NISSAN NOTE 2016 Service Repair Manual EC-338
< DTC/CIRCUIT DIAGNOSIS >[HR16DE]
P050A, P050B, P050E COLD START CONTROL
Is 1st trip DTC detected?
YES >> Go to EC-338, "Diagnosis Procedure".
NO >> INSPECTION END
Diagnosis ProcedureINFOID:000

Page 1466 of 3641

NISSAN NOTE 2016 Service Repair Manual P0520 EOP SENSOREC-339
< DTC/CIRCUIT DIAGNOSIS > [HR16DE]
C
D
E
F
G H
I
J
K L
M A
EC
NP
O
P0520 EOP SENSOR
DTC LogicINFOID:0000000012431537
DTC DETECTION LOGIC
NOTE:
If DTC P0520 is displayed with DTC

P0520 EOP SENSOREC-339
< DTC/CIRCUIT DIAGNOSIS > [HR16DE]
C
D
E
F
G H
I
J
K L
M A
EC
NP
O
P0520 EOP SENSOR
DTC LogicINFOID:0000000012431537
DTC DETECTION LOGIC
NOTE:
If DTC P0520 is displayed with DTC P0643, first pe
rform the trouble diagnosis for DTC P0643. Refer to
EC-356, "
DTC Logic".
DTC CONFIRMATION PROCEDURE
1.PRECONDITIONING
If DTC Confirmation Procedure has been previously conducted, always perform the following procedure
before conducting the next test.
1. Turn ignition switch OFF and wait at least 10 seconds.
2. Turn ignition switch ON.
3. Turn ignition switch OFF and wait at least 10 seconds.
>> GO TO 2.
2.CHECK ENGINE OIL LEVEL
Check engine oil level. Refer to LU-7, "
Inspection".
Is inspection result normal?
YES >> GO TO 3.
NO >> Check engine oil leak. Refer to LU-7, "
Inspection".
3.PERFORM DTC CONFIRMATION PROCEDURE
1. Start engine and let it idle for at least 5 seconds.
2. Check 1st trip DTC.
Is 1st trip DTC detected?
YES >> Proceed to EC-339, "Diagnosis Procedure".
NO >> INSPECTION END
Diagnosis ProcedureINFOID:0000000012431538
1.CHECK ENGINE OIL PRESSURE SENSOR POWER SUPPLY CIRCUIT
1. Turn ignition switch OFF.
2. Disconnect engine oil pressure sensor harness connector.
3. Turn ignition switch ON.
4. Check the voltage between engine oil pressure sensor harness connector terminals.
Is inspection result normal?
YES >> GO TO 2
NO >> Repair or replace error-detected parts.
DTC No. CONSULT screen terms
(Trouble diagnosis content) Detecting condition
Possible cause
P0520 EOP SENSOR/SWITCH
[Engine oil pressure sensor
circuit] ECM detects the following status continuously for
5 seconds or more:
• A voltage signal transmitted from the engine oil
pressure sensor is lower than 0.3 V.
• A voltage signal transmitted from the engine oil pressure sensor is higher than 5.02 V. • Harness or connectors
(Engine oil pressure sensor circuit is
open or shorted.)
• Engine oil pressure sensor
Engine oil pressure sensor GroundVo l ta g e
(Approx.)
Connector Terminal
F38 1Ground 5 V
Revision: August 2015 2016 Versa Note

cardiagn.com

Page 1467 of 3641

NISSAN NOTE 2016 Service Repair Manual EC-340
< DTC/CIRCUIT DIAGNOSIS >[HR16DE]
P0520 EOP SENSOR
2.CHECK ENGINE OIL PRESSURE SENSOR
GROUND CIRCUIT FOR OPEN AND SHORT
1. Check the continuity between engine oil pressure sensor harness conne

Page 1468 of 3641

NISSAN NOTE 2016 Service Repair Manual P0524 ENGINE OIL PRESSUREEC-341
< DTC/CIRCUIT DIAGNOSIS > [HR16DE]
C
D
E
F
G H
I
J
K L
M A
EC
NP
O
P0524 ENGINE OIL PRESSURE
DTC LogicINFOID:0000000012431540
DTC DETECTION LOGIC
NOTE:
If DTC P0524 is

P0524 ENGINE OIL PRESSUREEC-341
< DTC/CIRCUIT DIAGNOSIS > [HR16DE]
C
D
E
F
G H
I
J
K L
M A
EC
NP
O
P0524 ENGINE OIL PRESSURE
DTC LogicINFOID:0000000012431540
DTC DETECTION LOGIC
NOTE:
If DTC P0524 is displayed with DTC P0520 or P0075,
perform trouble diagnosis for DTC P0520 or P0075
first. Refer to EC-339, "
DTC Logic" or EC-180, "DTC Logic".
DTC CONFIRMATION PROCEDURE
CAUTION:
If “Diagnosis Procedure” is unfinish ed, be sure to perform Step 3 and 4.
1.PRECONDITIONING-I
If DTC Confirmation Procedure has been previously conducted, always perform the following procedure
before conducting the next test.
1. Turn ignition switch OFF and wait at least 10 seconds.
2. Turn ignition switch ON.
3. Turn ignition switch OFF and wait at least 10 seconds.
TESTING CONDITION:
Before performing the following procedure, confirm that battery voltage is 11 V or more at idle.
>> GO TO 2.
2.PRECONDITIONING-II
Is
“Diagnosis Procedure” of DTC P0524 finished?
YES >> GO TO 5.
NO >> GO TO 3.
3.CHECK ENGINE OIL LEVEL
Check engine oil level. Refer to LU-7, "
Inspection".
Is the inspection result normal?
YES >> GO TO 4.
NO >> Proceed to EC-342, "
Diagnosis Procedure"
4.CHECK ENGINE OIL PRESSURE
WITH CONSULT
1. Turn ignition switch ON.
2. Select “DATA MONITOR” mode of “ENGINE” using CONSULT.
3. Start the engine and check that “EOP SENSOR” changes, according to engine speeds.
Without CONSULT
DTC No. CONSULT screen terms
(Trouble diagnosis content) Detecting condition
Possible cause
P0524 ENGINE OIL PRESSURE
(Engine oil pressure too low) An engine oil pressure sensor signal
voltage applied to ECM remains lower
than the specified value continuously for
10 seconds or more when the engine
speed is 1,000 rpm or more. • Decrease in engine oil pressure
• Decrease in engine oil level
• Engine oil condition
• Engine oil pressure sensor
• Engine body
Monitor item
Condition Va l u e
(Approx.)
EOP SENSOR • Engine oil temperature: 80
°C (176 °F)
• Selector lever: P or N position (CVT), Neutral position (M/T)
• Air conditioner switch: OFF
• No load Engine speed:
600 rpm
1,053 mV or more
Engine speed:
2,000 rpm 1,802 mV or more
Revision: August 2015
2016 Versa Note

cardiagn.com

Page 1469 of 3641

NISSAN NOTE 2016 Service Repair Manual EC-342
< DTC/CIRCUIT DIAGNOSIS >[HR16DE]
P0524 ENGINE OIL PRESSURE
Check engine oil level. Refer to
LU-7, "Inspection".
Is the inspection result normal?
YES >> GO TO 5.
NO >> Proceed to EC-342, "
Di

EC-342
< DTC/CIRCUIT DIAGNOSIS >[HR16DE]
P0524 ENGINE OIL PRESSURE
Check engine oil level. Refer to
LU-7, "Inspection".
Is the inspection result normal?
YES >> GO TO 5.
NO >> Proceed to EC-342, "
Diagnosis Procedure"
5.PERFORM DTC CONFIRMATION PROCEDURE
1. Start engine and warm it up to normal operating temperature.
2. Maintain the following conditions for about 10 consecutive seconds.
NOTE:
With engine speed set around 4,000 rpm, the phenomenon can be reproduced more easily.
3. Check DTC.
Is 1st trip DTC detected?
YES >> Proceed to EC-342, "Diagnosis Procedure"
NO >> INSPECTION END
Diagnosis ProcedureINFOID:0000000012431541
1.CHECK ENGINE OIL LEVEL
1. Turn ignition switch OFF.
2. Check engine oil level. Refer to LU-7, "
Inspection".
Is the inspection result normal?
YES >> GO TO 2.
NO >> GO TO 4.
2.CHECK ENGINE OIL PRESSURE
WITH CONSULT
1. Turn ignition switch ON.
2. Select “DATA MONITOR” mode of “ENGINE” using CONSULT.
3. Start the engine and check that “EOP SENSOR” changes, according to engine speeds.
Without CONSULT
Check engine oil level. Refer to LU-7, "
Inspection".
Is the inspection result normal?
YES >> GO TO 3.
NO >> Check oil pressure. Refer to LU-7, "
Inspection".
3.CHECK ENGINE OIL PRESSURE SENSOR
Check engine oil pressure sensor. Refer to EC-340, "
Component Inspection".
Is the inspection result normal?
YES >> Check intermittent incident. Refer to GI-42, "Intermittent Incident".
NO >> Replace engine oil pressure sensor. Refer to EM-93, "
Exploded View".
4.CHECK ENGINE OIL LEAKAGE
Check engine oil leakage. Refer to LU-7, "
Inspection".
Selector leverP or N position (CVT)
Neutral position (M/T)
Engine coolant temperature 70° C (158°F) or more
Engine speed 1,000 rpm or more
Monitor item Condition Va l u e
(Approx.)
EOP SENSOR • Engine oil temperature: 80°
C (176°F)
• Selector lever: P or N position (CVT), Neutral position (M/T)
• Air conditioner switch: OFF
•No load Engine speed:
600 rpm
1,053 mV or more
Engine speed:
2,000 rpm 1,802 mV or more
Revision: August 2015
2016 Versa Note

cardiagn.com

Page 1470 of 3641

NISSAN NOTE 2016 Service Repair Manual P0524 ENGINE OIL PRESSUREEC-343
< DTC/CIRCUIT DIAGNOSIS > [HR16DE]
C
D
E
F
G H
I
J
K L
M A
EC
NP
O
Is the inspection result normal?
YES >> GO TO 5.
NO >> Repair or replace error-detected parts.
5.CHEC

Page 1471 of 3641

NISSAN NOTE 2016 Service Repair Manual EC-344
< DTC/CIRCUIT DIAGNOSIS >[HR16DE]
P059F ACTIVE GRILLE SHUTTER
P059F ACTIVE GRILLE SHUTTER
DTC LogicINFOID:0000000012431543
DTC DETECTION LOGIC
Active grille shutter normally stops within zone

Page 1472 of 3641

NISSAN NOTE 2016 Service Repair Manual P059F ACTIVE GRILLE SHUTTEREC-345
< DTC/CIRCUIT DIAGNOSIS > [HR16DE]
C
D
E
F
G H
I
J
K L
M A
EC
NP
O
Is the inspection result normal?
YES >> GO TO 3.
NO >> GO TO 6.
3.CHECK ACTIVE GRILLE SHUTTER GROUN
