Page 2841 of 3641

NISSAN NOTE 2016 Service Repair Manual SE-28 < REMOVAL AND INSTALLATION > REAR SEAT 1. Remove the seat cushion. Refer to SE-26, "SEAT CUSHION : Removal and Installation". 2. Release the seat cushion hook pawls as shown and remove. CAUTION:

Page 2842 of 3641

NISSAN NOTE 2016 Service Repair Manual FRONT HEATED SEAT SWITCHSE-29 < REMOVAL AND INSTALLATION > C DE F G H I K L M A B SE N O P FRONT HEATED SEAT SWITCH Removal and InstallationINFOID:0000000012432047 REMOVAL 1. Remove the center console

Page 2843 of 3641

NISSAN NOTE 2016 Service Repair Manual SE-30 < UNIT DISASSEMBLY AND ASSEMBLY > FRONT SEAT UNIT DISASSEMBLY AND ASSEMBLY FRONT SEAT DRIVER SIDE DRIVER SIDE : Exploded ViewINFOID:0000000012432048 DRIVER SEAT WITH LIFT AND ARMREST AWJIA1997ZZ

Page 2844 of 3641

NISSAN NOTE 2016 Service Repair Manual FRONT SEATSE-31 < UNIT DISASSEMBLY AND ASSEMBLY > C DE F G H I K L M A B SE N O P DRIVER SEAT WITHOUT LIFT AND ARMREST 1. Armrest 2. Seat cushion outer finisher (RH) 3. Seat belt buckle 4. Seat cushio

Page 2845 of 3641

NISSAN NOTE 2016 Service Repair Manual SE-32 < UNIT DISASSEMBLY AND ASSEMBLY > FRONT SEAT DRIVER SIDE : Seatback INFOID:0000000012834455 DISASSEMBLY 1. Remove the driver side front seat. Refer to SE-20, "DRIVER SIDE : Removal and Installa

Page 2846 of 3641

NISSAN NOTE 2016 Service Repair Manual FRONT SEATSE-33 < UNIT DISASSEMBLY AND ASSEMBLY > C DE F G H I K L M A B SE N O P ASSEMBLY Assembly is in the reverse order of disassembly. Smooth out all wrinkles during assembly. DRIVER SIDE : Seat

Page 2847 of 3641

NISSAN NOTE 2016 Service Repair Manual SE-34 < UNIT DISASSEMBLY AND ASSEMBLY > FRONT SEAT 7. Remove the seat cushion outer finisher (RH) (1). a. Pull to release clips and pawls in the direction ( ) shown andremove. 8. Remove the seat cushi

Page 2848 of 3641

NISSAN NOTE 2016 Service Repair Manual FRONT SEATSE-35 < UNIT DISASSEMBLY AND ASSEMBLY > C DE F G H I K L M A B SE N O P PASSENGER SIDE : Exploded ViewINFOID:0000000012432051 AWJIA1999ZZ 1. Headrest 2. Headrest holder (free) 3. Headrest ho
