2016 NISSAN NOTE Service Repair Manual

automatic transmission fluid wheel bolt torque auxiliary battery manual transmission oil type water pump

Load previous 8 pages

Page 2465 of 3641

NISSAN NOTE 2016 Service Repair Manual MWI
THE FUEL GAUGE INDICATOR DOES NOT OPERATEMWI-107
< SYMPTOM DIAGNOSIS > [TYPE B]
C
D
E
F
G H
I
J
K L
M B A
O P
SYMPTOM DIAGNOSIS
THE FUEL GAUGE INDICA TOR DOES NOT OPERATE
DescriptionINFOID:0000000

Page 2466 of 3641

NISSAN NOTE 2016 Service Repair Manual MWI-108
< SYMPTOM DIAGNOSIS >[TYPE B]
THE OIL PRESSURE WARNING LAMP DOES NOT TURN ON
THE OIL PRESSURE WARNING
LAMP DOES NOT TURN ON
DescriptionINFOID:0000000012432649
The engine oil pressure warning

Page 2467 of 3641

NISSAN NOTE 2016 Service Repair Manual MWI
THE OIL PRESSURE WARNING LAMP DOES NOT TURN OFFMWI-109
< SYMPTOM DIAGNOSIS > [TYPE B]
C
D
E
F
G H
I
J
K L
M B A
O P
THE OIL PRESSURE WARNING LAMP DOES NOT TURN OFF
DescriptionINFOID:0000000012432

Page 2468 of 3641

NISSAN NOTE 2016 Service Repair Manual MWI-110
< SYMPTOM DIAGNOSIS >[TYPE B]
THE DOOR OPEN WARNING CONTINU
ES DISPLAYING, OR DOES NOT DIS-
PLAY
THE DOOR OPEN WARNING CONTIN UES DISPLAYING, OR DOES NOT
DISPLAY
DescriptionINFOID:000000001243

MWI-110
< SYMPTOM DIAGNOSIS >[TYPE B]
THE DOOR OPEN WARNING CONTINU
ES DISPLAYING, OR DOES NOT DIS-
PLAY
THE DOOR OPEN WARNING CONTIN UES DISPLAYING, OR DOES NOT
DISPLAY
DescriptionINFOID:0000000012432653
• The door ajar warning is displayed even though all of the doors are closed.
• The door ajar warning is not displayed even though a door is ajar.
Diagnosis ProcedureINFOID:0000000012432654
1.CHECK BCM INPUT SIGNAL
Check the BCM input signal. Refer to DLK-98, "
ComponentFunctionCheck" (with Intelligent Key system) or
DLK-232, "
ComponentFunctionCheck" (without Intelligent Key system).
Is the inspection result normal?
YES >> GO TO 2.
NO >> GO TO 3.
2.CHECK COMBINATION METER INPUT SIGNAL
Select the METER/M&A Data Moni tor and check the DOOR W/L monitor value while opening and closing
doors.
Is the inspection result normal?
YES >> Replace combination meter. Refer to MWI-115, "Removal and Installation".
NO >> Replace BCM. Refer to BCS-74, "
Removal and Installation" (with Intelligent Key system) or BCS-
137, "Removal and Installation" (without Intelligent Key system).
3.CHECK DOOR SWITCH SIGNAL CIRCUIT
Check the door switch signal circuit. Refer to DLK-98, "
Diagnosis Procedure" (with Intelligent Key system) or
DLK-232, "
Diagnosis Procedure" (without Intelligent Key system).
Is the inspection result normal?
YES >> GO TO 4.
NO >> Repair or replace harness or connector.
4.CHECK DOOR SWITCH
Check the door switch. Refer to DLK-99, "
Component Inspection" (with Intelligent Key system) or DLK-234,
"Component Inspection" (without Intelligent Key system).
Is the inspection result normal?
YES >> Replace combination meter. Refer to MWI-115, "Removal and Installation".
NO >> Replace applicable door switch. Refer to DLK-181, "
Removal and Installation" (with Intelligent Key
system) or DLK-308, "
Removal and Installation" (without Intelligent Key system).
Monitor item Condition Status
DOOR W/L Door open
ON
Door closed OFF
Revision: August 2015 2016 Versa Note

cardiagn.com

Page 2469 of 3641

NISSAN NOTE 2016 Service Repair Manual MWI
THE PARKING BRAKE RELEASE WARNING CONTINUES DISPLAYING, OR
DOES NOT DISPLAY
MWI-111
< SYMPTOM DIAGNOSIS > [TYPE B]
C
D
E
F
G H
I
J
K L
M B A
O P
THE PARKING BRAKE RELEASE WA RNING CONTINUES DISPL

Page 2470 of 3641

NISSAN NOTE 2016 Service Repair Manual MWI-112
< SYMPTOM DIAGNOSIS >[TYPE B]
THE STEERING SWITCH (METER CO
NTROL SWITCH) IS INOPERATIVE
THE STEERING SWITCH (METER CONT ROL SWITCH) IS INOPERATIVE
DescriptionINFOID:0000000012432657
The steer

Page 2471 of 3641

NISSAN NOTE 2016 Service Repair Manual MWI
THE AMBIENT TEMPERATURE DISPLAY IS INCORRECTMWI-113
< SYMPTOM DIAGNOSIS > [TYPE B]
C
D
E
F
G H
I
J
K L
M B A
O P
THE AMBIENT TEMPERATURE DISPLAY IS INCORRECT
DescriptionINFOID:0000000012432659
•

Page 2472 of 3641

NISSAN NOTE 2016 Service Repair Manual MWI-114
< SYMPTOM DIAGNOSIS >[TYPE B]
THE LOW WASHER FLUID WARNING
CONTINUES DISPLAYING, OR DOES
NOT DISPLAY
THE LOW WASHER FLUID WARNING CONTINUES DISPLAYING, OR
DOES NOT DISPLAY
DescriptionINFOID:
