuity between BCM harness connecto r and back door request switch harness connector.
3. Check continuity between BCM harness connector and ground.
Is the inspection result normal?
YES >> Replace BCM. Refer to BCS-74, "Removal and Installation".
NO >> Repair harness or connector.
3.CHECK BACK DOOR REQUEST SWITCH GROUND CIRCUIT
Monitor item Condition Status
REQSW-BD/TR Back door request switch Pressed
ON
Released OFF
(+)
(–)Voltage (V)
(Approx.)
Back door request switch
Connector Terminal
D506 1GroundBattery voltage
BCM Back door request switch
Continuity
Connector TerminalConnector Terminal
M100 51D506 1Yes
BCM GroundContinuity
Connector Terminal
M100 51 No
Revision: August 2015 2016 Versa Note
