Page 3065 of 3641

NISSAN NOTE 2016 Service Repair Manual SRC-48
< DTC/CIRCUIT DIAGNOSIS >
B0020 SIDE AIRBAG MODULE LH
• Visible damage to connector or terminal
• Loose terminal
• Poor connectionNOTE:
All harness connectors should be inspected from t h

Page 3066 of 3641

NISSAN NOTE 2016 Service Repair Manual B0028 SIDE AIRBAG MODULE RHSRC-49
< DTC/CIRCUIT DIAGNOSIS >
C
DE
F
G
I
J
K L
M A
B
SRC
N
O P
B0028 SIDE AIRBAG MODULE RH
DescriptionINFOID:0000000012430624
DTC B0028 FRONT RH SIDE AIR BAG MODULE
The f

Page 3067 of 3641

NISSAN NOTE 2016 Service Repair Manual SRC-50
< DTC/CIRCUIT DIAGNOSIS >
B0028 SIDE AIRBAG MODULE RH
• Visible damage to connector or terminal
• Loose terminal
• Poor connectionNOTE:
All harness connectors should be inspected from t h

Page 3068 of 3641

NISSAN NOTE 2016 Service Repair Manual B0021 SIDE CURTAIN AIR BAG MODULE LHSRC-51
< DTC/CIRCUIT DIAGNOSIS >
C
DE
F
G
I
J
K L
M A
B
SRC
N
O P
B0021 SIDE CURTAIN AIR BAG MODULE LH
DTC LogicINFOID:0000000012430627
DTC DETECTION LOGIC
DTC CONF

B0021 SIDE CURTAIN AIR BAG MODULE LHSRC-51
< DTC/CIRCUIT DIAGNOSIS >
C
DE
F
G
I
J
K L
M A
B
SRC
N
O P
B0021 SIDE CURTAIN AIR BAG MODULE LH
DTC LogicINFOID:0000000012430627
DTC DETECTION LOGIC
DTC CONFIRMATION PROCEDURE (With CONSULT)
1.CHECK SELF-DIAG RESULT
1. Turn ignition switch ON.
2. Check for DTC using CONSULT.
Is the DTC detected?
YES (Current DTC)>>Refer to SRC-51, "Diagnosis Procedure".
YES (Past DTC)>>GO TO 2.
NO >> Inspection End.
2.ERASE SELF-DIAG RESULT
Erase the DTC using CONSULT.
Can the DTC be erased?
YES >> Inspection End.
NO >> Refer to SRC-51, "
Diagnosis Procedure".
DTC CONFIRMATION PROCEDURE (Without CONSULT)
1.CHECK SELF-DIAG RESULT
1. Turn ignition switch ON.
2. Check the air bag warning lamp status. Refer to SRC-14, "
On Board Diagnosis Function".
NOTE:
SRS will not enter diagnosis mode if no malfunction is detected in user mode.
Is the DTC detected?
YES >> Refer to SRC-51, "Diagnosis Procedure".
NO >> Inspection End.
Diagnosis ProcedureINFOID:0000000012430628
1.HARNESS CONNECTOR
Visually inspect all applicable harness connectors for the following:
• Visible damage to connector or terminal
• Loose terminal
• Poor connection NOTE:
All harness connectors should be inspected from t he air bag diagnosis sensor unit to the end component
(including in-line connectors).
Is the inspection result normal?
YES >> GO TO 2.
NO >> Perform one of the following repairs: • Visible damage: Replace the harness.
CONSULT name DTC DTC detecting condition Repair order
CURTAIN AIRBAG MODULE LH CIRCUIT [OPEN]
B0021LH side curtain air bag module circuit
is open.
Refer to SRC-51, "
Diagnosis Proce-
dure".
CURTAIN AIRBAG MODULE LH CIRCUIT [VB-SHORT] LH side curtain air bag module circuit
is shorted to a power supply circuit.
CURTAIN AIRBAG MODULE LH CIRCUIT [GND-SHORT] LH side curtain air bag module circuit
is shorted to ground.
CURTAIN AIRBAG MODULE LH CIRCUIT [SHORT] LH side curtain air bag module circuits
are shorted to each other.
Revision: August 2015
2016 Versa Note

cardiagn.com

Page 3069 of 3641

NISSAN NOTE 2016 Service Repair Manual SRC-52
< DTC/CIRCUIT DIAGNOSIS >
B0021 SIDE CURTAIN AIR BAG MODULE LH
• Loose terminal: Secure the terminal.
• Poor connection: Secure the connection.
2.CONFIRM DTC
1. Reconnect all harness connec

Page 3070 of 3641

NISSAN NOTE 2016 Service Repair Manual B0029 SIDE CURTAIN AIR BAG MODULE RHSRC-53
< DTC/CIRCUIT DIAGNOSIS >
C
DE
F
G
I
J
K L
M A
B
SRC
N
O P
B0029 SIDE CURTAIN AIR BAG MODULE RH
DTC LogicINFOID:0000000012430629
DTC DETECTION LOGIC
DTC CONF

B0029 SIDE CURTAIN AIR BAG MODULE RHSRC-53
< DTC/CIRCUIT DIAGNOSIS >
C
DE
F
G
I
J
K L
M A
B
SRC
N
O P
B0029 SIDE CURTAIN AIR BAG MODULE RH
DTC LogicINFOID:0000000012430629
DTC DETECTION LOGIC
DTC CONFIRMATION PROCEDURE (With CONSULT)
1.CHECK SELF-DIAG RESULT
1. Turn ignition switch ON.
2. Check for DTC using CONSULT.
Is the DTC detected?
YES (Current DTC)>>Refer to SRC-53, "Diagnosis Procedure".
YES (Past DTC)>>GO TO 2.
NO >> Inspection End.
2.ERASE SELF-DIAG RESULT
Erase the DTC using CONSULT.
Can the DTC be erased?
YES >> Inspection End.
NO >> Refer to SRC-53, "
Diagnosis Procedure".
DTC CONFIRMATION PROCEDURE (Without CONSULT)
1.CHECK SELF-DIAG RESULT
1. Turn ignition switch ON.
2. Check the air bag warning lamp status. Refer to SRC-14, "
On Board Diagnosis Function".
NOTE:
SRS will not enter diagnosis mode if no malfunction is detected in user mode.
Is the DTC detected?
YES >> Refer to SRC-53, "Diagnosis Procedure".
NO >> Inspection End.
Diagnosis ProcedureINFOID:0000000012430630
1.HARNESS CONNECTOR
Visually inspect all applicable harness connectors for the following:
• Visible damage to connector or terminal
• Loose terminal
• Poor connection NOTE:
All harness connectors should be inspected from t he air bag diagnosis sensor unit to the end component
(including in-line connectors).
Is the inspection result normal?
YES >> GO TO 2.
NO >> Perform one of the following repairs: • Visible damage: Replace the harness.
CONSULT name DTC DTC detecting condition Repair order
CURTAIN AIRBAG MODULE RH CIRCUIT [OPEN]
B0029RH side curtain air bag module circuit
is open.
Refer to SRC-53, "
Diagnosis Proce-
dure".
CURTAIN AIRBAG MODULE RH CIRCUIT [VB-SHORT] RH side curtain air bag module circuit
is shorted to a power supply circuit.
CURTAIN AIRBAG MODULE RH CIRCUIT [GND-SHORT] RH side curtain air bag module circuit
is shorted to ground.
CURTAIN AIRBAG MODULE RH CIRCUIT [SHORT] RH side curtain air bag module cir-
cuits are shorted to each other.
Revision: August 2015
2016 Versa Note

cardiagn.com

Page 3071 of 3641

NISSAN NOTE 2016 Service Repair Manual SRC-54
< DTC/CIRCUIT DIAGNOSIS >
B0029 SIDE CURTAIN AIR BAG MODULE RH
• Loose terminal: Secure the terminal.
• Poor connection: Secure the connection.
2.CONFIRM DTC
1. Reconnect all harness connec

Page 3072 of 3641

NISSAN NOTE 2016 Service Repair Manual B1430 SEAT BELT PRE-TENSIONERSRC-55
< DTC/CIRCUIT DIAGNOSIS >
C
DE
F
G
I
J
K L
M A
B
SRC
N
O P
B1430 SEAT BELT PRE-TENSIONER
DTC LogicINFOID:0000000012430631
DTC DETECTION LOGIC
DTC CONFIRMATION PROCE
