NISSAN NOTE 2016 Service Repair Manual POWER SUPPLY AND GROUND CIRCUITBRC-121
< DTC/CIRCUIT DIAGNOSIS > [VDC/TCS/ABS]
C
D
E
G H
I
J
K L
M A
B
BRC
N
O P
POWER SUPPLY AND GROUND CIRCUIT
Diagnosis ProcedureINFOID:0000000012430902
1.CHECK ABS

POWER SUPPLY AND GROUND CIRCUITBRC-121
< DTC/CIRCUIT DIAGNOSIS > [VDC/TCS/ABS]
C
D
E
G H
I
J
K L
M A
B
BRC
N
O P
POWER SUPPLY AND GROUND CIRCUIT
Diagnosis ProcedureINFOID:0000000012430902
1.CHECK ABS ACTUATOR AND ELECTRIC UNIT (CONTROL UNIT) IGNITION POWER SUPPLY (1)
1. Turn the ignition switch OFF.
2. Disconnect ABS actuator and electric unit (control unit) harness connector.
3. Check the voltage between ABS actuator and elec tric unit (control unit) harness connector and ground.
4. Turn the ignition switch ON NOTE:
Start the engine.
5. Check the voltage between ABS actuator and elec tric unit (control unit) harness connector and ground.
Is the inspection result normal?
YES >> GO TO 3.
NO >> GO TO 2.
2.CHECK ABS ACTUATOR AND ELECTRIC UNIT (CONTROL UNIT) IGNITION POWER SUPPLY CIRCUIT
1. Turn the ignition switch OFF.
2. Check the 10A fuse (50).
3. Disconnect IPDM E/R harness connector.
4. Check the continuity between ABS actuator and elec tric unit (control unit) harness connector and IPDM E/
R.
5. Check the continuity between ABS actuator and electric unit (control unit) harness connector and ground.
Is the inspection result normal?
YES >> Perform trouble diagnosis for ignition power supply.
NO >> Repair / replace harness, connector, or fuse.
3.CHECK MOTOR AND MOTOR RELAY POWER SUPPLY
1. Turn the ignition switch OFF.
2. Check the voltage between ABS actuator and elec tric unit (control unit) harness connector and ground.
3. Turn the ignition switch ON. NOTE:
ABS actuator and electric unit (control unit) —Voltag e
(Approx.)
Connector Terminal
E33 6Ground 0 V
ABS actuator and electric unit (control unit)
—Voltag e
(Approx.)
Connector Terminal
E33 6GroundBattery voltage
ABS actuator and electric unit (control unit) IPDM E/R
Continuity
Connector TerminalConnectorTerminal
E33 6E4520Yes
ABS actuator and electric unit (control unit)
—Con tin uit y
Connector Terminal
E33 6Ground No
ABS actuator and electric unit (control unit)
—Voltag e
(Approx.)
Connector Terminal
E33 1GroundBattery voltage
Revision: August 2015 2016 Versa Note

cardiagn.com

Page 570 of 3641

NISSAN NOTE 2016 Service Repair Manual BRC-122
< DTC/CIRCUIT DIAGNOSIS >[VDC/TCS/ABS]
POWER SUPPLY AND GROUND CIRCUIT
Start the engine.
4. Check the voltage between ABS actuator and elec tric unit (control unit) harness connector and groun

BRC-122
< DTC/CIRCUIT DIAGNOSIS >[VDC/TCS/ABS]
POWER SUPPLY AND GROUND CIRCUIT
Start the engine.
4. Check the voltage between ABS actuator and elec tric unit (control unit) harness connector and ground.
Is the inspection result normal?
YES >> GO TO 5.
NO >> GO TO 4.
4.CHECK MOTOR AND MOTOR RE LAY POWER SUPPLY CIRCUIT
1. Turn the ignition switch OFF.
2. Check the 40A fusible link (I).
3. Check the continuity and short circuit between ABS actuator and electric unit (control unit) harness con-
nector terminal 1 and 40A fusible link (I).
Is the inspection result normal?
YES >> Perform trouble diagnosis for battery power supply.
NO >> Repair / replace harness, connector, or fusible link.
5.CHECK ACTUATOR RELAY, ABS IN VALVE, ABS OUT VALVE POWER SUPPLY
1. Turn the ignition switch OFF.
2. Check the voltage between ABS actuator and elec tric unit (control unit) harness connector and ground.
3. Turn the ignition switch ON NOTE:
Start the engine.
4. Check the voltage between ABS actuator and elec tric unit (control unit) harness connector and ground.
Is the inspection result normal?
YES >> GO TO 7.
NO >> GO TO 6.
6.CHECK ACTUATOR RELAY, ABS IN VALV E, ABS OUT VALVE POWER SUPPLY CIRCUIT
1. Turn the ignition switch OFF.
2. Check the 30A fusible link (M).
3. Check the continuity and short circuit between ABS actuator and electric unit (control unit) harness con-
nector terminal 25 and 30A fusible link (M).
Is the inspection result normal?
YES >> Perform trouble diagnosis for battery power supply.
NO >> Repair / replace harness, connector, or fusible link.
7.CHECK ABS ACTUATOR AND ELECTRIC UNIT (CONTROL UNIT) GROUND CIRCUIT
Check the continuity between ABS actuator and electric unit (control unit) harness connector and the ground.
ABS actuator and electric unit (control unit)
—Vol tag e
(Approx.)
Connector Terminal
E33 1GroundBattery voltage
ABS actuator and electric unit (control unit)
—Vo l ta g e
(Approx.)
Connector Terminal
E33 25GroundBattery voltage
ABS actuator and electric unit (control unit)
—Vo l ta g e
(Approx.)
Connector Terminal
E33 25GroundBattery voltage
Revision: August 2015 2016 Versa Note

cardiagn.com

Page 571 of 3641

NISSAN NOTE 2016 Service Repair Manual POWER SUPPLY AND GROUND CIRCUITBRC-123
< DTC/CIRCUIT DIAGNOSIS > [VDC/TCS/ABS]
C
D
E
G H
I
J
K L
M A
B
BRC
N
O P
Is the inspection result normal?
YES >> GO TO 8.
NO >> Repair / replace harness, connec

Page 572 of 3641

NISSAN NOTE 2016 Service Repair Manual BRC-124
< DTC/CIRCUIT DIAGNOSIS >[VDC/TCS/ABS]
PARKING BRAKE SWITCH
PARKING BRAKE SWITCH
Component Function CheckINFOID:0000000012430903
1.CHECK PARKING BRAKE SWITCH OPERATION
Check that brake warning

Page 573 of 3641

NISSAN NOTE 2016 Service Repair Manual PARKING BRAKE SWITCHBRC-125
< DTC/CIRCUIT DIAGNOSIS > [VDC/TCS/ABS]
C
D
E
G H
I
J
K L
M A
B
BRC
N
O P
4. Check continuity between combination meter connector M82 (type A) or M24 (type B) terminal 10 a

Page 574 of 3641

NISSAN NOTE 2016 Service Repair Manual BRC-126
< DTC/CIRCUIT DIAGNOSIS >[VDC/TCS/ABS]
VDC OFF SWITCH
VDC OFF SWITCH
Component Function CheckINFOID:0000000012430906
1.CHECK VDC OFF SWITCH OPERATION
Check that VDC OFF indicator lamp in combi

BRC-126
< DTC/CIRCUIT DIAGNOSIS >[VDC/TCS/ABS]
VDC OFF SWITCH
VDC OFF SWITCH
Component Function CheckINFOID:0000000012430906
1.CHECK VDC OFF SWITCH OPERATION
Check that VDC OFF indicator lamp in combination meter turns ON/OFF when VDC OFF switch is operated.
Is the inspection result normal?
YES >> Inspection End.
NO >> Proceed to diagnosis procedure. Refer to BRC-126, "
Diagnosis Procedure".
Diagnosis ProcedureINFOID:0000000012430907
Regarding Wiring Diagram information, refer to BRC-44, "Wiring Diagram".
1.CONNECTOR INSPECTION
1. Turn ignition switch OFF.
2. Disconnect ABS actuator and electric unit (c ontrol unit) and VDC OFF switch connectors.
3. Check connectors and terminals for deformation, disconnection, looseness or damage.
Is the inspection result normal?
YES >> GO TO 2.
NO >> Repair or replace as necessary.
2.CHECK VDC OFF SWITCH
Check VDC OFF switch. Refer to BRC-127, "
Component Inspection".
Is the inspection result normal?
YES >> GO TO 3.
NO >> Replace VDC OFF switch. Refer to BRC-146, "
Removal and Installation".
3.CHECK VDC OFF SWITCH SIGNAL
With CONSULT.
1. Connect ABS actuator and electric unit (c ontrol unit) and VDC OFF switch connectors.
2. Turn ignition switch ON.
3. In “Data Monitor” select “OFF SW” and check VDC OFF switch signal.
Is the inspection result normal?
YES >> Refer to BRC-52, "Work Flow".
NO >> GO TO 4.
4.CHECK VDC OFF SWITCH CIRCUIT
1. Turn ignition switch OFF.
2. Disconnect ABS actuator and electric unit (c ontrol unit) and VDC OFF switch connectors.
3. Check continuity between ABS actuator and electr ic unit (control unit) connector E33 terminal 20 and
VDC OFF switch connector M34 terminal 1.
4. Check continuity between ABS actuator and electric unit (control unit) connector terminal E33 terminal 20 and ground.
Condition DATA MONITOR
VDC OFF switch is pressed and released On
VDC OFF switch is pressed and released again Off
ABS actuator and electric unit (control unit) VDC OFF switch
Continuity
Connector Terminal Connector Terminal
E33 20 M34 1 Yes
Revision: August 2015 2016 Versa Note

cardiagn.com

Page 575 of 3641

NISSAN NOTE 2016 Service Repair Manual VDC OFF SWITCHBRC-127
< DTC/CIRCUIT DIAGNOSIS > [VDC/TCS/ABS]
C
D
E
G H
I
J
K L
M A
B
BRC
N
O P
Is the inspection result normal?
YES >> GO TO 5.
NO >> Repair or replace malfunctioning components.
5.CH

Page 576 of 3641

NISSAN NOTE 2016 Service Repair Manual BRC-128
< DTC/CIRCUIT DIAGNOSIS >[VDC/TCS/ABS]
ABS WARNING LAMP
ABS WARNING LAMP
Component Function CheckINFOID:0000000012430909
1.CHECK ABS WARNING LAMP FUNCTION
Check that ABS warning lamp in combin
