Page 2529 of 3641

NISSAN NOTE 2016 Service Repair Manual PCS-26
< DTC/CIRCUIT DIAGNOSIS >[IPDM E/R]
U1000 CAN COMM CIRCUIT
DTC/CIRCUIT DIAGNOSIS
U1000 CAN COMM CIRCUIT
DescriptionINFOID:0000000012433277
Refer to
LAN-7, "CAN COMMUNICATION SYSTEM : System De

Page 2530 of 3641

NISSAN NOTE 2016 Service Repair Manual PCS
B2098 IGNITION RELAY ON STUCKPCS-27
< DTC/CIRCUIT DIAGNOSIS > [IPDM E/R]
C
D
E
F
G H
I
J
K L
B A
O P
N
B2098 IGNITION RELAY ON STUCK
DTC LogicINFOID:0000000012433280
DTC DETECTION LOGIC
DTC CONFIR

Page 2531 of 3641

NISSAN NOTE 2016 Service Repair Manual PCS-28
< DTC/CIRCUIT DIAGNOSIS >[IPDM E/R]
B2099 IGNITION RELAY OFF STUCK
B2099 IGNITION RELAY OFF STUCK
DTC LogicINFOID:0000000012433282
DTC DETECTION LOGIC
DTC CONFIRMATION PROCEDURE
1.PERFORM DTC C

Page 2532 of 3641

NISSAN NOTE 2016 Service Repair Manual PCS
POWER SUPPLY AND GROUND CIRCUITPCS-29
< DTC/CIRCUIT DIAGNOSIS > [IPDM E/R]
C
D
E
F
G H
I
J
K L
B A
O P
N
POWER SUPPLY AND GROUND CIRCUIT
Diagnosis ProcedureINFOID:0000000012433284
Regarding Wiring

Page 2533 of 3641

NISSAN NOTE 2016 Service Repair Manual PCS-30
< REMOVAL AND INSTALLATION >[IPDM E/R]
IPDM E/R
REMOVAL AND INSTALLATION
IPDM E/R
Exploded ViewINFOID:0000000012433285
Removal and InstallationINFOID:0000000012433286
CAUTION:
IPDM E/R integrat

Page 2534 of 3641

NISSAN NOTE 2016 Service Repair Manual PCS
IPDM E/RPCS-31
< REMOVAL AND INSTALLATION > [IPDM E/R]
C
D
E
F
G H
I
J
K L
B A
O P
N
3. Release pawls, then lift IPDM E/R (1) as shown and position
aside.
:Pawl
4. Disconnect the harness connector

Page 2535 of 3641

NISSAN NOTE 2016 Service Repair Manual PCS-32
< PRECAUTION >[POWER DISTRIBUTION SYSTEM]
PRECAUTIONS
PRECAUTION
PRECAUTIONS
Precaution for Supplemental Restraint Syst
em (SRS) "AIR BAG" and "SEAT BELT
PRE-TENSIONER"
INFOID:0000000012433287

Page 2536 of 3641

NISSAN NOTE 2016 Service Repair Manual PCS
COMPONENT PARTSPCS-33
< SYSTEM DESCRIPTION > [POWER DISTRIBUTION SYSTEM]
C
D
E
F
G H
I
J
K L
B A
O P
N
SYSTEM DESCRIPTION
COMPONENT PARTS
Component Parts LocationINFOID:0000000012433288
AWMIA1438Z

PCS
COMPONENT PARTSPCS-33
< SYSTEM DESCRIPTION > [POWER DISTRIBUTION SYSTEM]
C
D
E
F
G H
I
J
K L
B A
O P
N
SYSTEM DESCRIPTION
COMPONENT PARTS
Component Parts LocationINFOID:0000000012433288
AWMIA1438ZZ
No.
Component Description
1. Accessory relay-2 • Accessory relay-2 is controlled by BCM.
• Accessory relay-2 supplies accessory power supply or ignition switch ACC signal to each ECU
when ignition switch is turned to ACC or ON.
• BCM compares status of accessory relay-2 control signal, and ignition switch position judged
by BCM.
2. BCM • BCM controls power distribution system.
• BCM judges ignition switch position by push-button ignition switch (push switch) and vehicle
condition.
• BCM checks ignition switch position internally.
3. Push-button ignition
switch Push-button ignition switch (push switch) is pressed, and transmits status signal to BCM and
IPDM E/R.
4. IPDM E/R • IPDM E/R detects push-button ignition switch (push switch) status, and transmits push-button
ignition switch status signal (CAN) to BCM.
• IPDM E/R receives ignition relay-1 (IPDM E/R) control signal and ignition switch ON signal
(CAN) from BCM, and controls igniti on relay-1 (built into IPDM E/R)
5. Blower relay (in fuse
block) • Blower relay is controlled by BCM.
• Blower relay supplies ignition switch ON power supply or ignition switch ON signal to air con-
ditioning system when ignition switch is turned ON.
• BCM compares status of blower relay control signal and ignition switch position judged by BCM.
6. Accessory relay-1 (in
fuse block) • Accessory relay-1 is controlled by BCM.
• Accessory relay-1 supplies accessory power supply or ignition switch ACC signal to each ECU
when ignition switch is turned ACC or ON.
• BCM compares status of accessory relay-1 control signal, and ignition switch position judged by BCM.
7. Ignition relay-2 (in fuse
block) • Ignition relay-2 is controlled by BCM.
• Ignition relay-2 supplies ignition switch ON power supply or ignition switch ON signal to each
ECU and system when ignition switch is turned ON.
• BCM compares status of ignition relay-2 control signal and ignition switch position judged by
BCM.
• BCM monitors ignition relay-2 operating status by ignition relay feedback signal.
Revision: August 2015 2016 Versa Note
