EC-44
< SYSTEM DESCRIPTION >[HR16DE]
SYSTEM
*: When detecting a normal engine oil pressure, ECM turns OFF the oil pressure warning lamp.
FUEL FILLER CAP WARNING SYSTEM
FUEL FILLER CAP WARNING
SYSTEM : System DiagramINFOID:0000000012431326
FUEL FILLER CAP WARNING SYS TEM : System DescriptionINFOID:0000000012431327
INPUT/OUTPUT SIGNAL CHART
Input
*: This signal is sent to the ECM via the CAN communication line.
Output
*: This signal is sent to the combination meter via the CAN communication line.
SYSTEM DESCRIPTION
The fuel filler cap warning system alerts the driver to the prevention of the fuel filler being left uncapped and
malfunction occurrences after refueling, by turning ON the fuel filler cap warning display on the combination
meter.
ECM judges a refueled state, based on a fuel level signal transmitted from the combination meter.
When a very small leak is detected through the EVAP leak diagnosis performed after judging the refueled
state, ECM transmits a fuel filler cap warning display signal (request for display ON) to the combination meter
via CAN communication.
When receiving the signal, the combination meter turns ON the fuel filler cap warning display.
CAUTION:
Check fuel filler cap installation condition when the fuel filler cap warning display turns ON.
Reset Operation
Decrease in engine
oil pressure Engine speed Combination meter
Oil pressure warning lamp
Detection Less than 1,000 rpm
ON*
1,000 rpm or more ON
Unit/Sensor Input signal to ECM ECM function
EVAP control system pressure sensor Pressure in purge line
Fuel filler cap warning control
Combination meter Fuel level
Fuel filler cap warning reset signal
*
JSBIA0797GB
Unit
Output signal Actuator
ECM Fuel filler cap warning display signal
*Combination meter
Revision: August 2015 2016 Versa Note

cardiagn.com

EC-64
< SYSTEM DESCRIPTION >[HR16DE]
DIAGNOSIS SYSTEM (ECM)
ALT DUTY SIG ON/OFF• The control condition of the power generation
voltage variable control (determined by ECM ac-
cording to the input signals) is indicated.
- ON: Power generation voltage variable control is active.
- OFF: Power generation voltage variable control is inactive.
I/P PULLY SPD rpmIndicates the engine speed computed from the in-
put speed sensor signal.
VEHICLE SPEED km/h or mph The vehicle speed computed from the vehicle
speed signal sent from TCM is displayed.
IDL A/V LEARN YET/CMPLT • Displays the condition of Idle Air Volume Learn-
ing.
- YET: Idle air volume learning has not been per-
formed yet.
- CMPLT: Idle air volume learning has already been performed successfully.
TRVL AFTER MIL km or mile Distance traveled while MIL is activated.
ENG OIL TEMP °C or °F The engine oil temperature (determined by the sig-
nal voltage of the engine oil temperature sensor) is
indicated.
A/F S1 HTR(B1) %• Air fuel ratio (A/F) sensor 1 heater control value
computed by ECM according to the input signals.
• The current flow to the heater becomes larger as the value increases.
VHCL SPEED SE km/h or mph The vehicle speed computed from the vehicle
speed signal sent from combination meter is dis-
played.
SET VHCL SPD km/h or mph The preset vehicle speed is displayed.
MAIN SW ON/OFFIndicates [ON/OFF] condition from ASCD MAIN
switch signal.
CANCEL SW ON/OFFIndicates [ON/OFF] condit
ion from CANCEL switch
signal.
RESUME/ACC SW ON/OFF Indicates [ON/OFF] condition from ACCEL/RES
switch signal.
SET SW ON/OFFIndicates [ON/OFF] condition from COAST/SET
switch signal.
BRAKE SW1 ON/OFFIndicates [ON/OFF] condition from ASCD brake
switch signal.
BRAKE SW2 ON/OFFIndicates [ON/OFF] condition of stop lamp switch
signal.
VHCL SPD CUT NON/CUT • Indicates the vehicle cruise condition.
- NON: Vehicle speed is maintained at the ASCD
set speed.
- CUT: Vehicle speed decreased to excessively
low compared with the ASCD set speed, and
ASCD operation is cut off.
LO SPEED CUT NON/CUT • Indicates the vehicle cruise condition.
- NON: Vehicle speed is maintained at the ASCD
set speed.
- CUT: Vehicle speed decreased to excessively low, and ASCD operation is cut off.
AT OD MONITOR ON/OFF Indicates [ON/OFF] condition of CVT O/D accord-
ing to the input signal from the TCM.
AT OD CANCEL ON/OFF Indicates [ON/OFF] condition of CVT O/D cancel
request signal.
Monitored item Unit
DescriptionRemarks
Revision: August 2015 2016 Versa Note

cardiagn.com

ECM
EC-73
< ECU DIAGNOSIS INFORMATION > [HR16DE]
C
D
E
F
G H
I
J
K L
M A
EC
NP
O
EXH/V TIM B1
• Engine: After warming up
• Selector lever position: P or N
(CVT) or Neutral (M/T)
• Air conditioner switch: OFF
•No load Idle
−5 ° - 5 °CA
When revving engine up to 2,000rpm
Quickly Approx. 0
° - 40 °CA
INT/V SOL(B1) • Engine: After warming up
• Selector lever position: P or N
(CVT) or Neutral (M/T)
• Air conditioner switch: OFF
•No load Idle
0% - 2%
When revving engine up to 2,000rpm
Quickly Approx. 0% - 90%
AIR COND RLY • Engine: After warming up, idle
the engine Air conditioner switch: OFF
OFF
Air conditioner switch: ON
(Compressor operates.) ON
FUEL PUMP RLY • For 1 seconds after turning ignition switch: ON
• Engine running or cranking
ON
• Except above OFF
VENT CONT/V • Ignition switch: ON OFF
THRTL RELAY • Ignition switch: ON ON
COOLING FAN • Engine: After warning up, idle the
engine
• Air conditioner switch: OFF Engine coolant temperature is 98
°C
(208 °F) or less OFF
Engine coolant temperature is between
98 °C (208 °F) and 99° C (210°F) LOW
Engine coolant temperature is 100 °C
(212 °F) or more HIGH
HO2S2 HTR (B1) • Engine speed: Below 3,600 rpm after the following conditions are met.
- Engine: After warming up
- Keeping the engine speed between 3,500 and 4,000 rpm for 1 minute and at
idle for 1 minute under no load ON
ALT DUTY SIG • Power generation voltage variable control: Operating
ON
• Power generation voltage variable control: Not operating OFF
I/P PULLY SPD • Vehicle speed: More than 20 km/h (12 MPH) Almost the same speed as
the tachometer indication
VEHICLE SPEED • Turn drive wheels and compare CONSULT value with the speedometer indi-
cation. Almost the same speed as
speedometer indication
IDL A/V LEARN • En gine: running Idle air volume learning has not been per-
formed yet.
YET
Idle air volume learning has already been
performed successfully. CMPLT
TRVL AFTER MIL • Ignition switch: ON Vehicle has traveled after MIL has turned
ON.0 - 65,535 km
(0 - 40,723 miles)
ENG OIL TEMP • Engine: After warming up More than 70°C (158F)
A/F S1 H TR
(B1) •

Engine: After warming up, idle the engine
(More than 140 seconds after starting engine) 4 - 100%
VHCL SPEED SE • Turn drive wheels and compare CONSULT value with the speedometer indi-
cation. Almost the same speed as
speedometer indication
SET VHCL SPD • Engine: Running ASCD: OperatingThe preset vehicle speed is
displayed
MAIN SW • Ignition switch: ON MAIN switch: Pressed
ON
MAIN switch: Released OFF
CANCEL SW • Ignition switch: ON CANCEL switch: Pressed
ON
CANCEL switch: Released OFF
Monitor Item
Condition Values/Status
Revision: August 2015 2016 Versa Note

cardiagn.com

MWI
SYSTEMMWI-11
< SYSTEM DESCRIPTION > [TYPE A]
C
D
E
F
G H
I
J
K L
M B A
O P
• The combination meter includes an on board diagnosis function.
• The combination meter can be diagnosed with CONSULT.
METER CONTROL FUNCTION LIST
METER SYSTEM : Fail-safeINFOID:0000000012432544
The combination meter activates the fail-safe contro l if CAN communication with each unit is malfunctioning.
System DescriptionReference
Measuring instruments Speedometer
Indicates vehicle speed. MWI-12,
"SPEEDOME-
TER : System De-
scription"
Tachometer
Indicates engine speed. MWI-12, "
TA -
CHOMETER :
System Descrip-
tion"
Shift position indicator
Indicates shift position.MWI-13, "
SHIFT
POSITION INDI-
CATOR : System
Description"
Warning lamp/indicator
lamp
Engine oil pressure warning lamp The warning lamp turns ON or turns OFF,
according to engine hydraulic pressure. MWI-13, "
OIL
PRESSURE
WARNING LAMP
: System Descrip-
tion"
Meter illumination con-
trol
Meter illumination control function
Controls the back light of combination meter. MWI-13, "
METER
ILLUMINATION
CONTROL : Sys-
tem Description"
Information displayOdo/trip meter Indicates mileage.
MWI-14, "
INFOR-
MATION DIS-
PLAY : System
Description"
Engine coolant temperature gauge Indicates engine coolant temperature.
Fuel gaugeIndicates fuel level.
Loose fuel cap warning Indicates loose fuel cap.
Low fuel warning Indicates fuel level.
Trip computer Instant fuel consumption Displays current fuel consumption.
Average fuel consumption Displays average fuel consumption.
Distance to empty Displays distance to empty.
Travel distance
Displays mileage.
Function Specifications
Speedometer Reset to zero by suspending communication.
Tachometer
Illumination control When suspending communication, changes to nighttime mode.
Shift position indicator When suspending communication, not indicate.
Information display Trip com-
puterCurrent fuel consump-
tion
• When reception time of an abnormal signal is 2 seconds or
less, the last received datum is used for calculation to indi-
cate the result.
• When reception time of an abnormal signal is more than two
seconds, the last result calculated during normal condition is
indicated.
Average fuel consump-
tion
Distance to empty
Engine coolant temperature gauge Reset to zero by suspending communication.
Odo/trip meter An indicated value is maintained at communications blackout.
Buzzer The buzzer turns OFF by suspending communication.
Revision: August 2015 2016 Versa Note

cardiagn.com

MWI-24
< ECU DIAGNOSIS INFORMATION >[TYPE A]
COMBINATION METER
DTC Index
INFOID:0000000012432556
Information display Trip com-
puterCurrent fuel consump-
tion
• When reception time of an abnormal signal is 2 seconds or
less, the last received datum is used for calculation to indi-
cate the result.
• When reception time of an abnormal signal is more than two seconds, the last result calculated during normal condition is
indicated.
Average fuel consump-
tion
Distance to empty
Engine coolant temperature gauge Reset to zero by suspending communication.
Odo/trip meter An indicated value is maintained at communications blackout.
Buzzer The buzzer turns OFF by suspending communication.
Warning lamp/indicator lamp ABS warning lamp
The lamp turns ON by suspending communication.
Slip indicator lamp
Malfunction indicator lamp (MIL)
VDC OFF indicator lamp
EPS warning lamp
Brake warning lamp
High beam indicator lamp
The lamp turns OFF by suspending communication.
Turn signal indicator lamp
Door warning lamp
Light indicator lamp
Engine oil pressure warning lamp
O/D OFF indicator lamp
Function
Specifications
Display contents of CONSULTDiagnostic item is detected when... Refer to
CAN COMM CIRCUIT
[U1000] When combination meter is not transmitting or receiving CAN communication signal for
2 seconds or more.
MWI-38
CONTROL UNIT (CAN)
[U1010]When detecting error during the initial diagnosis of the CAN controller of combination
meter.
MWI-39
VEHICLE SPEED
[B2205]The abnormal vehicle speed signal is input from the ABS actuator and electric unit (con-
trol unit) for 2 seconds or more.
MWI-40
ENGINE SPEED
[B2267]If ECM continuously transmits abnormal engine speed signals for 2 seconds or more.
MWI-41
WATER TEMP
[B2268]If ECM continuously transmits abnormal engine coolant temperature signals for 60 sec-
onds or more.
MWI-42
Revision: August 2015
2016 Versa Note

cardiagn.com

MWI-62
< SYSTEM DESCRIPTION >[TYPE B]
SYSTEM
• The combination meter includes an on board diagnosis function.
• The combination meter can be diagnosed with CONSULT.
METER CONTROL FUNCTION LIST
METER SYSTEM : Fail-safeINFOID:0000000012432602
The combination meter activates the fail-safe contro
l if CAN communication with each unit is malfunctioning.
System DescriptionReference
Measuring instruments Speedometer
Indicates vehicle speed. MWI-63,
"SPEEDOME-
TER : System De-
scription"
Tachometer
Indicates engine speed. MWI-64, "
TA -
CHOMETER :
System Descrip-
tion"
Shift position indicator
Indicates shift position.MWI-64, "
SHIFT
POSITION INDI-
CATOR : System
Description"
Warning lamp/indicator
lampEngine oil pressure warning lamp
The warning lamp turns ON or turns OFF,
according to engine hydraulic pressure. MWI-65, "
OIL
PRESSURE
WARNING LAMP
: System Descrip-
tion"
High water temperature warning lamp
Turns ON when engine coolant reaches high
temperature. MWI-64, "
HIGH
WATER TEM-
PERATURE
WARNING LAMP
: System Descrip-
tion"
Meter illumination con-
trol
Meter illumination control function
Controls the back light of combination meter. MWI-66, "
METER
ILLUMINATION
CONTROL : Sys-
tem Description"
Information displayOdo/trip meter Indicates mileage.
MWI-66, "
INFOR-
MATION DIS-
PLAY : System
Description"
Fuel gaugeIndicates fuel level.
Loose fuel cap warning Indicates loose fuel cap.
Ambient temperature Indicates outside air temperature.
Trip computer Instant fuel consumption Displays current fuel consumption.
Average fuel consumption Displays average fuel consumption.
Distance to empty Displays distance to empty.
Travel distance
Displays mileage.
Function Specifications
Speedometer Reset to zero by suspending communication.
Tachometer
Illumination control When suspending communication, changes to nighttime mode.
Shift position indicator When suspending communication, not indicate.
Revision: August 2015 2016 Versa Note

cardiagn.com

MWI
COMBINATION METERMWI-77
< ECU DIAGNOSIS INFORMATION > [TYPE B]
C
D
E
F
G H
I
J
K L
M B A
O P
*1:For Canada
Fail-safeINFOID:0000000012432614
The combination meter activates the fail-safe contro l if CAN communication with each unit is malfunctioning.
DTC IndexINFOID:0000000012432615
Function Specifications
Speedometer Reset to zero by suspending communication.
Tachometer
Illumination control When suspending communication, changes to nighttime mode.
Shift position indicator When suspending communication, not indicate.
Information display Trip com-
puterCurrent fuel consump-
tion
• When reception time of an abnormal signal is 2 seconds or
less, the last received datum is used for calculation to indi-
cate the result.
• When reception time of an abnormal signal is more than two seconds, the last result calculated during normal condition is
indicated.
Average fuel consump-
tion
Distance to empty
Odo/trip meter An indicated value is maintained at communications blackout.
Buzzer The buzzer turns OFF by suspending communication.
Warning lamp/indicator lamp ABS warning lamp
The lamp turns ON by suspending communication.
Slip indicator lamp
Malfunction indicator lamp (MIL)
VDC OFF indicator lamp
EPS warning lamp
Brake warning lamp
High beam indicator lamp
The lamp turns OFF by suspending communication.
Turn signal indicator lamp
Door warning lamp
Light indicator lamp
Engine oil pressure warning lamp
High water temperature warning
lamp
Key warning lamp
O/D OFF indicator lamp
Shift P warning lamp
Engine start operation indicator lamp
Display contents of CONSULT
Diagnostic item is detected when... Refer to
CAN COMM CIRCUIT
[U1000] When combination meter is not transmitting or receiving CAN communication signal for
2 seconds or more.
MWI-93
CONTROL UNIT (CAN)
[U1010]When detecting error during the initial diagnosis of the CAN controller of combination
meter.
MWI-94
VEHICLE SPEED
[B2205]The abnormal vehicle speed signal is input from the ABS actuator and electric unit (con-
trol unit) for 2 seconds or more.
MWI-95
ENGINE SPEED
[B2267]If ECM continuously transmits abnormal engine speed signals for 2 seconds or more.
MWI-96
WATER TEMP
[B2268]If ECM continuously transmits abnormal engine coolant temperature signals for 60 sec-
onds or more.
MWI-97
Revision: August 2015
2016 Versa Note

cardiagn.com
