NISSAN NOTE 2016 Service Repair Manual C1145, C1146 YAW RATE/SIDE/DECEL G SENSORBRC-105
< DTC/CIRCUIT DIAGNOSIS > [VDC/TCS/ABS]
C
D
E
G H
I
J
K L
M A
B
BRC
N
O P
C1145, C1146 YAW RATE/SIDE/DECEL G SENSOR
DTC DescriptionINFOID:0000000012430

C1145, C1146 YAW RATE/SIDE/DECEL G SENSORBRC-105
< DTC/CIRCUIT DIAGNOSIS > [VDC/TCS/ABS]
C
D
E
G H
I
J
K L
M A
B
BRC
N
O P
C1145, C1146 YAW RATE/SIDE/DECEL G SENSOR
DTC DescriptionINFOID:0000000012430883
DTC DETECTION LOGIC
POSSIBLE CAUSE
NOTE:
Confirm if DTC is PAST or CRNT. If DTC is CRNT, proceed with Diagnosis Procedure. If DTC is PAST, clear
the DTC. Do not replace the ABS actuator and electric unit (control unit) for a PAST DTC.
DTC CONFIRMATION PROCEDURE
1.PRECONDITIONING
If “DTC CONFIRMATION PROCEDURE” has been previously conducted, always turn the ignition switch OFF
and wait at least 10 seconds before conducting the next test.
>> GO TO 2.
2.CHECK DTC DETECTION
With CONSULT
1. Turn the ignition switch OFF. NOTE:
Wait at least 10 seconds after turning ignition switch OFF.
2. Start the engine. NOTE:
Wait at least 10 seconds after starting the engine.
3. Perform “Self Diagnostic Result” of “ABS”.
Is DTC
“C1145” or “C1146” detected?
YES-1 >> “C1145” or “C1146” is displayed as “CRNT”: Proceed to BRC-105, "Diagnosis Procedure".
YES-2 >> “C1145” or “C1146” is displayed as “PAST” : Inspection End (Erase “Self Diagnostic Result” of
“ABS”).
NO-1 >> To check malfunction symptom before repair: Refer to GI-42, "
Intermittent Incident".
NO-2 >> Confirmation after repair: Inspection End.
Diagnosis ProcedureINFOID:0000000012430884
1.CHECK SELF-DIAGNOSIS RESULTS
Replace the ABS actuator and electric unit (control unit) even if other DTCs are displayed along with “C1145”
or “C1146” in “Self Diagnostic Result” of “ABS”.
>> Replace the ABS actuator and electric unit (control unit). Refer to BRC-144, "
Removal and Instal-
lation".
DTCDisplay Item
(Trouble diagnosis content) Malfunction detected condition
C1145 YAW RATE SENSOR
(Yaw rate sensor circuit) When a malfunction is detected in yaw rate signal.
C1146 SIDE G SEN CIRCUIT
(Side G sensor circuit) When a malfunction is detected in side/decel G signal.
PAST DTC
CRNT DTC
• Harness or connector
• ABS actuator and electric unit (control unit) power supply sys-
tem
•Fuse
• Fusible link
•Battery ABS actuator and electric
unit (control unit)
Revision: August 2015 2016 Versa Note

cardiagn.com

Page 554 of 3641

NISSAN NOTE 2016 Service Repair Manual B RC-106
< DTC/CIRCUIT DIAGNOSIS >[VDC/TCS/ABS]
C1154 TRANSMISSION RANGE SWITCH
C1154 TRANSMISSION RANGE SWITCH
DTC DescriptionINFOID:0000000012430885
DTC DETECTION LOGIC
POSSIBLE CAUSE
NOTE:
Confirm

B RC-106
< DTC/CIRCUIT DIAGNOSIS >[VDC/TCS/ABS]
C1154 TRANSMISSION RANGE SWITCH
C1154 TRANSMISSION RANGE SWITCH
DTC DescriptionINFOID:0000000012430885
DTC DETECTION LOGIC
POSSIBLE CAUSE
NOTE:
Confirm if DTC is PAST or CRNT. If DTC is CRNT, proceed with Diagnosis Procedure. If DTC is PAST, clear
the DTC. Do not replace the
ABS actuator and electric unit (control unit) for a PAST DTC.
DTC CONFIRMATION PROCEDURE
1.PRECONDITIONING
If “DTC CONFIRMATION PROCEDURE” has been previously conducted, always turn the ignition switch OFF
and wait at least 10 seconds before conducting the next test.
>> GO TO 2.
2.CHECK DTC DETECTION
With CONSULT
1. Turn the ignition switch OFF.
NOTE:
Wait at least 10 seconds after turning ignition switch OFF.
2. Start the engine.
NOTE:
Wait at least 10 seconds after starting the engine.
3. Perform “Self Diagnostic Result” of “ABS”.
Is DTC
“C1154” detected?
YES-1 >> “C1154” is displayed as “CRNT”: Proceed to BRC-106, "Diagnosis Procedure".
YES-2 >> “C1154” is displayed as “PAST”: Inspection End (Erase “Self Diagnostic Result” of “ABS”).
NO-1 >> To check malfunction symptom before repair: Refer to GI-42, "
Intermittent Incident".
NO-2 >> Confirmation after repair: Inspection End.
Diagnosis ProcedureINFOID:0000000012430886
CAUTION:
“C1154” may be detected when goin g up a slope, being towed with ignition switch ON and the shift
selector in a position other than R position. This is not a shift position error. The system returns to
normal once the vehicle is stopped, parked on level ground and the engine is started.
1.CHECK CVT SYSTEM
With CONSULT
Perform “Self Diagnostic Resu lt” of “TRANSMISSION”.
Is DTC detected?
YES >> Check the DTC. Refer to TM-110, "DTC Index".
NO >> GO TO 2.
DTC Display Item
(Trouble diagnosis content) Malfunction detected condition
C1154 PNP POSI SIG
(PNP position signal) When a malfunction is detected in TCM system.
PAST DTC
CRNT DTC
• Harness or connector
• Transmission range switch • Harness or connector
• ABS actuator and electric unit (control unit)
•TCM
• Transmission range switch
Revision: August 2015
2016 Versa Note

cardiagn.com

Page 555 of 3641

NISSAN NOTE 2016 Service Repair Manual C1154 TRANSMISSION RANGE SWITCHBRC-107
< DTC/CIRCUIT DIAGNOSIS > [VDC/TCS/ABS]
C
D
E
G H
I
J
K L
M A
B
BRC
N
O P
2.PERFORM SELF-DIAGNOSIS
With CONSULT
1. Erase “Self Diagnostic Result” of “ABS�

Page 556 of 3641

NISSAN NOTE 2016 Service Repair Manual BRC-108
< DTC/CIRCUIT DIAGNOSIS >[VDC/TCS/ABS]
C1155 BRAKE FLUID LEVEL SWITCH
C1155 BRAKE FLUID LEVEL SWITCH
DTC DescriptionINFOID:0000000012430887
DTC DETECTION LOGIC
POSSIBLE CAUSE
NOTE:
Confirm if

BRC-108
< DTC/CIRCUIT DIAGNOSIS >[VDC/TCS/ABS]
C1155 BRAKE FLUID LEVEL SWITCH
C1155 BRAKE FLUID LEVEL SWITCH
DTC DescriptionINFOID:0000000012430887
DTC DETECTION LOGIC
POSSIBLE CAUSE
NOTE:
Confirm if DTC is PAST or CRNT. If DTC is CRNT, proceed with Diagnosis Procedure. If DTC is PAST, clear
the DTC. Do not replace the
ABS actuator and electric unit (control unit) for a PAST DTC.
DTC CONFIRMATION PROCEDURE
1.PRECONDITIONING
If “DTC CONFIRMATION PROCEDURE” has been previously conducted, always turn the ignition switch OFF
and wait at least 10 seconds before conducting the next test.
>> GO TO 2.
2.CHECK DTC DETECTION
With CONSULT
1. Turn the ignition switch OFF. NOTE:
Wait at least 10 seconds after turning ignition switch OFF.
2. Start the engine. NOTE:
Wait at least 10 seconds after starting the engine.
3. Perform “Self Diagnostic Result” of “ABS”.
Is DTC
“C1155” detected?
YES-1 >> “C1155” is displayed as “CRNT”: Proceed to BRC-108, "Diagnosis Procedure".
YES-2 >> “C1155” is displayed as “PAST”: Inspection End (Erase “Self Diagnostic Result” of “ABS”).
NO-1 >> To check malfunction symptom before repair: Refer to GI-42, "
Intermittent Incident".
NO-2 >> Confirmation after repair: Inspection End.
Diagnosis ProcedureINFOID:0000000012430888
1.CHECK BRAKE FLUID LEVEL
1. Turn the ignition switch OFF.
2. Check the brake fluid level. Refer to BR-12, "
Inspection".
Is the inspection result normal?
YES >> GO TO 3.
NO >> Refill brake fluid. Refer to BR-12, "
Refilling". GO TO 2.
2.PERFORM SELF-DIAGNOSIS (1)
With CONSULT
1. Erase “Self Diagnostic Result” of “ABS”
DTC Display Item
(Trouble diagnosis content) Malfunction detected condition
C1155 BR FLUID LEVEL LOW
(Brake fluid level low) • When brake fluid level low signal is detected.
• When an open circuit is detected in brake fluid level switch circuit.
PAST DTC
CRNT DTC
• Harness or connector
• Brake fluid level is low • Harness or connector
• ABS actuator and electric unit (control unit)
• Brake fluid level switch
• Combination meter
• Brake fluid level is low
Revision: August 2015
2016 Versa Note

cardiagn.com
