Page 1473 of 3641

NISSAN NOTE 2016 Service Repair Manual EC-346 < DTC/CIRCUIT DIAGNOSIS >[HR16DE] P059F ACTIVE GRILLE SHUTTER 4. Also check harness for short to ground. Is the inspection result normal? YES >> GO TO 7. NO >> Repair or replace the error-detec

Page 1474 of 3641

NISSAN NOTE 2016 Service Repair Manual P059F ACTIVE GRILLE SHUTTEREC-347 < DTC/CIRCUIT DIAGNOSIS > [HR16DE] C D E F G H I J K L M A EC NP O 3. Also check harness for short to ground. Is the inspection result normal? YES >> Perform trouble

Page 1475 of 3641

NISSAN NOTE 2016 Service Repair Manual EC-348 < DTC/CIRCUIT DIAGNOSIS >[HR16DE] P059F ACTIVE GRILLE SHUTTER 2. Remove active grille shutter relay. 3. Apply battery voltage to active grille shutter re lay terminal, and check the continuity

Page 1476 of 3641

NISSAN NOTE 2016 Service Repair Manual P0603 ECMEC-349 < DTC/CIRCUIT DIAGNOSIS > [HR16DE] C D E F G H I J K L M A EC NP O P0603 ECM DTC LogicINFOID:0000000012741284 DTC DETECTION LOGIC DTC CONFIRMATION PROCEDURE 1.PRECONDITIONING TESTING C

Page 1477 of 3641

NISSAN NOTE 2016 Service Repair Manual EC-350 < DTC/CIRCUIT DIAGNOSIS >[HR16DE] P0604 ECM P0604 ECM DTC LogicINFOID:0000000012741286 DTC DETECTION LOGIC DTC CONFIRMATION PROCEDURE 1.PRECONDITIONING 1. Turn ignition switch OFF and wait at l

Page 1478 of 3641

NISSAN NOTE 2016 Service Repair Manual P0605 ECMEC-351 < DTC/CIRCUIT DIAGNOSIS > [HR16DE] C D E F G H I J K L M A EC NP O P0605 ECM DTC LogicINFOID:0000000012741288 DTC DETECTION LOGIC DTC CONFIRMATION PROCEDURE 1.PRECONDITIONING 1. Turn i

Page 1479 of 3641

NISSAN NOTE 2016 Service Repair Manual EC-352 < DTC/CIRCUIT DIAGNOSIS >[HR16DE] P0606 ECM P0606 ECM DTC LogicINFOID:0000000012741290 DTC DETECTION LOGIC DTC CONFIRMATION PROCEDURE 1.PRECONDITIONING 1. Turn ignition switch OFF and wait at l

Page 1480 of 3641

NISSAN NOTE 2016 Service Repair Manual P0607 ECMEC-353 < DTC/CIRCUIT DIAGNOSIS > [HR16DE] C D E F G H I J K L M A EC NP O P0607 ECM DTC LogicINFOID:0000000012741292 DTC DETECTION LOGIC DTC CONFIRMATION PROCEDURE 1.PRECONDITIONING 1. Turn i
