Page 657 of 3641

NISSAN NOTE 2016 Service Repair Manual DEF-6 < SYSTEM DESCRIPTION > SYSTEM SYSTEM System DescriptionINFOID:0000000012431755 SYSTEM DIAGRAM Operation Description • When rear window defogger switch is turned ON while ignition switch is ON,

Page 658 of 3641

NISSAN NOTE 2016 Service Repair Manual DIAGNOSIS SYSTEM (BCM) (WITH INTELLIGENT KEY SYSTEM) DEF-7 < SYSTEM DESCRIPTION > C D E F G H I J K M A B DEF N O P DIAGNOSIS SYSTEM (BCM) (WIT H INTELLIGENT KEY SYSTEM) COMMON ITEM COMMON ITEM : CONS

Page 659 of 3641

NISSAN NOTE 2016 Service Repair Manual DEF-8 < SYSTEM DESCRIPTION > DIAGNOSIS SYSTEM (BCM) (WITH INTELLIGENT KEY SYSTEM) REAR DEFOGGER REAR DEFOGGER : CONSULT Func tion (BCM - REAR DEFOGGER)INFOID:0000000012542308 DATA MONITOR ACTIVE TEST

Page 660 of 3641

NISSAN NOTE 2016 Service Repair Manual DIAGNOSIS SYSTEM (BCM) (WITHOUT INTELLIGENT KEY SYSTEM)DEF-9 < SYSTEM DESCRIPTION > C DE F G H I J K M A B DEF N O P DIAGNOSIS SYSTEM (BCM) (WITHO UT INTELLIGENT KEY SYSTEM) COMMON ITEM COMMON ITEM :

Page 661 of 3641

NISSAN NOTE 2016 Service Repair Manual DEF-10 < SYSTEM DESCRIPTION > DIAGNOSIS SYSTEM (BCM) (WITHOUT INTELLIGENT KEY SYSTEM) REAR DEFOGGER REAR DEFOGGER : CONSULT Function (BCM - REAR DEFOGGER)INFOID:0000000012542310 DATA MONITOR ACTIVE TE

Page 662 of 3641

NISSAN NOTE 2016 Service Repair Manual BCM DEF-11 < ECU DIAGNOSIS INFORMATION > C D E F G H I J K M A B DEF N O P ECU DIAGNOSIS INFORMATION BCM List of ECU ReferenceINFOID:0000000012431760 ECU Reference BCM (with Intelligent Key system)

Page 663 of 3641

NISSAN NOTE 2016 Service Repair Manual DEF-12 < WIRING DIAGRAM > REAR WINDOW DEFOGGER SYSTEM WIRING DIAGRAM REAR WINDOW DEFOGGER SYSTEM Wiring DiagramINFOID:0000000012431761 ABLWA3280GB Revision: August 20152016 Versa Note cardiagn.com

Page 664 of 3641

NISSAN NOTE 2016 Service Repair Manual REAR WINDOW DEFOGGER SYSTEMDEF-13 < WIRING DIAGRAM > C DE F G H I J K M A B DEF N O P ABLIA8087GB Revision: August 2015 2016 Versa Note cardiagn.com
