NISSAN NOTE 2016 Service Repair Manual AV-60
< REMOVAL AND INSTALLATION >[BASE AUDIO]
ROD ANTENNA
ROD ANTENNA
Exploded ViewINFOID:0000000012432897
Removal and InstallationINFOID:0000000012432898
REMOVAL
1. Lower the rear portion of the hea

Page 66 of 3641

NISSAN NOTE 2016 Service Repair Manual AV
ANTENNA FEEDERAV-61
< REMOVAL AND INSTALLATION > [BASE AUDIO]
C
D
E
F
G H
I
J
K L
M B A
O P
ANTENNA FEEDER
Feeder LayoutINFOID:0000000012432899
1. Antenna base (antenna amp.) 2. Rod Antenna 3. M351

Page 67 of 3641

NISSAN NOTE 2016 Service Repair Manual AV-62
< PRECAUTION >[DISPLAY AUDIO]
PRECAUTIONS
PRECAUTION
PRECAUTIONS
Precaution for Supplemental Restraint Syst
em (SRS) "AIR BAG" and "SEAT BELT
PRE-TENSIONER"
INFOID:0000000012432945
The Suppleme

AV-62
< PRECAUTION >[DISPLAY AUDIO]
PRECAUTIONS
PRECAUTION
PRECAUTIONS
Precaution for Supplemental Restraint Syst
em (SRS) "AIR BAG" and "SEAT BELT
PRE-TENSIONER"
INFOID:0000000012432945
The Supplemental Restraint System such as “A IR BAG” and “SEAT BELT PRE-TENSIONER”, used along
with a front seat belt, helps to reduce the risk or severity of injury to the driver and front passenger for certain
types of collision. Information necessary to service the system safely is included in the SR and SB section of
this Service Manual.
WARNING:
• To avoid rendering the SRS inopera tive, which could increase the risk of personal injury or death in
the event of a collision which would result in air bag inflation, all maintenance must be performed by
an authorized NISSAN/INFINITI dealer.
• Improper maintenance, including in correct removal and installation of the SRS, can lead to personal
injury caused by unintent ional activation of the system. For re moval of Spiral Cable and Air Bag
Module, see the SR section.
• Do not use electrical test equipmen t on any circuit related to the SRS unless instructed to in this
Service Manual. SRS wiring harn esses can be identified by yellow and/or orange harnesses or har-
ness connectors.
PRECAUTIONS WHEN USING POWER TOOLS (AIR OR ELECTRIC) AND HAMMERS
WARNING:
• When working near the Airbag Diagnosis Sensor Unit or other Airbag System sensors with the Igni-
tion ON or engine running, DO NOT use air or electri c power tools or strike near the sensor(s) with a
hammer. Heavy vibration could activate the sensor( s) and deploy the air bag(s), possibly causing
serious injury.
• When using air or electric power tools or hammers , always switch the Ignition OFF, disconnect the
battery and wait at least three minutes before performing any service.
Precaution for Trouble DiagnosisINFOID:0000000012432946
AV COMMUNICATION SYSTEM
• Do not apply voltage of 7.0 V or higher to the measurement terminals.
• Use the tester with its open terminal voltage being 7.0 V or less.
• Be sure to turn ignition switch OFF and disconnect the battery cable from\
the negative terminal before checking the circuit.
Precaution for Harness RepairINFOID:0000000012432947
AV COMMUNICATION SYSTEM
• Solder the repaired parts, and wrap with tape. [Frays of twisted line
must be within 110 mm (4.33 in).]
PKIA0306E
Revision: August 2015 2016 Versa Note

cardiagn.com

Page 68 of 3641

NISSAN NOTE 2016 Service Repair Manual AV
PRECAUTIONSAV-63
< PRECAUTION > [DISPLAY AUDIO]
C
D
E
F
G H
I
J
K L
M B A
O P
• Do not perform bypass wire connections for the repair parts. (The spliced wire will become separated and the charac

Page 69 of 3641

NISSAN NOTE 2016 Service Repair Manual AV-64
< PREPARATION >[DISPLAY AUDIO]
PREPARATION
PREPARATION
PREPARATION
Special Service ToolsINFOID:0000000012432949
The actual shape of the tools may differ from those illustrated here.
Commercial S

Page 70 of 3641

NISSAN NOTE 2016 Service Repair Manual AV
COMPONENT PARTSAV-65
< SYSTEM DESCRIPTION > [DISPLAY AUDIO]
C
D
E
F
G H
I
J
K L
M B A
O P
SYSTEM DESCRIPTION
COMPONENT PARTS
Component Parts LocationINFOID:0000000012432951
Audio UnitINFOID:0000000

Page 71 of 3641

NISSAN NOTE 2016 Service Repair Manual AV-66
< SYSTEM DESCRIPTION >[DISPLAY AUDIO]
COMPONENT PARTS
• AM/FM electronic tuner radio, CD drive and camera controller are
integrated into the audio unit.
• The display can show audio status a

Page 72 of 3641

NISSAN NOTE 2016 Service Repair Manual AV
COMPONENT PARTSAV-67
< SYSTEM DESCRIPTION > [DISPLAY AUDIO]
C
D
E
F
G H
I
J
K L
M B A
O P
Steering Wheel Audio Control SwitchesINFOID:0000000012432955
• Operations for audio and hands-free phone

Load next 8 pages
