Page 3137 of 3641

NISSAN NOTE 2016 Service Repair Manual SIDE CURTAIN AIR BAG MODULESR-21 < REMOVAL AND INSTALLATION > C DE F G I J K L M A B SR N O P SIDE CURTAIN AIR BAG MODULE Exploded ViewINFOID:0000000012430572 Removal and InstallationINFOID:0000000012

Page 3138 of 3641

NISSAN NOTE 2016 Service Repair Manual SR-22 < REMOVAL AND INSTALLATION > SIDE CURTAIN AIR BAG MODULE • For removing/installing the side curtain air bag moduleharness connector, insert a thin screwdriver wrapped in tape into the notch, l

Page 3139 of 3641

NISSAN NOTE 2016 Service Repair Manual SIDE AIR BAG MODULESR-23 < REMOVAL AND INSTALLATION > C DE F G I J K L M A B SR N O P SIDE AIR BAG MODULE Removal and InstallationINFOID:0000000012430574 The side air bag module is part of the front s

Page 3140 of 3641

NISSAN NOTE 2016 Service Repair Manual SR-24 < REMOVAL AND INSTALLATION > CRASH ZONE SENSOR CRASH ZONE SENSOR Exploded ViewINFOID:0000000012430575 Removal and InstallationINFOID:0000000012430576 WARNING: • Before servicing the SRS, turn

Page 3141 of 3641

NISSAN NOTE 2016 Service Repair Manual CRASH ZONE SENSORSR-25 < REMOVAL AND INSTALLATION > C DE F G I J K L M A B SR N O P 2. Remove and discard crash zone sensor nut (A). CAUTION: Do not reuse crash zone sensor nut. 3. Remove bracket (1)

Page 3142 of 3641

NISSAN NOTE 2016 Service Repair Manual SR-26 < REMOVAL AND INSTALLATION > SATELLITE SENSOR SATELLITE SENSOR Exploded ViewINFOID:0000000012430577 Removal and Installation - Front Door Satellite SensorINFOID:0000000012430578 WARNING: • Bef

Page 3143 of 3641

NISSAN NOTE 2016 Service Repair Manual SATELLITE SENSORSR-27 < REMOVAL AND INSTALLATION > C DE F G I J K L M A B SR N O P 3. Disconnect the slide double locking type harness connecto r from the front door satellite sensor, as shown. 4. Rem

Page 3144 of 3641

NISSAN NOTE 2016 Service Repair Manual SR-28 < REMOVAL AND INSTALLATION > SATELLITE SENSOR 5. Disconnect the slide double locking type harness connector from front side air bag satellite sensor, asshown. INSTALLATION Installation is in th
