TM-16
< SYMPTOM DIAGNOSIS >[5MT: RS5F91R]
NOISE, VIBRATION AND HARSHNESS
(NVH) TROUBLESHOOTING
SYMPTOM DIAGNOSIS
NOISE, VIBRATION AND HARSHNESS (NVH) TROUBLESHOOTING
NVH Troubleshooting ChartINFOID:0000000012430946
Use the chart below to find the cause of the symptom. T he numbers indicate the order of the inspection. If nec-
essary, repair or replace these parts.
Reference pageTM-17TM-26TM-21TM-26
SUSPECTED PARTS
(Possible cause)
OIL (Oil level is low)
OIL (Wrong oil)
OIL (Oil level is high)
GASKET (Damaged)
OIL SEAL (Worn or damaged)
O-RING (Worn or damaged)
SHIFT CONTROL LINKAGE (Worn)
SHIFT FORK (Worn)
GEAR (Worn or damaged)
BEARING (Worn or damaged)
BAULK RING (Worn or damaged)
INSERT SPRING (Damaged)
Symptoms Noise
1 2 3 3
Oil leakage 31222
Hard to shift or will not shift 1 123 3
Jumps out of gear 1 2 2
Revision: August 2015 2016 Versa Note
cardiagn.com
Page 3258 of 3641
![NISSAN NOTE 2016 Service Repair Manual GEAR OILTM-17
< PERIODIC MAINTENANCE > [5MT: RS5F91R]
C
EF
G H
I
J
K L
M A
B
TM
N
O P
PERIODIC MAINTENANCE
GEAR OIL
InspectionINFOID:0000000012430947
GEAR OIL LEAKS
Make sure that gear oil is not l ea NISSAN NOTE 2016 Service Repair Manual GEAR OILTM-17
< PERIODIC MAINTENANCE > [5MT: RS5F91R]
C
EF
G H
I
J
K L
M A
B
TM
N
O P
PERIODIC MAINTENANCE
GEAR OIL
InspectionINFOID:0000000012430947
GEAR OIL LEAKS
Make sure that gear oil is not l ea](/manual-img/5/57363/w960_57363-3257.png)
GEAR OILTM-17
< PERIODIC MAINTENANCE > [5MT: RS5F91R]
C
EF
G H
I
J
K L
M A
B
TM
N
O P
PERIODIC MAINTENANCE
GEAR OIL
InspectionINFOID:0000000012430947
GEAR OIL LEAKS
Make sure that gear oil is not l eaking from transaxle or around it.
GEAR OIL LEVEL
1. Remove filler plug (1) and gasket from transaxle case.
2. Check the gear oil level from filler plug hole as shown.
CAUTION:
Do not start engine whil e checking gear oil level.
3. Install a new gasket on filler plug and then install filler plug to transaxle case.
CAUTION:
Do not reuse gasket.
4. Tighten filler plug to the specified torque. Refer to TM-26,
"Exploded View".
DrainingINFOID:0000000012430948
1. Start engine and let it run to warm up transaxle.
2. Stop engine. Remove drain plug (1) and gasket, using suitable
tool and then drain gear oil.
3. Install a new gasket on drain plug (1) and install drain plug to clutch housing, using suitable tool.
CAUTION:
Do not reuse gasket.
4. Tighten drain plug (1) to the specified torque. Refer to TM-26,
"Exploded View".
RefillingINFOID:0000000012430949
1. Remove filler plug (1) and gasket from transaxle case.
2. Fill with new gear oil until gear oil level reaches the specified limit at filler plug hole as shown.
CAUTION:
Do not start engine whil e checking gear oil level.
3. Install a new gasket on filler plug and then install filler plug to transaxle case.
CAUTION:
Do not reuse gasket.
4. Tighten filler plug to the specified torque. Refer to TM-26, "
Exploded View".
SCIA7119E
PCIB1504E
Oil capacity
and viscosity: Refer to
MA-11, "Fluids and Lubri-
cants".
SCIA7119E
Revision: August 2015 2016 Versa Note
cardiagn.com
Page 3259 of 3641
![NISSAN NOTE 2016 Service Repair Manual TM-18
< REMOVAL AND INSTALLATION >[5MT: RS5F91R]
SIDE OIL SEAL
REMOVAL AND INSTALLATION
SIDE OIL SEAL
Removal and InstallationINFOID:0000000012430950
REMOVAL
1. Remove front drive shaft from transaxle NISSAN NOTE 2016 Service Repair Manual TM-18
< REMOVAL AND INSTALLATION >[5MT: RS5F91R]
SIDE OIL SEAL
REMOVAL AND INSTALLATION
SIDE OIL SEAL
Removal and InstallationINFOID:0000000012430950
REMOVAL
1. Remove front drive shaft from transaxle](/manual-img/5/57363/w960_57363-3258.png)
TM-18
< REMOVAL AND INSTALLATION >[5MT: RS5F91R]
SIDE OIL SEAL
REMOVAL AND INSTALLATION
SIDE OIL SEAL
Removal and InstallationINFOID:0000000012430950
REMOVAL
1. Remove front drive shaft from transaxle assembly. Refer to
FAX-19, "Removal and Installation".
2. Remove differential side oil seal (1) using suitable tool. CAUTION:
Do not damage transaxle case and clutch housing.
INSTALLATION
1. Install differential side oil seal (1) to transaxle case side (B) andclutch housing side (C) using Tool.
CAUTION:
• Do not reuse differential side oil seal.
• Do not tilt differential side oil seal.
• Do not damage clutch housing and transaxle case.
2. Install the front drive shaft. Refer to FAX-19, "
Removal and Installation".
InspectionINFOID:0000000012430951
INSPECTION AFTER INSTALLATION
Check the gear oil level and for gear oil leaks. Refer to TM-17, "Inspection".
JPDIC0118ZZ
Dimension (L1) : 5.7 – 6.3 mm (0.224 – 0.248 in)
Dimension (L
2): 2.4 – 3.0 mm (0.094 – 0.118 in)
Tool number : KV32500QAA ( — )
JPDIC0401ZZ
Revision: August 2015 2016 Versa Note
cardiagn.com
Page 3260 of 3641
![NISSAN NOTE 2016 Service Repair Manual POSITION SWITCHTM-19
< REMOVAL AND INSTALLATION > [5MT: RS5F91R]
C
EF
G H
I
J
K L
M A
B
TM
N
O P
POSITION SWITCH
Removal and InstallationINFOID:0000000012430952
REMOVAL
1. Drain gear oil. Refer to TM NISSAN NOTE 2016 Service Repair Manual POSITION SWITCHTM-19
< REMOVAL AND INSTALLATION > [5MT: RS5F91R]
C
EF
G H
I
J
K L
M A
B
TM
N
O P
POSITION SWITCH
Removal and InstallationINFOID:0000000012430952
REMOVAL
1. Drain gear oil. Refer to TM](/manual-img/5/57363/w960_57363-3259.png)
POSITION SWITCHTM-19
< REMOVAL AND INSTALLATION > [5MT: RS5F91R]
C
EF
G H
I
J
K L
M A
B
TM
N
O P
POSITION SWITCH
Removal and InstallationINFOID:0000000012430952
REMOVAL
1. Drain gear oil. Refer to TM-17, "Draining".
2. Disconnect the harness connector (A) from position switch.
3. Remove position switch from transaxle case.
INSTALLATION
1. Apply recommended sealant to threads of position switch.
CAUTION:
• Use Genuine Silicone RTV or equivalent. Refer to GI-22, "
Recommended Chemical Products and
Sealants".
• Remove old sealant and gear oil adhering to threads.
2. Install position switch to transaxle case.
3. Tighten position switch to the specified torque. Refer to TM-26, "
Exploded View".
4. Refill gear oil. Refer to TM-17, "
Refilling".
InspectionINFOID:0000000012430953
INSPECTION AFTER INSTALLATION
• Check continuity between position switch terminals. Refer to TM-15, "BACK-UP LAMP SWITCH : Compo-
nent Inspection" (Back-up lamp switch) and TM-15, "PARK/NEUTRAL POSITION (PNP) SWITCH : Compo-
nent Inspection" (PNP switch).
• Check the gear oil level and for gear oil leaks. Refer to TM-17, "
Inspection".
JPDIC0733ZZ
Revision: August 2015 2016 Versa Note
cardiagn.com
Page 3261 of 3641
![NISSAN NOTE 2016 Service Repair Manual TM-20
< REMOVAL AND INSTALLATION >[5MT: RS5F91R]
CONTROL LINKAGE
CONTROL LINKAGE
Exploded ViewINFOID:0000000012430954
Removal and InstallationINFOID:0000000012430955
REMOVAL
1. Move the shift selecto NISSAN NOTE 2016 Service Repair Manual TM-20
< REMOVAL AND INSTALLATION >[5MT: RS5F91R]
CONTROL LINKAGE
CONTROL LINKAGE
Exploded ViewINFOID:0000000012430954
Removal and InstallationINFOID:0000000012430955
REMOVAL
1. Move the shift selecto](/manual-img/5/57363/w960_57363-3260.png)
TM-20
< REMOVAL AND INSTALLATION >[5MT: RS5F91R]
CONTROL LINKAGE
CONTROL LINKAGE
Exploded ViewINFOID:0000000012430954
Removal and InstallationINFOID:0000000012430955
REMOVAL
1. Move the shift selector to the neutral position.
2. Remove the battery tray. Refer to
PG-71, "
Removal and Installation (Battery Tray)".
3. Pull out and disconnect cables from shifter lever A and selector lever, using a suitable tool.
4. While pressing the lock of the selector cable in the direction of the arrows shown, remove the selector cable from the cable
mounting bracket.
5. While pressing the lock of the shifter cable in the direction of the arrows shown, remove the shifter cable from the cable mounting
bracket.
6. Remove cable mounting bracket from clutch housing.
7. Pull the shift selector handle upward to remove.
8. Remove center console assembly. Refer to IP-18, "
Removal and
Installation".
9. Pull out and disconnect each cable from the shift selector assembly, using a suitable tool.
1. Shifter lever A 2. Selector lever 3. Selector cable
4. Shifter cable 5. Cable mounting bracket6. Tapping bolt
7. Bracket 8. Grommet9. Shift selector assembly
10. Shift selector 11. Shift selector handle
JPDIC0789GB
JPDIC0793ZZ
Revision: August 2015 2016 Versa Note
cardiagn.com
Page 3262 of 3641
![NISSAN NOTE 2016 Service Repair Manual CONTROL LINKAGETM-21
< REMOVAL AND INSTALLATION > [5MT: RS5F91R]
C
EF
G H
I
J
K L
M A
B
TM
N
O P
a. While pressing the lock of the selector cable in the direction of the arrows shown, remove the selec NISSAN NOTE 2016 Service Repair Manual CONTROL LINKAGETM-21
< REMOVAL AND INSTALLATION > [5MT: RS5F91R]
C
EF
G H
I
J
K L
M A
B
TM
N
O P
a. While pressing the lock of the selector cable in the direction of the arrows shown, remove the selec](/manual-img/5/57363/w960_57363-3261.png)
CONTROL LINKAGETM-21
< REMOVAL AND INSTALLATION > [5MT: RS5F91R]
C
EF
G H
I
J
K L
M A
B
TM
N
O P
a. While pressing the lock of the selector cable in the direction of the arrows shown, remove the selector cable from the shift
selector assembly.
b. While pressing the lock of the shifter cable in the direction of the arrows shown, remove the shifter cable from the shift selector
assembly.
10. Remove the shift selector assembly.
11. Remove center muffler, exhaust front tube, and heat plate. Refer to EX-5, "
Exploded View".
12. Remove the bracket from the vehicle.
13. Remove the grommet and then remove the shifter cable and selector cable from the vehicle.
INSTALLATION
Installation is in the reverse order of removal.
CAUTION:
• Install each cable without causing in terference with other parts. Do not allow cable to bend less than
120 mm (4.72 in), or exceed 180 degree twist.
• Install boot of each cable without causing interference with other parts. Do not exceed 90 degree twist.
• Fit boot to center console assembly an d the groove on shift selector handle.
• To install the shift selector handle, press it onto the shift selector. CAUTION:
• Do not reuse shift selector handle.
• Be careful with orientation of shift selector handle.
• Bolt hole is not threaded on new clutch housing. Self-tapping bolt is used to attach lock plate to clutch hous-
ing.
CAUTION:
Do not reuse self-tapping bolt.
• Insert each cable until it reaches the cable mounting bracket and shift selector assembly.
• Insert each cable until it reaches the shifter lever A and the selector lever.
• Move the shift selector to the neutral position.
InspectionINFOID:0000000012430956
INSPECTION AFTER INSTALLATION
Shift Selector Handle
Check that the shift selector handle is installed in the right position.
Shifter Cable and Selector Cable
• Pull each cable in the removal direction to check that it does not disconnect from the cable mounting
bracket.
• Pull each cable in the removal direction to check that it does not disconnect from the shift selector assembly.
• Pull grommet in the removal direction to che ck that it does not disconnect from the vehicle.
Shift Selector Assembly and Shift Selector
• Check that there is no unusual noise, binding, bending, looseness, and interference when the shift selector
is moved to each position. If there is a malfuncti on, then repair or replace the malfunctioning part.
• Check that the shift selector smoothl y returns to the neutral position after moving the shift selector from 1st
to 2nd gear and releasing it. If there is a malfunction, then repair or replace the malfunctioning part.
• Check that the shift selector smoothly returns to the neutral position after moving the shift selector from 5th to the reverse gear position and releasing it. If there is a malfunction, then repair or replace the malfunction-
ing part.
JPDIC0793ZZ
Revision: August 2015 2016 Versa Note
cardiagn.com
Page 3263 of 3641
TM-22
< REMOVAL AND INSTALLATION >[5MT: RS5F91R]
AIR BREATHER HOSE
AIR BREATHER HOSE
Exploded ViewINFOID:0000000012430957
Removal and InstallationINFOID:0000000012430958
REMOVAL
1. Remove air cleaner case. Refer to
EM-26, "Removal and Installation".
2. Remove air breather hose from the 2-way connector. CAUTION:
When removing air breather hose, be su re to hold 2-way connector securely.
3. Remove cap from air breather hose.
INSTALLATION
Installation is in the reverse order of removal.
CAUTION:
• Install air breather hose. Do not bend hose tightly, which may result in pinching or clogging.
• Insert the air breather hose to the base of the 2-way connector.
1. Cap 2. Air breather hose3. 2-way connector
JPDIC0788ZZ
Revision: August 2015 2016 Versa Note
cardiagn.com
Page 3264 of 3641
![NISSAN NOTE 2016 Service Repair Manual 5TH MAIN GEAR ASSEMBLYTM-23
< REMOVAL AND INSTALLATION > [5MT: RS5F91R]
C
EF
G H
I
J
K L
M A
B
TM
N
O P
5TH MAIN GEAR ASSEMBLY
Removal and InstallationINFOID:0000000012430959
REMOVAL
1. Move the shift NISSAN NOTE 2016 Service Repair Manual 5TH MAIN GEAR ASSEMBLYTM-23
< REMOVAL AND INSTALLATION > [5MT: RS5F91R]
C
EF
G H
I
J
K L
M A
B
TM
N
O P
5TH MAIN GEAR ASSEMBLY
Removal and InstallationINFOID:0000000012430959
REMOVAL
1. Move the shift](/manual-img/5/57363/w960_57363-3263.png)
5TH MAIN GEAR ASSEMBLYTM-23
< REMOVAL AND INSTALLATION > [5MT: RS5F91R]
C
EF
G H
I
J
K L
M A
B
TM
N
O P
5TH MAIN GEAR ASSEMBLY
Removal and InstallationINFOID:0000000012430959
REMOVAL
1. Move the shift selector to the 3rd gear position.
2. Disconnect the shifter cable and the selector cable fr om shifter lever A and selector lever. Refer to TM-20,
"Removal and Installation".
CAUTION:
Do not move shifter lever A and selector lever to disconnect each cable.
3. Drain gear oil. Refer to TM-17, "
Draining".
4. Remove fender protector (LH). Refer to EXT-38, "
Removal and Installation".
5. Remove the harness clamp (A) from rear housing (1).
6. Remove rear housing and O-ring. CAUTION:
Remove in direction of input shaft ( ) as shown. Rear
housing gear oil channel is inserted to input shaft center
hole.
7. Remove 5th main gear assembly. Refer to step 5 through 8 of “Disassembly of TRANSAXLE ASSEMBLY”. Refer to TM-30,
"Disassembly".
INSTALLATION
Installation is in the reverse order of removal.
• Shift into 3rd with shifter lever to install the 5th main gear assembly, referring to Step 36 to 39 of “Assemblyof TRANSAXLE ASSEMBLY” Refer to TM-36, "
Assembly".
• Install O-ring and the rear housing to the transaxle case and tighten the bolts to the specified torque. Refer to TM-26, "
Exploded View".
CAUTION:
• Do not reuse O-ring.
• Do not pinch O-ring when installing rear housing.
• Refill gear oil. Refer to TM-17, "
Refilling".
InspectionINFOID:0000000012430960
INSPECTION AFTER INSTALLATION
• Check the operation of the control linkage. Refer to TM-21, "Inspection".
• Check the gear oil level and for oil leaks. Refer to TM-17, "
Inspection".
JPDIC0734ZZ
SCIA1709J
Revision: August 2015 2016 Versa Note
cardiagn.com
