DOOR MIRROR
Exploded ViewINFOID:0000000012542516
Removal and InstallationINFOID:0000000012542517
REMOVAL
1. Remove the front door finisher. Refer to INT-15, "Removal and Installation".
2. Partially remove the vapor barrier.
3. Release door mirror harness connector clip from inside door and disconnect harness connector.
4. Remove door mirror inner bolt.
5. Release door mirror base finisher pawls using a suitable tool (A) and remove.
: Pawl
1. Door mirror rear finisher 2. Side turn signal lamp (if
equipped)
3. Door mirror
4. Door mirror glass 5. Side camera (if equipped) 6. Door mirror base finisher
Pawl
AWLIA2708ZZ
AWLIA2183ZZ
Revision: August 2015 2016 Versa Note
cardiagn.com
Page 2490 of 3641
MIR-16
< REMOVAL AND INSTALLATION >
DOOR MIRROR
6. Remove the door mirror outer bolts (A) and the door mirror (1).
7. Remove side camera (if necessary). Refer to AV-252, "
Removal
and Installation".
INSTALLATION
Installation is in the reverse order or removal.
CAUTION:
• Visually check door mirror base cover pawls fo r deformation and damage during installation.
• Perform camera image calibration (if equipp ed with around view camera). Refer to AV-179, "
CALI-
BRATING CAMERA IMAGE (AROUND VIEW MONITOR) : Description".
AWLIA2181ZZ
Revision: August 2015 2016 Versa Note
cardiagn.com
Page 2491 of 3641
DOOR MIRROR GLASSMIR-17
< REMOVAL AND INSTALLATION >
C
DE
F
G H
I
J
K
M A
B
MIR
N
O P
DOOR MIRROR GLASS
Removal and InstallationINFOID:0000000012432094
REMOVAL
1. Place a piece of protective tape on the mirror housing.
2. Tilt the door mirror glass upward (1).
3. Remove the door mirror glass lower side, using a suitable tool (A) in the recess between door mirror glass (1) and actuator (2)
and push up on pawls and rotate (twist).
4. Disconnect harness connector from door mirror glass (if equipped with heated mirrors).
5. Remove the glass using a suitable tool in the (LH/RH) recesses between door mirror glass and actuator and push up on pawls
and rotate (twist).
INSTALLATION
Installation is in the reverse order of removal.
NOTE:
After installation, visually check that pawls are securely engaged.
ALLIA1036ZZ
ALLIA1037ZZ
Revision: August 2015 2016 Versa Note
cardiagn.com
Page 2492 of 3641
MIR-18
< REMOVAL AND INSTALLATION >
DOOR MIRROR REAR FINISHER
DOOR MIRROR REAR FINISHER
Removal and InstallationINFOID:0000000012432095
REMOVAL
1. Remove door mirror glass. Refer to MIR-17, "Removal and Installation".
2. Release pawls using a suitable tool and remove door mirror rear finisher from the door mirror.
INSTALLATION
Installation is in the reverse order of removal.
CAUTION:
Visually check door mirror rear finisher pawls fo r deformation and damage during installation.
Revision: August 2015 2016 Versa Note
cardiagn.com
Page 2493 of 3641
DOOR MIRROR REMOTE CONTROL SWITCHMIR-19
< REMOVAL AND INSTALLATION >
C
DE
F
G H
I
J
K
M A
B
MIR
N
O P
DOOR MIRROR REMOTE CONTROL SWITCH
Removal and InstallationINFOID:0000000012432096
REMOVAL
1. Remove the instrument lower panel LH. Refer to IP-15, "Removal and Installation".
2. Remove door mirror remote control switch (1) from the instru- ment lower panel LH using a suitable tool.
: Pawl
INSTALLATION
Installation is in the reverse order of removal.
AWLIA2157ZZ
Revision: August 2015 2016 Versa Note
cardiagn.com
Page 2494 of 3641

PB-1
BRAKES
C
DE
G H
I
J
K L
M
SECTION PB
A
B
PB
N
O P
CONTENTS
PARKING BRAKE SYSTEM
PRECAUTION ....... ........................................2
PRECAUTIONS .............................................. .....2
Precaution for Supplemental Restraint System
(SRS) "AIR BAG" and "SEAT BELT PRE-TEN-
SIONER" ............................................................. ......
2
PREPARATION ............................................3
PREPARATION .............................................. .....3
Commercial Service Tool .................................... ......3
PERIODIC MAINTENANCE ..........................4
PARKING BRAKE SYSTEM .......................... .....4
Inspection and Adjustment .................................. ......4
REMOVAL AND INSTALLATION ................6
PARKING BRAKE CONTROL ...........................6
Exploded View ..................................................... .....6
Removal and Installation ..........................................6
PARKING BRAKE CABLE ................................7
Removal and Installation ..........................................7
PARKING BRAKE REAR CABLE .....................8
Removal and Installation ..........................................8
PARKING BRAKE SWITCH ..............................9
Removal and Installation ..........................................9
SERVICE DATA AND SPECIFICATIONS
(SDS) ............... .......................................... ...
10
SERVICE DATA AND SPECIFICATIONS
(SDS) .................................................................
10
Parking Brake Control ......................................... ....10
Revision: August 2015 2016 Versa Note
cardiagn.com
Page 2495 of 3641

PB-2
< PRECAUTION >
PRECAUTIONS
PRECAUTION
PRECAUTIONS
Precaution for Supplemental Restraint System (SRS) "AIR BAG" and "SEAT BELT
PRE-TENSIONER"
INFOID:0000000012430686
The Supplemental Restraint System such as “A IR BAG” and “SEAT BELT PRE-TENSIONER”, used along
with a front seat belt, helps to reduce the risk or severity of injury to the driver and front passenger for certain
types of collision. Information necessary to service the system safely is included in the SR and SB section of
this Service Manual.
WARNING:
• To avoid rendering the SRS inopera tive, which could increase the risk of personal injury or death in
the event of a collision which would result in air bag inflation, all maintenance must be performed by
an authorized NISSAN/INFINITI dealer.
• Improper maintenance, including in correct removal and installation of the SRS, can lead to personal
injury caused by unintent ional activation of the system. For re moval of Spiral Cable and Air Bag
Module, see the SR section.
• Do not use electrical test equipmen t on any circuit related to the SRS unless instructed to in this
Service Manual. SRS wiring harn esses can be identified by yellow and/or orange harnesses or har-
ness connectors.
PRECAUTIONS WHEN USING POWER TOOLS (AIR OR ELECTRIC) AND HAMMERS
WARNING:
• When working near the Airbag Diagnosis Sensor Unit or other Airbag System sensors with the Igni-
tion ON or engine running, DO NOT use air or electri c power tools or strike near the sensor(s) with a
hammer. Heavy vibration could activate the sensor( s) and deploy the air bag(s), possibly causing
serious injury.
• When using air or electric power tools or hammers , always switch the Ignition OFF, disconnect the
battery and wait at least three minutes before performing any service.
Revision: August 2015 2016 Versa Note
cardiagn.com
Page 2496 of 3641
PREPARATIONPB-3
< PREPARATION >
C
DE
G H
I
J
K L
M A
B
PB
N
O P
PREPARATION
PREPARATION
Commercial Service ToolINFOID:0000000012430687
Tool name Description
Power tool Loosening nuts, screws and bolts
