DLK-264
< SYMPTOM DIAGNOSIS >[WITHOUT INTELLIGENT KEY SYSTEM]
SQUEAK AND RATTLE TROUBLE DIAGNOSES
1. Cluster lid A and the instrument panel
2. Acrylic lens and combination meter housing
3. Instrument panel to front pillar finisher
4. Instrument panel to windshield
5. Instrument panel pins
6. Wiring harnesses behind the combination meter
7. A/C defroster duct and duct joint
These incidents can usually be located by tapping or
moving the components to duplicate the noise or by
pressing on the components while driving to stop the noise. Most of these incidents can be repaired by apply-
ing felt cloth tape or silicone spray (in hard to reach areas). Urethane pads can be used to insulate wiring har-
ness.
CAUTION:
Do not use silicone spray to isolate a squeak or rattle. If you saturate the ar ea with silicone, you will
not be able to recheck the repair.
CENTER CONSOLE
Components to pay attention to include:
1. Shift selector assembly cover to finisher
2. A/C control unit and cluster lid C
3. Wiring harnesses behind audio and A/C control unit
The instrument panel repair and isolation pr ocedures also apply to the center console.
DOORS
Pay attention to the:
1. Finisher and inner panel making a slapping noise
2. Inside handle escutcheon to door finisher
3. Wiring harnesses tapping
4. Door striker out of alignment causing a popping noise on starts and stops
Tapping or moving the components or pressing on them wh ile driving to duplicate the conditions can isolate
many of these incidents. You can usually insulate the areas with felt cloth tape or insulator foam blocks from
the NISSAN Squeak and Rattle Kit (J-50397) to repair the noise.
TRUNK
Trunk noises are often caused by a loose jack or loose items put into the trunk by the owner.
In addition look for:
1. Trunk lid bumpers out of adjustment
2. Trunk lid striker out of adjustment
3. The trunk lid torsion bars knocking together
4. A loose license plate or bracket
Most of these incidents can be repaired by adjusting, se curing or insulating the item(s) or component(s) caus-
ing the noise.
SUNROOF/HEADLINING
Noises in the sunroof/headlining area c an often be traced to one of the following:
1. Sunroof lid, rail, linkage or seals making a rattle or light knocking noise
2. Sun visor shaft shaking in the holder
3. Front or rear windshield touching headlining and squeaking
Again, pressing on the components to stop the noise while duplicating the conditions can isolate most of these
incidents. Repairs usually consist of insulating with felt cloth tape.
OVERHEAD CONSOLE (FRONT AND REAR)
Overhead console noises are often caused by the c onsole panel clips not being engaged correctly. Most of
these incidents are repaired by pushing up on the c onsole at the clip locations until the clips engage.
In addition look for:
1. Loose harness or harness connectors.
2. Front console map/reading lamp lens loose.
Revision: August 2015 2016 Versa Note
cardiagn.com
Page 954 of 3641
![NISSAN NOTE 2016 Service Repair Manual SQUEAK AND RATTLE TROUBLE DIAGNOSESDLK-265
< SYMPTOM DIAGNOSIS > [WITHOUT INTELLIGENT KEY SYSTEM]
C
D
E
F
G H
I
J
L
M A
B
DLK
N
O P
3. Loose screws at console attachment points.
SEATS
When isolating s NISSAN NOTE 2016 Service Repair Manual SQUEAK AND RATTLE TROUBLE DIAGNOSESDLK-265
< SYMPTOM DIAGNOSIS > [WITHOUT INTELLIGENT KEY SYSTEM]
C
D
E
F
G H
I
J
L
M A
B
DLK
N
O P
3. Loose screws at console attachment points.
SEATS
When isolating s](/manual-img/5/57363/w960_57363-953.png)
SQUEAK AND RATTLE TROUBLE DIAGNOSESDLK-265
< SYMPTOM DIAGNOSIS > [WITHOUT INTELLIGENT KEY SYSTEM]
C
D
E
F
G H
I
J
L
M A
B
DLK
N
O P
3. Loose screws at console attachment points.
SEATS
When isolating seat noise it's important to note the position the seat is in and the load placed on the seat when
the noise is present. These conditions should be duplicated when verifying and isolating the cause of the
noise.
Cause of seat noise include:
1. Headrest rods and holder
2. A squeak between the seat pad cushion and frame
3. The rear seatback lock and bracket
These noises can be isolated by moving or pressing on the suspected components while duplicating the con-
ditions under which the noise occurs. Most of thes e incidents can be repaired by repositioning the component
or applying urethane tape to the contact area.
UNDERHOOD
Some interior noise may be caused by components under the hood or on the engine wall. The noise is then
transmitted into the passenger compartment.
Causes of transmitted underhood noise include:
1. Any component installed to the engine wall
2. Components that pass through the engine wall
3. Engine wall mounts and connectors
4. Loose radiator installation pins
5. Hood bumpers out of adjustment
6. Hood striker out of adjustment
These noises can be difficult to isolate since they cannot be reached from the interior of the vehicle. The best
method is to secure, move or insulate one component at a time and test drive the vehicle. Also, engine rpm or
load can be changed to isolate the noise. Repairs can usually be made by moving, adjusting, securing, or
insulating the component causing the noise.
Revision: August 2015 2016 Versa Note
cardiagn.com
Page 955 of 3641
DLK-266
< SYMPTOM DIAGNOSIS >[WITHOUT INTELLIGENT KEY SYSTEM]
SQUEAK AND RATTLE TROUBLE DIAGNOSES
Diagnostic Worksheet
INFOID:0000000012430230
LAIA0072E
Revision: August 2015 2016 Versa Note
cardiagn.com
Page 956 of 3641
SQUEAK AND RATTLE TROUBLE DIAGNOSESDLK-267
< SYMPTOM DIAGNOSIS > [WITHOUT INTELLIGENT KEY SYSTEM]
C
D
E
F
G H
I
J
L
M A
B
DLK
N
O P
LAIA0071E
Revision: August 2015 2016 Versa Note
cardiagn.com
Page 957 of 3641
DLK-268
< REMOVAL AND INSTALLATION >[WITHOUT INTELLIGENT KEY SYSTEM]
HOOD
REMOVAL AND INSTALLATION
HOOD
Exploded ViewINFOID:0000000012430231
HOOD ASSEMBLY
HOOD ASSEMBLY : Removal and InstallationINFOID:0000000012430232
CAUTION:
• Use two people when removing or installing hood assembly due to its heavy weight.
• Use protective tape or shop cloths to protect surrounding components from damage during removal
and installation of hood assembly.
REMOVAL
1. Support hood assembly using a suitable tool.
WARNING:
Bodily injury may occur if hood assembly is not supported properly when removing hood assem-
bly.
2. Remove hood hinge nuts and hood assembly.
3. Remove clips and hood insulator (if necessary).
INSTALLATION
1. Hood 2. Bumper rubber (hood side) 3. Hood insulator
4. Hood rod clamp 5. Bumper rubber (body side) 6. Hood rod grommet
7. Hood hinge (LH) 8. Hood support rod 9. Hood hinge (RH)
A. Hood insulator clip
AWKIA2564ZZ
Revision: August 2015 2016 Versa Note
cardiagn.com
Page 958 of 3641
![NISSAN NOTE 2016 Service Repair Manual HOOD
DLK-269
< REMOVAL AND INSTALLATION > [WITHOUT INTELLIGENT KEY SYSTEM]
C
D
E
F
G H
I
J
L
M A
B
DLK
N
O P
Installation is in the reverse order of removal.
CAUTION:
• Before installing hood assemb NISSAN NOTE 2016 Service Repair Manual HOOD
DLK-269
< REMOVAL AND INSTALLATION > [WITHOUT INTELLIGENT KEY SYSTEM]
C
D
E
F
G H
I
J
L
M A
B
DLK
N
O P
Installation is in the reverse order of removal.
CAUTION:
• Before installing hood assemb](/manual-img/5/57363/w960_57363-957.png)
HOOD
DLK-269
< REMOVAL AND INSTALLATION > [WITHOUT INTELLIGENT KEY SYSTEM]
C
D
E
F
G H
I
J
L
M A
B
DLK
N
O P
Installation is in the reverse order of removal.
CAUTION:
• Before installing hood assembl y, apply anticorrosive agent to the surface of hood hinge.
• After installation, perform the hood assembly adjustment procedure. Refer to DLK-269, "
HOOD
ASSEMBLY : Adjustment".
• After installation, ap ply touch-up paint (body color) to the head of hood hinge nuts.
HOOD ASSEMBLY : AdjustmentINFOID:0000000012430233
Check the clearance and the surface height between hood and each part by visual inspection and tactile feel.
If the clearance and the surface height are out of specific ation, adjust them according to the adjustment proce-
dure.
Unit: mm (in)
1. Hood assembly 2. Bumper rubber (body side) 3. Hood hinge (LH)
4. Hood lock 5. Front grille finisher6. Front combination lamp
7. Front fender
AWKIA2565ZZ
Section Item Measurement StandardParallelism Equality
A – A D
Clearance 4.4 ± 2.0 (0.17 ± 0.08) 2.0 (0.08) —
E Surface height -0.5 +2.0, -1.5 (0.02 +0.08, -0.06) 2.0 (0.08) —
B – B F
Clearance 4.0 ± 2.0 (0.16 ± 0.08) 2.0 (0.08) 3.0 (0.12)
G Surface height ———
Revision: August 2015 2016 Versa Note
cardiagn.com
Page 959 of 3641
![NISSAN NOTE 2016 Service Repair Manual DLK-270
< REMOVAL AND INSTALLATION >[WITHOUT INTELLIGENT KEY SYSTEM]
HOOD
CLEARANCE ADJUSTMENT
1. Loosen hood hinge nuts and bolts.
2. Loosen hood lock assembly bolts.
3. Adjust the hood lock assembly NISSAN NOTE 2016 Service Repair Manual DLK-270
< REMOVAL AND INSTALLATION >[WITHOUT INTELLIGENT KEY SYSTEM]
HOOD
CLEARANCE ADJUSTMENT
1. Loosen hood hinge nuts and bolts.
2. Loosen hood lock assembly bolts.
3. Adjust the hood lock assembly](/manual-img/5/57363/w960_57363-958.png)
DLK-270
< REMOVAL AND INSTALLATION >[WITHOUT INTELLIGENT KEY SYSTEM]
HOOD
CLEARANCE ADJUSTMENT
1. Loosen hood hinge nuts and bolts.
2. Loosen hood lock assembly bolts.
3. Adjust the hood lock assembly so the clearance m
easurements are within the specifications provided.
4. Tighten hood hinge nuts and bolts to specified torque.
5. Tighten hood lock assembly bolts to specified torque.
HEIGHT ADJUSTMENT
1. Loosen hood lock assembly bolts.
2. Adjust the surface height of hood assembly to front upper grille, front fender and front combination lamp to
the specified values by rotating hood bumper rubber.
3. Temporarily tighten hood lock assembly bolts.
4. Adjust (A) as shown to the following value with hood’s own weight by dropping it from approximately 200 mm (7.87 in) height or by pressing hood lightly [approximately 29 N (3.0 kg, 6.5 lb)].
5. After adjustment, tighten hood lock assembly bolts to specified torque.
HOOD HINGE
HOOD HINGE : Removal and InstallationINFOID:0000000012430234
REMOVAL
1. Remove hood assembly. Refer to DLK-268, "HOOD ASSEMBLY : Removal and Installation".
2. Remove front fender. Refer to DLK-275, "
Removal and Installation".
3. Remove cowl top side cover. Refer to EXT-36, "
Exploded View".
4. Remove hood hinge bolts and hood hinge.
INSTALLATION
Installation is in the reverse order of removal.
CAUTION:
• Before installing the hood hinge, apply anticorrosive agent onto the surface of the vehicle.
C – CH Clearance 3.5
± 1.0 (0.14 ± 0.04) 1.5 (0.06) 1.5 (0.06)
J Surface height 0.0 ± 1.5 (0.0 ± 0.06) 1.5 (0.06) 1.5 (0.06)
Section Item Measurement
StandardParallelism Equality
1. Hood striker 2. Secondary latch3. Primary latch
A. 20.0 mm (0.79 in)
ALKIA3162ZZ
Revision: August 2015 2016 Versa Note
cardiagn.com
Page 960 of 3641
HOOD
DLK-271
< REMOVAL AND INSTALLATION > [WITHOUT INTELLIGENT KEY SYSTEM]
C
D
E
F
G H
I
J
L
M A
B
DLK
N
O P
• Check hood hinge rotating point for poor lubrication. If neces-
sary, apply a suitable multi-purpose grease.
HOOD SUPPORT ROD
HOOD SUPPORT ROD : Removal and InstallationINFOID:0000000012430235
REMOVAL
1. Support hood assembly using a suitable tool.
WARNING:
Bodily injury may occur if hood assembly is not supported properly when removing hood support
rod.
2. Rotate and remove hood support rod from grommet.
3. Release tab and remove grommet from hood hinge (if necessary).
INSTALLATION
Installation is in the reverse order of removal.
JMKIA7995ZZ
Revision: August 2015 2016 Versa Note
cardiagn.com
