NISSAN NOTE 2016 Service Repair Manual SRC-80
< DTC/CIRCUIT DIAGNOSIS >
B0097 REAR SIDE AIR BAG SATELLITE SENSOR RH
B0097 REAR SIDE AIR BAG SATELLITE SENSOR RH
DescriptionINFOID:0000000012430658
DTC B0097 REAR SATELLITE SENSOR RH
The rear

SRC-80
< DTC/CIRCUIT DIAGNOSIS >
B0097 REAR SIDE AIR BAG SATELLITE SENSOR RH
B0097 REAR SIDE AIR BAG SATELLITE SENSOR RH
DescriptionINFOID:0000000012430658
DTC B0097 REAR SATELLITE SENSOR RH
The rear side air bag satellite sensor RH is wired to the air bag diagnosis sensor unit. The air bag diagnosis
sensor unit will monitor the rear side air bag satellite sensor RH for internal failures and its circuits for commu-
nication errors.
PA R T L O C AT I O N
Refer to SRC-5, "Component Parts Location".
DTC LogicINFOID:0000000012430659
DTC DETECTION LOGIC
With CONSULT
DTC CONFIRMATION PROCEDURE (With CONSULT)
1.CHECK SELF-DIAG RESULT
1. Turn ignition switch ON.
2. Check for DTC using CONSULT.
Is the DTC detected?
YES (Current DTC)>>Refer to SRC-81, "Diagnosis Procedure".
YES (Past DTC)>>GO TO 2.
NO >> Inspection End.
2.ERASE SELF-DIAG RESULT
Erase the DTC using CONSULT.
Can the DTC be erased?
YES >> Inspection End.
NO >> Refer to SRC-81, "
Diagnosis Procedure".
DTC CONFIRMATION PROCEDURE (Without CONSULT)
1.CHECK SELF-DIAG RESULT
1. Turn ignition switch ON.
2. Check the air bag warning lamp status. Refer to SRC-14, "
On Board Diagnosis Function".
NOTE:
SRS will not enter diagnosis mode if no malfunction is detected in user mode.
Is the DTC detected?
YES >> Refer to SRC-81, "Diagnosis Procedure".
NO >> Inspection End.
CONSULT name DTCDTC detecting condition Repair order
C-PILLAR SATELLITE SENSOR RH [SENSOR FAIL]
B0097Rear side air bag satellite sensor RH has
malfunctioned.
Refer to SRC-81, "
Diagnosis Procedure".
C-PILLAR SATELLITE SENSOR RH [COMM FAIL] Rear side air bag satellite sensor RH
communication error.
C-PILLAR SATELLITE SENSOR RH [DISCONNECT] Rear side air bag satellite sensor RH is
disconnected.
C-PILLAR SATELLITE SENSOR RH [UNMATCH] Rear side air bag satellite sensor RH is
out of specification.
C-PILLAR SATELLITE SENSOR RH [GND-SHORT] Rear side air bag satellite sensor RH cir-
cuit is shorted to ground.
Revision: August 2015
2016 Versa Note

cardiagn.com

Page 3098 of 3641

NISSAN NOTE 2016 Service Repair Manual B0097 REAR SIDE AIR BAG SATELLITE SENSOR RH
SRC-81
< DTC/CIRCUIT DIAGNOSIS >
C
D E
F
G
I
J
K L
M A
B
SRC
N
O P
Diagnosis ProcedureINFOID:0000000012430660
1.HARNESS CONNECTOR
Visually inspect all appli

Page 3099 of 3641

NISSAN NOTE 2016 Service Repair Manual SRC-82
< DTC/CIRCUIT DIAGNOSIS >
B0097 REAR SIDE AIR BAG SATELLITE SENSOR RH
NO >> Clear DTC. Inspection End.
7.RELATED HARNESS
Replace the related harness.
>>END
Revision: August 2015 2016 Versa Note

Page 3100 of 3641

NISSAN NOTE 2016 Service Repair Manual B00A0 OCS SYSTEMSRC-83
< DTC/CIRCUIT DIAGNOSIS >
C
DE
F
G
I
J
K L
M A
B
SRC
N
O P
B00A0 OCS SYSTEM
DescriptionINFOID:0000000012430661
DTC B00A0 OCCUPANT CLASSIFICATION SYSTEM (OCS)
The OCS control uni

Page 3101 of 3641

NISSAN NOTE 2016 Service Repair Manual SRC-84
< DTC/CIRCUIT DIAGNOSIS >
B00A0 OCS SYSTEM
SRS will not enter diagnosis mode if no malfunction is detected in user mode.
Is the DTC detected?
YES >> Refer to SRC-84, "Diagnosis Procedure".
NO >

Page 3102 of 3641

NISSAN NOTE 2016 Service Repair Manual B00A0 OCS SYSTEMSRC-85
< DTC/CIRCUIT DIAGNOSIS >
C
DE
F
G
I
J
K L
M A
B
SRC
N
O P
2. Turn ignition switch ON.
3. Check for DTC using CONSULT.
Is DTC still current?
YES >> GO TO 7.
NO >> Clear DTC. Ins

Page 3103 of 3641

NISSAN NOTE 2016 Service Repair Manual SRC-86
< DTC/CIRCUIT DIAGNOSIS >
B14XX AIR BAG DIAGNOSIS SENSOR UNIT
B14XX AIR BAG DIAGNOSIS SENSOR UNIT
DescriptionINFOID:0000000012430664
DTC B1XXX AIR BAG DIAGNOSIS SENSOR UNIT
The air bag diagnosi

Page 3104 of 3641

NISSAN NOTE 2016 Service Repair Manual B14XX AIR BAG DIAGNOSIS SENSOR UNITSRC-87
< DTC/CIRCUIT DIAGNOSIS >
C
DE
F
G
I
J
K L
M A
B
SRC
N
O P
Is the inspection result normal?
YES >> GO TO 2.
NO >> Perform one of the following repairs: • Vi
