Page 3633 of 3641

NISSAN NOTE 2016 Service Repair Manual WW-68 < REMOVAL AND INSTALLATION > WIPER AND WASHER SWITCH WIPER AND WASHER SWITCH Removal and InstallationINFOID:0000000012433251 The wiper and washer switch is part of the combination switch. Refer

Page 3634 of 3641

NISSAN NOTE 2016 Service Repair Manual REAR WIPER ARMWW-69 < REMOVAL AND INSTALLATION > C DE F G H I J K M A B WW N O P REAR WIPER ARM Exploded ViewINFOID:0000000012433252 Removal and InstallationINFOID:0000000012433253 REMOVAL 1. Operate

Page 3635 of 3641

NISSAN NOTE 2016 Service Repair Manual WW-70 < REMOVAL AND INSTALLATION > REAR WIPER ARM Adjustment INFOID:0000000012433254 WIPER BLADE POSITION ADJUSTMENT 1. Back door window glass 2. Back door3. Rear wiper blade A. 30.7 ± 7.5 mm (1.21

Page 3636 of 3641

NISSAN NOTE 2016 Service Repair Manual REAR WIPER BLADEWW-71 < REMOVAL AND INSTALLATION > C DE F G H I J K M A B WW N O P REAR WIPER BLADE Removal and InstallationINFOID:0000000012433255 REMOVAL 1. Lift the rear wiper arm and blade assembl

Page 3637 of 3641

NISSAN NOTE 2016 Service Repair Manual WW-72 < REMOVAL AND INSTALLATION > REAR WIPER MOTOR REAR WIPER MOTOR Exploded ViewINFOID:0000000012433256 Removal and InstallationINFOID:0000000012433257 REMOVAL 1. Remove rear wiper arm. Refer to WW-

Page 3638 of 3641

NISSAN NOTE 2016 Service Repair Manual REAR WASHER NOZZLE AND TUBEWW-73 < REMOVAL AND INSTALLATION > C DE F G H I J K M A B WW N O P REAR WASHER NOZZLE AND TUBE Component Parts LocationINFOID:0000000012433258 WASHER NOZZLE WASHER NOZZLE :

Page 3639 of 3641

NISSAN NOTE 2016 Service Repair Manual WW-74 < REMOVAL AND INSTALLATION > REAR WASHER NOZZLE AND TUBE If washer nozzle (1) spray pattern is not within specification, adjust using a suitable tool (A). WASHER TUBE WASHER TUBE : Removal and

Page 3640 of 3641

NISSAN NOTE 2016 Service Repair Manual REAR WASHER NOZZLE AND TUBEWW-75 < REMOVAL AND INSTALLATION > C DE F G H I J K M A B WW N O P 9. Disconnect the rear washer tube grommet (1) from the back door. 10. Disconnect the rear washer tube fro
