DLK-232
< DTC/CIRCUIT DIAGNOSIS >[WITHOUT INTELLIGENT KEY SYSTEM]
DOOR SWITCH
DOOR SWITCH
DescriptionINFOID:0000000012430182
Detects door open/close condition.
Component Function CheckINFOID:0000000012430183
1.CHECK FUNCTION
With CONSULT
Check door switches “DOOR SW-DR”, “DOOR SW-AS”, “DOOR SW-RL”, “DOOR SW-RR” in “Data Monitor”.
Is the inspection result normal?
YES >> Door switch is OK.
NO >> Refer to DLK-232, "
Diagnosis Procedure".
Diagnosis ProcedureINFOID:0000000012430184
Regarding Wiring Diagram information, refer to DLK-206, "Wiring Diagram".
1.CHECK DOOR SWITCH INPUT SIGNAL
1. Turn ignition switch OFF.
2. Check signal between BCM connector and ground with oscilloscope.
Monitor item Condition
DOOR SW-DR
CLOSE → OPEN: OFF → ON
DOOR SW-AS
DOOR SW-RL
DOOR SW-RR
Revision: August 2015 2016 Versa Note
cardiagn.com
Page 922 of 3641
DOOR SWITCHDLK-233
< DTC/CIRCUIT DIAGNOSIS > [WITHOUT INTELLIGENT KEY SYSTEM]
C
D
E
F
G H
I
J
L
M A
B
DLK
N
O P
Is the inspection result normal?
YES >> GO TO 4.
NO >> GO TO 2.
2.CHECK DOOR SWITCH CIRCUIT
1. Disconnect BCM connector and door switch connector.
2. Check continuity between BCM connector and door switch connector.
Te r m i n a l s
Door condition Voltage (V)
(Approx.)
(+)
(–)
BCM
connector Te r m i n a l
M20 60
Ground Front RH
OPEN
0
CLOSE
57 Rear RHOPEN
0
CLOSE
59 Front LHOPEN
0
CLOSE
58 Rear LHOPEN
0
CLOSE
PKIB4960J
PKIB4960J
PKIB4960J
PKIB4960J
BCM connector Terminal Door switch
connector Terminal Continuity
M20 60
B16 (Front RH)
3Yes
57
B17 (Rear RH)
59 B8 (Front LH)
58 B6 (Rear LH)
Revision: August 2015 2016 Versa Note
cardiagn.com
Page 923 of 3641
DLK-234
< DTC/CIRCUIT DIAGNOSIS >[WITHOUT INTELLIGENT KEY SYSTEM]
DOOR SWITCH
3. Check continuity between BCM connector and ground.
Is the inspection result normal?
YES >> GO TO 3.
NO >> Repair or replace harness between BCM and door switch.
3.CHECK DOOR SWITCH
Refer to DLK-234, "
Component Inspection".
Is the inspection result normal?
YES >> GO TO 4.
NO >> Replace malfunctioning door switch.
4.CHECK INTERMITTENT INCIDENT
Refer to GI-42, "
Intermittent Incident".
>> Inspection End.
Component InspectionINFOID:0000000012430185
1.CHECK DOOR SWITCH
1. Turn ignition switch OFF.
2. Disconnect door switch connector.
3. Check door switch.
Is the inspection result normal?
YES >> Inspection End.
NO >> Replace malfunctioning door switch.
BCM connector Terminal
GroundContinuity
M20 60
No
57
59
58
Te r m i n a l
Door switch condition Continuity
Door switch
3 Ground part of door switch Pressed
No
Released Yes
Revision: August 2015 2016 Versa Note
cardiagn.com
Page 924 of 3641
