Page 3521 of 3641

NISSAN NOTE 2016 Service Repair Manual WCS-6 < SYSTEM DESCRIPTION > COMPONENT PARTS TYPE A TYPE B NOTE: To identify combination meter type, refer to WCS-3, " Information". AWNIA3061ZZ AWNIA3600ZZ Revision: August 2015 2016 Versa Note card

Page 3522 of 3641

NISSAN NOTE 2016 Service Repair Manual WCS SYSTEMWCS-7 < SYSTEM DESCRIPTION > C DE F G H I J K L M B A O P SYSTEM WARNING CHIME SYSTEM WARNING CHIME SYSTEM : System DescriptionINFOID:0000000012432669 SYSTEM DIAGRAM (WITH INTELLIGENT KEY S

Page 3523 of 3641

NISSAN NOTE 2016 Service Repair Manual WCS-8 < SYSTEM DESCRIPTION > SYSTEM Output signal DESCRIPTION Combination Meter The combination meter sounds the alarm buzzer installed in the combination meter when receiving the buzzer output signal

Page 3524 of 3641

NISSAN NOTE 2016 Service Repair Manual WCS SYSTEMWCS-9 < SYSTEM DESCRIPTION > C DE F G H I J K L M B A O PWARNING CHIME CANCEL CONDITIONS Warning is canceled if any of the following conditions is fulfilled: SIGNAL PATH 1. BCM requires warn

Page 3525 of 3641

NISSAN NOTE 2016 Service Repair Manual WCS-10 < SYSTEM DESCRIPTION > SYSTEM WARNING CANCEL CONDITIONS Warning is canceled if any of the following conditions are fulfilled: SIGNAL PATH Combination meter sounds integrated buzzer when it judg

Page 3526 of 3641

NISSAN NOTE 2016 Service Repair Manual WCS SYSTEMWCS-11 < SYSTEM DESCRIPTION > C DE F G H I J K L M B A O P 1. BCM requires warning chime output to combination meter when it judges seat belt warning chime is nec- essary from signals below.

Page 3527 of 3641

NISSAN NOTE 2016 Service Repair Manual WCS-12 < SYSTEM DESCRIPTION > SYSTEM 2. Combination meter sounds integrated buzzer, when it receives a buzzer output signal from BCM. Key switch signal Key switch BCM Driver door switch signal Front

Page 3528 of 3641

NISSAN NOTE 2016 Service Repair Manual WCS DIAGNOSIS SYSTEM (COMBINATION METER)WCS-13 < SYSTEM DESCRIPTION > C DE F G H I J K L M B A O P DIAGNOSIS SYSTEM (C OMBINATION METER) TYPE A TYPE A : On Board Diagnosis FunctionINFOID:0000000012542
